Atlas Equipment BP12000X Installation instructions

Revised: 11/ 30/ 2020
Read this entire manual before operation begins.
Record below the following inform at ion which is located on t he serial num ber
dat a plat e.
Serial No.
Model No.
Dat e of I nstallat ion

Cont ent s
General I nform ation . . . . . . . . . . 5
Product I dentifi cat ion . . . . . . . . . 8
Packing / Transport / St orage . . . . . 9
Lift Description . . . . . . . . . . . . 11
Technical Specifi cation. . . . . . . . . 12
Safet y . . . . . . . . . . . . . . . . 17
I nstallat ion . . . . . . . . . . . . . . 20
Operat ion And Use . . . . . . . . . . 29
Maintenance . . . . . . . . . . . . . 31
Troubleshoot ing . . . . . . . . . . . . 33
Part s Lists . . . . . . . . . . . . . . 34
Warrant y . . . . . . . . . . . . . . . 45

4
BP12000X
Printing Characters And Symbols
Throughout t his m anual, t he following sym bols and
print ing charact ers are used to facilit at e reading:
I ndicates t he operat ions which
need proper care
I ndicates prohibited
I ndicates a possibilit y of danger
to t he operators
BOLD
TYPE I m port ant inform ation
W ARN I N G: before operat ing t he lift and
ca rr ying ou t a ny a dj ust m ent s, r ea d ca r efully
cha pt e r 7 “I n st a lla t ion ” w h er e a ll ope r at ions
for a pr ope rly funct ionin g lift a re show n .

General Information 5
BP12000X
Ge nera l I nform a t ion
This chapt er cont ains warning instruct ions to operat e t he lift properly and
prevent inj ury t o operat ors or obj ects. This m anual has been writ t en t o be used
by shop technicians in charge of t he lift ( operat or) and routine m aintenance
t echnician ( m aint enance operat or) . The operat ing inst ruct ions ar e consider ed t o
be an integral part of the m achine and m ust rem ain wit h it for it s whole useful
life. Read every sect ion of this m anual carefully before operat ing t he lift and
unpacking. I t provides helpful inform at ion about :
• Sa fet y Of People
• Sa fet y Of The Lift
• Sa fet y Of Lift e d V ehicle s
The com pany is not liable for possible problem s, dam age, accidents, installat ion,
etc. result ing from failure t o follow t he inst ructions contained in t his m anual.
Only skilled t echnicians of AUTHORI ZED DEALERS or SERVI CE CENTERS
AUTHORI ZED by t he m anufact urer shall be allowed t o carry out lifting, t ransport,
assem bling, inst allat ion, adj ust m ent, calibrat ion, set tings, ext raordinary
m aint enance, repairs, overhauling and dism antling of t he lift.
The m a nufact ure r is not r esponsible for possible da m age t o people ,
vehicles or object s if sa id operations are carr ied out by una ut horized
per sonnel or t he lift is im pr ope rly used.
Any use of the lift by operat ors who are not fam iliar wit h t he inst ructions and
procedures contained herein is unauthorized.
1.1 Manual Keeping
For a proper use of t his m anual, the following is recom m ended:
• Keep the m anual near the lift , in an easily accessible place.
• Keep the m anual in an area prot ect ed from t he dam p.
• Use this m anual properly wit hout dam aging it.
• Any use of the m achine m ade by operators who are not fam iliar wit h t he
inst ruct ions and procedures contained herein shall be forbidden.
This m anual is an integral part of t he lift: it shall be given t o t he new owner if
and when t he lift is resold.

General Information 6
BP12000X
1.2 Obligation In Case Of Malfunction
I n ca se of m a ch in e m a lfu nct ion, follow t he in st r uct ions
cont a in e d in t he follow in g ch apt e rs.
1.3 Cautions For The Safety Of The Operator
Operat ors m ust not be under t he influence of sedatives, drugs or alcohol when
operat ing t he m achine.
Be for e ope r at in g t h e lift , oper a t or s m ust be fa m iliar w it h
t he posit ion a nd fu nct ion of a ll con t rols, a s w e ll a s w it h t h e
m a ch in e f ea t ur es sh ow n in t he cha pt er “Op er at ion a nd u se ”
1.4 Warnings
Una ut h or iz ed ch an ge s a nd/ or m odifi ca t ion s t o t he m ach ine
r elie ve t h e m a nufa ct ur e r of a ny lia bilit y for possible da m a ges t o
obj ect s or people . Do not rem ove or m ak e inopera t ive t he sa fet y
devices, t his w ould cause a violation of sa fety a t w ork la w s and
r egula t ion s.
An y ot h er u se w h ich dif fe r s f rom t ha t pr ovide d for b y t h e
m a n ufa ct ur er of t h e m a ch in e is st r ict ly f or bid de n.
The use of non ge nuine parts m a y ca use dam a ge t o people or
ob j ect s
1.5 Scrapping
When your m achine’s working life is over and it can no longer be used, it m ust
be m ade inoperat ive by rem oving any connect ion t o power sources. These
unit s are considered as special wast e m at erial, and should be broken down int o
uniform parts and disposed of in com pliance with current laws and regulat ions. I f
the packing are not polluting or non-biodegradable, deliver them to appropriat e
handling st at ion.

General Information 7
BP12000X
Declaration Of Warranty And Limitation Of Liability
The m anufact urer has paid proper at t ention to t he preparat ion of this m anual.
However, nothing contained herein m odifi es or alters, in any way, the term s
and condit ions of m anufact urer agreem ent by which t his lift was acquired, nor
increase, in any way, m anufact urer’s liabilit y t o t he cust om er.
To The Reader
Every effort has been m ade t o ensure that the inform at ion contained in t his
m anual is correct , com plet e, and up- to dat e. The m anufact urer is not liable for
any m ist akes m ade when drawing up this m anual and reserves t he right t o m ake
any changes due the developm ent of the product , at any tim e.

Product Identification 8
BP12000X
Product I dent ifica t ion
The identifi cat ion data of t he m achine are shown in t he serial plat e placed on t he
power side colum n.
Use t h e id ent ifi ca t ion t a g on t h e lift colu m n t o orde r spa re
pa rt s a nd w h en ge t t ing in t ouch w it h t h e m an ufa ct u re r
( inqu ir y) . The r em ova l of t his la be l is st r ict ly f or bidde n.
Machines m ay be updat ed or slight ly m odifi ed from an aest het ic point of view
and, as a consequence, they m ay present different feat ures from these shown,
this wit hout prej udicing what has been described herein.
2.1 Warranty Certificate
The warranty is valid for a period of 12 m onths st arting from t he date of
the purchase invoice. The warranty will com e im m ediat ely to an end when
unauthorized m odifi cat ions to t he m achine or parts of it are carried out. The
presence of defects in workm anship m ust be verifi ed by t he Manufact urer ’s
personnel in charge.
2.2 Technical Servicing
For all servicing and m aintenance operations not specifi ed or shown in t hese
inst ruct ions, contact your Dealer where the m achine has been bought or the
Manufact urer ’s Com m ercial Depart m ent .

Packing / Transport / Storage 9
BP12000X
Packing / Transport / Storage
Only skilled personnel who are fam iliar wit h t he lift and t his m anual shall
be allowed to carry out packing, lifting, handling, t ransport and unpacking
operat ions.
3.1 Packing
The packing of t he lift is delivered in following com ponents:
• 1 base unit packed in a steel fram e, wrapped up in non- scrat ch m at erial,
including all t he accessories.
• 1 power unit packed in a cart on box.
Figure 1 - Packages
3.2 Lifting And Handling
When loading/ unloading or t ransporting t he equipm ent t o t he sit e, be sure to
use suit able loading (e.g. cranes, t rucks) and hoist ing m eans. Be sure also to
hoist and transport t he com ponents securely so t hat they cannot drop, taking
into considerat ion t he package’s size, weight and center of gravit y and it ’s fragile
part s.

Packing / Transport / Storage 10
BP12000X
3.3 Storage And Stacking Of Packages
Packages m ust be st ored in a covered place, out of direct sunlight and in low
hum idity, at a t em perat ure bet ween - 10° C and + 40° C.
3.4 Delivery And Check Of Packages
When t he lift is delivered, check for possible dam ages due t o t ransport and
storage; verify t hat what is specifi ed in t he m anufact ur er ’s confi rm at ion of or der
is included. I n case of dam age in t ransit , t he custom er m ust im m ediat ely inform
the carrier of the problem .
Packages m ust be opened paying at t ention not t o cause dam age t o people ( keep
a safe dist ance when opening st raps) and part s of t he lift ( be careful t he obj ects
do not drop from t he package when opening) .

Lift Description 11
BP12000X
Lift Descript ion
The lift is suitable for lifting m ot or vehicles having m axim um weight as described
in t he nam eplat e on the power side colum n of t he lift . All m echanical parts such
as colum ns, carriages and lift arm s have been built in st eel plat e t o m ake t he
fram e st iff and st rong while keeping a low weight. The elect ro hydraulic
operat ion is described in det ail in chapt er 8.
This chapter describes t he lift ’s principal elem ents, allowing t he user to be
fam iliar wit h t he m achine.
As shown in fi gure 2, t he lift is com posed of t wo colum ns: power- side colum n
( 1) and off- side colum n ( 2) , each equipped wit h a car riage ( 3) and a pair of
lift ing arm s ( 4) w it h t he adapt or ( 5) anchor ed t o t he ground by m eans of base
plat es of colum ns. The base plat e ( 6) is used t o prot ect routed lines bet ween
colum ns. Raising m ot ion is carried out by pushing the lifting but t on on a power
unit ( 7) w hich delivers
t he hydraulic fl uid t o
cylinders inside the
colum ns to act on t he
chain syst em t o raise
the lift.
Lowering t he vehicle
by pushing down t he
lowering handle on
the power unit while
holding down t he
safet y lock handle ( 8) .
The synchronization
is controlled by t he
equalizer cables. The
arm safet y can be
engaged autom at ically
when t he lift is raised.
Figure 2 – Lift

Technical Specification 12
BP12000X
Technical Specificat ion
5.1 Size And Main Features
CAPACI TY 1 2 0 0 0 lbs
Max. stroke 34 3/ 8”
Max. lift ing height wit h no pad extension 77 1/ 2”
Min. adapt or height 3 7/ 8”
Overall height 126”
Overall widt h 145 5/ 8” - 150 3/ 4”
Lifting t im e 60 S
Lowering t im e 35 S
Noise level 75 dB( A) / 1m
Working t em perat ure 32 ° F - 110 ° F
Average weight of package 2085 lbs
5.2 Electric Motor
Volt age 220V/ 60Hz/ 1Ph
Power 2.2kw
N° Poles 2
Speed 3450 rpm
Motor enclosure type B14
I nsulation class I P 54
Motor connect ion m ust be carried out referring to t he at t ached wiring diagram s
the fi gure 6. The m ot or direct ion of rot ation is shown in t he label placed on t he
m ot or.
Before use of t he lift, m ake sure to check if t he m ot or specifi cat ion shown in t he
nam eplat e of the m ot or conform s to t he local elect ric supply. I f t here is over
10% fl uct uat ion on the elect rical power supply, it is suggest ed t o use the volt age
stabilizer to prot ect the elect rical com ponents and syst em from overloading.

Technical Specification 13
BP12000X
5.3 Pump
Type Gear
Flow rate 2.5 cm 3/ g
Continuous working pressure 180 bar
Peak pressure 220 bar
Figure 3 – Layout

Technical Specification 14
BP12000X
5.4 Hydraulic Power Unit
Figure 4 – Hydraulic Power Unit
5.5 Oil
Use wear proof oil for hydraulic drive, in conform it y with I SO 6743 / 4 r ules ( HM
class) . The oil wit h feat ures sim ilar t o t hose shown in t he table is recom m ended.
Te st st a nda r ds Fe a t ur es Va lu e
ASTM D 1298 Densit y 20° C 0.8 kg/ l
ASTM D 445 Viscosit y 40° C 32 cSt
ASTM D 445 Viscosit y 100° C 5.43 cSt
ASTM D 2270 Viscosit y index 104 N°
ASTM D 97 Pour point ~ 30 ° C
ASTM D 92 Flash point 215 ° C
ASTM D 644 Neutralizat ion num ber 0.5 m g KOH/ g
Cha nge h yd ra ulic oil a t 1 ye ar in t er vals

Technical Specification 15
BP12000X
Figure 5 - Hydraulic Plan
1 Oil fi lt er 6 Hydraulic cylinder
2 Gear pum p 7 Pressure overload valve
3 Flow rest rict or 8 Manual lowering valve
4 Non ret urn valve 9 Motor
5 Lowering speed control valve 10 St art up valve

Technical Specification 16
BP12000X
Figure 6 – Elect rical Diagram ( 220V/ 50Hz/ 60Hz/ 1Ph)

Safety 17
BP12000X
Sa fet y
Read t his chapt er carefully and com pletely because it contains im portant
inform at ion for t he safet y of t he operator and t he person in charge of
m aintenance.
The lift has been designed a nd built for lift ing vehicles and
m a k in g t he m st a n d a bove le ve l in a close d a r ea . Any ot he r u se is
for bidden.
The m a nufact ure r is not lia ble for possible da m ages to people ,
ve hicle s or obj ect s r esu lt ing fr om a n im pr op er or u na ut horiz ed
use of t he lift .
For operator and people safet y, a square space for a safet y area at least 3 feet
free away from t he lift m ust be vacated during lifting and lowering. The lift m ust
be operated only from the operat or ’s control site in t his safet y area.
Operat or ’s presence under t he vehicle, during working, is only adm it t ed when
the vehicle is lifted and t he safet y lock is engaged.
N ever u se t he lift w he n sa fet y devices ar e off- line. Pe ople , t he
lift , a nd t he ve hicle s lift e d ca n be se riously da m a ge d if t h ese
in st r u ct ions a r e n ot follow e d.
6.1 General Warnings
The operat or and t he person in charge of m aintenance m ust follow accident-
prevent ion laws and rules in force in t he count ry where the lift is inst alled.
They also m ust carry out t he following:
• Neit her rem ove nor disconnect hydraulic, elect ric or ot her safet y devices;
• Carefully follow t he safet y indicat ions applied on t he m achine and included
in t he m anual;
• Observe t he safet y area during lifting;

Safety 18
BP12000X
• Be sure t he m otor of t he vehicle is off, t he gear engaged and t he parking
brake put on;
• Be sure only authorized vehicles are lifted without exceeding t he m axim um
lift ing capacit y;
• Verify t hat no one is on the arm s during lifting or st anding.
6.2 Safety Device
To avoid overloading and possible breaking, t he following safet y devices have
been used:
• A pressure overload valve built inside t he hydraulic power unit t o prevent
excessive weight .
The pressure over load valve has been pr eset by the
m a n ufa ct ur er t o a pr ope r pre ssu re . D O N OT t r y t o a dj u st it t o
ov er ru n t h e r a t ed lif t in g ca pa cit y.
• Mechanical safet ies built in each carriage wit h aut om at ic engagem ent for
lift ing safet y.
I t is st r ict ly f or bid de n t o m odif y a n y sa fet y d evice . Alw a ys
ensure t he sa fet y device for prope r ope rat ion during t he se rvice .

Safety 19
BP12000X
6.3 Safety Signs
All safet y warning signs ( r ef. fi gure 7) displayed on t he lift are wit h t he purpose
to draw the operat or’s at t ention t o dangerous or unsafe situat ions. The labels
m ust be kept clean and t hey have to be replaced if det ached or dam aged. Read
the m eaning of t he labels carefully and m em orize it .
Figure 7 – Safet y Signs

Installation 20
BP12000X
I nst alla t ion
On ly sk illed t e ch nicia ns, a pp oin t ed by t h e m a n ufa ct u re r, or by
a ut horiz ed de ale rs, m u st be a llow e d t o ca r ry out in st a lla t ion .
Se rious da m a ge t o pe ople a nd t o t h e lift ca n b e ca u se d if
in st a lla t ions a re m a de by u nsk ille d p er son ne l.
Alw a ys re fer t o t h e e x ploded v ie w s a t t ach e d dur in g inst a lla t ion.
7.1 Tool Required
Rot ary Ham m er Drill D.20 Hex- Key/ Allen Wrench Set
Masonry Bit Crow Bar For Shim I nst allat ion
Ham m er Chalk Line
Level Medium Cross Screwdriver
Open- End Wr ench Set Medium Flat Screwdr iver
Medium Crescent Wrench Tape Measure
7.2 Checking For Room Suitability
The lift has been designed to be used in covered and shelt ered places free of
overhead obst ruct ions. The place of inst allat ion m ust not be next to washing
areas, painting workbenches, solvent or varnish deposits. The installat ion
near t o room s, where a dangerous sit uat ion of explosion can occur, is strict ly
forbidden. The relevant st andards of t he local Health and Safet y at Work
regulat ions, for inst ance, with respect to m inim um distance to wall or other
equipm ent, escapes and the like, m ust be observed.
7.3 Lighting
Light ing m ust be carried out according t o t he effect ive regulat ions of t he place of
inst allat ion. All areas next t o t he lift m ust be well and uniform ly lit.
