Alcatel-Lucent OpenTouch 8088 User manual

Alcatel-Lucent OpenTouch™ Conversation
8088 Smart DeskPhone
User Manual
8AL90314ENAA ed01 -1517
R100

8AL90314ENAAed01 2 /70
Thank you for choosing this phone.
This model offers enhanced ergonomical features for more effective communication.
With its touch screen and built-in interactive capabilities, the 8088 Smart DeskPhone can deliver the
comfort and convenience you are looking for.
The availability of certain functions described in this guide may depend on the version or
configuration of your system.
The labels and icons presented in this document are not contractually binding and may be modified
without prior warning. The pictures are not contractually binding and are not localized.

8AL90314ENAAed01 3 /70
1GETTING TO KNOW YOUR TELEPHONE 7
1.1 PHONE DESCRIPTION 7
1.2 DESCRIPTION OF THE CONNECTORS 8
1.3 PERMANENT FEATURES KEYS 9
1.4 ABOUT THE HOMEPAGE 10
1.5 NAVIGATION 13
1.6 BLUETOOTH® WIRELESS HANDSET 14
1.7 INSTALL A COMFORT WIRED HANDSET 15
1.8 HDMI CONNECTOR 15
2USING YOUR TELEPHONE 17
2.1 MAKING A CALL 17
2.2 MAKE A CALL USING THE PERSONAL PHONE BOOK (CONTACTS) 18
2.3 USING CALL BY NAME 18
2.4 CALL FROM CALL LOG (HISTORY) 18
2.5 CALL BACK ONE OF THE LAST NUMBERS DIALED 19
2.6 REDIALING THE LAST NUMBER DIALED (REDIAL) 19
2.7 CALL A CONTACT FROM THE FAVORITES APPLICATION (FAVORITES) 19
2.8 ANSWER THE CALL 19
2.9 IGNORE CALL 20
2.10 DIVERT AN INCOMING CALL 20
2.11 USING THE TELEPHONE IN “HANDS FREE“ MODE 20
2.12 RECEIVING INTERCOM CALLS (INTERPHONY) 21
2.13 MASK MY IDENTITY (EXTERNAL CALLS ONLY) 21
2.14 CONTACT CALL LOG 21
2.15 DELETE ONE CALL LOG EVENT 22
2.16 DELETE EVENTS FROM THE CALL LOG 22
2.17 SET AN ALARM 22
3DURING A CONVERSATION 25
3.1 PUTTING A CALLER ON HOLD 25
3.2 CALLING A SECOND PERSON DURING A CONVERSATION 25
3.3 SWITCHING BETWEEN CALLS (BROKER CALL) 25
3.4 TRANSFERRING A CALL 26
3.5 THREE-PARTY CONFERENCE 26
3.6 N-PARTY CONFERENCE (MORE THAN THREE) 27
3.7 MUTE, SO THAT YOUR CALLER CANNOT HEAR YOU 27
3.8 VOICE FREQUENCY 27
3.9 RECORDING THE CURRENT CONVERSATION 28
3.10 SETTING AUTO VOLUME 28

8AL90314ENAAed01 4 /70
4VIDEO CALL 29
4.1 VIDEO CALL 29
4.2 START A VIDEO CALL 29
4.3 MUTE/UNMUTE THE VIDEO CALL 29
4.4 HIDE/SHOW THE ‘PICTURE IN PICTURE’ 30
4.5 DISPLAY VIDEO IN FULLSCREEN MODE 30
4.6 RECEIVING A SECOND CALL 30
4.7 VIDEO CONFERENCE 30
4.8 SCHEDULED VIDEO CONFERENCE 31
5CONTACTS MANAGEMENT 32
5.1 DEFINE A CONTACT 32
5.2 ADD A CONTACT FROM THE CALL LOG 32
5.3 MAKE A CALL USING THE PERSONAL PHONE BOOK (CONTACTS) 32
5.4 MODIFY A CONTACT 33
5.5 DELETE A CONTACT 33
5.6 FAVORITES 33
5.7 DEFINE A CONTACT AS A FAVORITE (FAVORITES) 34
5.8 PROGRAMMING A DIRECT SHORTCUT FOR A CONTACT. 34
6KEEP IN TOUCH 36
6.1 TELEPHONY PRESENCE 36
6.2 IMMEDIATE FORWARD TO A NUMBER 36
6.3 IMMEDIATE FORWARD TO VOICE MAILBOX 37
6.4 YOUR VISUAL VOICE MAIL 22
6.5 OVERFLOW TO AN INTERNAL NUMBER 37
6.6 MULTI DEVICES ROUTING 38
7KEYPAD 39
7.1 CHANGE THE KEYBOARD TYPE 39
7.2 DELETE A CHARACTER 39
7.3 WRITE IN UPPERCASE 40
7.4 WRITE A NUMBER 40

8AL90314ENAAed01 5 /70
8PROGRAMMING YOUR TELEPHONE 41
8.1 DEFINE THE PHONE LANGUAGE 41
8.2 LOCK / UNLOCK YOUR TELEPHONE 41
8.3 AUTOMATIC LOCK 42
8.4 ADJUSTING THE AUDIO FUNCTIONS 42
8.5 ACTIVATE/DEACTIVATE SILENT MODE 42
8.6 RING TONES 43
8.7 PROGRESSIVE RINGING 43
8.8 ADJUSTING THE RINGER VOLUME 43
8.9 ADJUST RINGER VOLUME WHILE A CALL ARRIVES 43
8.10 ADJUST THE LOUDSPEAKER AND THE HANDSET VOLUME 43
8.11 INSTALL A JACK ACCESSORY (HEADSET, HANDSFREE, LOUDSPEAKER) 44
8.12 IF NECESSARY, YOU CAN ALSO SELECT THE ACCESSORY TYPE IN THE AUDIO SETTINGS: 44
8.13 INSTALL A BLUETOOTH® DEVICE (PAIRING) 45
8.14 INSTALL THE ALE INTERNATIONAL BLUETOOTHØ WIRELESS HANDSET 46
8.15 UNINSTALL A BLUETOOTH® DEVICE (UNPAIRING) 46
8.16 HEARING AID KIT 47
8.17 PHONE WALLPAPER 47
8.18 PHONE SCREENSAVER 48
8.19 CHANGE THE THEME (SKIN) OF YOUR PHONE 49
8.20 RESET USER DATA 49
9FILE MANAGER 50
9.1 DELETE A FILE 50
9.2 COPY A FILE FROM THE EXTERNAL STORAGE DEVICE TO THE PHONE INTERNAL MEMORY 51
9.3 BROWSE PICTURES 51
9.4 LISTEN TO AN AUDIO FILE 51
9.5 PLAY ALL AUDIO FILES 52
10 MANAGER/ASSISTANT 53
10.1 MANAGER/ASSISTANT 53
10.2 SELECT AND ACTIVATE THE FILTERING MODE BETWEEN THE MANAGER AND ASSISTANT
PHONES 54
10.3 CONSULT THE MANAGER OR THE ASSISTANT WHILE IN A CALL 55
10.4 TRANSFER A CALL TO THE ASSISTANT PHONE 55
10.5 TRANSFER A CALL TO THE MANAGER SET 56
10.6 DEFINE A PRIORITY NUMBER (“WHITE LIST“) 56
10.7 DELETE A PRIORITY NUMBER (“WHITE LIST“) 56
10.8 ACTIVATE/DEACTIVATE A TEMPORARY BACKUP ASSISTANT 57
10.9 FORWARD AND FILTERING MODE INTERACTION 57

8AL90314ENAAed01 6 /70
11 SUPERVISION AND CALL PICK UP 58
12 CONTACT-SYNC 61
12.1 INTRODUCTION 61
12.2 PREREQUISITES 61
12.3 INSTALLING THE APPLICATION ON YOUR PC 61
12.4 UNINSTALLING THE APPLICATION 63
12.5 REPAIRING THE APPLICATION 63
12.6 CONFIGURATION 63
12.7 SYNCHRONIZE YOUR PHONE AND YOUR PC 66
12.8 TROUBLESHOOTING 67
13 GUARANTEE AND CLAUSES 68

8AL90314ENAAed01 7 /70
1Getting to know your telephone
1.1 Phone description
1
Sensitive LCD wide screen with ambient light sensor.
2
Embedded HD Video camera with shutter. Swipe the shutter right or left to use or hide the camera.
3
Permanent feature keys: quick access to the phone’s main features.
4
Bluetooth® handset for optimized communication. A wired handset is also available and can replace the
Bluetooth® handset.
5
Wideband loudspeaker for optimized sound.
6
LED
Arrival of a new call (Flashing).
7
An adjustable and stable foot.
8
3.5 mm and 4 pin stereo headset jack.
9
Microphone.
1
3
4
5
6
7
8
2
9

8AL90314ENAAed01 8 /70
1.2 Description of the connectors
Various connections to allow phone extensions.
1
2
3
4
5
6
7
1
Add-on module connector (SATA type).
2
Two Universal Serial Bus (USB) ports (1.1/2.0) to connect an external camera, audio
equipment, a low smartphone charger or USB stick.
3
HDMI® 1.4 output for screen replication and for dedicated HD video display.
4
10/100/1000 Mbps Ethernet connectors to a PC (RJ45).
5
10/100/1000 Mbps Ethernet connectors to the enterprise network (LAN - RJ45).
6
DC power jack for an external power adaptor.
7
Wired handset connector (RJ9).

8AL90314ENAAed01 9 /70
1.3 Permanent features keys
They are located just below the touch screen
Mute key.
During a call, press this key to stop your contact from hearing you. As long as the mute feature
is activated, the mute key stays lit (blue). Press this key to deactivate the mute feature.
Turn down the volume.
Turn up the volume.
Answer an incoming call or make a call (keypad) in hands free mode (the key is blue).
During a conversation, the first press opens the audio taster. The next press switches between
handsfree, handset and audio accessories mode #.
Ignore incoming call.
Hang up the ongoing call.
Show or hide the keypad. During conversation use the keypad to send DTMF signals.
Use this key to consult the call log. This key is lit when you have received a new voicemail or a
missed call. During conversation, press this key to take you back to the call screen.
Open user settings and information (logs of telephony services, routing management, video
self-view). This key is lit when your device is not routed.
Return to the homepage at any time.

8AL90314ENAAed01 10 /70
1.4 About the homepage
Homepage in standard mode
Homepage in business mode
Personal area
This area displays information about the user's phone and configuration, including last name, first
name, avatar, and routing. The colored bar under your photo/avatar shows your present status.
Routing profile
Access programming and configuration of routing profiles.
Overflow
Access programming and configuration of overflow.
User Information
Information about the user: lastname, firstname, phone number,...
Video
Information about the user: lastname, firstname, phone number,...
Notifications area
In idle state: This area displays information on the latest phone events, such as missed calls
and voice messages.
During a call: Call status (ongoing, on hold, incoming call) is shown in this area. Pressing this
area during a call takes you back to the call screen.
Call status
Incoming call.
Ongoing call.
Ongoing video call.
Call on hold.
Video call on hold.
Conference.
Video conference active.
Your phone is supervised or a supervisor phone.
2
1
1
3
1
1
2
6
3
1
1
2
4
5

8AL90314ENAAed01 11 /70
Date, time and connectivity area
This area displays time, date, connectivity and customization information (wake-up on,
intercom mode on).
Security mode (encrypted audio communication).
USB Accessory or storage device connected to USB port.
Bluetooth® device pairing in progress.
Bluetooth® device connected (Other than your Bluetooth® handset).
Headset plugged in.
Alarm programmed.
Silent ring activated.
Interphony (See chapter: Receiving intercom calls).
External camera plugged in. (white color).
Video running.
Your phone is a supervisor phone or is supervised.
Identity secrecy activated.
Upgrade download. All features of the set are available during the upgrade.
This icon is displayed until the upgrade is complete.
No VoIP connection.
Communication is not possible. For more information, contact your installer or
administrator.
This icon appears when you are not connected to the data server (safe mode,
authentication failed or problem with the server).
All features are unaccessible. You can still call using the dialpad.
Make sure your password is correct.

User Information
Login
Enter your password
Bluetooth® device not connected
3

8AL90314ENAAed01 12 /70
Active area
This area is reserved for running applications and for previews of applications selected by the
user.
When you start an application, it is displayed in the active zone. If no application has been
launched, the active zone displays the application previews that you have preset on the
homepage. An application preview allows you to view this application information and easily
access it.
Applications that can be previewed are: History, Favorites, Manager/Assistant, Supervision,
Dial-pad.
Add or delete an application in the active area
Settings Application
Select the application that you want to add to the homepage or delete from the
homepage (History, Favorites, Manager/Assistant, Supervision, Dial-pad).
Activate or deactivate preview of the application (yes or no)
Back to homepage
Applications bar (Homepage in business mode)
This area allows access to all applications and to different features of the running application
Applications area (Homepage in standard mode)
You can access your phone applications from this area. Press the application button to access
the application. Once you run an application, the display is the same as the business mode
display.
Programmable keys are available in this mode. (See Programming a direct shortcut for a
contact. ).
Make a call.
To access voice mail functions.
Open the dial keypad to
make a conversation.
This application contains favorite
contacts that you have selected from
your list of contacts. Call a contact from
the favorites application.
Search for a contact.
Make a call using your list of contacts.
Access the settings menu.
Lock / unlock your telephone.
This application allows you to
manage audio files and
images.
This application is for synchronizing
your address book and agenda between
your phone and your PC Microsoft®
Outlook application.
The history application shows
two tabs, listing new phone
events such as missed calls,
and older phone events.
Set an alarm.
6
5
4

8AL90314ENAAed01 13 /70
1.5 Navigation
The phone set homepage can be viewed in standard or advanced mode.
Scroll your finger up or down to get the page or menus scrolling vertically (in advanced mode), or
scroll right or left to get the page scrolling horizontally. (in standard mode only).
Homepage in standard mode
Homepage in business mode
Make your selection by pressing the right icon on the sensitive screen.
In standard mode, personalize the homepage by pressing and holding.
Scroll through the application area pages (advanced mode) or the application bar (business mode).
In standard mode only, you can have up to 2 pages.
Scroll the list (call log, contacts...)
First press: back to the previous homepage page.
Second press: back to the first homepage page.
This dark greyed circle symbolizes the current page (default skin).
This light greyed circle symbolizes another available page (default skin).

8AL90314ENAAed01 14 /70
1.6 Bluetooth® Wireless handset
If the Bluetooth® handset is on its base, you do not need to press the Off-hook/On-hook key to take or
terminate the call. Just off-hook/on-hook the Bluetooth® handset.
LED
Off: operating normally
Blinking green: in communication
Green steady: handset charging
Orange flashing: battery charge low or handset outside coverage zone
Orange steady: malfunction
LED
Ignore incoming call .
Off-hook/On-hook: press this key to take or
terminate a call .
Volume/Mute:
Short successive presses to
change the handset volume
level (3 levels)
Long press to activate or
deactivate mute mode
Location of the battery

8AL90314ENAAed01 15 /70
Installing or replacing the Bluetooth® handset battery
The battery recharges when the Bluetooth® handset is on its base.
1.7 Install a comfort wired handset
You can install a wired handset in place of the Bluetooth® Wireless Handset.
Remove the rubber
Plug-in the wired handset to the appropriate connector
(refer to phone description).
Make sure you position the cable correctly in the
compartment intended for that purpose:
Switch off the Bluetoothø Wireless Handset (press and hold
the On/Off hook key until you hear two distinct tones).
1.8 HDMI connector
Your set is equipped with an HDMI 1.4 output for a better video experience.
The 8088 Smart DeskPhone can be connected to a large screen or video projector. Moreover, an
external camera can be connected to the phone to broadcast the entire room. Your deskphone can
easily find its place in a meeting room.
There are two ways to use the HDMI connector:
Broadcast the video conversation (HD capability).
Broadcast the entire display of the phone.
Your set has to be connected to the appropriate equipment.
Lift up the battery cover
Slide out the battery holding
part

8AL90314ENAAed01 16 /70
Broadcast the video conversation (HD capability)
Use one of the following:
oDuring the video conversation, swipe up on the video
displayed on the phone to broadcast it to the
equipment connected via HDMI.
oTo stop the broadcast, swipe down on the video
displayed on the phone.
Select the HDMI button.
Broadcast the entire display of the phone
To broadcast the entire display of the phone or stop the broadcast, you have to activate or deactivate
this feature:
Settings
Device Display Clone display to HDMI
Activate or deactivate the HDMI output
Back to homepage.

8AL90314ENAAed01 17 /70
2Using your telephone
2.1 Making a call
Use one of the following:
oDial directly the number for your call.
oLift the receiver Enter the destination number.
oPress the on-hook/off-hook key of the Bluetooth® device. (Bluetooth® Wireless
handset) Dial the destination number.
oDialer. Dial the destination number.
oHands free Dial the destination number.
oProgrammed line key.
oSearch by name
Press the call icon to call your contact.
To make an external call, dial the outside line access code before dialing your contact number.The
default outside-line access code is usually 0. However, please check this code with your installer.
End the call
Use one of the following:
oHang up the handset.
oPress on the On-hook key on the permanent features keys panel
oOn-hook key on the Bluetooth® handset.

8AL90314ENAAed01 18 /70
2.2 Make a call using the personal phone book (Contacts)
Contacts
Select the contact to call Information regarding your contact is displayed on the screen.
Press the call icon to call your contact.
If there are several numbers for the same contact, select the desired number.
2.3 Using call by name
Use one of the following:
oSearch
oSwipe up on the screen
Enter the first letters of your contact name.
The names of contacts matching your search criteria are automatically displayed on
the screen.
Call your contact by choosing him/her in the list.
If you wish you can also display your contact complete file.
When searching by name, results are displayed showing all matching names followed by first names.
You can also search by initials. Type the initials of first name and surname, separated by a space. All
first names/names matching these initials will be displayed in the search.
2.4 Call from call log (History)
All incoming, outgoing, missed or unanswered calls are displayed in the call log.
You can call back from your phone call log.
Access the call log by pressing the Communication key.
oSelect the tab: History All call logs are displayed.
oSelect the tab: New Only new missed calls are displayed.
Use one of the following:
oCall your contact directly by selecting the badge.
oSelect the contact to call.
Answered outgoing call
Unanswered outgoing call
Callback (Call back the last number of the selected contact)
If there are several numbers for the same contact, select the desired number.
You can also access the feature by selecting the application preview History.

8AL90314ENAAed01 19 /70
2.5 Call back one of the last numbers dialed
Open the dialpad
Select the contact to call in the list of last number dialed.
Call your contact directly by selecting the badge
You can also access the feature by selecting the application preview History.
2.6 Redialing the last number dialed (redial)
Open the dialpad
Select twice to call the last number dialed
2.7 Call a contact from the favorites application (Favorites)
Favorites: This application contains favorite contacts that you have selected in your personal
directory.
Use one of the following:
oFavorites
oContacts
Select the tab: Favorites
All contacts defined as a favorite are displayed.
Select the contact to call.
Call
If there are several numbers for the same contact, select the desired number.
You can also access the feature by selecting the application preview Favorites.
Refer to chapter: "Define a contact as a favorite ".
2.8 Answer the call
Use one of the following:
oAnswer call
oTake the handset off the hook.
oHandsfree key.
oOff-hook key on the Bluetooth® handset.

8AL90314ENAAed01 20 /70
2.9 Ignore call
A call is received:
Use one of the following:
oIgnore
oPress on the On-hook key on the permanent features keys panel
Your phone no longer rings but your caller still hears the ringing tone.
You can still answer the call after you have ignored it.
2.10 Divert an incoming call
A call is received: Your telephone rings.
Deflect the call to voicemail
Deflect to VM
The call is directly transfered
Deflect the call to another number
Deflect
Dial the recipient of the transfer.
The call is directly transfered
Deflect the call to the personal assistant
Deflect DVA
The call is directly transfered
2.11 Using the telephone in “Hands free“ mode
You are in communication.
Handsfree key:
Press on the handsfree mode.
The handsfree mode is activated.
When the handfree is activated, the corresponding feature key is lit blue.
To take the call back with the handset
Use one of the following:
oTake the handset off the hook.
oIf the handset is off hook: Press the “handsfree“ key again Handset
oOff-hook key on the Bluetooth® handset.
