Analog Devices EVAL-ADA4570SDZ User manual

User Guide | EVAL-ADA4570
UG-2004
Integrated AMR Angle Sensor and Signal Conditioner with Differential Outputs
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS. Rev. 0 | 1 of 17
FEATURES
►Full featured evaluation board for the ADA4570
►PC control in conjunction with the System Demonstration Plat-
form (SDP) (EVAL-SDP-CS1Z, SDP-S or EVAL-SDP-CB1Z,
SDP-B)
►PC software for data measurement and display
EVALUATION KIT CONTENTS
►EVAL-ADA4570SDZ evaluation board
►ADA4570 magnet stimulus
►Dipole magnet
►Hand movable mounting
ADDITIONAL HARDWARE REQUIRED
►The SDP-S or the SDP-B controller board with a USB cable
ADDITIONAL SOFTWARE REQUIRED
►EVAL-ADA4570SDZ Software Installer
GENERAL DESCRIPTION
The ADA4570 is an anisotropic magnetoresistive (AMR) sensor
with integrated signal conditioning amplifiers and analog-to-digital
converter (ADC) drivers. The ADA4570 produces two differential
analog output pairs that indicate the angular position of the sur-
rounding magnetic field.
The EVAL-ADA4570SDZ evaluation board features the ADA4570 in
an end of shaft magnet configuration.
The evaluation kit is composed of the EVAL-ADA4570SDZ and
a magnetic stimulus on a printed circuit board (PCB) mount. To in-
terface to a computer, the EVAL-SDP-CS1Z (SDP-S) or the EVAL-
SDP-CB1Z (SDP-B) is required which must be ordered separately.
An illustration of the ADA4570 evaluation system consisting of
the PC graphic user interface (GUI), the SDP, and the EVAL-
ADA4570SDZ is shown in Figure 1. In this user guide, SDP refers
to either the SDP-S or the SDP-B interface card.
The EVAL-ADA4570SDZ allows a detailed evaluation of the
ADA4570 where the software GUI demonstrates angular measure-
ment and performs system level calibration.
The EVAL-ADA4570SDZ also provides access via a standard
header for power and digital signals to the on-board ADC interface
(AD7266), which allows evaluation of the ADA4570 with a user
preferred microcontroller platform and to start the system software
development. Users can also access the analog output signals
of the ADA4570 to a user preferred ADC with a microcontroller
platform.
The PCB is designed so that the sensor board can be detached
from the SDP interface to provide a smaller form factor. Power
supplies can be sourced from either the USB port via the SDP card
or an external bench supply.
For full details, see the ADA4570 data sheet, which must be
used in conjunction with this user guide when using the EVAL-
ADA4570SDZ.
ADA4570 END OF SHAFT MAGNETIC EVALUATION SYSTEM
Figure 1. ADA4570 End of Shaft Magnetic Evaluation System Consisting of the PC GUI, the SDP, and the EVAL-ADA4570SDZ

User Guide EVAL-ADA4570
TABLE OF CONTENTS
analog.com Rev. 0 | 2 of 17
Features................................................................ 1
Evaluation Kit Contents......................................... 1
Additional Hardware Required...............................1
Additional Software Required................................ 1
General Description...............................................1
ADA4570 End of Shaft Magnetic Evaluation
System.................................................................1
Getting Started...................................................... 3
Quick Start Steps............................................... 3
Evaluation Board Hardware...................................4
Configuration of the EVAL-ADA4570SDZ.......... 4
Evaluation Board Quick Start ............................... 6
Software Installation Procedures........................6
Evaluation Board Software.................................... 8
Starting the Evaluation GUI................................8
Overview of the Main ADA4570 Evaluation
Software GUI Window......................................9
Evaluation Board Schematics and Silkscreen..... 13
Ordering Information ...........................................16
Evaluation Board Bill of Materials.....................16
Notes................................................................17
REVISION HISTORY
7/2021—Revision 0: Initial Version

User Guide EVAL-ADA4570
GETTING STARTED
analog.com Rev. 0 | 3 of 17
QUICK START STEPS
The SDP is the controller board, which is the communication link
between the PC and the EVAL-ADA4570SDZ, and provides the
serial peripheral interface (SPI) required to transfer ADA4570 data
sampled by the ADC directly to the host PC.
Note that the evaluation software and the SDP USB driver must be
installed before connecting the EVAL-ADA4570SDZ board and the
SDP board to the USB port of the PC to ensure that the evaluation
system is correctly recognized when the EVAL-ADA4570SDZ is
connected.
The SDP USB Driver Installer can be found by following the Soft-
ware tab on the EVAL-SDP-CS1Z (SDP-S) or the EVAL-SDP-CB1Z
(SDP-B) product pages.
To begin using the EVAL-ADA4570SDZ, take the following steps:
1. Connect the SDP board to the EVAL-ADA4570SDZ (see
Figure 2).
2. Slide the EVAL-ADA4570SDZ into the magnet mounting brack-
et at the bottom PCB mount side rail. To correctly align
the magnet with the ADA4570 sensor, ensure that the EVAL-
ADA4570SDZ is fully inserted into the magnet PCB mount.
3. Connect the SDP board to the computer using the supplied
USB cable (USB Type A to Mini-B).
4. To launch the EVAL-ADA4570SDZ software, click the Win-
dows® key to open the Windows Start menu and Programs list.
Navigate to Analog Devices and click EVAL-ADA4570SDZ.
Figure 2. Hardware Configuration Showing the Demonstration Magnet Assembly, EVAL-ADA4570SDZ, and the SDP-B

User Guide EVAL-ADA4570
EVALUATION BOARD HARDWARE
analog.com Rev. 0 | 4 of 17
The EVAL-ADA4570SDZ end of shaft evaluation system comprises
a PCB with the ADA4570, an AD7266 ADC, and an external
mountable magnetic stimulus.
CONFIGURATION OF THE EVAL-ADA4570SDZ
The EVAL-ADA4570SDZ was designed to provide flexibility for
users. The following configurations are available:
►SDP and Analog Devices, Inc, software controlled
►Using an external digital interface
►A direct analog interface with the ADA4570 sensor
If an external power supply is connected to supply the EVAL-
ADA4570SDZ, the current limitation of the external power supply
must be set to 100 mA as a precaution.
SDP and Analog Devices Software Controlled
The ADA4570 evaluation system can be powered directly from
the host PC USB by the SDP controller board via the P3 connec-
tor. Use the CON A connector of the SDP controller board to
connect to P3 (see SDP and Analog Devices Software Controlled).
The Connector P3 pinout with the used SDP connections for the
EVAL-ADA4570SDZ is listed in Table 1, which is the recommended
configuration for the user to quickly achieve high performance
measurement.
This configuration uses the SDP to communicate with the AD7266
ADC to sample the sensor output and display the data with the
software provided.
Figure 3. Connector P3 to Interface SDP and EVAL-ADA4570SDZ
Table 1. P3 Socket for the SDP Interface
Pin Number Function Description
3, 4, 6, 11, 23, 28, 36, 40, 46, 52, 58, 63, 69, 75, 81, 86, 93, 98, 104,
109, 115, 117, 118
GND System ground
5 5 V supply 5 V supply from the USB port of the connected PC
43 REF_SESECT Reference voltage select
44 RANGE Input range select
45 SGL/DIFF Differential and single-ended select
56 EEPROM_A0 Address A0 of the board identifier EEPROM
76 GPIO5 SDP general-purpose input and output (GPIO)
77 GPIO3 SDP GPIO
78 GPIO1 SDP GPIO
79 I2C SCL I2C clock
80 I2C SDA I2C data
82 SPI SCL SPI clock
83 SPI SDO SPI slave data out
84 SPI SDI SPI slave data in
85 SPI SPI chip select for the GPIO expander, SDP Chip Select A
116 3.3 V supply Main supply for supporting devices

User Guide EVAL-ADA4570
EVALUATION BOARD HARDWARE
analog.com Rev. 0 | 5 of 17
Using an External Digital Interface
The EVAL-ADA4570SDZ facilitates a configuration option where
the user can connect an external microcontroller or field program-
mable gate array (FPGA) to the on-board AD7266 ADC (see
Figure 4).
Figure 4. Typical Connection Diagram for Using the Digital Interface
Connector P2, shown in Figure 4, provides the required connectivity
to power the AD7266 ADC and the ADA4570 as well as the
interface to the AD7266 ADC. This configuration allows users to
monitor the digitized output of the ADA4570 with a user preferred
embedded hardware platform. The pinout of Connector P2 is listed
in Table 2. The SDP controller board supports a maximum SPI
speed of 10 MHz, which limits the sampling rate of the AD7266
ADC to 625 kSPS. This configuration can be used to facilitate data
acquisition with a faster sampling rate up to 2 MSPS.
Figure 5. Connector P2 for Access to the SPI of the ADC of the EVAL-
ADA4570SDZ
Table 2. Optional Digital Interface Connection of P2
Pin Name Input Type Description
VDD Supply The 5 V input that supplies the evaluation
board.
OUT1, OUT2,
CLK, CS
Digital inputs and
outputs
SPI.
VIO Supply and digital
input for
REF_SELECT of
the AD7266
When used in this configuration, VIO
selects the AD7266 ADC reference
source. If high, it is the external ADC
reference, and if low it is the internal 2.5 V
reference.
A0, A1, A2 Digital inputs Digital inputs to control the input channel
of the ADC. The Ax pins can control which
output configuration is sampled by the on-
board ADC.
GND Ground Ground connection of the EVAL-
ADA4570SDZ.
For full details about the SPI and how to interface the different pins,
refer to the EVAL-ADA4570SDZ schematics (see Figure 27 and
Figure 28) and the AD7266 data sheet.
Direct Analog Interface with the ADA4570
The EVAL-ADA4570SDZ facilitates a configuration option where
the user can connect an external ADC to the ADA4570 output
signals (see Figure 6).
Figure 6. Typical Connection Diagram for Using Direct Access to the
ADA4570 Sensor
Connector P1, shown in Figure 7, provides the required connectivity
to supply the ADA4570 and access to the ADA4570 output signals
for the external ADC. This configuration allows users to sample
the sine and cosine outputs of the ADA4570 with a user preferred
differential ADC. The pinout of Connector P1 is listed in Table 3.
Figure 7. Connector P1 for Direct Access to the Sensor Output
Table 3. Optional Analog Interface Connection of P1
Pin Name Input Type Description
VDD Supply 5 V supply of the EVAL-ADA4570SDZ
VSIN− Analog output Negative analog sine output from the
ADA4570
VSIN+ Analog output Positive analog sine output from the
ADA4570
VCOS− Analog output Negative analog cosine output from the
ADA4570
VCOS+ Analog output Positive analog cosine output from the
ADA4570
VTEMP Analog output Analog output from the ADA4570
NC Ground No connect pin
GND Ground Ground connection of the EVAL-
ADA4570SDZ
For full details about the ADA4570 sensor interface and how to
connect the device, refer to the EVAL-ADA4570SDZ schematics
(see Figure 27 and Figure 28) and the ADA4570 data sheet.

User Guide EVAL-ADA4570
EVALUATION BOARD QUICK START
analog.com Rev. 0 | 6 of 17
The EVAL-ADA4570SDZ evaluation board can be controlled with
the EVAL-ADA4570SDZ Evaluation Board Software. The following
sections provide instructions for installing the supporting software
and an overview for connecting the hardware to the PC.
SOFTWARE INSTALLATION PROCEDURES
Installing the EVAL-ADA4570SDZ Evaluation
Software
To install the EVAL-ADA4570SDZ evaluation software, take to the
following steps:
1. Start the Windows operating system of the PC and download
the ADA4570 Evaluation Board Installer software.
2. Unzip the downloaded file. Run the setup.exe file.
3. Click the setup.exe file to begin installing the evaluation soft-
ware. The software installation window opens as shown in
Figure 8.
Figure 8. EVAL-ADA4570SDZ Evaluation Software Install Window
4. Choose the installation directory and click Next. The default
location is C:\Program Files (x86)\Analog Devices\.
Figure 9. Destination Directory Window
5. Installing the EVAL-ADA4570SDZ Evaluation Software re-
quires users to accept the license agreement shown in
Figure 10. Read the agreement before clicking Next to proceed.
Figure 10. License Agreement Window
6. The window shown in Figure 11 provides a summary of the
software installation. Click Next to install the software listed in
the window.
Figure 11. Start Installation Window
7. A pop-up window then opens and displays a bar showing the
installation progress, as shown in Figure 12.
Figure 12. Overall Progress
The installation then completes, and the next step is to install the
SDP drivers.

User Guide EVAL-ADA4570
EVALUATION BOARD QUICK START
analog.com Rev. 0 | 7 of 17
SDP Installation
To install the SDP drivers, download the SDPDrivers.exe file from
the SDP product page (SDP-S or SDP-B) and complete the follow-
ing steps:
1. To initialize the installation, run the SDPDrivers.exe executable
file.
2. When the SDP drivers setup wizard appears, click Next (see
Figure 13).
Figure 13. SDP Driver Setup Wizard
3. When the Choose Install Location window appears (see
Figure 14), click Install. To select a different destination folder,
click Browse, select a destination, then click Install.
Figure 14. Choose Install Location Window
4. Click Finish to complete the installation of the SDP drivers.
5. When plugging in the SDP controller board via the provided
USB cable, allow the Found New Hardware Wizard to run.
Check that the SDP drivers are installed and that the SDP
controller board are connected properly by checking the Device
Manager of the PC. If the drivers and board are connected
properly, the Analog Devices System Demonstration Plat-
form SDP appears under ADI Development Tools
(see Figure 15).
Figure 15. Device Manager Menu
6. The computer now recognizes the SDP controller board, and
the EVAL-ADA4570SDZ Evaluation Software can be opened.
Uninstalling the Software
To uninstall the EVAL-ADA4570SDZ Evaluation Software, take the
following steps:
1. Launch the Uninstall Wizard by navigating to Start > Control
Panel > Programs and Features > EVAL-ADA4570SDZ to
open a window with the Uninstall button.
2. Click Uninstall.
3. Click Yes in the confirmation window that appears.
To uninstall the SDP drivers, adhere to the following steps:
1. Launch the Uninstall Wizard by navigating to Start > Control
Panel > Programs and Features > ADI SDP Drivers to open
a window with the Uninstall button.
2. Click Uninstall.
3. Click Yes in the confirmation window that appears.

User Guide EVAL-ADA4570
EVALUATION BOARD SOFTWARE
analog.com Rev. 0 | 8 of 17
STARTING THE EVALUATION GUI
To use the EVAL-ADA4570SDZ with the SDP controller board, start
by connecting the two boards together with the CON A connector of
the SDP.
When launching the GUI, the SDP controller board must be
recognized by the GUI before proceeding. The GUI automatically
searches for the SDP controller board and tries to read the EE-
PROM identification of the EVAL-ADA4570SDZ and to ensure that
the correct program is in use.
If the SDP controller board is not connected, or if the drivers are not
installed correctly, a Hardware Select window appears (see
Figure 16). If this occurs, ensure that the drivers are installed
correctly and that the PC recognizes the SDP controller board. Figure 16. Hardware Select Window
The Hardware Select window also appears when the EVAL-
ADA4570SDZ is not recognized or is not connected to the SDP
controller board. When the EVAL-ADA4570SDZ is detected, the
board appears preselected in the Hardware Select window. Click
Select to continue.

User Guide EVAL-ADA4570
EVALUATION BOARD SOFTWARE
analog.com Rev. 0 | 9 of 17
OVERVIEW OF THE MAIN ADA4570
EVALUATION SOFTWARE GUI WINDOW
Figure 17 shows the main EVAL-ADA4570SDZ GUI window when
starting the ADA4570 Evaluation Board Software.
Initially, all plots are blank, and the data capture is preset for data
acquisition of the differential VSIN and VCOS signals data capture.
Click Start to begin the data acquisition, and the Captured Data
window of the GUI displays the selected signals.
Figure 17. ADA4570 Evaluation Board Software (EVAL-ADA4570SDZ) Main Window

User Guide EVAL-ADA4570
EVALUATION BOARD SOFTWARE
analog.com Rev. 0 | 10 of 17
VSIN and VCOS Raw Outputs
The Captured Data graph shows measurement result in volts of
the selected outputs from the ADA4570 magnetic angle sensor (see
Figure 18).
Figure 18. Captured Data Graph
The red and blue waveforms in Figure 18 indicate the differential
signals of the selected VSIN channel and VCOS channel outputs
as the magnet rotates over the ADA4570. The VSIN and VCOS
differential signals output data is used to calculate the angle and
radius.
In the application, it is important that these two channels are
simultaneously sampled to avoid the introduction of errors resulting
in a phase delay between the sampling of the individual channels.
GUI Settings and Capture Modes
The GUI allows the user to change some settings that are accessed
via the system icon, Configure (see Figure 19).
Figure 19. Configure Icon
When the Configure icon is activated, the GUI opens a window
that allows the user to modify the captured data display settings,
data accusation and update rate settings, and the method the data
is captured. Figure 20 shows the GUI default settings.
Figure 20. Configure Window
The GUI provides two capture modes, Continuous and Burst.
When the EVAL-ADA4570SDZ operates in continuous capture
mode, the GUI constantly samples the VSIN channel and VCOS
channel. The number of samples displayed is set with the Chart
Length field and, by default, is set to 500 samples. The GUI
allows the user to set delays between sample reads via the Time
Between Bursts (s) field. The default delay is set to 10 ms.
After every sample read by the GUI, the Captured Data graph, the
angle, the radius, and the temperature values are updated.
When the EVAL-ADA4570SDZ operates in burst read mode, the
GUI samples a burst of samples, defined in the Samples to
Capture field, without updating the display. After the burst read has
finished, the GUI updates the display values with the collected data.
By default, the sampling frequency is set to 100,000 SPS.

User Guide EVAL-ADA4570
EVALUATION BOARD SOFTWARE
analog.com Rev. 0 | 11 of 17
Electrical Angle
The electrical angle plot displays the calculated arctan2 (angle)
value in a visual format, as shown in Figure 21.
Figure 21. Electrical Angle Plot
Sine and Cosine Plot
The sine and cosine plot, shown in Figure 22, displays VSIN vs.
VCOS (differential signals) from the ADA4570. The radius calculat-
ed from VSIN and VCOS is indicated in the Radius indicator shown
in Figure 18.
Figure 22. Sine and Cosine Plot
Offset Calibration
An offset calibration may be required to maximize the accuracy of
the ADA4570. See the ADA4570 data sheet for full details on the
offset voltage ranges for the outputs.
The EVAL-ADA4570 GUI uses a maximum and a minimum output
value to calculate the VSIN channel and the VCOS channel offsets.
The GUI requires the user to perform at least one full electric angle
rotation to determine a meaningful offset value.
Click Apply Offset to enable the offset calibration. When the
calibration is applied, the light emitting diode (LED) turns bright
green (see Figure 23).
Figure 23. Offset Calibration Pane
Temperature Calibration
The EVAL-ADA4570SDZ GUI also allows the user to perform a
single point temperature calibration for the temperature channel
indicated in Figure 24.
Figure 24. Temperature Calibration Pane
Click the Cal. symbol to open a window to enter a reference tem-
perature. The GUI uses this temperature to calculate the offset and
applies it to the temperature measurement when the Cal Active
LED is enabled by the user (see Figure 25).
Figure 25. Temperature Calibration Activated

User Guide EVAL-ADA4570
EVALUATION BOARD SOFTWARE
analog.com Rev. 0 | 12 of 17
Data Logging
The EVAL-ADA4570SDZ GUI provides functionality that allows the
user to store the collected data into a file for post processing and
analysis.
Click the File symbol, shown in Figure 26, and a window opens that
allows the user to select the storage path and define a file name.
A default file name is provided consisting of the device name, date,
and time. The file format is predefined as .tdms.
The .tdms file is a binary format useful for storing large sets of
data. The data file is automatically defragmented at the end of a
capture sequence as indicated by the Defragmentation Progress
(%) indicator shown in Figure 26.
Figure 26. Data Log
The data logging function is immediately activated after confirming
the log file details. The logging can be stopped by clicking on the
File symbol again. To view the log file, click the Eye symbol to open
a window that points to the location where the log file is stored. The
user can then select the log file of interest by double-clicking on the
file to open it in Excel. Note that users must install an add-in for
Excel to view the .tdms file. The .tdms Excel add-in is available as a
free download from the National Instrument website.

User Guide EVAL-ADA4570
EVALUATION BOARD SCHEMATICS AND SILKSCREEN
analog.com Rev. 0 | 13 of 17
Figure 27. ADA4570 with AD7266

User Guide EVAL-ADA4570
EVALUATION BOARD SCHEMATICS AND SILKSCREEN
analog.com Rev. 0 | 14 of 17
Figure 28. SDP Connector and Voltage Supply

User Guide EVAL-ADA4570
EVALUATION BOARD SCHEMATICS AND SILKSCREEN
analog.com Rev. 0 | 15 of 17
Figure 29. EVAL-ADA4570SDZ Silkscreen

User Guide EVAL-ADA4570
ORDERING INFORMATION
analog.com Rev. 0 | 16 of 17
EVALUATION BOARD BILL OF MATERIALS
Table 4. Bill of Materials
Reference Designator Description Manufacturer Part Number
C1, C9, C19, C22, C23, C25, C30 0.1 μF capacitors, 16 V, 10%, X7R, 0603 Kemet C0603C104K4RAC
C2, C20, C29 10 μF capacitors, 6.3 V, 20%, 0805 Taiyo Yuden JMK212BJ106MG-T
C3, C4 5600 pF capacitors, 50 V, 10%, X7R, 0603 Samsung CL10B562KB8NNNC
C5, C6, C7, C8 0.01 μF capacitors, 50 V, 10%, X8R, 0603 TDK CGA3E2X8R1H103K080AA
C10, C21 0.47 μF capacitors, 25 V, 10%, X8R, 0603 Murata GCG188R91E474K
C11, C18 1 μF capacitors, 16 V, 10%, X7R, 0603 AVX 0603YC105KAT2A
C14 0.022 μF capacitor, 25 V, 10%, X7R, 0402 Samsung CL05B223KA5NNNC
C24, C26 10 μF capacitors, 6.3 V, 20%, X5R, 0603 Murata GRM188R60J106ME47D
C28 10 μF capacitor, 16 V, 10%, X5R, 0805 Murata GRM21BR61C106KE15L
D2 Schottky diode, DO41A Vishay 1N5818-E3
P3 SDP connector HRS FX8-120S-SV(21)
R3, R4, R6 100 kΩ resistors, 1%, 1/10 W, 0603 Vishay CRCW0603100KFKEA
R7 to R10, R15, R20, R29, R45 0 Ω resistors, 1/10 W, 0603 Yageo RC0603JR-070RL
R11 to R14, R24 200 kΩ resistors, 1%, 1/10 W, 0603 Panasonic ERJ-3EKF2003V
R30, R31, R36 to R38 0 Ω resistors, 1/16 W, 0402 Stackpole Electronics, Inc. RMCF0402ZT0R00
R42 56 kΩ resistor, 1%, 1/10 W, 0603 Panasonic ERJ-3EKF5602V
R43 150 kΩ resistor, 1%, 1/10 W, 0603 Panasonic ERJ-3EKF1503V
R44, R47, R48, R51 to R53 10 kΩ resistors, 1%, 1/10 W, 0603 Panasonic ERJ-3EKF1002V
U1 Differential/single-ended input, dual, simultaneous
sampling, 2 MSPS, 12-bit, 3-channel SAR ADC
Analog Devices AD7266BSUZ
U2 I2C EEPROM, 32 kb, 8-lead SOIC Microchip Technology 24LC32A/SN
U3 20 V, 500 mA, low noise, CMOS low dropout (LDO)
regulator
Analog Devices ADP7104ARDZ-R7
U6 Integrated AMR angle sensor and signal conditioner
with differential outputs
Analog Devices ADA4570BRZ
P1 8-pin connector (2.54 mm pitch), do not install (DNI) Samtec TSW-108-08-G-S
P2 10-pin connector (2.54 mm pitch), DNI Samtec TSW-110-18-T-S
R1 10 kΩ resistor, 1%, 1/10 W, 0603, DNI Panasonic ERJ-3EKF1002V
R2, R5 100 kΩ resistors, 1%, 1/10 W, 0603, DNI Vishay CRCW0603100KFKEA
R25 to R27, R32, R39, R46, R49, R50 0 Ω resistors, 1/10 W, 0603, DNI Yageo RC0603JR-070RL
R28, R33 to R35, R40, R41 0 Ω resistors, 1/16 W, 0402, DNI Stackpole Electronics, Inc. RMCF0402ZT0R00

User Guide EVAL-ADA4570
ORDERING INFORMATION
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary
protection circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of
functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and
conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the
Evaluation Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you
(“Customer”) and Analog Devices, Inc. (“ADI”), with its principal place of business at Subject to the terms and conditions of the Agreement, ADI hereby grants to Customer a free, limited, personal,
temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and agrees that the Evaluation
Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted is expressly made
subject to the following additional limitations: Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board; and (ii) permit any Third Party to access
the Evaluation Board. As used herein, the term “Third Party” includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is NOT sold
to Customer; all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all be
considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation
of use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble,
decompile or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including
but not limited to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but
not limited to the RoHS Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board
at that time. LIMITATION OF LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS” AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY
KIND WITH RESPECT TO IT. ADI SPECIFICALLY DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE
EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF
INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING
FROM CUSTOMER’S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL.
ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or
indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States federal laws and regulations relating to exports. GOVERNING LAW. This Agreement
shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts (excluding conflict of law rules). Any legal action regarding this Agreement will
be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits to the personal jurisdiction and venue of such courts. The United Nations
Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
©2021 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
One Analog Way, Wilmington, MA 01887-2356, U.S.A.
Rev. 0 | 17 of 17
NOTES
I2C refers to a communications protocol originally developed by Philips Semiconductors (now NXP Semiconductors).
