ART+SOUND PWR12 User manual

EN
Dear Customer, Congratulations on the purchase of your
loudspeaker(s). Please read these instructions carefully and
keep them tor future reference.
PWR12
Professional ABS Molded
Loudspeaker
Introduction:
Congratulations on your purchase of the PWR12
multi-function, engineered and manufactured by us.
The PWR12 includes a high-output compression
driver, and 12” woofer that produces an even and
smooth studio quality sound in a sound rein-force-
ment speaker. Our design goal was to build a speak-
er with accurate playback, smooth dispersion of mid
and high frequencies, and an ergonomic design for
easy transport and setup. The result is a sound rein-
forcement system dynamic enough to use at home,
in the studio, parties or in a home theater.
Features:
1. 2-way Active Speaker.
2. Steel basket woofer
3. High wattage powered amplifier
4. Auxiliary line input
5. High Temperature Voice Coil
6. Bluetooth Stereo Pairing
7. DSP Processer
8. USB Charging
Step1: Press and releasethe PAIR button on o ne
speaker only. Select PWR12 on your device to pairwith
your audio source device.
Step2: Press and releasethe LINK button on each
speaker to link two PWR12 speakers.
Note: Please onl y startplaying audio once all
pairing and linking are successful.
PWR12
220-240V T2.5AL 250V
Important Safety Instructions:
1. Read these instructions. Keep these instruc-
tions.
2. Heed all warnings.
3. Follow all instructions.
4. Do not use this apparatus near water.
5. Clean only with dry cloth.
6. Do not block any ventilation openings.
7. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other appa-
ratus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the pro-
vided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service person-
nel. Servicing is required when the apparatus
has been damaged in any way, such as pow-
er-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the ap-
paratus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has
been dropped.
ׁFailing to adhere to the cautions above will
void the manufacturer warranty!
Functions [fig 1]:
1. USB Port
2. Bluetooth Stereo Function.
3. Mic level: Control the signal for Mic input when
using the Mic input.
4. Line Level: Control the output volume for Line
Level Input.
5. Aux level: Control the signal for Aux input when
using the Aux input.
6. Sub Level: Adjust the overall level available from
the subwoofer.
7. Main Level: Overall level adjustment. The sub
level is also adjusted in accordance with the
preset level of the Sub Level controller.
8. Mic/Inst Input: These balanced inputs accept
a standard XLR and a 1/4” Jack phone plug.
A board range of signals from microphones,
fig1
OPERATIONS MANUAL
1 - ArtSound

2 - ArtSound
PWR12
audio mixing consoles and electronic musical
instruments may be connected here.
9. Line Input left: Use XLR and a 1/4” jack connec-
tor balanced or unbalance.
10. Line Input right: Use XLR and a 1/4” jack con-
nector balanced or unbalance.
11. Aux Input: Use RCA and 3.5mm connector bal-
anced or unbalance.
12. Mix Out: Use XLR connector balanced or unbal-
anced.
13. INDICATOR LEDS
14. ON: Lights up once the system is properly con-
nected to the power mains and switched on.
SIGNAL: Lights up as soon as an audio signal
is present. The signal acquisition is performed
before the MAIN LEVEL controller.
15. LIMIT: Lights up if the loudspeaker system is
operating in the clipping range. A short flash of
the LED is not critical. To protect the system,
an excessive signal level is gently turned down
by the built-in limiter. If the limiter LED lights
up permanently or for longer periods, reduce
the volume level. Failure to do so may result in
a distorted sound and damage to the speaker
system.
16. Power Supply Input Connector: Use with power
cord.
17. Power Supply Switch.
ׁWarning: Make sure speaker is off and all
LEVEL controls are down (counterclockwise)
before every use.
Connections:
1. Connect the output from your signal source
(mixing console, microphone, preamp, or other
mic- or line-level source) directly to the INPUT
connector on the back of the speaker. It ac-
cepts balanced line-level signals from mixers,
preamplifiers, CD players, tape decks, etc., and
accepts direct connections from dynamic mi-
crophones through the MIC input.
2. There is also an XLR Output connector labeled
LINE OUT. This allows you to connect more than
one PWR12 to the output of your sound source.
Simply plug an XLR cable from the Line Out
connector of one speaker to the input connector
of another speaker, and so on, daisy-chaining
multiple speakers.
3. Turn on your signal source. (Make sure volume
is turned down) Turn on PWR12. Start signal
source and adjust volume controls on the signal
source and PWR12 speaker.
Bluetooth Pairing instructions:
1. Press and release the PAIR button on one
speaker only.
2. While pairing light is flashing and the PWR12
name should appear on your pairing device.
3. Click on PWR12 name on your pairing device to
complete pairing to the PWR12.
Bluetooth Stereo Function Usage:
1. Press and release PAIR button on one speaker
only, this PWR12 will be left channel.
2. Select PWR12 on your device.
3. Press and release STEREO LINK button on each
speaker, both speakers should be PWR12 and
the other PWR12 will be right channel. Note:
Please only start playing audio once all pairing
and linking are successful.
4. Press and hold STEREO LINK button for 3 sec-
onds to exit the connection.
Note: Only exit after connected successfully.
5. LEDs flash while pairing or linking. LEDs light
solid when paired or linked.
6. To reset pairing and linking, press and hold ei-
ther button for 2 seconds.
Note: Initial pairing or linking may require 1
minute.
Technical specifications
• range: <800 m2
• system: 2-way with active filter
• woofer: 12” polypropylene cone
• satellites (tweeter): 8 x 3” neodymium full range
• equaliser: low pitched tones
• amp power RMS: class D, 500 W
• amp power max.: class D, 1500 W
• sensitivity: 122dB/130dB (peak)
• frequency range: 50Hz-20KHz
• line input: XLR or 1/4» TRS
• Aux input: RCA or 1/8» TRS
• instrument input: ¼” TRS
• sources: stereo Bluetooth, USB (to be charged)
• weight/piece: 17.5 (sub) + 3.25 (sat) kg
• housing: wood + ABS plastic
• colour: black
• Satellite dim. (hxwxd): 1,620 x 80 x 105 mm
• subwoofer dim. (hxwxd): 435 x 370 x 440 mm
• accessories: carrying pouch
Warranty conditions
2 year warranty from the date of manufacture.
The warranty is limited to the repair of replacement
of the detective material insofar as this defect is a
resu Il of normal use and the device has not been
damaged. Artsound is not responsible lor any other
casts that ensue as a result of the defect (e.g. trans-
port). For details, please consult our general terms
and conditions of sale.
