Allen + Roth Reagan 72-BVF11-BB-AR User manual

1
07-13-2020
ITEM # 835542, 1361729, 1361728, 1864847
VESSEL FILLER
BATHROOM FAUCET
MODELS 72-BVF11-BB-AR, 72-BVF11-AR,
72-BVF11-BN-AR, 72-BVF11-BRZ-AR
Español p. 9
ALLEN + ROTH and logo design are
trademarks or registered trademarks of LF, LLC.
All rights reserved.
ATTACH YOUR RECEIPT HERE
Serial Number ___________________________ Purchase Date___________________________
Questions, problems, missing parts? Before returning to the store, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
SM20280

2
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
AFaucet body 1 C Grid drain assembly 1
B Flange 1 D Allen wrench 1
Due to constant design and quality improvements, the product inside may look slightly different from the picture.
HARDWARE CONTENTS (not shown actual size)
AA BB
Washer Lock nut
Qty. 1 Qty. 1
PACKAGE CONTENTS
C
D
A
B

3
B
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
CAUTION
• If you solder the joints during installation of the faucet, the seats, cartridges, and washers must be
removed before using a ame or the warranty will be voided on these parts.
• Cover the sink drain to avoid losing parts.
WARNING
• Protect your eyes with safety glasses when cutting or soldering water supply lines.
• NOTE: When making water line connections, HAND TIGHTEN. DO NOT OVERTIGHTEN. Do not
use PTFE pipe tape, plumber’s putty, pipe dope or any other type of sealing compound on water
inlet or threads. Additional compound is unnecessary. A watertight seal between the thread inlet
and supply tube is achieved by compression.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble
the product. Contact customer service for replacement parts.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included): Adjustable Wrench, Slip Joint Pliers, Pipe Wrench,
Phillips Screwdriver, and Silicone.
Installation may vary depending on how the previous faucet was installed. Supplies necessary for the
installation of the faucet are not all included; however, they are available wherever plumbing supplies
are sold.
Prior to beginning installation, turn off the hot and cold water lines, then turn on the old faucet to
release built-up pressure. When installing the new faucet, hand tighten the connector nuts. DO NOT
OVERTIGHTEN. Connections that are too tight will reduce the integrity of the system.
PRODUCT SPECIFICATIONS
Maximum ow rate: 1.2 GPM (4.54 LPM) at 60 PSI Total weight of item: 3.23 lbs.
ASME A112.18.1/CSA B125 Ceramic cartridge
NSF/ANSI 61 Manufactured to include no more than 0.25%
weighted average lead content on wetted
surfaces
Oil-rubbed bronze nish - 835542
Chrome nish - 1361729
Brushed nickel nish - 1361728
Brushed bronze nish - 1864847

4
INSTALLATION INSTRUCTIONS
1. Shut off the water at the supply valves under the sink or at the main water
supply. Disconnect the supply lines. Remove the existing faucet from the
sink.
Clean and dry the surface area where the new faucet will be mounted.
1
2. Conrm that the hole in sink and/or countertop is 1.3 in. - 1.5 in. to accommodate
the new faucet.
Remove the preassembled lock nut (BB), and metal washer (AA) from the faucet
body (A). Before installation, make sure the ange (B) is on the bottom of the
faucet body (A). Insert the faucet body (A) through the mounting hole in the sink
(2.1). From underneath the sink, secure the faucet body (A) to the sink
using the washer (AA) and lock nut (BB). Use a wrench to tighten the lock
nut (BB).
Hardware used
2
BB
AA
2.1
A
B
AA Washer x 1
BB Lock nut x 1
3. Remove the bottom gasket (3.1) and mounting nut (3.2) from the drain
assembly (C). Push the bottom gasket (3.1) down onto the top of the
mounting nut (3.2) and twist to attach together.
3
3.1
3.2
C
4. Insert the drain assembly (C) into the drain hole in the sink (4.1). Ensure the top
gasket (4.2) rests securely between the top of the sink and the top of the drain
assembly (C).
4
4.2
C
4.1

5
INSTALLATION INSTRUCTIONS (continued)
5. From underneath the sink, screw the bottom gasket (5.1) and mounting
nut (5.2) onto the drain assembly (C) by twisting until secure against the
bottom of the sink.
IMPORTANT: Remember to reconnect the drain body to the P-Trap drain
assembly (not included) before testing the faucet.
5
5.1
5.2
C
6. Attach the end of each integrated supply line (6.1) from the faucet body (A)
to the hot and cold water supply valves (6.2). Thread the nut of the integrated
supply line (6.1) onto the outlet of the water supply valve and tighten with a
wrench. Do not overtighten. NOTE: The hot side inlet tube is indicated by a
label.
NOTE: Do not use PTFE pipe tape, plumber’s putty, pipe dope, or any other
type of sealing compound on the water inlets or threads. Additional compound
is not necessary. A watertight seal between the supply valve and the nut on the
integrated supply line is achieved by compression.
6
6.1
6.2
7. Once the installation is complete, remove the aerator (7.1) from the spout (7.2)
on the faucet body (A) to ush the water lines. Do not lose the gasket (7.3)
from the aerator (7.1). Turn on the water supply and allow both hot and cold
water to run for at least one minute to ush away any debris that could cause
damage to internal parts. While the water is running, check for leaks. If leaks
occur, gently tighten the nut on the connection that is leaking. Fill the sink with
water to check the drain for leaks. If water is leaking from the drain, tighten the
nut on the drain assembly and empty the sink. Turn off the water, reinsert the
gasket (7.3), and screw the aerator (7.1) back onto the spout (7.2) of the
faucet body (A).
7
A
7.1
7.3
7.2
