Assa Abloy Norton 6000 Series Installation manual

80-9360-1043-020 Rev 1 05/21
6000 Series Full Feature Low Energy Operator
Single Door Installation
Programming Instructions
Onboard or Wi-Fi Smart Device
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
These programming instructions guide setup of the 6000 operator installed
on a single door via the onboard LCD screen or a Wi-Fi smart device.
Pour la version francaise voir www.nortondoorcontrols.com.
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
WARNING

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
2
6000 Series Programming Instructions
Contents
Initial Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Onboard Programming Method .............................................................................. 5
Wi-Fi Programming Method .................................................................................. 9
Input Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Error Code Chart and Status Denitions......................................................................15
To Update 6000 Wi-Fi Inverter ...............................................................................16
Wiring Diagrams
Basic Single Door Using Factory Presets ......................................................................17
Hard Wired Push Button.....................................................................................18
Wave to Open...............................................................................................19
RF Standard .................................................................................................20
Fail Secure Electric Strike . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fail Safe Electric Strike .......................................................................................22
Electric Dogging Exit Device .................................................................................23
MKA2 x 24V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Electric Latch Retraction Powered Through 782N Controller .................................................25
Electric Latch Retraction Smoke Ventilation..................................................................26
Hard Wired Executive Function ..............................................................................27
RF Executive Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
433MHz Receiver User’s Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Vestibule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
585 Presence Detector on Standard Opening................................................................31
596 Presence Detector on Single Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Troubleshooting Guide......................................................................................33

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
3
6000 Series Programming Instructions
FCC:
Class B Equipment
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the use is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Warning:
Changes or modications to this device may void the user’s authority
to operate the equipment.
Industry Canada:
This Class A digital apparatus meets all requirements of the
Canadian Interference Causing Equipment Regulations.
Cet appareillage numérique de la classe A répond à toutes les
exigences de l’interférence canadienne causant des règlements
d’équipement.
Declaración de México:
La operación de este equipo está sujeta a las siguientes dos
condiciones: (1) es posible que este equipo o dispositivo no cause
interferencia perjudicial y (2) este equipo o dispositivo debe
aceptar cualquier interferencia, incluyendo la que pueda causar su
operación no deseada.

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
4
6000 Series Programming Instructions
1. With building power feed turned off, route
120VAC wiring through conduit holes in back
plate for concealed wiring or through the Union
Assembly knock-out for surface wiring and
connect conduit to Conduit Assembly.
2. Connect 120VAC power to terminal strip on top
of Conduit Assembly: HOT to “+”, NEUTRAL to
“-”, and GROUND to green ground screw.
(Figure 1)
NOTE: Union Assembly may need to be
removed for ease of access. Remove AND SAVE
(4) 8-32 x 5/16" Philips pan head screws.
3. Wire in any devices needing outputs, such as
electric strikes, mag locks, exit devices, door
open position output, etc to green terminals on
top of control board. (Figure 2)
4. Reinstall Union Assembly using (4) 8-32x5/16"
screws previously removed.
5. Turn on building power to unit.
6. Conrm ON/OFF/HO switch is in ON position
before proceeding to Setup. (Figure 3)
NOTE: On control board there should be one
solid red LED for POWER and one white LED
that flashes every 1.5 - 2 seconds for STATUS.
CLOSE button of Setup Buttons should be
flashing orange continuously.
NOTE: If red LED is flashing, refer to
Troubleshooting section of this manual or
contact Technical Product Support.
Initial Wiring
Conduit Hole
Terminal Strip
Figure 1
Figure 2
Figure 3
Shown in
ON Position
Door Setup
REQUIRED GO
Status LED
Input Terminals
WARNING: Door may begin to move immediately
when selector mode switch is changed. An open
union assembly door has potential to pinch fingers
if hand is not withdrawn quickly when adjusting
selector mode switch. There is also potential of
damaging or breaking door if door is open during
closing cycle of a pull side assembly.

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
5
6000 Series Programming Instructions: Onboard Method
Select arm type.
1. Select GO from the Door Setup REQUIRED menu
by pushing joystick to the right. (Figure 4)
2. Depending on your application, select PUSH or
PULL by moving joystick LEFT or RIGHT. (Figure 5)
Figure 6
Figure 5
Door Mode
PULL
Figure 4
Door Setup
REQUIRED GO
Setup Using LCD Screen
PULL:
6011 PULL 110°
Select operator model.
1. After setting arm type, push joystick UP to select
operator model.
2. Select specic operator model by pushing joystick
LEFT or RIGHT. (Figure 6)
Pull: (Figure 7)
6011 PULL 110 deg
6051 PULL 110 deg
PUSH: (Figure 8 or Figure 9)
6021 PUSH 110 deg
6031 PUSH 110 deg
6061 PUSH 85 deg
6061 PUSH 90 deg
6061 PUSH 95 deg
6061 PUSH 100 deg
6061 PUSH 105 deg
6061 PUSH 110 deg
6071 PUSH 85 deg
6071 PUSH 90 deg
6071 PUSH 95 deg
6071 PUSH 100 deg
6071 PUSH 105 deg
6071 PUSH 110 deg
3. Push joystick UP.
Follow these steps after operator has been
successfully installed and power has been turned on
(see Page 4, Initial Wiring):
PULL: 6011 or 6051
PUSH: 6021 or 6031
PUSH: 6061 or 6071
Figure 7
Figure 8
Figure 9

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
6
6000 Series Programming Instructions: Onboard Method
Set door open and door closed positions.
1. To set closed position, fully close door. Press and
release CLOSE button on board. Flashing ORANGE
LED should turn solid. (Figure 10)
NOTE: Any time door is in closed position, orange
LED should be solid.
2. GREEN OPEN LED should now be ashing.
3. To set the fully open position, manually open door to
open position and hold door there.
NOTE: If there is a wall or door stop at open
position, hold door slightly away from wall or stop.
4. Press and release OPEN button on board. Flashing
GREEN OPEN LED should turn solid. Let door close.
(Figure 11)
NOTE: Any time door is in open position, green LED
should be solid.
NOTE: If open position is not set within 30 seconds
of setting closed position, closed position must set
again.
NOTE: Once door has fully closed, make sure there
are no obstructions that could prevent door from
opening. Latching hardware must not prevent
door from opening during following step.
5. Operator must now learn its internal settings. Press
and release LEARN button on board. BLUE LEARN
LED will start ashing and door will open in small
increments. Allow door to open and close without
interference. (Figure 12)
NOTE: After operator has learned settings, if spring
is adjusted or accessories are attached to door that
would make door heavier, operator MUST relearn
internal settings by repeating step 5.
6. Once setup is complete, use Open Pos Adjust setting
to gain up to an additional 5 degrees of opening.
Figure 10
Open Door and
Push OPEN Button
Close Door and
Push CLOSE Button
Close Door and
Push LEARN Button
Figure 11
Figure 12

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
7
6000 Series Programming Instructions: Onboard Method
Adjust opening and closing.
Using joystick, make selections to adjust
electrical opening and closing of door.
(Figure 13)
NOTE: Latch, Sweep, and Backcheck
valves were adjusted during initial
installation so unit functions properly
as a mechanical door closer. See
Installation Instructions for your
model.
Figure 13
Open Speed
6: iiiiii----
Speed/Force and Timing/Location
settings must be adjusted to meet
ANSI BHMA A159.19 (American
National Standard for Power Assist and
Low Energy Power Operated Doors)
requirements for opening and closing
based on door weight and width. (See
tables below)
Note: To determine minimum times from close to full open, the operator shall be adjusted as shown in the chart. Backcheck occurring at a point
between positions in Table II shall use the lowest setting. For example, if the backcheck occurs at 75 degrees, the full open shall be the time shown in
Table I plus 1.5 seconds.
Doors of other weights and widths can be calculated using the formula:
T = D ÖW/ 133 in US Units T = D ÖW/ 2260 in SI (metric) Units
Where: T = Time, seconds
D = Door width, inches (mm)
W = Door weight, lbs. (kg)
The values for “T” time have been rounded up to the nearest half secound. These values are based on a kinetic energy of 1.25 lbf-ft.
Table I
Minimum Opening Time to Backcheck or 80 degrees (whichever occurs rst) and
Minimum Closing Time from 90 degrees to Latchcheck or 10 degrees (whichever occurs rst)
“D” Door Leaf Width
Inches (mm)
“W” Door Weight in Pounds (kg)
100 (45.4) 125 (56.7) 150 (68.0) 175 (79.4) 200 (90.7)
*30 (762) 3.0 3.0 3.0 3.0 3.5
36 (914) 3.0 3.5 3.5 4.0 4.0
42 (1067) 3.5 4.0 4.0 4.5 4.5
48 (1219) 4.0 4.5 4.5 5.0 5.5
* Check applicable Building Codes for clear width requrements in the Means of Egress. See Appendix for additional door weights.
Table II: Total Opening Time to 90 Degrees
Backcheck at 60 degrees Backcheck at 70 degrees Backcheck at 80 degrees
Table I plus 2 seconds Table I plus 1.5 seconds Table I plus 1 second
If the door opens more than 90 degrees, it shall continue at the same rate as backcheck speed. Matrix values are in seconds.

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
8
6000 Series Programming Instructions: Onboard Method
• OPEN SPEED: Speed at which door opens.
• MAX OPEN FORCE: Force exerted by motor to open door.
• OPEN START FORCE: Force exerted by motor at start of
opening cycle to help overcome stack pressure or latch device.
• OPEN STALL FORCE: Force exerted when door is slowed to
a stop while opening, with 1 being lightest and 10 being
strongest. Measure door force to ensure compliance with
standards and codes.
• ADJUST HOLD OPEN: Time door is held at open position when
ON/OFF/HO switch is in ON position.
• HOLD OPEN FORCE: Force exerted to hold door in max open
position. Can be adjusted to overcome stack pressure, wind, or
other forces pushing on door.
• OBST DET SENS: Amount of time door will push against an
obstruction before stalling or moving in opposite direction.
• OPEN DELAY 1: Time before door will begin to open once
activation has been received.
Set options.
Using joystick, set options. (Figure 14)
Continue with Input Connections on page 13
Figure 14
Max Open Force
• OPEN DELAY 2: Time before door will begin to open once
activation has been received. Part of Vestibule functionality.
• PUSH & GO: As door is manually opened, operator ‘senses’
movement and opens door to full-open position.
• OBSTR DURING CLOSE: Door will reverse to open position if
it hits an obstruction while closing.
• NO OBSTR NEAR OPEN: Used with door mounted presence
sensor. Operator will ignore obstruction input from sensor
in last 30 degrees of opening.
• NO OBSTR NEAR CLOSE: Used with door mounted presence
sensor. Operator will ignore obstruction input from sensor
in last 10 degrees of closing.
• ENERGIZE <20°: 24V outputs will change state when door is
20 degrees from close after a manual or automatic cycle.
• AUDIBLE BEEP: Turn audible beep feedback from interface
PCB off/on.

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
9
6000 Series Programming Instructions: Wi-Fi Method
Shown in
ON Position
Follow these steps after operator has been
successfully installed and power has been turned on
(see Page 4, Initial Wiring):
1. Turn on Operator Wi-Fi
With cover off:
Using joystick, scroll to Wi-Fi Link menu on LCD
screen. Select ON by pushing joystick RIGHT or
LEFT. Red LED indicates ON. (Figure 15)
With cover on:
Toggle 3 Position switch on end cap 3 times.
(Figure 16)
NOTE:
• Operator will emit a long beep when Wi-Fi
has been successfully turned on.
• Wi-Fi automatically turns off after 20 minutes
of inactivity.
• For further security, Wi-Fi can be turned off
immediately by selecting OFF on LCD screen
or toggling 3 Position switch again. Operator
will emit a short beep when Wi-Fi has been
successfully turned off.
• Operator serial number, password and IP
address are located inside 3 Position switch
door. (Figure 17)
2. From your smart device open Wi-Fi Networks to
search for operator SSID. Once your specic ID
beginning with NDC6000_ is found, connect to
network.
3. Enter operator password.
4. From your web browser, enter 192.168.1.1 into
search bar.
5. The 6000 Series Operator homepage is indication
of a successful connection. (Figure 18)
Figure 15
WiFi Link
ON (192.168.1.1)
BEEP
Toggle
OFF/ON
3x
Figure 16
Figure 17
Setup Using Wi-Fi
Figure 18
Serial Number
Password
IP Address

80-9360-1043-020 Rev 1 05/21
Copyright © 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
10
6000 Series Programming Instructions: Wi-Fi Method
Status
Use Status page to quickly access important
information about your operator.
NOTE: “Door Setup Needed” will be displayed if
door setup has not been completed.
Setup
To set up your operator, select Setup page and
proceed through four steps.
1. Select “Operator Model and Opening Range”
that matches your installation.
2. Manually close door and select “Set Closed
Position”.
3. Open door to fully open position. While
holding door open, select “Set Open
Position”.
4. Close door completely and select “Learn” to
perform Learn process.
NOTE: Door will automatically move
through an opening cycle. Be sure there is
no obstruction.
5. Refresh browser page to conrm all
steps have indicating setup has been
successful.
✓✓
