Alpine INE-W928R User manual

All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
12
3
4
• (1) facia plate
• (2) mounting bracket right
• (3) mounting bracket left
• (4) recessed countersunk at head screw
• Seat Alhambra (6N)
• Škoda Fabia II
• Škoda Octavia II
• Škoda Roomster
• VW Caddy
• VW Sharan
• VW Tiguan
• VW Touran
part-no.:
KIT-8VWT
KIT-8VWTD
colour: black
Installation Manual
INE-W928R Kit
Compatible with these Alpine navigation devices
INE-W928R

VW Tiguan
Škoda Fabia II / Octavia II / Roomster / VW Caddy / Touran
2. Remove 4 screws
Remove head unit
1. Unclip and remove OEM panel
(see arrows)
3. Attach mounting frames to
Alpine INE-W928R
4. Connect all requred circuit points
Place Alpine INE-W928R
on dashboard
Install OEM panel to nish
installation
Place facia plate
Put dome of facia plate
exactly over the holes of
mounting frames
(see arrow above)
5. Connect all requred
circuit points
Place Alpine INE-W928R
on dashboard

VW Tiguan
2. Remove 4 screws
Remove head unit
3. Cut away plastic to clear space
for Alpine INE-W928R
1. Unclip and remove OEM panel
(see arrows)
Remove 4 screws of
OEM head unit
4. Attach mounting frames to
Alpine INE-W928R
Put dome of facia plate
exactly over the holes
of mounting frames
(see arrow above)
Fix facia plate with 4 screws
7. Install OEM panel to nish
installation
6. Place facia plate
5. If necessary:
Cut away plastic to clear space
for Alpine INE-W928R
Škoda Fabia II / Octavia II / Roomster / VW Caddy / Touran

1. Open top shelf
Remove 2 screws
2. Remove top shelf inlay
Remove 2 screws on top
3. Remove OEM panel
Seat Alhambra / VW Sharan Seat Alhambra / VW Sharan
4. Remove 4 screws
Remove OEM head unit
If necessary:
Cut away plastic to clear space
for Alpine INE-W928R
5. Attach mounting frames to
Alpine INE-W928R
7. Connect all requred circuit
points
Place Alpine INE-W928R
on dashboard
Fix facia plate with 4 screws
Install everything in reverse
order to nish installation
6. Place facia plate
