Alcatel-Lucent 8082 My IC Phone User manual

Alcatel-Lucent
OmniTouch™ 8082 My IC Phone
OmniPCX Office Rich Communication Edition
User Manual
R300
8AL90835USBDed01 -1409

2
Introduction
Thank you for choosing an Alcatel-Lucent phone.
This model offers enhanced ergonomical features for more effective communication.

3
1GETTING TO KNOW YOUR TELEPHONE 7
1.1 PERMANENT FEATURES KEYS 8
1.2 ABOUT THE HOMEPAGE 9
1.3 NAVIGATION 12
1.4 APPLICATION 13
1.5 BLUETOOTH® WIRELESS HANDSET 14
1.6 INSTALL A COMFORT WIRED HANDSET 15
2USING YOUR TELEPHONE 16
2.1 CHANGE THE DEFAULT PASSWORD 16
2.2 MAKING A CALL 16
2.3 MAKE A CALL USING THE PERSONAL PHONE BOOK (CONTACTS) 17
2.4 USING CALL BY NAME 17
2.5 CALL FROM CALL LOG ( HISTORY) 18
2.6 CALL BACK ONE OF THE LAST NUMBERS DIALED 18
2.7 CALL A CONTACT FROM THE FAVORITES APPLICATION ( FAVORITES) 19
2.8 ANSWER THE CALL 19
2.9 IGNORE CALL 20
2.10 FORWARD AN INCOMING CALL 20
2.11 USING THE TELEPHONE IN “HANDS FREE“ MODE 20
2.12 RECEIVING INTERCOM CALLS ( INTERPHONY) 21
2.13 MASK MY IDENTITY 21
2.14 CONTACT CALL LOG 21
2.15 DELETE ONE CALL LOG EVENT 22
2.16 DELETE EVENTS FROM THE CALL LOG 22
3DURING A CONVERSATION 23
3.1 PUTTING A CALLER ON HOLD 23
3.2 CALLING A SECOND PERSON DURING A CONVERSATION 23
3.3 SWITCHING BETWEEN CALLS (BROKER CALL) 24
3.4 TRANSFERRING A CALL 24
3.5 THREE-PARTY CONFERENCE 24
3.6 MUTE, SO THAT YOUR CORRESPONDENT CANNOT HEAR YOU 25
3.7 VOICE FREQUENCY 25
3.8 RECORDING THE CURRENT CONVERSATION 25
3.9 SETTING AUTO VOLUME 25

4
4VIDEO CALL 26
4.1 VIDEO CALL 26
4.2 START A VIDEO CALL 26
4.3 MUTE/UNMUTE THE VIDEO CALL 27
4.4 HIDE/SHOW THE ‘PICTURE IN PICTURE’ 27
4.5 DISPLAY VIDEO IN FULLSCREEN MODE 27
4.6 RECEIVING A SECOND CALL 28
5CONTACTS MANAGEMENT 29
5.1 DEFINE A CONTACT 29
5.2 ADD A CONTACT FROM THE CALL LOG 29
5.3 ADD A CONTACT TO THE CONTACTS LIST FROM THE SEARCH BY NAME RESULTS 30
5.4 MAKE A CALL USING THE PERSONAL PHONE BOOK ( CONTACTS) 30
5.5 MODIFY A CONTACT 30
5.6 DELETE A CONTACT 31
5.7 DEFINE A CONTACT AS A FAVORITE ( FAVORITES) 31
5.8 PROGRAMING A DIRECT SHORTCUT FOR A CONTACT. 32
6KEEP IN TOUCH 33
6.1 DEFINE A FORWARD 33
6.2 ACTIVATE A PREDEFINED FORWARD 34
6.3 IMMEDIATE FORWARD TO VOICE MAILBOX 34
6.4 YOUR VISUAL VOICE MAIL 34
6.5 CANCEL THE FORWARD 36
6.6 MODIFY THE FORWARD 36
6.7 DELETE A FORWARD 36
7KEYPAD 37
7.1 CHANGE THE KEYBOARD TYPE 37
7.2 DELETE A CHARACTER 37
7.3 WRITE IN UPPERCASE 37
7.4 WRITE A NUMBER 38
7.5 WRITE SPECIAL CHARACTERS 38

5
8PROGRAMMING YOUR TELEPHONE 39
8.1 DEFINE THE PHONE LANGUAGE 39
8.2 FAVORITES 39
8.3 LOCK / UNLOCK YOUR TELEPHONE 40
8.4 AUTOMATIC LOCK 41
8.5 ADJUSTING THE AUDIO FUNCTIONS 41
8.6 ACTIVATE/DEACTIVATE SILENT MODE 41
8.7 RING TONES 42
8.8 PROGRESSIVE RINGING 42
8.9 ADJUSTING THE RINGER VOLUME 42
8.10 ADJUST RINGER VOLUME WHILE A CALL ARRIVES 42
8.11 ADJUST THE LOUDSPEAKER AND THE HANDSET VOLUME 42
8.12 ACTIVATE/DEACTIVATE TACTILE FEEDBACK 42
8.13 ACTIVATING HEADSET MODE 43
8.14 INSTALL A BLUETOOTH® DEVICE (PAIRING) 43
8.15 INSTALL THE ALCATEL-LUCENT MY IC PHONE BLUETOOTH® WIRELESS HANDSET 44
8.16 UNINSTALL A BLUETOOTH® DEVICE (UNPAIRING) 45
8.17 HEARING AID KIT 45
8.18 SET AN ALARM 45
8.19 FILE MANAGER 46
8.20 DELETE A FILE 46
8.21 COPY A FILE FROM THE EXTERNAL STORAGE DEVICE TO THE PHONE INTERNAL MEMORY 47
8.22 LISTEN TO AN AUDIO FILE 47
8.23 PLAY ALL AUDIO FILES 48
8.24 PHONE WALLPAPER 48
8.25 PHONE SCREENSAVER 49
8.26 CUSTOMIZE THE USER PICTURE 50
8.27 PROGRAMMING SHORTCUT KEYS ON THE HOMEPAGE 50
8.28 CHANGE THE THEME (SKIN) OF YOUR PHONE 52
8.29 RESET USER DATA 53
9MANAGER/ASSISTANT 54
9.1 MANAGER/ASSISTANT 54
9.2 SELECT AND ACTIVATE THE FILTERING MODE BETWEEN THE MANAGER AND ASSISTANT PHONES 54
9.3 TALK TO THE ASSISTANT WHILE ON A CALL 55
9.4 TRANSFER A CALL TO THE ASSISTANT PHONE 55

6
10 MY IC PHONE SYNCHRONIZER 56
10.1 INTRODUCTION 56
10.2 PREREQUISITES 56
10.3 INSTALLING THE APPLICATION ON YOUR PC 56
10.4 UNINSTALLING THE APPLICATION 58
10.5 REPAIRING THE APPLICATION 58
10.6 CONFIGURATION 58
10.7 SYNCHRONIZE YOUR PHONE AND YOUR PC 62
10.8 TROUBLESHOOTING 63
11 GUARANTEE AND CLAUSES 64

7
1Getting to know your telephone
A sensitive LCD wide screen
Permanent feature keys: quick access to the phone’s
main features
A Bluetooth® handset for optimized communication
A wired handset is also available and can replace the
Bluetooth® handset.
A wideband loudspeaker for optimized sound
LED
Arrival of a new call( Flashing)
An adjustable and stable foot
One 3.5 mm headset jack
Various connections to allow phone extensions
Add-on module connector (SATA type).
2 USB connectors for video or USB storage device
1 mini-USB connector for a keyboard(1)
Two 10/100/1000 Mbps Ethernet connectors to
enterprise network (LAN) and a PC
One DC power jack for an external power adaptor
1 RJ9 connector for a corded handset
(1) For future use
8
7
6
5
4
3
2
1

8
1.1 Permanent features keys
They are located just below the touch screen
Mute key.
During a call, press this key to stop your contact from hearing you. As long as the mute
feature is activated, the mute key stays lit (blue). Press this key to deactivate the
mute feature.
Turn down the volume.
Turn up the volume.
Pressing this key answers an incoming call in handsfree mode (the key is blue). When a
call is in progress, pressing this key switches from handsfree mode to headset or
handset mode.
Pressing this key takes you to the routing menus.
This key is lit when you have received a new voicemail, text message or callback
request. When not lit you can access various message services. This key flashes if you
have missed calls.
Activate or deactivate the virtual keyboard.
This key lights blue when there is a wake-up alarm.
This key is used to return to the homepage at any time.

9
1.2 About the homepage
Homepage in advanced mode Homepage in standard mode
Personal area
This area displays information about the user's phone and configuration, including last name,
first name, avatar, and routing.
Routing profile
Access programming and configuration of routing profiles.
User
Information
Information about the user.
Video
Pressing on this menu item starts the self video on your phone. You can then check
that your video camera is working correctly.
Select this area to access the user parameters and status of the phone.
Notifications area
In idle state: This area displays information on the latest phone events, such as missed calls
and voice messages.
During a call: Call status (ongoing, on hold, incoming call) is shown in this area. Pressing this
area during a call takes you back to the call screen.
Call status:
Incoming call
Ongoing call
Call on hold
Three-party conference
Video active on your phone (blue color)
Video available on your phone (white color)
Your phone is a supervisor phone or is supervised.
2
1

10
Date, time and connectivity area
This area displays time, date, connectivity and customization information (wake-up on,
intercom mode on).
Security mode.
Storage device connected to USB port.
Bluetooth® device pairing in progress.
Bluetooth® device connected (Other than your Bluetooth® handset).
Headset plugged in.
Wake-up feature activated.
Silent ring activated.
Interphony (See chapter: Receiving intercom calls).
Video available on your phone (See chapter Video call).
Upgrade download.
1,000 Mbits Ethernet connection.
100 Mbits Ethernet connection.
10 Mbits Ethernet connection.
10 Mbits Ethernet connection.
VoIP Connection established.
No VoIP connection.
Communication is not possible. For more information, contact your installer or
administrator.
Server connection established
This icon appears when you are not connected to the data server (safe mode,
authentication failed or problem with the server).
All features are unaccessible. You can still call using the dialpad.
3

11
Make sure your password is correct.
Press your information area in the top left corner of the screen
User Information
Login
Enter your password
Bluetooth® device not connected
Video active on your phone (blue color)
Video available on your phone (white color)
Active area
This area is reserved for running applications and for previews of applications selected by the
user.
When you start an application, it is displayed in the active zone. If no application has been
launched, the active zone displays the application previews that you have preset on the
homepage. One application preview allows you to view this application information and
easily access it.
Applications that can be previewed are: History, Favorites, Manager/Assistant.
Add or delete an application in the active area
Settings Application
Select the application that you want to add to the homepage or delete
from the homepage
Activate or deactivate preview of the application (yes or no)
Back to homepage
Applications bar( Homepage in advanced mode)
This area allows access to all set applications and to different features of the running
application
Applications area( Homepage in standard mode)
You can access your phone applications from this area. Press the application button to access
the application. Programmable keys are available in this mode.
Once you run an application, the display is the same as the preview mode display.
6
5
4

12
1.3 Navigation
Homepage
The phone set homepage can be viewed in standard or advanced mode.
Scroll your finger up or down to get the page or menus scrolling vertically (in advanced mode), or
scroll right or left to get the page scrolling horizontally. (in standard mode only).
Homepage in standard mode Homepage in standard mode
Make your selection by pressing on the screen
Access the Advanced Homepage mode
First press: back to the previous homepage page
Second press: back to the first homepage page
Go to next screen
Back to previous screen
In standard mode only, you can have up to 6 pages. In standard mode, homepages are for applications
and programmable keys. Two types of icons are displayed at the bottom of the page :
Symbolizes the first page (Homepage).
Symbolizes extra pages (empty circle). When this icon is full, it means that you are
currently viewing the page. This helps you to know which page you are on when navigating
through the different pages.

13
1.4 Application
The homepage in standard mode and the applications bar on the homepage in advanced mode allow
you to access the phone applications.
Scroll through the application area pages (standard mode) or the application bar
(advanced mode) to find the application you want.
Press the application button to access to the application

14
1.5 Bluetooth® Wireless handset
If the Bluetooth® handset is on its base, you do not need to press the Off-hook/On-hook key to take or
terminate the call. Just off-hook/on-hook the Bluetooth® handset.
LED
Off: operating normally
Blinking green: in communication
Green steady: handset charging
Orange flashing: battery charge low or handset outside coverage zone
Orange steady: malfunction
Installing or replacing the Bluetooth® handset battery
The battery recharges when the Bluetooth® handset is on its base.
If the Bluetooth® handset is on its base, you do not need to press the Off-hook/On-hook key to take
or terminate the call. Just off-hook/on-hook the Bluetooth® handset.
LED
Off-hook/On-hook: press this key to take or terminate a call
Volume/Mute:
Short successive presses
to change the handset
volume level (3 levels)
Long press to activate or
deactivate mute mode
Location of the battery
Lift up the battery cover
Slide out the battery holding
part

15
1.6 Install a comfort wired handset
You can install a wired handset in place of the My IC Phone Bluetooth® Wireless Handset.
Plug-in the wired handset to the appropriate connector (refer to phone description).
Switch off the My IC Phone Bluetooth® Wireless Handset (long press on the On/Off hook key
until you hear two distinct tones).

16
2Using your telephone
2.1 Change the default password
To access all your phone's features you need to replace the default password with a new password.
Use one of the following:
oPress the User services key.
oPress your information area in the top left corner of the screen User Information
Login
Enter the default password (151515).
Enter the new password.
Your password has 6 digits.
A weak personal code with 6 identical digits (000000, 111111, etc.) or a simple sequence of 6
digits (012345, 123456, etc.) will be rejected by the system.
Confirm the new password.
Ok
After a system upgrade, the password may still have only 4 digits. For security reasons, we
recommend you use a password with 6 digits. Contact your installer for more information.
2.2 Making a call
Use one of the following:
oDial directly the number for your call.
oLift the receiver Enter the destination number.
oPress the on-hook/off-hook key of the Bluetooth® device ( Bluetooth® Wireless
handset) Dial the destination number.
oDialer
oHands free Dial the destination number.
oProgrammed line key.
oSearch by name (you can also access the search by name feature via the
alphapad).
Call
To make an external call, dial the outside line access code before dialing your contact number. The
default outside-line access code is usually 0. However, please check this code with your installer.
The picture of your correspondent can appear on the phone only if a picture was initially copied in the
set memory and associated to your contact (See: Define a contact).

17
End the call
Use one of the following:
oHang up the handset.
oEnd call
oOn-hook key on the Bluetooth® handset.
2.3 Make a call using the personal phone book (Contacts)
Select the application.
Contacts
Select the contact to call Information regarding your contact is displayed on the screen.
Press the call icon to call your contact.
If there are several numbers for the same contact, select the desired number.
2.4 Using call by name
Search
Enter the first letters of your contact name.
Ok The names of contacts matching your search criteria are automatically displayed on the
screen.
Call your contact by choosing him/her in the list.
If you wish you can also display your contact complete file.
Depending on the configuration (external LDAP server may be available in your company for the
contacts management, and/or you may have configured manually some contacts in your set), the
system can display a picture of your correspondent when you do a search by name. When calling the
correspondent, a picture will be displayed only if the contact is part of your list of contacts and if a
picture was initially copied in the set memory and associated to your contact (See: Define a contact).

18
2.5 Call from call log ( History)
All incoming, outgoing, missed or unanswered calls are displayed in the call log.
You can call back from your phone call log.
Select the application.
History
The history application shows two tabs, listing new phone events such as missed calls, and
older phone events.
New
All new missed incoming call events.
History
All events.
Select the appropriate tab.
Select the contact to call.
Callback
If there are several numbers for the same contact, select the desired number.
You can also access the feature by selecting the application preview History.
Refer to chapter: "Define a contact as a favorite".
2.6 Call back one of the last numbers dialed
Select the application.
History
From the call log, select one of the last numbers dialed.
Answered outgoing call.
Unanswered outgoing call.
Callback
You can also access the feature by selecting the application preview History.

19
2.7 Call a contact from the favorites application ( Favorites)
Favorites: This application contains favorite contacts that you have selected in your personal
directory.
Select the application.
Favorites
All contacts defined as a favorite are displayed.
Select the contact to call.
Call
If there are several numbers for the same contact, select the desired number.
You can also access the feature by selecting the application preview Favorites.
Refer to chapter: "Define a contact as a favorite".
2.8 Answer the call
Use one of the following:.
oAnswer call
oTake the handset off the hook.
oHandsfree key.
oOff-hook key on the Bluetooth® handset.
The picture of your correspondent can appear on the phone only if a picture was initially copied in the
set memory and associated to your contact (See: Define a contact).
End the call
Use one of the following:
oHang up the handset.
oEnd call
oOn-hook key on the Bluetooth® handset.

20
2.9 Ignore call
A call is received:
Ignore
Your phone no longer rings but your caller still hears the ringing tone.
You can still answer the call after you have ignored it
2.10 Forward an incoming call
A call is received:. Your telephone rings.
Forward to voicemail
Deflect to VM
The call is directly forwarded to your voice mail.
Forward to another number
Deflect
Call the recipient of the transfer.
The call is immediately forwarded.
2.11 Using the telephone in “Hands free“ mode
You are in communication.
Handsfree key.
Select the desired audio mode:.
oHandsfree.
oSpeaker (Group Listen).
To take the call back with the handset
Use one of the following:
oTake the handset off the hook.
oHandset.
oOff-hook key on the Bluetooth® handset.
To go back to “handsfree“ mode
Press the “handsfree“ key again.
You can hang-up the handset.
