Argos Beech Effect TV Bench 609/0162 User manual

Simple Assembly Instructions - Please keep for future reference
IMPORTANT
1. Read these instructions carefully and
familiarise yourself with the procedure
before assembling the unit.
2. Check that you have all the component
parts following the list on the back
cover and familiarise yourself with
each part before proceeding.
3. Take all the fittings out of the plastic bag
and separate them into their groups.
4. Ensure you have enough space to lay out
all the parts before assembly.
Beech Effect TV Bench
Components
5. To avoid scratching it is recommended
that you assemble the unit on a soft
level surface.
Fittings
B
G
8-06
E
D
C
A
B6 x Dowel
H8 x Plastic Plug
D4 x Screw
C12 x Screw
1 x Bottom Panel
4 x Foot
1 x Left Side Panel
1 x Right Side Panel
1 x Shelf
1 x Table Top
F1 x Support
E4 x Locking Nuts
A4 x Locking Pin

Assembly Instructions Assembly Instructions
Stage 2 – Fitting the Bottom PanelStage 1 – Fitting the Shelf
fig. 3
fig. 4
fig. 5
fig. 2
2. Use Screws Cto fix the Right
Side Panel D and Left Side
Panel E onto the Support F
and Shelf C.
See fig. 2.
NOTE: It would be useful to ask
someone to help you at this
stage.
NOTE: It would be useful to ask
someone to help you at this
stage.
1. Insert Dowels B into the Shelf C.
See fig. 1.
3. Insert Dowels B into the unit.
See fig. 3.
1. Use Screws Cto fix the Bottom
Panel B onto the unit.
See fig. 4.
2. Use Screws Dto fix the Feet
Gonto the unit.
See fig. 5.
B
B
C
D
C
C
CF
C
E
D
fig. 1
B
B
C
B
G

Assembly Instructions Assembly Instructions
Stage 4 – Finishing the UnitStage 3 – Fitting the Table Top
2. Carefully place the unit in the
desired location.
See fig. 10.
1. Use Plastic Plugs H to cover the
Screw Heads.
See fig. 9.
fig. 8
fig. 10
fig. 9
NOTE: It would be useful to ask
someone to help you at this
stage.
NOTE: It would be useful to ask
someone to help you at this
stage.
1. Screw in Locking Pins A into the
Table Top A.
See fig. 6.
2. Carefully locate the Table Top A
onto the unit.
See fig. 7.
3. Use Locking Nuts Eto fix the
Table Top A onto the unit.
See fig. 8.
H
H
Care and Maintenance
Safety
To avoid any risk of suffocation to animals or children dispose of the plastic
bags immediately.
Fitting
From time to time please ensure there are no loose screws on the product.
Cleaning
As with all surfaces clean with a damp cloth and mild detergent, do not use bleach
or abrasive products.
fig. 6 A
A
fig. 7
A
E
A
