TOOLS NEEDED:
• 18 Volt (or higher) Drill
• T30 Torx Bit
Assembly Instructions
Recycled
RCPTC4 - Recycled Plastic 4' Wide Plank Bench
BENCH COMPONENTS: ASSEMBLY HARDWARE:
(2) 2" X 6" Edge Planks (4) 2" X 6" Inner Planks (2) Bench Supports
ASSEMBLY:
Inspect the shipping container contents for damage and to
determine that all components and hardware are present.
1.
2. Lay all parts on a so work surface or on the shipping
packaging to prevent damage to nish.
3. Locate one of the 2” x 6” inner planks and position the plank over
the innermost sets of predrilled holes in the bench supports. Make
sure the clearance holes in the plank align with the pilot holes in the
bench supports. Using the 18 volt drill and the T30 Torx bit, drive
one of the 1/4" X 3" washer head screws through the clearance hole
at one end of the plank and into the corresponding pilot hole in the
bench support until tight.
Align one clearance hole in the other end of the plank with the
appropriate pilot hole in the other bench support and install a
washer head screw in the same manner.
Install screws into the other two clearance holes in the plank in the
same manner.
4. Locate one of the edge planks and align the clearance holes in the
plank with the uppermost pairs of pilot holes in the bench supports.
Be sure to align the plank so that the pilot holes are closer to the
lower edge of the plank. Use the 18 volt drill and the Torx T30 bit to
drive four screws through the clearance holes into the pilot holes.
5. Locate the other edge plank and align the clearance holes in the
plank with the outermost pair of pilot holes in the bench support and
install four screws. Be sure to align the plank so that the pilot holes
are closer to the inner edge of the plank.
1
Recycled Plastic 4' Wide Plank Bench
1 1/2" between holes 4 1/2" between holes
(24) 1/4" X 3" Torx
Washer Head Screw
1/4" X 3" Torx Washer
Head Screw
2" X 6"Inner Plank
The assembly is a two-person operation
Bench Support
Orient the edge
planks with screws
toward the inside
of the bench

2
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
Copyright 2019 ANOVA® Manufactured in the U.S.10/25/2018
6. Attach the rest of the inner planks in the same manner, starting from
the top working down.
7. Move bench to desired location.
A A B B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 1
DRAWN
CHECKED
QA
MFG
APPROVED
dmetz 1/24/2018
DWG NO
TITLE
SIZE
D
SCALE
REV
0.12 : 1
9.66"
26.00"
 .50"
9.66"
28.00"
 .50"
FOOT MOUNT
Assembly and Replacement Parts
2" X 6" Edge Plank
2" X 6" Inner Plank
Bench Support
Start from the top and work down.
