Atlas Equipment Garage Pro 8000 EXT User manual

Revision Date: 9/28/2017
Read this entire manual before operation begins.
Record below the following information which is located on the serial number
data plate.
Serial No.
Model No.
Date of Installation

Contents
General Information. . . . . . . . . . 8
Product Identification . . . . . . . . . 11
Packing / Transport / Storage . . . . . 12
Tools Required For Installation . . . . . 14
Specifications . . . . . . . . . . . . . 15
Safety . . . . . . . . . . . . . . . . 19
Installation . . . . . . . . . . . . . . 23
Operation And Use . . . . . . . . . . 35
Maintenance . . . . . . . . . . . . . 38
Troubleshooting. . . . . . . . . . . . 40
Additional Information. . . . . . . . . 41
Illustrated Parts Breakdown . . . . . . 48
GP8000 EXT Parts List . . . . . . . . . 54
Warranty . . . . . . . . . . . . . . . 58

4
Garage Pro 8,000 EXT
Please read this manual in its entirety before installing or operating your lift.
By proceeding, you agree that you fully understand the contents of this manual
and the installation, operation, and maintenance instructions contained within.
Please deliver this manual to the lift owner and/or operator along with all other
documentation provided with the lift. Failure to operate this equipment as
intended may cause injury or death.
Check for any freight damages. The shipment should be thoroughly inspected
as soon as it is received. The signed bill of lading is acknowledgement by the
carrier of receipt in good condition of shipment covered by your invoice. If any of
the goods called for on your bill of lading are shorted or damaged, do not accept
to unload until the carrier makes a notation on the freight bill of the missing
or damaged goods. Do this for your own protection. Check the contents of the
accessory and hardware boxes to make sure no parts are missing.
Record the following information which can be located on the serial number data
plate: Serial No, Model No, and Date of Installation.

5
Garage Pro 8,000 EXT
IMPORTANT SAFETY INSTRUCTIONS
Please read carefully
• Read all instructions and warnings thoroughly before servicing, or
maintaining the lift.
• Inspect the lift daily. Never operate if there are broken or damaged parts
or if the lift is malfunctioning.
• Do not operate if there are damaged cords or if any piece of the equipment
has been dropped or damaged until it has been examined by a qualified
professional.
• Do not touch hot parts as burns can occur.
• Keep area well lit at all times and do not use in damp or wet locations.
• Do not let any cords come in contact with hot manifolds or moving blades.
• A cord with a current rating equal to or more than that of the equipment
should be used if an extension cord is necessary. Cords rated for less
current than the equipment may overhead. Be careful to avoid putting in
an area where it could be tripped over or interfered with.
• Always unplug equipment when not in use. Do not attempt to grab the
cord, grasp plug to disconnect.
• Allow equipment to cool completely before storing away. Loop cord loosely
around the equipment when storing.
• To reduce the risk of fire, never operate near open containers of flammable
liquids (for example, gasoline).
• Adequate ventilation should be provided when working on or operating
internal combustion engines.
• Always keep loose clothing, hair, fingers, and all parts of the body away
from any moving parts.
• To reduce the risk of electric shock, never use on wet surfaces or expose to
rain.
• Always wear safety glasses. Everyday glasses are not safety glasses and do
not provide adequate protection.
• Use only as described in this manual – use only Atlas Automotive
Equipment optional accessories and attachments.
• Never attempt to overload the lift. The rated capacity is shown on the
identification label.
• Never modify the lift or attempt to override the operating controls.
• Do not attempt to raise a vehicle until installation is completed per
instructions in this manual.

6
Garage Pro 8,000 EXT
• Only trained and qualified personnel are to operate, maintain, service or
repair the lift.
• Keep hands and feet clear of any moving parts and avoid pinch points.
• Always use all four arms to raise and support the vehicle.
• Never work under or near the lift unless the mechanical safety locks are
securely engaged.
• Always keep the work area free of spills and debris.
• Never permit anyone in a vehicle or on the lift when it is either being raised
or lowered.
• Always check for obstructions before lowering the lift.
• Never remove hydraulic fittings while the lift is under pressure.
• Clear the work area immediately if a vehicle is in danger of falling.
• Do not hit or drive over arms or adapters. Always provide an unobstructed
entrance between columns prior to loading vehicle onto the lift.
• Always ensure that the lift is grounded while in use to protect the operator
from electric shock.
• Disconnect power unit before performing any electrical repairs.
• Avoid rocking a vehicle while it is on the lift.
• Always use safety and/or support stands when removing or installing heavy
vehicle components.
• Never remove or tamper with safety components.
• Use common sense and always stay alert.
• SAVE THESE INSTRUCTIONS

7
Garage Pro 8,000 EXT
Printing Characters And Symbols
Throughout this manual, the following symbols and printing characters are used
to facilitate reading:
Indicates the operations which need proper care
Indicates prohibition
Indicates a possibility of danger for the operators
Indicates the direction of access for motor vehicles to the lift
BOLD
TYPE Important information
WARNING: before operating the lift and carrying out any
adjustment, read carefully chapter 7 “installation” where all
proper operations for a better functioning of the lift are shown.

General Information 8
Garage Pro 8,000 EXT
General Information
This chapter contains warning instructions to operate the lift properly and prevent
injury to operators or objects. This manual has been written to be used by shop
technicians in charge of the lift (operator) and routine maintenance technician
(maintenance operator). The operating instructions are considered to be an
integral part of the machine and must remain with it for its whole useful life.
Read every section of this manual carefully before operating the lift and
unpacking it since it gives helpful information about:
• safety of people
• safety of the lift
• safety of lifted vehicles
The company is not liable for possible problems, damage, accidents, etc.
resulting from failure to follow the instructions contained in this manual.
Only skilled technicians of AUTHORISED DEALERS or SERVICE CENTRES
AUTHORISED by the manufacturer shall be allowed to carry out lifting, transport,
assembling, installation, adjustment, calibration, settings, extraordinary
maintenance, repairs, overhauling and dismantling of the lift.
The manufacturer is not responsible for possible damage to people,
vehicles or objects if said operations are carried out by unauthorized
personnel or the lift is improperly used.
Any use of the machine made by operators who are not familiar with the
instructions and procedures contained herein shall be forbidden.
1.1 Manual Keeping
For a proper use of this manual, the following is recommended:
• keep the manual near the lift, in an easily accessible place.
• keep the manual in an area protected from the damp.
• use this manual properly without damaging it.
• Any use of the machine made by operators who are not familiar with the
instructions and procedures contained herein shall be forbidden.

General Information 9
Garage Pro 8,000 EXT
This manual is an integral part of the lift: it shall be given to the new owner if
and when the lift is resold.
1.2 Obligation In Case Of Malfunction
In case of machine malfunction, follow the instructions
contained in the following chapters.
1.3 Cautions For The Safety Of The Operator
Operators must not be under the influence of sedatives, drugs or alcohol when
operating the machine.
Before operating the lift, operators must be familiar with
the position and function of all controls, as well as with the
machine features shown in the chapter “Operation and use”
1.4 Warnings
Unauthorized changes and/or modifications to the machine
relieve the manufacturer of any liability for possible damages
to objects or people. Do not remove or make inoperative the
safety devices, this would cause a violation of safety at work
laws and regulations.
Any other use which differs from that provided for by the
manufacturer of the machine is strictly forbidden.
The use of non genuine parts may cause damage to people or
objects

General Information 10
Garage Pro 8,000 EXT
Declaration Of Warranty And Limitation Of Liability
The manufacturer has paid proper attention to the preparation of this manual.
However, nothing contained herein modifies or alters, in any way, the terms
and conditions of manufacturer agreement by which this lift was acquired, nor
increase, in any way, manufacturer’s liability to the customer.
To The Reader
Every effort has been made to ensure that the information contained in this
manual is correct, complete and up-to date. The manufacturer is not liable for
any mistakes made when drawing up this manual and reserves the right to make
any changes due the development of the product, at any time.

Product Identification 11
Garage Pro 8,000 EXT
Product Identification
The identification data of the machine are shown in the serial plate placed on the
power side column.
The removal of this serial plate is strictly forbidden.
Machines may be updated or slightly modified from an aesthetic point of view
and, as a consequence, they may present different features from these shown,
this without prejudicing what has been described herein.
2.1 Warranty Certificate
The warranty is valid for a period of 12 months starting from the date of the
purchase invoice.
The warranty will come immediately to an end when unauthorized modifications
to the machine or parts of it are carried out.
The presence of defects in workmanship must be verified by the Manufacturer’s
personnel in charge.
2.2 Technical Servicing
For all servicing and maintenance operations not specified or shown in these
instructions, contact your Dealer where the machine has been bought or the
Manufacturer’s Commercial Department.
Only skilled personnel who are familiar with the lift and this manual shall
be allowed to carry out packing, lifting, handling, transport and unpacking
operations.

Packing / Transport / Storage 12
Garage Pro 8,000 EXT
Packing / Transport / Storage
3.1 Packing
The packing of the lift is shown in the figure 1: N. 1 base unit packed in a steel
frame, wrapped up in non-scratch material, and N.1 package of power unit.
The package weight is about 1739 lbs.
If requested, optional accessories are available to satisfy each customer’s
requirements.
Figure 1 - Package
3.2 Lifting And Handling
When loading/unloading or transporting the equipment to the site, be sure to
use suitable loading (e.g. cranes, trucks) and hoisting means. Be sure also to
hoist and transport the components securely so that they cannot drop, taking
into consideration the package’s size, weight and centre of gravity and it’s fragile
parts.

Packing / Transport / Storage 13
Garage Pro 8,000 EXT
3.3 Storage And Stacking Of Packages
Packages must be stored in a covered place, out of direct sunlight and in low
humidity, at a temperature between -10°C and +40°C.
Stacking is not recommended: the package’s narrow base, as well as its
considerable weight and size make it difficult and hazardous.
3.4 Delivery And Check Of Packages
When the lift is delivered, check for possible damages due to transport and
storage; verify that what is specified in the manufacturer’s confirmation of order
is included. In case of damage in transit, the customer must immediately inform
the carrier of the problem.
Packages must be opened paying attention not to cause damage to people (keep
a safe distance when opening straps) and parts of the lift (be careful the objects
do not drop from the package when opening).

Tools Required For Installation 14
Garage Pro 8,000 EXT
Tools Required For Installation
The installation of this lift is relatively simple and can be accomplished
by two men in a few hours.
The following tools and equipment are needed:
• Set of metric wrenches and/or sockets
• Locking pliers
• Adjustable wrench
• 25’ Tape measure
• ISO 32 Light Hydraulic Oil (approx. 3 gallons)
• Step Ladder

Specifications 15
Garage Pro 8,000 EXT
Specifications
5.1 Size And Main Features (Ref. Fig. 3)
LIFT CAPACITY 3600kg (8,000lbs)
Max. raised height 84-1/2”
Min. Lowered height 6’ 7”
Runway length 165-1/2”
Runway width 21-1/4”
Free width between runways 37-3/8”
Max. overall length 207-1/2”
Overall height 100”
Overall width 114”
Raised time 112s
Drive Thru 80-1/2”
Maximum Wheel Base 153-1/2”
Working temperature 5 °C - 40 °C
Average weight of package 1,739 lbs
5.2 Electric Motor
Voltage 115V/60Hz/1Ph
Power 3HP
N° Poles 2
Speed 3450rpm
Motor enclosure type B14
Insulation class IP 54
Motor connection must be carried out referring to the attached wiring diagrams
(fig.6). The motor direction of rotation is shown in the label placed on the motor.
Before use of the lift, make sure to check if the motor specification shown in the
nameplate of the motor conforms to the local electric supply. NOTE: You will
need at least 9’ of clearance from all sides of the lift including power unit.
5.3 Pump
Type Gear
Flow rate 1.3 cm3/g
Continuous
working
pressure
2870 psi

Specifications 16
Garage Pro 8,000 EXT
5.4 Hydraulic Power Unit
The hydraulic unit is equipped with
Figure 4 – Hydraulic Power Unit
5.5 Oil
Use wear proof oil for hydraulic drive, in conformity with ISO 6743/4 rules (HM
class). The oil with features similar to those shown in the table is recommended.
Test standards Features Value
ASTM D 1298 Density 20°C 0.8 kg/l
ASTM D 445 Viscosity 40°C 32 cSt
ASTM D 445 Viscosity 100°C 5.43 cSt
ASTM D 2270 Viscosity index 104 N°
ASTM D 97 Pour point ~ 30 °C
ASTM D 92 Flash point 215 °C
ASTM D 644 Neutralization number 0.5 mg KOH/g
Change hydraulic oil at 1 year intervals

Specifications 17
Garage Pro 8,000 EXT
Figure 5 -Hydraulic Plan
1 Oil filter 6 Manual lowering valve
2 Gear pump 7 Startup valve
3 Motor 8 Flow restrictor
4 Non return valve 9 Hydraulic cylinder
5 Pressure overload valve

Specifications 18
Garage Pro 8,000 EXT
Figure 6 – Electrical Diagram (110V/60Hz/1Ph)
1.5HP motor

Safety 19
Garage Pro 8,000 EXT
Safety
Read this chapter carefully and completely because it contains important
information for the safety of the operator and the person in charge of maintenance.
The lift has been designed and built for lifting vehicles and
making them stand above level in a closed area. any other
use is forbidden.
The manufacturer is not liable for possible damages to
people, vehicles or objects resulting from an improper or
unauthorized use of the lift.
For operator and people safety, a safety area at least 1m free away from the lift
must be vacated during lifting and lowering. The lift must be operated only from
the operator’s control site in this safety area.
Operator’s presence under the vehicle, during working, is only admitted when
the vehicle is lifted and runways are not running.
Never use the lift when safety devices are off-line. People,
the lift and the vehicles lifted can be seriously damaged if
these instructions are not followed.
6.1 General Warnings
The operator and the person in charge of maintenance must follow accident-
prevention laws and rules in force in the country where the lift is installed
They also must carry out the following:
• neither remove nor disconnect hydraulic, electric or other safety devices;
• carefully follow the safety indications applied on the machine and included
in the manual;
• observe the safety area during lifting;
• be sure the motor of the vehicle is off, the gear engaged and the parking
brake put on;

Safety 20
Garage Pro 8,000 EXT
• be sure only authorized vehicles are lifted without exceeding the maximum
lifting capacity;
• Verify that no one is on the runways during lifting or standing.
Any use of the lift other than that herein specified can cause
serious accidents to people in close proximity of the machine.
6.2 Risks For People
All risks the personnel could run, due to an improper use of the lift, are
described in this section.
6.3 Personnel Crushing Risks
During lowering of runways and vehicles, personnel must not be within the
area covered by the lowering trajectory. The operator must be sure no one is in
danger before operating the lift.
Fig. 7a Fig. 7b Fig. 7c
6.4 Risk Of The Vehicle Falling From The Lift
Vehicle falling from the lift can be caused when the vehicle is improperly placed
on platforms, and when its dimensions are incompatible with the lift or by
excessive movement of the vehicle.
In this case, keep immediately away from the working area.
Fig. 8a Fig. 8b Fig. 8c
