Anova F1030R User manual

Assembly Instructions
Component parts:
Assembly:
1
Hardware Needed: All hardware is stainless steel.
Contact Us:
800.231.1327
[email protected]
1. Inspect the shipping container contents for damaged or missing components.
2. Lay all parts on a so work surface or on the shipping packaging to prevent damage to nish.
NOTE: Before assembly, it is recommended that a light oil or petroleum jelly be applied to screw threads.
Tools Needed:
• 3/4” Hex Wrench
• 3/4 Hex Socket with Ratchet
• Retractable Measuring Tape
• Pencil
F1030R - 2-1/2’ Recycled Plastic Flat Bench, Portable
F1030T - 2-1/2’ Thermory Flat Bench, Portable
2-1/2’ Flat Bench, Portable
Cross Brace (2) Seat (1) Legs (2)
Hex Head Bolt
5/16” x 1-1/4” (6)
Nylock Nut
5/16”-18
316 (8)
Flat Washer
5/16”(16)
Rubber Foot (4)
Hex Head Bolt
5/16” x 3” (2)

Assembly Instructions
2
2-1/2’ Flat Bench, Portable
3. Locate the leg and two rubber feet and place
them as shown.
4. Insert the two rubber feet into the bottom of
the leg. Use a rubber mallet if necessary.
5. Repeat steps 3 and 4 with the remaining leg
and rubber feet.
6. Mount a leg to the bench seat by inserting two
1-1/4” hex head bolts and two at washers
through the mounting holes of the bench seat
and the leg. Place a washer and nylock nut on
each bolt and tighten nger tight.
Repeat this step to attach the remaining leg.
3
4
6a
6b
6c

Assembly Instructions
3
• Furniture must not be used other than for its intended purpose and should be inspected regularly for loose,
missing, or broken hardware, and general instability
• Furniture that is damaged or appears to be unstable must be removed from service and repaired or replaced
• Repairs must be made using only factory authorized parts and methods.
WARNING
• Do not drag the assembled unit across any surface.
• This product requires only periodic cleaning with a sponge and a solution of mild detergent and water to remove
surface dirt. Do not clean with a solvent or petroleum based products.
CARE AND
MAINTENANCE
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
05/12/2023 Manufactured in the U.S.
2-1/2’ Flat Bench, Portable
Copyright 2023 Anova®
7. Mount a cross brace to a leg by inserting one
3” hex head bolt and a at washer through the
mounting holes. Place a at washer and nylock
nut on the end of the bolt and tighten nger
tight.
Repeat this step to mount the remaining cross
braces on the other leg.
a. Align the cross brace with the mounting
hole on the bench. Insert one 1-1/4” hex
head bolt and a at washer through the
mounting hole. Place a at washer and
nylock nut on the end of the bolt and
tighten nger tight.
8. Turn the bench upright and move it to desired
location.
7a
7b
7c
Replacement Parts
Bench
Leg
Cross
Brace
