Anova D1121 User manual

anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
• 1/2" Open-end or box-end wrench
• Ratchet with 1/2" socket
• Level
• Rubber Mallet or Hammer
Assembly Instructions
D1121- Octagonal Perforated Steel Table, Portable Frame
TABLE COMPONENTS:
Assembly Hardware: All hardware is stainless steel; extra hardware may be included
(4) 5/16"X 2.25" Long
Hex Head Bolts
(20) 5/16"x 1 .25"
Hex Head Bolts
(24) 5/16" Flanged
Hex Nut
(48) 5/16"
Washers
Assembly:
Inspect the shipping container contents for damage and to determine that all components and hardware are present.1.
2. Assemble the table over shipping packaging or padded work area to avoid scratching the product.
NOTE: Before assembling the nuts to the bolts, it is recommended that a light oil or petroleum jelly be applied to the screw threads.
1
The assembly is a two-person operation.
(8) Plastic Plugs
Table Top (4) Seats (4) Legs (1) Cross Brace

Copyright 2019 ANOVA® Made in USA. 2
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
6/20/2019
Use a Rubber Mallet or Hammer to seat the Plastisol Plugs into the holes
on the bottom of each leg
Position a Seat upside-down next to one of the Legs as shown.
The leg brackets attach to the outside of each of the seat frame
cross-members. Put a Washer on one of the 1.25” long Bolts
and insert the Bolt through the leg bracket and seat frame
cross-member with the bolt head toward the outside of the
Seat. Install a Washer and Nut to the Bolt and hand tighten,
leaving the Nut nger-tight. Repeat this step for each of the
three remaining mounting holes in that Seat. Install the three
remaining Seats in the same manner.
Turn the table right side up and tighten the table frame hardware while
checking with a Level; minor adjustments can be made while tightening
the hardware to make the Tabletop level.
5.
6.
7.
Tighten the hardware on each of the seat frames
while checking the Seat with a Level; minor
adjustments can be made while tightening the
hardware to make the Seat level.
8.
4. Aer all the Legs are attached (only two are shown Plugs
here for clarity), install the Cross Brace. Put a
Washer on one of the 2.25” long Bolts and insert
the Bolt through the Leg and Cross Brace with
the bolt head toward the outside of the Tabletop.
Install a Washer and Nut to the Bolt and hand
tighten, leaving the Nut nger-tight. Repeat this
step for each of the three remaining Legs
. Place one of the Table Legs next to the tabletop frame
support as shown. When viewing down the frame
support from the outside of the table, the Leg should go
on the right side of the frame support. Put a Washer on
one of the 1.25” long Bolts and insert the Bolt through
the Leg and frame support with the bolt head toward
the outside of the Tabletop. Install a Washer and Nut to
the Bolt and hand tighten, leaving the Nut nger-tight.
Repeat this step for each of the three remaining Legs.
3.
Retighten all hardware two weeks aer initial assembly.9.
