Assa Abloy HES KS100 Aperio Assembly instructions

Page 1 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Product Specifications
Wireless Frequency: 2.4GHz, IEEE 802.15.4, using AES 128-bit encryption
Lock Battery Type: AA Lithium, 1.5 Volts (V)
Battery Life: 50,000 cycles*
Holding Force: 400 lbs
FCC Part 15 Compliant, Industry Canada Compliant
Operating Temperature: 32 to 122 F (0 to 50 C)
HID® multiCLASS SE® technology Credentials Supported: High Frequency (13.56 MHz) –HID iCLASS,
HID iClass SE (SIO-enabled), HID iCLASS Seos, HID MIFARE SE, HID DESfire EV1 SE, MIFARE
CLASSIC DESfire EV1. Low Frequency (125KHz) –HID Prox, AWID, EM4102, ioProx. NFC Enabled
Mobile Phones.
AA Lithium Batteries
required. Use of other
types of batteries, such as
alkaline, will significantly
decrease battery life.
2x
*All battery life claims are approximate and based on a set
configuration profile. Battery performance is based on pre-
defined system settings such as battery chemistry and battery
model used, credential presentation settings (LED/buzzer), UHF
polling period, UHF status intervals, and operations per
day. Actual battery performance will vary and depends on the
factors above.
HES KS100 Aperio
Wireless Cabinet Lock
Installation and Operating Instructions

Page 2 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Recommended tools
Cutting Wheel
Phillips #2 Screwdriver
Hardware Specifications
Table 1 –Cam
DPS Cable Extension
Optional –The DPS signal is closed when the handle is resting in its locked position. The DPS circuit can be
extended to include normally open DPS switches arranged in a series to monitor additional doors and panels
CAM
CAM LENGTH
CAM
DEPTH
38mm - 4
(Standard)
38mm [1-1/2"]
26mm [1”]
38mm - 5
(Optional)
38mm [1-1/2”]
28mm
[1-1/10"]
45 mm - 1
(Optional)
45mm
[1-3/4”]
18mm
[7/10”]
For Technical Support Please call 1-800-810-WIRE
DPS Extension Cable
DPS
Switches
(SPST-NO):
As Needed
Optional
Switch #1
(SPST-NO):
Provided
Extending the DPS Circuit:
A: Remove the DPS jumper
B: Connect the included DPS extension
cable
C: Connect additional normally open
DPS switches as shown to monitor
additional panels.

Page 3 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Package Contents
Lock Body
Battery Bracket
Handle Assembly
Handing Selectors
SFIC Cam and
Spacer
Cam
2x AA Lithium
Batteries
Screw A
#1/4-20 x .50
Truss Head
Phillips
3x Screw B
8/32 x 5/16”
Pan Head
Phillips
Optional External DPS Cable
Harness
3x Dolphin
Connector
Note: SFIC mechanical key
override/SFIC blank sold
separately.

Page 4 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Installing the Lock
1. Locate the 150mm x 25mm lock cutout on the door. Connect battery cable and
optional DPS cable to lock body. Secure battery bracket to lockbody using 3x screw
B.
2. Ensure lock body is flush against the
mounting surface to depress tamper
switch.
3. Select appropriate handing selector.
Tamper
Switch
Door Edge
Note: ensure that the arrow on the
handing selector is pointing towards
the edge of the door.
DPS Cable
(optional)

Page 5 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
4. Install handle, handing selector, and cam. Secure with screw A.
Installing the SFIC Core (Optional)
1. Insert SFIC core and cam into handle. Use spacer for 6 pin SFIC core.
Note: SFIC blank plastic core (SFIC-BC)
sold separately. SFIC Blank is required if
no cylinder Is used.

Page 6 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Installing the Batteries
1. Loosen screw on battery cover, slide cover down, and install batteries in the
appropriate orientation.
Micro USB Port
For emergency power & local (hard wired) firmware
updates, use micro USB port located on the side of
the KS100 reader.

Page 7 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Optional Accessories
Part Number
Description
SFIC
MEDECO X4 7-pin SFIC cylinder & 2 keys
(1 Control,1 User)
SFIC-BC
KS SFIC blank, black plastic core
KS-DPS
Surface mount DPS (external)
KS-CAM38
CAM: 38MM - 5 (28mm Depth)
KS-CAM45
CAM: 45MM - 1 (18mm Depth)
AH20W14
ASSA ABLOY Aperio™ AH20 1:1 Wiegand Hub
EXT-10-ANT
ASSA ABLOY Aperio™ Hub External Antenna - 3,9
dBi Omnidirectional
APA-10-PC
ASSA ABLOY Aperio™ Programming Kit
APD-10-USB
ASSA ABLOY Aperio™ USB Radio Dongle

Page 8 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
LED Codes

Page 9 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Aperio Hub
Technical Data - AH20
Approvals
CE, ETL, FCC, IC, C-Tick
Safety and emissions
FCC 47CFR Part 15 subpart
B and subpart C; IC RSS-210
EN ETSI 301 489-17 v2.1.1;
ENETSI 300 328 v1.7.1;
EN 60950-1 ed.2 2007
Dimensions (mm)
82x82x37
Power Supply
8-24 VDC
Current
250 mA minimum
Internal Antenna
2cross polarized dipoles
External Antenna
(Part No. EXT-10-ANT)
One reverse polarity SMA external
antenna connector.
Optional antenna type dipole with
max antenna gain of 3.9dBi
Radio Standard
IEEE 802.15.4(2.4GHz) -
15 channels (11-25)
Encryption (Radio
Communications)
AES 128 bits
Wireless Operating
Range
Up to 50 ft
Receiver Sensitivity
100dBm 20%PER
Wireless Transmit
Power
10 dBm/MHz
Class of Protection
IP 20
Operating temperature
5°C to 35°C
Humidity
< 95% non-condensing
Status
LED (red/green/orange)

Page 10 of 12
For more information visit website assaabloyesh.com P/N: 3080006.017_1
Connecting the Hub
The following applies only to Aperio factory paired kits with AH20 Hubs.
Note: The Green LED input is used to grant access to the cabinet lock. If the Green LED
signal is not available to indicate approved access, the approval input can be
activated by a relay with “NO” attached to Green LED and “C” to GND.
The Red LED input is used to indicate access denied. If the RED LED signal is
not connected, the lock will flash RED three times when a non-approved card is
presented indicating loss of connection to the hub rather than access denied. Any
other codes may be reference on the LED reference card.
Connect the Wiegand D1, D0, red, and green LED signals.
