Assa Abloy shine User manual

User Guide
SHINE
The functions and design of this product can be changed without
prior notice for quality improvement.

2
x
x
Dry
Cloth
Do not attempt to
disassemble the unit
by yourself. That can
cause an electronic shock
and product damage.
Do not install the product in
the outdoor environment.
Be careful not to let any
unauthorized users discover
your PIN Code.
Please keep your PIN Code safe.
Make sure the door is securely
locked whenever you leave
your house, especially in the
manual lock mode.
Do not force with a tool.
Keep foreign materials away
from the Card Key Sensor to
maintain it cleanly and do not
use it with wet ngers.
If the sheet is already papered,
the product's adhesive strength
lessens Please remove the sheet
completely before installing.
When a double-opening door
l ock is installed, one of the doors
must be closed.
Do not spray water directly to
the product or wipe it with
chemical substances such as
benzene, thinner, or alcohol
when cleanig the product.
Safety Feature

3
Product Features
Safety Mode
Safety Mode can be used for professional and high secure
management.
Magic Mirror
A magic Mirror function is applied, which the keypad number appears on the
Mirror as soon as a user touches the product. The user can chech the rear
through the Magic Mirror, so that security can be enhanced.
Safe Thumb-turn
Only if a user pushes the two safe buttons simultaneously axed to the thumb-turn
knob, the user can turn the thumb-turn knob. Its security is improved compared to
normal knob.
Modern & Thin design
It is the Solid and thin design using digital keypad on a solid base.
High Temperature Alarm
When there’s re, it detects the temperature of the inside.
It not only goes o an alarm but also releases the lock status automatically.

4
The durability depends on the battery life and the frequency of use.
The color of the product may change if it is under the direct light for a long time, and it is not a defect.
Optional Accessory (purchase separately)
Specications
Remote Control
Remote Control Module
Parts
Front Body 14(D) x 72.8(W) x 186(H)
48.8(D) x 77.5(W) x 190.5(H)
4EA 1.5 AA alkaline batteries
(Operating voltage: 4.5 ~ 6V)
Operating temperature :
Last up to 1 year
(10 times used a day)
Back Body
Battery
Specications Remarks
Basic Contents
Magnet for
a single door
Extension
type deadbolt
10mm door
thickness gasket
Front Body Back Body
Screws
Card Keys (4EA)
User Guide
Installation Template
Components Overview

5
Specications
Front Body Back Body
Keypad
Lowbatt.
Card key
Reader
Emergency Power
Supply Terminal
Battery
Cover
Slot for Remote
Control module
(optional extra)
Manual
Thumb Turn
Safe Knob
Open/Close
Button
Registration
button
Dead Bolt

6
Registering User PIN Code
Registering Card Keys
Open Door with User PIN Code
Open Door with Card key
To Use Card Key
Contact Card Key.
To Use User PIN Code
Caution
How to Use
Press
(Registration) button
Press
(Registration) button
Enter User PIN Code
(4 to 12 digits)
Press
(Registration) button
Press
(Registration) button
Contact all the keys
you wish to register
on one by one
User PIN Code should be set Within 4 to 12 digits. [ ] and [ ] are not allowed.
Touch with palm
Enter User PIN Code
(4 to 12 digits)
Touch with palm or
Press button to end
Keep the door open while you register Card Key to prevent yourself from accidentally getting locked out.
The previously registered Card Key will automatically be deleted when the new Card Key is registered.
Please use the only provided RF Cards in the package for security.

7
To Close Door from Outside
To Close Door from Inside
Lock Door
Step Icon Description
Step Icon Description
Auto Lock status
Touch the keypad in the front body gently with your
palm to lock a door.
Manual Lock status
- Please check the deadbolt as it turns to standby mode and stop when closing a door.
- If the door is twisted, the auto-lock feature will not function properly. Please check before use.
The built-in Auto Lock sensor automatically locks
a door within 5 seconds after closing the door.
Turn the manual thumb turn to
unlock pressing buttons together.
Press open / Close button.
The built-in Auto Lock sensor automatically locks
a door within 5 seconds after closing the door.
(If an auto-lock magnetic is not installed, you cannot
enable the auto-lock feature.)
Manual Lock status
(The default setting)
Auto Lock status
How to Use

8
Set
Release
Outside Forced Lock Setting - PIN Code
Forced Lock
Inside Forced Lock Setting
Outside Forced Lock Setting - Card Key
- If compulsory external lock is setup, the door open/close button will not function.
The alarm will go o if one tries to open the door through the manual opening/closing unit.
- To open the door with the manual opening/closing unit under compulsory external lock setting,
one must completely turn the knob within one second. Or else, the door will lock itself again.
Set
Press the Registration button or,
Turn the manual thumb turn to pressing
buttons together.
Release
Press the Open / Close button
for 5 seconds.
Touch with palm
Enter User PIN Code
Enter button
for 3 sconds
Contact Card Key for 3 seconds until you hear 3 beeps.
How to Use

9
To Set Auto Locking Mode
To Set Manual Locking Mode * The default setting
Auto / Manual Locking Mode
Auto lock setting locks a door in 5 second after the door was closed.
Even after a door was locked by the Auto Lock function, please check again
if the door was completely locked.
Press (Registration)
button
Press (Registration)
button
Enter
button
Enter number and
on the keypad
Be careful not to leave the door open at manual lock mode.
MUTE
* The default setting : High
Volume Setting Feature
It enables you adjust the sound volume.
LOW
HIGH
,
,
,
How to Use
Press (Registration)
button
Press (Registration)
button
Enter
button
Enter number and
on the keypad
Press (Registration)
button
Press (Registration)
button
Enter
button

10
Open / Close Button Setting Feature
It enable you set the Open / Close button .
* The on/o of the function changes every time one sets the setting.
* When the system is set to o, the open/close button does not function.
Press
(Registration) button
Press
(Registration) button
Enter button Enter number and
on the keypad
How to Use

11
Safety Feature
Alarm Feature
The alarm sound continues for 30 minutes or until it is reset.
Break-in / Damage Alarm
High Temperature Alarm
Break-in : When someone tries to Break-in by opening a door when it is locked, the alarm will Sound.
When there’s re, it detects the temperature of the inside. It not only Sounds an alarm
but also releses the lock status automatically.
Even when the inside Forced Lock mode is set, the High Temperature Alarm releases
the lock status automatically.
Damage : When the front body was damaged due to forced separation or drilling, the alarm will Sound.

12
To Release 3-minute Lock
3-minute Lock Feature
Open Door with Fake PIN Code
If incorrect security codes or unregistered Card Keys are attempted
5 times in a row, it will lock out for about 3 minutes with the blinking LED.
This is an security measure to prevent your PIN Code being accidentally
exposed. It is only available for your family code PIN number and not
use with the visitor code.
Press the Open / Close button.
Method 1
Method 2
Method 3
Press the Back Body button.
Open with a thumb turn.
* 3-minute Lock mode won’t aect any alarm and is sustained even after the product is rebooted.
* Fake PIN code is not working right after 3-minute Lock mode is o, just for once. We should use User PIN Code,
Card key or opening the door from inside to unlock.
Method 1
Method 2
Touch with palm Touch with palmPress Any button Press PIN Code
Touch with palm Touch with palmPress PIN Code Press Any button
Safety Feature

13
Emergency Power
Emergency Power Supply for Discharged Batteries
Emergency Power Supply for Discharged Batteries
Expiry Period
The product uses four 1.5V Alkaline AA batteries. They may sustain 1 year if used 10 times a day.
(Users are advised to use authentic alkaline batteries.)
Low Battery Alarm
You must replace all 4 batteries for the following cases:
The Low Battery Lamp on the Front Body lights on
The alarm melody will sound (a nursery rhyme starting
with ting-a-ling melodies)
You may open a door when contacting the 9V battery.
The battery life vary depending on temperature, moisture levels,
Frequncy of use and the quality of the batteries.
Contact the
9V Alkaline battery
Open the emergency cover. Keep contacting the 9V
Alkaline battery onto the emergency power supply terminal.
Touch the keypad gently with your palm.
Enter each number of User PIN Code.
Touch with a palm
Enter User PIN Code
Touch with palm
or Enter button.
Touch the keypad gently with your palm or
Enter button to conrm.
Step Icon Description

14
Safety Mode
Safety Mode
Safety Mode can be used for professional and high secure management.
Normal Mode is enough for general use, because managing Safety Mode is more
complicated than Normal Mode.
User PIN CodeMaster PIN Code
New Master PIN Code
ONENEW
One Time User PIN Code
Registration Button
(Open Battery Cover)
Enter
Card Key
Registration Button
(Open Battery Cover)
Important
tMaster PIN Code ≠ User PIN Code ≠ One Time PIN Code.
tWhen Safety Mode, Fake PIN Code cannot be used.
tIt is impossible to change mode by using Card Key, User PIN Code and One Time PIN Code.
tWhen mode change from Safety Mode to Normal Mode.
- Most registration information(Card Key, User PIN Code, One Time PIN Code) is removed.
- Remote controller information is not removed.
≠≠
tWhen mode change from Normal Mode to Safety Mode.
- Most registration information(Card Key, User PIN Code) is removed.
tOne Time PIN Code doesn’t support setting of Outside Forced Lock
and Releasing Alarm.
t
t

15
Safety Mode
Normal Mode)
Change Master PIN Code (Old New)
One Time User PIN Code
t8IFOBMSFBEZ 4BGFUZ.PEF this process doesn’t work User Pin Code is removed after changing mode
Change Mode (Normal Mode 4BGFUZ.PEF
or or
/&8
$IBOHF.PEF4BGFUZ.PEF
t8IFOBMSFBEZ/PSNBM.PEFUIJTQSPDFTTEPFTOUXPSL
t$VSSFOU.BTUFS1*/$PEFJTchanged to User PIN Code
or
t8IFO/PSNBM.PEFUIJTQSPDFTTEPFTOUXPSL
Setting
oror
oror
or
ONE
To register User PIN Code / Card Key
3FHJTUFS1*/$PEF$BSE,FZ
or or

Manuel d'utilisation
SHINE
Le design et les fonctions de ce produit peuvent être modiées à tout moment
dans un souci d'amélioration

2
x
x
Dry
Cloth
N'essayez pas de démonter le
verrou, ceci peut entraîner un
court-circuit et endommager
le verrou
Ne pas installer
le verrou en extérieur
Gardez précieusement
votre code Vériez que le verrou soit bien fermé lorsque vous quittez la
pièce, particulièrement lorsque
le mode verrouillage
manuel est activé
N'utilisez pas d'outils inappropriés
qui pourraient endommager
le produit
Ne touchez pas le verrou avec
les doigts mouillés Si la porte en verre présente un adhésif, le retirer avant
installation du produit.
Dans le cas d’une installation
sur porte double, une des
2 portes doit pouvoir être xe
N'utilisez aucun solvant
tel que l'essence ou le benzène
sur le verrou car cela pourrait
endommager le circuit
électronique ou écailler la nition
Conseils de sécurité

3
Fonctionnalités
Mode AVANCE
Le Mode avancé doit être utilisé par une personne qualiée
Miroir magique
Une fonction miroir est achée, dès qu’un utilisateur touche le produit
pour faire apparaitre le clavier.
L’utilisateur peut alors voir derrière lui pour plus de sécurité.
Bouton sécurisé
L’utilisateur peut tourner le bouton uniquement en appuyant simultanément
de chaque côté.
La sécurité est augmentée par rapport à un simple bouton.
Design n et moderne
Ce produit ore un design n intégrant un clavier digital
Alarme de température élevée
En cas d’incendie, ce produit détecte les températures à l’intérieur de la pièce.

4
La durée des piles dépend de la fréquence d'utilisation
Options
Specifications
Contre boitier porte double
Badge
Parties
Boitier avant 14(D) x 72.8(W) x 186(H)
48.8(D) x 77.5(W) x 190.5(H)
4 piles 1,5v AA alcalines
(Tension de fonctionnement: 4,5-6V)
Selon la réglementation, les déchets des
produits DEEE (Déchets d'Equipements
Electriques et Electroniques) ne doivent
pas être mis au rebut avec les déchets ménagers.
En respectant le tri des piles et du matériel électronique,
vous contribuez à la protection de l'environnement
Températures de
fonctionnnement:
Jusqu'à 1 an (pour 10
utilisations par jour)
Boitier arrière
Piles
Caractéristiques
Tri des déchets
Remarques
Présentation des éléments
Aimant Pênes rallongés Cale verre 10mm Boitier avant Boitier arrière Vis
4 badges
Manuel
d'utilisation
Piles
Principaux éléments
