Argos White Tidy Cupboard 830/1732 User manual

White Tidy Cupboard
830/1732
17cm
17.5cm
63.5cm
Issue 3 - 12/07/12

Components - Panels
Please check you have all the panels listed below
123
4
7
56
Top Panel x 1 Bottom Panel x 1 Fixed Shelf x 1
Adjustable Shelf x 2 Lower Door x 1
Upper Door x 1
Left Side Panel x 1 8Right Side Panel x 1
10 Paper Holder x 1
9Back Panel x 1
If you have damaged or missing components,
call the Customer Helpline:08456 400800
2

Components - Fittings
Please check you have all the fittings listed below
Note:The quantities below are the correct amount to complete the assembly .In some cases more
fittings may be supplied than are required.
ABC
D
Door Knob x 1
G
J
E
H
F
30mm Screw x 8 Screw Cap x 8
25mm Screw x 1
12mm Screw x 4
I
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Phillips screwdriver
(medium & large)
3
Hinge x 4
Plastic Support x 8 Magnetic Catch x 2
Catch Plate x 2
Wooden Dowel x 4
Ruler - Use this ruler to help correctly identify the screws
K
10mm Screw x 18

B
H
H
H
F
J
J
J
J
J
Assembly Instructions
Step 1
Step 2
Assembling the fixed shelf
Assembling bottom panel
Assembling back panel
NOTE:It would be useful to ask
someone to help you at this stage.
a:Attach the magnetic catch to
the underside of the fixed shelf
using 12mm screws
Insert the wooden dowels into
the holes of fixed shelf.
b:Use the wooden dowel to fit the
fixed shelf to the side panels
and .The shelf should attach to
the upper set of the holes.This may
be a tight fit.
4
a: b:
Step 3
Lay the cupboard on its back and
use 30mm screws to attach the
bottom panel .
Slide the back panel into the
grooves of the side panels
and bottom panel .
2
9
2
2
9
7
7
8
8
2
3
7
7
8
8
3
3
B
B
F
F
7

Assembly Instructions
Step 5
Step 6
Step 4
5
Assembling top panel
Assembling doors
Assembling abjustable shelf
a:Attach magnetic catch to the
underside of the top panel
using 12mm screws
b:Use 30mm screws to fix the
top panel to the unit.
a:Attach catch plates to the upper
door and lower door using
10mm screws .Also attach the
knob to the lower door with
25mm screw
b:Attach door hinges to the upper
and lower door and the main body
of the cupboard with 10mm screws
Insert the shelf supports into the
holes in the side panels,and put
the abjustable shelves onto the
shelf support.
Insert the paper holder
To finish the assembly of the unit,
insert the screw caps over the
screw holes on the outside.
B
B
HH
G
G
G
F
I
I
I
E
E
E
D
D
C
C
A
A
K
K
KKK
B
F
a:
a: b:
b:
F
NOTE:If you have damaged or missing components,
call the Customer Helpline:08456 400800
Argos LTD,489-499
Central Milton Keynes, MK9 2NW
5
1
4
10 4
4
1
1
5
6
6
6
5
NOTE: Please make sure the
unit is secure before use
The assembly is now complete
10
10
H
