From Bicom Systems Wiki
Contents
1 Introduction
■
2 Requirements
■
2.1 Identifying Phone Model
■
2.2 Phone Firmware
■
2.3 DHCP Server
■
2.4 PBXware Version
■
3 Installation
■
3.1 Power Adapter
■
3.2 Power over Ethernet (PoE)
■
3.3 Find the Phone's IP Address
■
3.4 Reset to Factory Settings
■
4 Registering Phone
■
4.1 Manual Configuration
■
4.2 Auto Provisioning
■
5 Additional Configuration Template
■
Introduction

This configuration guide is written as a general guide on how to configure the Alcatel-Lucent
M7 phone model to work with PBXware 5.3.9 and 6.4.
Requirements
Identifying Phone Model
To start and successfully complete the registration of your Alcatel-Lucent phone, you need to
know which phone model to set up.
On the back of each Alcatel-Lucent phone, there is model information that you should check.
Although various phone models can have exactly the same requirements and installation
procedures, phone models can also have significantly different requirements and installation
procedures, so that is why it is important to know the model you own which results in you
setting up the device successfully.
Phone Firmware
Make sure that your phone is loaded with appropriate firmware version, 2.12.04.000.1720.
■
To find out the firmware version of the Alcatel phone model, open a new browser window and
■
enter the phone's IP address in order to access the phone's web administration interface login
screen. Example: http://192.168.1.22.
Log in to the phone's web administration interface with your username and password. Please
■
note that the factory default login details are as follows: username is admin and password is
123456.

DHCP Server
Fully configured and operational DHCP server.
PBXware Version
PBXware version 5.3.9
In order to find out the PBXware version:
Log in to PBXware
■
Navigate to Settings: About.
■
On the top of About page, you may see a code similar to this one PBXware Edition: Multi-
Tenant Release: 5.3.9.0 (41a4f0e6) Running: 13.23.1-gc-2e09fa3d, Proxy v5.3.9
(231c5f3), API: 5.3, libmemcached version: 1.0.18, where Release denotes the current
version of your PBXware.
Installation
This section describes how to install and connect the phone to the electrical power and data
network as well as how to apply factory settings.
The following topics are covered:
Power Adapter
■
Power over Ethernet (PoE)
■
Factory Settings
■
Power Adapter
Connect the Network and Power
Connect the DC plug on the power adapter to the DC port on the phone and connect the other
■
end of the power adapter into an electrical power outlet.
Connect the Ethernet cable between the Internet port on the phone and the network port on a
■
router or switch to access LAN.
NOTE: If you are using Power over Ethernet (PoE), you do not need to connect the AC adapter.
Make sure that the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant.
Power over Ethernet (PoE)
Connect the Network (only)
Using a regular Ethernet cable, your phone can be powered from a Power over Ethernet (PoE)
compliant router or switch.
Connect the Ethernet cable between the Internet port on the phone and an available port on
■
the in-line power router or switch.
NOTE: If you are using Power over Ethernet (PoE), you do not need to connect the AC adapter.

Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant.
Find the Phone's IP Address
Find out your Alcatel phone's IP Address.
Press the OK button.
■
The IP address will be displayed on the top of display.
Reset to Factory Settings
This step is not required for brand new out-of-the-box phones, however, if the phone has been
already used, then it is a must.
Click Maintenance in the left-hand navigation menu.
■
Click the Reboot&Restore sub-section.
■
Click OK next to the 'Restore Factory' field to initiate action.
■
Wait for some time for a device to reset to factory settings.
■
NOTE: Do not unplug or remove power from the phone while it is updating firmware and
configuration.
Registering Phone
This section describes how to identify the Alcatel phone model, requirements that must be met,
and how to register the phone using manual configuration or auto-provisioning.
The following topics are covered:
Manual Configuration
■
Auto Provisioning
■
Manual Configuration
This section describes how to set the UAD settings, create a PBXware Extension and register
the phone.
The following topics are covered:
UAD Settings
■
Creating an Extension
■
Registering a Phone
■
UAD Settings

UAD settings
Log in to the PBXware's web administration interface
Open a new browser window and enter the IP address in order to access the PBXware's web
■
administration login screen. Example: http://192.168.1.10.
Log in to PBXware with the e-mail address and password.
■
UAD settings
Navigate to Settings: UAD.
■
Make sure Alcatel M7 UAD is enabled. To check the UAD status, click the Edit icon
■
corresponding to your Alcatel phone.
Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
■
Click the Save button to save changes.
■
Creating an Extension
Creating Extension
Add an Extension
Navigate to Extensions. Click Add Extension.
■
The standard options window will be shown below.
■
Select the Alcatel phone model from the UAD select box.
■
Select Location: Local or Remote.
■
Local is for all Extensions registered on the LAN and Remote is for all Extensions
registered from remote networks, WAN, Internet etc.
Click the Next step button.
■
Extension values
Enter values into the required field text boxes.
REQUIRED FIELDS:
Name
■
Enter a name for the Extension being created. Example: John Smith.

E-mail
■
Enter the e-mail address associated with this Extension. This e-mail address will receive
all system notification messages. Example: [email protected]
Department
■
Department to which Extension belongs. Example: Sales.
Click the Save button.
■
Registering a Phone
This section describes how to register the Alcatel phone using Hostname or IP Address.
Hostname or IP Address
Log in to the phone's web administration interface
Open a new browser window and enter your phone IP address in order to access the phone's
■
web administration interface login screen. Example: http://192.168.1.22
Log in to the phone's web administration interface with your username and password. Please
■
note that the factory default login details are as follows: username is admin and password is
123456.
Click Account -> Basic.
■
Enter or set the following details into the respective fields.
■
REQUIRED FIELDS:
Account Active
■
Make sure the toggle button is enabled.
SIP Label Name
■
PBXware Extension user name. Example: John
Display Name
■
Usually the same number as the Register Name.
User Name
■
PBXware Extension number. Example 1003.
Register Name
■

PBXware Extension number. Example 1003.
Password
■
The Secret of the Extension as received in the e-mail associated with this extension.
Example: _%Z4M3*Ts9y7. A password is generated automatically for each newly created
Extension.
SIP Server
■
Enter the Hostname or IP Address of PBXware.
- Example of a Hostname: voip.bicomsystems.com
- Example of an IP Address: 192.168.1.10
Click the Confirm button at the bottom of the page.
■
If everything is done as described above, you should have successfully registered your phone
■
to PBXware.
Dial *123 to verify the registration.
Auto Provisioning
This section describes how to set UAD settings, create a PBXware Extension and register the
phone using DHCP or Static IP address.
The following topics are covered:
UAD Settings
■
Creating an Extension
■
Registering a Phone
■
UAD Settings
UAD settings
Log in to the PBXware's web administration interface.
Open a new browser window and enter the IP address in order to access the PBXware's web
■
administration login screen. Example: http://192.168.1.10.
Log in to PBXware with your e-mail address and password.
■
UAD settings

Navigate to Settings: UAD.
■
Make sure Alcatel M7 UAD is enabled. To check the UAD status, click the Edit icon
■
corresponding to your Alcatel phone.
Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
■
Click Save to save changes.
■
Creating an Extension
Creating Extension
Add Extension
Navigate to Extensions. Click Add Extension.
■
The standard options window will be shown below.
■
Select Alcatel phone model from the UAD select box.
■
Select Location: Local or Remote.
■
Local is for all Extensions registered on the LAN and Remote is for all Extensions
registered from remote networks, WAN, Internet etc.
Click the Next step button.
■
Extension values
Enter values into the required field text boxes.
REQUIRED FIELDS:
Name
■
Enter a name for the Extension being created. Example: John Smith.
E-mail
■
Enter the e-mail address associated with this Extension. This e-mail address will receive
all system notification messages. Example: [email protected]
Auto Provisioning
■
Set to Yes.
MAC Address
■

Enter the Alcatel phone's MAC address. Example: 001565FF1536. The MAC address can
be found at the back of the phone.
Click Save.
■
Registering a Phone
This section describes how to register the Alcatel phone using DHCP, TFTP, or HTTP &
HTTPS.
DHCP
Configure DHCP
Make sure your DHCP router is configured to use option 66 to automatically instruct phones
■
with the URL for auto provisioning. For more information, please refer to the router
documentation or contact your network administrator.
Phone's first boot or user-initiated reboot
The auto-provisioning process will start during the phone's first boot or after the reboot
■
process has been initiated by the user. The DHCP server will instruct the phone from where to
pick up an appropriate configuration file. If everything is done as described above, you should
have successfully registered your phone to PBXware.
Dial *123 to verify registration.
TFTP or HTTP or HTTPS
Open a new browser window and enter the phone's IP address, e.g. http://192.168.1.22.
■
Enter username and password and press Confirm. NOTE: The factory default login details
■
are as follows: username is admin and password is 123456.
Click the Provision tab.
■
Click Auto Provision in the sub-menu.
■
Choose what server type you intend to use: HTTP, HTTPS, and Trivial FTP. NOTE: Our
■
recommendation is to use HTTP.
Enter http:// or https:// followed by Hostname or IP Address, then followed by
/prov in the DM URL and Backup DM URL fields.
Example of a Hostname using HTTP: http://abc.bicomsystems.com/prov

Example of a Hostname using HTTPS: https://abc.bicomsystems.com/prov
Example of an IP Address using HTTP: http://192.168.1.10/prov
Example of an IP Address using HTTPS: https://192.168.1.10/prov
Enter Auto Provisioning username and password into the Username and Password fields.
■
If you choose to use TFTP, enter tftp:// followed by Hostname or IP Address
Example of a Hostname: tftp://voip.bicomsystems.com
Example of an IP Address: tftp://192.168.1.10
Click the Confirm button at the bottom of the page.
■
Click the Auto Provision Now button.
■
A pop up window will show up, click OK to confirm.
■
You will have to wait a couple of seconds for the configuration to be updated. NOTE: Do not
■
power off your phone.
The auto-provisioning process will start during the phone's reboot process. The phone will pick
■
up an appropriate configuration file from PBXware. If everything is done as described above,

you should have successfully registered your phone to PBXware.
Dial *123 to verify registration.
Additional Configuration Template
If you want to include some additional UAD configuration for Alcatel-Lucent M7, just add fields
to User Agent General Auto Provisioning Template in Settings -> UAD -> Alcatel M7
menu, or add them directly to the Extension in the UAD Auto Provisioning Template section.
