Assa Abloy EMTEK LISCIO Troubleshooting guide

ASSA ABLOY, the global leader in door opening solutions
Installation Guide & User Manual
Electronic Keypad Lever Lockset
with Bluetooth Programming

2
ITEM NO. DESCRIPTION QTY.
1Key 2
2Outside Trim Plate Assembly 1
3Latch for 2⁄” or 2¾” Backset 1
4Inside Trim Plate Assembly 1
4a Inside Chassis 1
4b Inside Trim Plate 1
4c #8-32 x ⁄" Flat Head Machine Screw 2
4d 9V Alkaline Battery 1
5#8-32 x 1½" Flat Head Machine Screw 2
6#8 x ¾" Wood Screw 5
7Strike Plate 1
8Plastic Extender 1
8
7
6
What’s in the Box
36
1
2
4
4d
5
4b
4c
4a
6

3
EN
Confirm Handing
HANDING OF DOOR IS ALWAYS DETERMINED FROM THE OUTSIDE
Hinge is on the left.
Door is Left Hand (LH)
Hinge is on the right.
Door is Right Hand (RH)
Hinge is on the right.
Door is Right Hand (RH)
Hinge is on the left.
Door is Left Hand (LH)
In-Swing Doors Out-Swing Doors
outsideoutside
Preparation
Fasten Strike Plate using
two #8 x ¾”Wood Screws
(item #6).
A
2 ⁄”or 2 ¾”
Backset
2 ⁄”Dia
Bore
⁄”Deep
2 ¼”
1“ 1”Diameter
Edge Bore
Door Prep
B D
Door Jamb Prep
1”Deep,
1”Diameter
Edge Bore
⁄”Deep
1-1/8"
2-3/4"
C
2 ¼”
1 ½”
Install Strike Plate

4
Use a Phillips head screwdriver to remove
screws (item #4c) shown below and detach
Inside Trim Plate from the Inside Chassis.
Fasten Latch using two
#8 x ¾” Wood Screws
(item #6).
Remove Screws from Inside Trim Plate
How to Install
!
Remove inside chassis from
trim plate before installing
the outside trim. Thumbturn
must be in neutral position.
Install Latch
LH RH
See Page 3 for Handing
Information.
1
2

EN
5
TOP
!
Once positioned,
outside trim plate
assembly requires
support.
This side
on top.
!
Fit Plastic Extender
through latch.
Feed wire harness
through the bore hole.
Install Outside Trim Plate Assembly
While holding Outside Trim
Plate Assembly, Press the Plastic
Extender (A) into end of Spindle
Shaft (B). The Shaft is properly
aligned when the marking
‘TOP’ can be seen from
an overhead view.
Position the Outside Trim Plate Assembly through the bore hole.
With the Outside Trim Plate Assembly ush to the door, REMOVE the Plastic Extender.
B
A3
STEP 2
STEP 3
STEP 1

6
Install Inside Chassis
Cam link must remain
in the correct position
during installation.
!
Conrm the position of Cam Link.
For Left Hand Locks:
Turn to left position.
For Right Hand Locks:
Turn to right position.
Feed the Wire Harness through Inside Chassis. 4
STEP 1
STEP 2

7
EN
Check alignment before
fully tightening screws.
!
Connect Wire Harness (A) and tuck Connectors as shown (B).
A B
Install Battery.
For optimal performance, always
use a good quality battery.
9V Battery
Fasten Inside Chassis using two
#8-32 x 1½”Flat Head Machine
Screw (item #5).
STEP 3
STEP 4
STEP 5
Optional - An additional #8
wood screw (provided) can
be installed to prevent the
interior trim from rotating

8
Inside
*Neutral position is required for installation and removal of the Inside Trim Plate Assembly.
!
Correct position for installation.
Thumbcam must be positioned
as shown (Neutral Position)*
!
5
User codes are located
on the inside trim plate
& back cover page.
Fasten Inside Trim Plate using two#8-32 x ⁄”
Flat Head Machine Screws (item #4c).
Install Inside Trim Plate
Screws (item #4c)

9
EN
Using the Lock
Once installed on door with the battery connected - your lock is ready for use.
Factory Default Setting
User & Master Codes are labeled on the inside trim plate and back cover page.
Entering User Codes
• Entering a correct, active user code (green LED x1 & beep x1) - unlocks
• Entering an incorrect or inactive code (red LED x2 & beep x2) - remains locked
• Three incorrect entries will result in lockout, signaled by 3 red LED ashes
& 3 short beeps, lockout lasts for 30 seconds.
To Restart Code Entry
Press and hold #1 button for three seconds (this works in entry or programming mode).
Key Access
Lock may also be unlocked and locked via keyed cylinder, each lock comes with two keys.
Passage & Privacy Mode
Use inside thumbturn.
Lever buttons
Keyed Cylinder
Thumbturn
Enable ON
Thumbturn
Enable OFF
Green
Amber
Lock access is regulated. A correct, active user code is required for
access. (Privacy Mode)
Lock access in NOT regulated. Always Unlocked (Passage Mode)
Thumbturn
Setting Setting Description Thumbturn Position LED Feedback
Your Lock is Ready to Use
How to Use
EN

10
Getting Started
Device App
App is free and available at App Store ( devices) or Play Store ( devices).
From devices (iPhone 4S, 5, 5S & 5C; iPad 3rd
generation and later running iOS 8 and later)
1. Go to App Store, select Search, enter “Emtek”,
select “Emtek Liscio Bluetooth”, select download
icon, when ready select Open. If upon opening
app you receive a screen that advises you that
your device is “Unsupported” you will not be able
to run app on this device.
From devices (OS 4.3 and later)
1. Go to Play Store, select Search icon, enter
“Emtek”, select “Emtek Liscio Bluetooth” app,
select Install, select Accept, when ready select
Open. If app does not appear then your device
is running OS prior to 4.3.
Once App is opened you will be on the
Welcome screen
1. Selecting Start you will move through the
setup wizard, lock will need to be nearby
for this.
2. Select Videos, Quick Reference, About or
Show Phone Info as needed
3. If you call Emtek for customer service please
have the information listed in the Show Phone
Info available.
A
B
C
