ASCOM d63 User manual

TD 93119EN
28 June 2016 / Ver. PA5
User Manual
Ascom d63 DECT Handset
86
After the old handset has been in the charger, the new handset needs to be placed in the
charger regardless if the replacement was successful or not. Failing to do so may result in
malfunction that requires the new handset to be returned for service.
ABC DEF
GHI JKL
PQRS TUV WXYZ
MNO
1
2
New New Old
New
4, 8 5 67
ABC DEF
GHI JKL
PQRS TUV WXYZ
MNO
ABC DEF
GHI JKL
PQRS TUV WXYZ
MNO
ABC DEF
GHI JKL
PQRS TUV WXYZ
MNO
3
Figure 17. Easy Replacement via DC4 Advanced Desktop Charger.
1On the new handset, press and hold
Note: Do not release until you are instructed to do so.
2Put the new handset in the charger.
3When the text "Start phone replacement?" is displayed, release .
Press "Yes" (left soft key).
The text "Follow the instructions. Each step can take several minutes." appears in the
display. Press "OK"(left soft key).
4, 5 When the text "Please insert old phone in charger" is displayed, replace the new
handset with the old handset. The handset can either be switched on or off.
NOTE: The left charging slot in the CR3 Charging Rack has to be used for both
handsets.
The handset is restarted and after a few seconds, the text "Saving settings. Do not
remove phone from charger" appears. The charger LED changes to slow orange
flashing. It may take several minutes.
IMPORTANT: If the old handset cannot communicate with the charger, put the new
handset in the charger to restore its settings (that is, the handset’s IPDI). If this step
is not performed, the new handset must be sent for service. The old handset’s
settings might be transferred to the new handset by using WinPDM. See the
Configuration Manual for the handset (TD number: See 17 Related Documents on
page 91).
6, 7 When the text "Please insert new phone in charger" is displayed, replace the old
handset with the new handset. The text "Restoring settings" is displayed.
IMPORTANT: Do not remove the handset while the text "Restoring settings" is
displayed.

TD 93119EN
28 June 2016 / Ver. PA5
User Manual
Ascom d63 DECT Handset
87
LED Indications during Easy Replacement
The following table shows the LED indications that are used for the charger during the easy
replacement procedure.
LED indication Description
Orange, flashing (1 000 ms on, 1 000
ms off)
File transfer during Easy Replacement.
Orange, flashing (100 ms on, 800 ms
off)
“Change phone” indication during Easy
Replacement.
Red, flashing (100 ms on, 800 ms off) Error indication during Easy Replacement. Put back
old handset in charger.
Red, flashing (900 ms on, 100 ms off) Error during Easy Replacement. Service needed for
both handsets.
See also Figure 15. Update Completed while in Charger on page 79.
8When the text "Phone successfully replaced. Please remove phone to restart."
appears in the display, remove the handset from the charger. The handset is
automatically restarted.

TD 93119EN
28 June 2016 / Ver. PA5
User Manual
Ascom d63 DECT Handset
88
15.3 Attach the Hinge-type Clip
Attach the hinge-type belt clip as described in the illustration below.
Figure 18. Screw the hinge-type clip into position.
15.4 Attach the Swivel-type Clip
Attach the swivel-type belt clip as described in the illustration below.
Figure 19. Screw the swivel-type clip into position.
15.5 Attach Cover for No Clip
Attach the enclosed cover as described in the illustration below when no clip is to be used
