Agora Models JAGUAR E-TYPE Manual

STAGE 41: RIGHT FRONT WHEEL
STAGE 42: FRONT FLOOR PANEL
STAGE 43: FLOOR PANEL ASSEMBLY
STAGE 44: FINAL DRIVE UNIT
STAGE 45: REAR SUBFRAME
STAGE 46: REAR SUBFRAME
LEFT SUSPENSION
STAGE 47: REAR SUBFRAME
RIGHT SUSPENSION
STAGE 48: INSTALLING THE
REAR SUBFRAME
Pack 06
BUILD INSTRUCTIONS

AGORAMODELS JAGUAR E-TYPE
2
Spare screws are included with each part. Occasionally, you may be instructed to keep spare or
unused screws for a later stage. Keep these spares in a safe place and label them correctly.
Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary
slightly. Using the wrong screws may damage the parts.
When securing parts together using multiple screws, fit each screw loosely to ensure all the
parts are correctly aligned before gently tightening them firmly, but not overtight, in the order
in which you placed them.
The screwdriver can be magnetized by stroking it with a magnet (fridge magnet, etc.) enabling
it to hold the screws and make assembly easier.
If a screw is tight going into a metal part, do not force it as you may shear the head off. Remove
it and put a tiny smear of Vaseline, soap or light oil on the thread. That will lubricate it and make
it easier to drive home.
During the course of this build, you will receive many pieces that you will assemble immediately
– following the instructions in the corresponding stage – and other pieces that you should store
safely to one side, for use in future assembly stages.
Left and Right! When building your Jaguar, the left or right hand side refers to each side as you
are sitting in the car.
WARNING: Some parts are assembled using magnets. These magnets can cause serious injury
if they are swallowed. Keep away from children. If you suspect a magnet has been swallowed,
seek medical help straight away.
Advice from the experts
!

AGORAMODELS JAGUAR E-TYPE
3
Name
Tyre
Washer
Screws type AM07 x2
STAGE 41 PARTS LIST
In this stage you’ll fix the right front
wheel to the subframe.
Washer
Stage 41: Right Front Wheel
AM07 x2
Tyre

AGORAMODELS JAGUAR E-TYPE
4
1
3
2
4
Take the completed wheel from stage 40. Prepare a hot water bath by
filling a small bowl with boiling water. Soak the tyre in the water for 2
minutes.
Note: The tyre shown in pictures 1-4 is the spare tyre from Stage 25,
and differs slightly in the tread pattern from the tyre supplied in this
Stage. The method for fitting the tyre is the same.
Working quickly while the tyre is pliable, push the wheel into the tyre
and twist to fit the outer wheel rim under the inner rim of the tyre.
Carefully remove the tyre from the water bath using tongs or tweezers
- the tyre will be very hot! Shake off any excess water and dab on
kitchen paper or a towel.
Keep pushing and pulling, working around the tyre, until the side walls
fit comfortably over the wheel rim on both sides.
Stage 41: Right Front Wheel
STEP 1

AGORAMODELS JAGUAR E-TYPE
5
5
7
6
8
The tyre has been fully fitted to the wheel and is now ready to fix to
the front subframe assembly from Stage 37.
Take the washer and drop it onto the end of the stub axle, as shown in
picture 8.
Holding the wheel as shown, align the two lugs on the wheel centre
with the two notches in the right front axle. Position the wheel in
place, ensuring the lugs fit into the notches.
Stage 41: Right Front Wheel

AGORAMODELS JAGUAR E-TYPE
6
9
Secure the washer and right wheel in place using a type AM07 screw.
Stage 41: Right Front Wheel
AM07
STAGE COMPLETE

AGORAMODELS JAGUAR E-TYPE
7
Name
Front floor panel
STAGE 42 PARTS LIST
There is no assembly in this Stage,
unpack the front floor panel and
move straight to Stage 43.
Stage 42: Front Floor Panel
Front floor panel

AGORAMODELS JAGUAR E-TYPE
8
Name
Rear floor panel
Screws type AG06 x5
STAGE 43 PARTS LIST
Now you’ll assemble the floor
panel, attaching the front and rear
components together.
AG06 x5
Stage 43: Floor Panel Assembly
Rear floor panel

AGORAMODELS JAGUAR E-TYPE
9
1
3
2
4
Take the rear floor panel and the front floor panel from Stage 42. Line
up the four screw holes on the rear panel with the protruding holes on
the front panel as shown.
Screw the parts together using 4x type AG06 screws.
Fit the rear panel onto the front panel.
Stage 43: Floor Panel Assembly
AG06
AG06
STEP 1

AGORAMODELS JAGUAR E-TYPE
10
STAGE COMPLETE
Stage 43: Floor Panel Assembly

AGORAMODELS JAGUAR E-TYPE
11
Name
Rear brake (left-hand)
Rear brake (right-hand)
Upper casing
Universal joint (left-hand)
Universal joint (right-hand)
Lower casing
Bonnet catch plate
Screws typr AG06 x4
Screws type AG02 x2
STAGE 44 PARTS LIST
In this next stage you will build
the final drive unit and attach the
bonnet catch plate to the front
subframe assembly.
AG02 x2
Stage 44: Final Drive Unit
Rear brake
(left-hand)
Upper casing
Lower casing
Bonnet catch plate
AG06 x4
Universal joint
(left-hand)
Rear brake
(right-hand)
Universal joint
(right-hand)

AGORAMODELS JAGUAR E-TYPE
12
1
3
2
1
Take the bonnet catch plate and the front subframe assembly. Fit the
pin on the back of the catch plate into the hole located in the centre of
the front bulkhead.
The front subframe assembly should now look like this, with the
bonnet catch plate in place.
Holding the catch plate in place, fix it to the bulkhead using a
type AG02 screw as shown.
Take the upper and lower casing parts, along with the two rear brakes
and two universal joints. Match up the left rear brake with the left
universal joint by locating the ‘L’ on the parts (inset).
Do the same for the right rear brake and joint by locating the ‘R’.
Stage 44: Final Drive Unit
AG02
STEP 1
STEP 2

AGORAMODELS JAGUAR E-TYPE
13
2
4
3
5
Take the left universal joint and align it with the slot in the left rear
brake as shown.
Then fit the universal joint and brake assembly onto the lower casing
as shown.
Fit the universal joint into the rear brake.
Secure in place using a type AG06 screw.
Stage 44: Final Drive Unit
AG06

AGORAMODELS JAGUAR E-TYPE
14
6
8
7
9
Take the right universal joint and fit into the right rear brake.
Fit into the lower casing as shown. Fix in place with a type AG06 screw.
Stage 44: Final Drive Unit
AG06

AGORAMODELS JAGUAR E-TYPE
15
10
12
11
Take the upper casing and fit it onto the bottom casing, aligning the
central pillar on the bottom half with the hole of the top half (arrows).
Fit a type AG06 screw through the hole in the top of the casing to fix
the two halves together.
The two halves should fit together as shown. Check that the join is
flush all the way around.
Stage 44: Final Drive Unit
AG06

AGORAMODELS JAGUAR E-TYPE
16
STAGE COMPLETE
Stage 44: Final Drive Unit

AGORAMODELS JAGUAR E-TYPE
17
Name
Rear subframe
Handbrake linkage
Screws type AG04 x2
Screws type AG06 x2
Screws type AM18 x3
STAGE 45 PARTS LIST
In this stage you’ll attach the final
drive unit and the handbrake
linkage to the rear subframe.
Handbrake linkage
Stage 45: Rear Subframe
AG06 x2 AM18 x3AG04 x2
Rear subframe

AGORAMODELS JAGUAR E-TYPE
18
1
3
2
4
Align the drive unit from Stage 44 with the rear subframe, noting the
holes at the centre of the subframe and the posts on the drive unit
(circled).
The drive unit should project through the opening in the subframe
with the posts fitting into the screw holes indicated in picture 1.
Insert the drive unit through the opening in the subframe as shown.
Holding the drive unit in place, turn the subframe over and secure the
assembly with 1 x type AG04 screw and 1 x type AG06 screw.
Note: be aware two different screws are used. Make sure to screw
the correct type in place to avoid damaging the threads.
Stage 45: Rear Subframe
STEP 1
AG06
AG04

AGORAMODELS JAGUAR E-TYPE
19
5
7
6
8
Take the handbrake linkage and align it with the subframe. Note the
locating pin on the handbrake linkage which will fit into the hole on
the subframe (arrow).
Once in place the handbrake linkage should look like this.
Push the pin into place, fitting the two arms of the handbrake linkage
into the opening of the subframe.
Screw both of the arms to the subframe using 2 x AM18 type screws.
Stage 45: Rear Subframe
AM18

AGORAMODELS JAGUAR E-TYPE
20
STAGE COMPLETE
Stage 45: Rear Subframe
