Allen + Roth VBL10SBNK User manual

Model VBL10SBNK
Model VBL10LBNK
ITEM #0760085 / #0760086
#1010728 / #1010729
MODEL#VBL10SBNK / #VBL10LBNK
#VBL10-20BNK / VBL10-20BZ
LED VANITY BAR
VR20213
For Damp
Location
1
Purchase Date
allen + roth® is a registered trademark
of LF, LLC. All Rights Reserved.
Français p.10
Español p.19
Model VBL10-20BNK
VBL10-20BZ
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
ATTACH YOUR RECEIPT HERE
welcoming • sophisticated • inspiring

A Fixture 1
PART DESCRIPTION QUANTITY
B Mounting Plate 1
C Mounting Plate Screw 2
(preassembled to fixture (A))
(preassembled to fixture (A))
2
PACKAGE CONTENTS
Package Contents ...........................................................................................................
. ... 2
Hardware Contents
............................................................................................................... . .......... 3
Safety Information ......................................................................................................... . . . ... 3
Preparation .....................................................................................................................
. .... 5
Assembly Instructions ..........................................................................................................
5
Care and Maintenance ..............................................................................................
. ....... 9
Troubleshooting................................................................................................................... 9
Warranty .......................................................................................................................
. ...... 9
TABLE OF CONTENTS
C
B
A
Model VBL10SBNK
Model VBL10LBNK
Model VBL10-20BNK
VBL10-20BZ

3
READ AND SAVE THESE INSTRUCTIONS.
DANGER
•For your protection and safety, carefully read and understand the information provided in this
manual completely before attempting to assemble, install or operate this product. Failure to do so
could lead to fire, electrical shock or other injuries that could be hazardous or even fatal.
•DO NOT connect this fixture to an electrical system that does not provide a means for equipment
grounding. Never use a fixture in a two-wire system that is not grounded. Installing a fixture into an
electrical system not having a proper grounding means could cause metal parts of the fixture to
carry electrical currents if any of the fixture wires, wire connections or splices were to become
broken, cut or loose during the mounting or normal operation of the fixture. Under this condition,
anyone coming in contact with the fixture would be subject to electrical shock, which could cause
serious injury or death.
•DO NOT connect the bare or green insulation fixture ground wire to the black (HOT) current-carrying
wire or the white (NEUTRAL) house wire. Connection of the bare or green fixture ground wire to the
black or white house wires may cause metal parts of the fixture to carry electrical currents. Under
this condition anyone coming in contact with the fixture will receive electrical shock, which could
cause serious injury or death.
•DO NOT damage or cut the wire insulation (covering) during installation of fixture. DO NOT permit
wires to contact any surface having a sharp edge. To do so may damage or cut the wire insulation,
which could cause serious injury or death from electrical shock.
SAFETY INFORMATION
•All electrical connections must be in agreement with local codes and ordinances, the National Electric
Code (NEC) and ANSI/NFPA 70-1999. Contact your municipal building department to learn about
your local codes, permits and/or inspections. Risk of fire - most dwellings built before 1985 have
supply wire rated for 140° F. Consult a qualified electrician before installation.
•To avoid personal injury, the use of gloves may be necessary while handling fixture parts with sharp
edges.
•DO NOT suspend any fixture by the house wires. A fixture must always be mounted directly to an
outlet box or to a mounting plate which is first attached to the outlet box. Wire connectors will not
support the weight of a fixture. Suspending a fixture by the house wires and wire connectors will
result in the fixture falling, with the possibility of personal injury and the danger of electrical shock or
fire.
WARNING
HARDWARE CONTENTS (shown actual size)
Wire
Connector
Qty. 3
AA BB
Machine
Screw
Qty. 2

4
•To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this light
fixture are designed to accept only one 12-gauge house wire and two lead wires from the light fixture.
If your house wire is larger than 12-gauge or there is more than one house wire to connect to the
corresponding fixture lead wires, consult an electrician for the proper size wire connectors to use.
•TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning installation by
removing the fuse (or switching the circuit breaker off).
•If you are not sure the lighting system has a grounding means, DO NOT attempt to install this fixture.
Contact a qualified, licensed electrician for information regarding the proper grounding methods as
required by the local electrical code in your area.
•All fixtures must be mounted to an outlet box that is supported by the building structure.
•If a dimmer control switch is used with this fixture, obtain professional advice to determine the correct
type to use as well as the electrical rating required.
•Do NOT tamper with or attempt to repair LED component of fixture. The light source is designed for
this specific application and should not be serviced by untrained personnel. If any servicing is
required, call our customer service department.
CAUTION
NOTE: Dimmable to 10% with select dimmers. See Lowes.com for more information.
SAFETY INFORMATION
Modifications not approved by the party responsible for compliance could void the user's authority to
operate the equipment.
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, (2) this device must accept any interference
received, including interference that may cause undesired operation.
• Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures: - Reorient or
relocate the receiving antenna. - Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Distributed by: Litex Industries Inc., P.O. Box 535639, Grand Prairie, TX, 75050; 1-800-527-1292

PREPARATION
5
ON
OFF
ON
OFF
Turn off circuit breakers and wall switch to
the fixture supply line leads.
DANGER: Failure to disconnect power
supply prior to installation may result in
serious injury or death.
1
Remove existing fixture and disconnect all
electrical wiring. 2
1.
2.
ASSEMBLY INSTRUCTIONS
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble
the product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included):Flathead Screwdriver, Phillips Screwdriver, Wire Strippers,
Pliers, Wire Cutters, Safety Glasses, Stepladder, Electrical Tape
Helpful Tools (not included):A/C Tester Light, Do-It-Yourself Guide, Soft Cloth, Level

ASSEMBLY INSTRUCTIONS
6
Remove mounting plate (B) from fixture (A) by
removing mounting plate screws (C) from the
edges of the fixture (A).
Save mounting plate screws (C) for later use.
Attach mounting plate (B) to outlet box
(not included) using existing washers and
outlet box screws or the machine screws
(BB). NOTE: If the outlet box screws
required for your outlet box are of a different
size than the machine screws (BB), consult
a licensed electrician before proceeding.
Tighten machine screws (BB) to secure
mounting plate (B).
CAUTION: The fixture must be mounted
to an outlet box that is supported by the
building structure. Plastic outlet boxes are
not recommended.
3.
4.
B
Hardware Used
Machine Screw x 2
BB
4
Outlet Box
B
BB
BB
3
C
A
C

ASSEMBLY INSTRUCTIONS
7
5.
6.
Unwrap BARE fixture wire from BLACK and WHITE
fixture wires. Prepare wires by stripping 3/4 in. of
insulation from wire ends using wire strippers (not
included). Connect WHITE wire from fixture (A) to
WHITE wire from outlet box using existing wire
connector or wire connector (AA). Connect BLACK
wire from fixture (A) to BLACK wire from outlet box
using existing wire connector or wire connector (AA).
Connect BARE/GREEN ground wire from outlet box
to BARE ground wire from fixture (A) with wire
connector (AA).
NOTE: Screw wire connectors (AA) on in a clockwise
direction.
WARNING: Never connect ground wire to
WHITE or BLACK power supply wires.
WARNING: To reduce the risk of fire, electrical
shock or personal injury, wire connectors (AA) are
designed to accept only one 12-gauge house wire
and two lead wires from the light fixture. If your
house wire is larger than 12-gauge or there is more
than one house wire to connect to the corresponding
fixture lead wires, consult an electrician for the
proper size wire connectors to use.
Hardware Used
Wire Connector x 3
AA
Wrap electrical tape (not included) around
each individual wire connector (AA) down
to the wire. Push wire connectors (AA)
gently back into outlet box. Carefully push
excess wiring into outlet box.
WARNING: Make sure no bare wire or
wire strands are visible after making
connections.
Outlet Box
5
BLACK
WHITE
BARE/
GREEN
A
AA
AA
AA
Outlet Box
6
A
AA
AA
AA

ASSEMBLY INSTRUCTIONS
8
7. Attach fixture (A) to mounting plate (B) using the
mounting plate screws (C) previously removed
(Step 3, Page 6).
NOTE: Before tightening mounting plate screws
(C) completely, use level (not included) to check
fixture (A) -- adjust if necessary.
Restore power and test fixture (A).
If lights do not function, please refer to
TROUBLESHOOTING.
8.
7
B
A
8
C
C
A

Printed In China
9
PWLI2006
CARE AND MAINTENANCE
•Shut off main power supply. Wipe with soft cloth or use window cleaner. Do not use an abrasive
cleaner.
WARRANTY
The distributor warrants all of its lighting fixtures against defects in materials and workmanship for
five (5) years from the date of purchase. If within this period the product is found to be defective, take
a copy of the bill of sale as a proof of purchase and the product in its original carton to the place of
purchase. The distributor will, at its option, repair, replace or refund the purchase price to the
consumer. All costs of installation and removal of the fixture is the responsibility of the consumer. This
warranty does not cover fixtures becoming defective due to misuse, accidental damage or improper
handling and/or installation and specifically excludes liability for direct, incidental or consequential
damages, improper packaging of returned products and acts of God. As some states do not allow
exclusions of limitations on an implied warranty, the above exclusion and limitation may not apply.
This warranty gives you specific rights and you may also have other rights which may vary from state
to state.
Light does not come on
initially or no longer
comes on.
Fuse blows out or
circuit breaker trips.
1. Power is OFF.
2. Faulty connection.
3. LED component is not working
properly.
1. Crossed wires.
2. Power wire is grounding out.
1. Check wiring.
2. Check all connections.
1. Make sure power supply is ON.
2. Check wiring and all connections.
3. Contact Customer Service.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
TROUBLESHOOTING
WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
