Autel MaxiSys MS906S User manual

i
Trademarks
Autel®, MaxiSys®, MaxiDAS®, MaxiScan®, MaxiTPMS®, MaxiRecorder®, and
MaxiCheck® are trademarks of Autel Intelligent Technology Corp., Ltd., registered in
China, the United States and ot her countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or transmitted,
in any form or by any means, electronic, mechanical, photocopying, recording, or
otherwise, without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on t he latest
information available at the time of printing. Autel reserves the right to make changes at
any time without notice. While information of this manual has been carefully checked
for accuracy, no guarantee is given to the completeness and correctness of the
contents, including but not limited to the product specifications, functions, and
illustrations.
Autel will not be liable for any direct damages or for any special, incidental, or indirect
damages or for any economic consequential damages (including lost profits).
IMPORTANT: Before operating or maintaining this unit, please read this manual
carefully, paying extra attention to the safety warnings and precautions.
For Services and Support:
pro.autel.com
www.autel.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-86147779 (China)
[e-mail]
For technical assistance in all other markets, please contact your local selling agent

ii
Safety Information
For your own safety and the safety of others, and to prevent damage to the device and
vehicles upon which it is used, it is important that the safety instructions herein
presented throughout this manual be read and understood by all persons operating, or
coming into contact with, the device.
There are various procedures, techniques, tools, and parts for servicing vehicles, as
well as in the skill of the person doing the work. Because of the vast number of test
applications and variations in the products that can be tested with this equipment, we
cannot possibly anticipate or provide advice or safety messages to cover every
circumstance. It is the automotive technician’s responsibility to be knowledgeable of the
system being tested. It is crucial to use proper service methods and test procedures. It
is essential to perform tests in an appropriate and acceptable manner that does not
endanger your safety, the safety of others in the work area, the device being used, or
the vehicle being tested.
Before using the device, always refer to and follow the safety messages and applicable
test procedures provided by the manufacturer of the vehicle or equipment being tested.
Use the device only as described in this manual. Read, understand, and follow all
safety messages and instructions in this manual.
Safety Messages
Safety messages are provided to help prevent personal injury and equipment damage.
All safety messages are introduced by a signal word indicating the hazard level.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury to the operator or to bystanders.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury to the operator or to bystanders.
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot know,
evaluate or advise you as to all of the possible hazards. You must be certain that any
condition or service procedure encountered do not jeopardize your personal safety.
DANGER: When an engine is operating, keep the service area WELL
VENTILATED or attach a building exhaust removal system to the engine exhaust
system. Engines produce carbon monoxide, an odorless, poisonous gas that
causes slower reaction time and can lead to serious personal injury or loss of
life.

Safety Information Important Safety Instructions
iii
Do Not Turn the Volume Up Too Loud When Using Headphones
Listening at high volumes that over-stimulate the ear for long periods of time
may result in loss of hearing.
SAFETY WARNINGS:
 Always perform automotive testing in a safe environment.
 Wear safety eye protection that meets ANSI standards.
 Keep clothing, hair, hands, tools, test equipment, etc. away from all
moving or hot engine parts.
 Operate the vehicle in a well ventilated work area, for exhaust gases are
poisonous.
 Put the transmission in PARK (for automatic transmission) or NEUTRAL
(for manual transmission) and make sure the parking brake is engaged.
 Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
 Use extreme caution when working around the ignition coil, distributor cap,
ignition wires and s park plugs. These components create hazardous
voltages when the engine is running.
 Keep a fire extinguisher suitable for gasoline, chemical, and electrical fires
nearby.
 Do not connect or disconnect any test equipment while the ignition is on or
the engine is running.
 Keep the test equipment dry, clean, free from oil, water or grease. Use a
mild detergent on a clean cloth to clean the outside of the equipment as
necessary.
 Do not drive the vehicle and operate the test equipment at the same time.
Any distraction may cause an accident.
 Refer to the service manual for the vehicle being serviced and adhere to
all diagnostic procedures and precautions. Failure to do so may result in
personal injury or damage to the test equipment.
 To avoid damaging the test equipment or generating false data, make
sure the vehicle battery is fully charged and the connection to the vehicle
DLC is clean and secure.
 Do not place the test equipment on the distributor of the vehicle. Strong
electro-magnetic interference can damage the equipment.

Contents
SAFETY INFORMATION ............................................................................................ II
CHAPTER 1 USING THIS MANUAL ...................................................................... 1
1.1CONVENTIONS ............................................................................................... 1
1.1.1 B o l d Tex t ............................................................................................. 1
1.1.2 Terminology........................................................................................ 1
1.1.3 Notes and Important Messages ........................................................... 1
1.1.4 Hyperlinks........................................................................................... 1
1.1.5 Procedures .......................................................................................... 2
CHAPTER 2 GENERAL INTRODUCTION ............................................................... 3
2.1 MAXISYS MS906 DI SPL AY TABLET ..................................................................... 3
2.1.1 Functional Description ......................................................................... 3
2.1.2 Power Sources..................................................................................... 5
2.1.3 Technical Specifications....................................................................... 5
2.2 ACCESSORY KIT .............................................................................................. 6
2.2.1 Main Cable.......................................................................................... 6
2.2.2 OBD I Adapters.................................................................................... 7
2.2.3 Other Accessories................................................................................ 7
CHAPTER 3 GETTING STARTED ........................................................................... 9
3.1 POWERING UP............................................................................................... 9
3.1.1 Application Buttons............................................................................10
3.1.2 Locator and Navigation Buttons .........................................................11
3.1.3 System Status Icons ............................................................................12
3.2 POWERING DOWN .........................................................................................13
3.2.1 Reboot System....................................................................................13
3.3 INSTALLING COMPUTER SO F T WAR E ....................................................................14
3.3.1 Printing Operation..............................................................................14
CHAPTER 4 DIAGNOSTICS OPERATIONS............................................................16
4.1 ESTABLISHING VEHICLE COMMUNICATION ............................................................16
4.1.1 Vehicle Connection .............................................................................16
4.2 GETTING STARTE D..........................................................................................17
4.2.1 Vehicle Menu Layout ..........................................................................17
4.3 VEHICLE IDENTIFICATION..................................................................................19
4.3.1 Auto VIN Scan ....................................................................................20
4.3.2 Manual VIN Input...............................................................................21
4.3.3 Manual Vehicle Selection....................................................................22

4.3.4 Alternative Vehicle Identification ........................................................22
4.4 NAVIGATION .................................................................................................23
4.4.1 Diagnostics Screen Layout ..................................................................23
4.4.2 Screen Messages................................................................................26
4.4.3 Making Selections ..............................................................................26
4.5 MAIN MENU ................................................................................................27
4.6 DIAGNOSIS...................................................................................................27
4.6.1 ECU Information.................................................................................31
4.6.2 Read Codes ........................................................................................32
4.6.3 Erase Codes........................................................................................33
4.6.4 Live Data............................................................................................34
4.6.5 Active Test..........................................................................................40
4.6.6 Special Functions................................................................................41
4.7 SERVICE.......................................................................................................43
4.7.1 Function Descriptions .........................................................................43
4.8 GENERIC OBD II OPERATIONS ..........................................................................44
4.8.1 General Procedure..............................................................................44
4.8.2 Function Descriptions .........................................................................46
4.9 EXITING DIAGNOSTICS.....................................................................................49
CHAPTER 5 DATA MANAGER OPERATIONS........................................................50
5.1 OP E R AT I O N S .................................................................................................50
5.1.1 Image Files.........................................................................................50
5.1.2 PDF Files ............................................................................................52
5.1.3 Review Data .......................................................................................53
5.1.4 Apps Manager....................................................................................53
5.1.5 Data Logging......................................................................................54
CHAPTER 6 MAXIFIX OPERATIONS ....................................................................55
6.1 NAVIGATION .................................................................................................55
6.1.1 Terminology .......................................................................................57
6.2 OP E R AT I O N S .................................................................................................58
6.2.1 Home .................................................................................................59
6.2.2 Search Fix Features.............................................................................59
6.2.3 Ask.....................................................................................................59
6.2.4 My MaxiFix ........................................................................................60
6.2.5 My Messages .....................................................................................62
6.2.6 Support ..............................................................................................63
CHAPTER 7 SETTINGS OPERATIONS ..................................................................64
7.1 OP E R AT I O N S .................................................................................................64

7.1.1 Unit....................................................................................................64
7.1.2 Language ...........................................................................................65
7.1.3 Printing Setting ..................................................................................65
7.1.4 Notification Center .............................................................................65
7.1.5 Multitask............................................................................................66
7.1.6 About.................................................................................................66
7.1.7 System Settings ..................................................................................67
CHAPTER 8 SHOP MANAGER OPERATIONS .......................................................68
8.1 VEHICLE HISTORY ...........................................................................................69
8.1.1 Historical Test Record .........................................................................70
8.2 WORKSHOP INFORMATION...............................................................................71
8.3 CUSTOMER MANAGER ....................................................................................72
8.3.1 History Notes......................................................................................74
CHAPTER 9UPDATE OPERATIONS .....................................................................76
CHAPTER 10 REMOTE DESK OPERATIONS ...........................................................78
10.1 OP E R AT I O N S .............................................................................................78
CHAPTER 11 SUPPORT OPERATIONS...................................................................80
11.1 PRODUCT REGISTRATION ..............................................................................80
11.2 SUPPORT SCREEN LAYOUT ............................................................................81
11.3 MY ACCOUNT ...........................................................................................82
11.4 USER COMPLAINT ......................................................................................82
11.5 DATA LOGGING ..........................................................................................85
11.6 COMMUNITIES...........................................................................................86
11.7 TRAINING CHANNELS ..................................................................................88
11.8 FAQ DATABASE..........................................................................................89
CHAPTER 12 TRAINING OPERATIONS..................................................................90
CHAPTER 13 QUICK LINK OPERATIONS ...............................................................92
CHAPTER 14 MAINTENANCE AND SERVICE.........................................................93
14.1 MAINTENANCE INSTRUCTIONS .......................................................................93
14.2 TROUBLESHOOTING CHECKLIST ......................................................................94
14.3 ABOUT BATTERY USAGE ...............................................................................94
14.4 SERVICE PROCEDURES .................................................................................95
CHAPTER 15 COMPLIANCE INFORMATION..........................................................97
CHAPTER 16 WARRANTY ....................................................................................98

1
Chapter 1 Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional equipment
that are not included on your system. Contact your sales representative for availability
of other modules and optional tools or accessories.
1.1 Conventions
The following conventions are used.
1.1.1 Bold Text
Bold emphasis is used to highlight selectable items such as buttons and menu
options.
Example:
 Tap OK.
1.1.2 Terminology
The term “select” means highlighting a button or menu item and tapping it to
confirm the selection.
1.1.3 Notes and Important Messages
The following messages are used.
Notes
A NOTE provides helpful information such as additional explanations, tips,
and comments.
Important
IMPORTANT indicates a situation which, if not avoided, may result in damage
to the test equipment or vehicle.
1.1.4 Hyperlinks
Hyperlinks, or links, that take you to other related articles, procedures, and
illustrations are available in electronic documents. Blue colored text indicates
a selectable hyperlink.

Using This Manual Conventions
2
1.1.5 Procedures
An arrow icon indicates a procedure.
Example:
 To use the camera:
1 Tap the Camera button. The camera screen opens.
2 Focus the image to be captured in the view finder.
3 Tap the blue circle. The view finder now shows the captured picture
and auto-saves the taken photo.

3
Chapter 2 General Introduction
The MaxiSys® MS906 is an advanced diagnostic device developed for customers
looking for a tool with ultra-convenient and modern design while still delivering ultimate
performance. Featuring the powerful Samsung Exynos 5260 6-core processor (1.3
GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), and an 8.0 inch
LED capacitive touch screen, based on the multitasking operating system, and
combined with the best possible coverage of OE-level diagnostics, the MaxiSys MS906
is the ideal solution to manage your repair jobs smartly and conveniently with greater
integration.
This manual describes the construction and operation of the device and how it works to
deliver diagnostic solutions.
2.1 MaxiSys Display Tablet
2.1.1 Functional Description
Figure 2-1 MaxiSys Tablet Front View
1. 8.0” LED Capacitive Touch Screen
2. Power LED – indicates battery level & charging or system status
3. Vehicle Communication LED – flashes green when the display tablet is
communicating/linking with vehicle’s system
4. Ambient Light Sensor – detects ambient brightness
5. Microphone
The power LED displays differently in response to the 4 status below:

General Introduction MaxiSys Display Tablet
4
A. Charging (above 90%) – indicated by steady green light
B. Charging (below 90%) – indicated by steady yellow light
C. Low Battery (below 15%) – indicated by steady red light
D. System Failure – indicated by steady blue light
Figure 2-2 MaxiSys Tablet Back View
1. Camera Lens
2. Camera Flash
Figure 2-3 MaxiSys Tablet Top View
1. Mini SD Card Slot - holds the mini SD Card
2. DC Power Supply Input Port - Connects the 12 volt power adapter to
charge
3. DB15-Pin Port - connects the vehicle DLC cable
4. USB-B Port
5. Lock/Power Button – turns the device on & off with long press, or locks
the screen with short press

General Introduction MaxiSys Display Tablet
5
2.1.2 Power Sources
The display tablet can receive power from any of the following sources:
 Internal Battery Pack
 AC/DC Power Supply
 Vehicle Power
Internal Battery Pack
The display tablet can be powered with the internal rechargeable battery,
which if fully charged can provide sufficient power for about 6 hours of
continuous operation.
AC/DC Power Supply
The display tablet can be powered from a wall socket using the AC/DC power
adapter. The AC/DC power supply also charges the internal battery pack.
Vehicle Power
The display tablet can be powered from the cigarette lighter or other suitable
power port on the test vehicle through a di rect cable connection. The vehicle
power cable connects to the DC power supply port on the top side of the
display unit.
2.1.3 Technical Specifications
Item Description
Operating System AndroidTM 4.4.2, KitKat
Processor
Samsung T5260 6-Core Processor
(1.3 GHz
quad-core ARM Cortex-A7 + 1.7 GHz dual-core
ARM Cortex-A15)
Memory 2GB RAM & 32GB ROM
Display
8.0
inch LED capacitive touch screen with
1024x768P resolution
Connectivity
 Wi-Fi (802.11 b/g/n)
 DB16 DLC
 USB-B 2.0
Camera (rear)
Rear-facing, 8.0 Megapixel, AF with Flashlight

General Introduction MaxiSys Display Tablet
6
Item Description
Sensors
Gravity Accelerometer, Ambient Light Sensor
(ALS)
Audio Input/Output
 Microphone
 Single Speakers
Power and Battery
 5000 mAh 3.7 V lithium-polymer battery
 Charging via 12 V AC/DC power supply
Input Voltage
12 V (9-35 V)
Power Consumption
5 W
Operating
Temperature
-10 to 55°C (14 to 131°F)
Storage Temperature
-20 to 70°C (-4 to 158°F)
Housing
Strong plastic housing with protective rubber boot
Dimensions (
W x H x D
)
270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0mm
(1.4”)
Weight
NW: 0.96 kg (2.12 lb.),
Protocols
ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L lins,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, CAN ISO 11898, Highspeed, Middlespeed,
Lowspeed and Singlewire CAN, GM UART, UART
Echo Byte Protocol, Honda Diag-H Protocol, TP
2.0, TP 1.6, SAE J1939, SAE J1708,
Fault-Tolerant CAN
2.2 Accessory Kit
2.2.1 Main Cable
The display tablet can be powered through the Main Cable when connected to
an OBD II/EOBD compliant vehicle. The Main Cable connects the display
tablet to the vehicle’s data link connector (DLC).

General Introduction Accessory Kit
7
Figure 2-4 Main Cable – 1.7 m in length
2.2.2 OBD I Adapters
The OBD I adapters are for Non-OBD II vehicles. The adapter used depends
on the type of vehicle make being tested. The most common adapters are
shown below.
Benz-14 Chrysler-16 BMW-20 Kia-20
Nissan-14 GM/Daewoo-12 Honda-3 VW/Audi-2+2
Mitsubishi/
Hyundai -12+16 Benz-38 PSA-2 Fiat-3
2.2.3 Other Accessories
AC/DC External Power Adapter
Connects the display tablet to the external DC power
port for power supply.

General Introduction Accessory Kit
8
Compact Disc (CD)
Includes the User Manual, Printing Services Program
etc.
Cigarette Lighter
Provides power to the display tablet through
connection to the vehicle’s cigarette lighter receptacle,
as some non-OBD II vehicles cannot provide power
via the DLC connection.
Clipper Cable
Provides power to the display tablet through
connection to the vehicle battery as some non-OBD II
vehicles cannot provide power via DLC connection
Lighter Fuse
A safety device for the cigarette lighter.

9
Chapter 3 Getting Started
Make sure the display tablet has a charged battery or is connected to the DC power
supply (see 2.1.2 Power Sources on page 5).
3.1 Powering Up
Press the Lock/Power button on the top right side of the display tablet to
switch the unit on. The system boots up, and shows the lock screen. Press
and drag the inner ring to the edge of the circle to unlock the screen; the
MaxiSys Job Menu is shown.
Figure 3-1 Sample MaxiSys Job Menu
1. Application Buttons
2. Locator and Navigation Buttons
3. Status Icons
NOTE: The screen is locked by default when you first turn on the display tablet.
It is recommended to lock the screen to protect information in the system and
reduce battery usage.
Almost all operations on the display tablet are controlled through the touch
screen. The touch screen navigation is menu driven, which allows you to
quickly locate the test procedure, or data that you need, through a s eries of
choices and questions. Detailed descriptions of the menu structures are found
in the chapters for the various applications.

Getting Started Powering Up
10
3.1.1 Application Buttons
The Application buttons configure the MaxiSys for the type of operation or
activity to be performed. The table below gives brief descriptions of the
available applications.
Use your finger tip to select an application from the Job Menu.
Table 3-1 Applications
Name Button Description
Diagnostics
Configures the unit to operate as a d iagnostic
tool. See Diagnostics Operations on page 16.
Data
Manager
Opens the organization system for saved data
files. See Data Manager Operations on page 50.
MaxiFix
Launches the MaxiFix platform which provides the
most compatible and abundant repair techniques
and diagnostics database. See MaxiFix
Operations on page 55.
Settings
Allows you to set the MaxiSys system settings,
and to view the general
information about the
Display Tablet. See Settings Operations on page
64.
Shop
Manager
Allows you to edit and save workshop information
and customer data, as well as reviewing test
vehicle history records. See
Shop Manager
Operations on page 68.
Update
Checks for the
latest update available for the
MaxiSys system, and performs updating
procedures. See Update Operations on page 76.
Remote
Desk
Configures your unit to receive remote support
using the TeamViewer application program. See
Remote Desk Operations on page 78.

Getting Started Powering Up
11
Name Button Description
Support
Launches the Support platform which
synchronizes Autel’s on-line service base station
with the MaxiSys tablet. See Support Operations
on page 80.
Training
Allows you to store and play technical tutorial and
training videos about the device usage or vehicle
diagnostic techniques. See Training Operations
on page 90.
Quick Link
Provides associated website bookmarks to allow
quick access to product update, service, support
and other information. See Quick Link Operations
on page 92.
3.1.2 Locator and Navigation Buttons
Operations of the Navigation buttons at the bottom of the screen are described
in the table below:
Table 3-2 Locator and Navigation Buttons
Name Button Description
Locator
Indicates the location of the screen. Swipe the
screen left or right to view the previous or next
screen.
Back Returns to the previous screen.
Home Returns to Android System’s Home screen.
Recent Apps
Displays a list of applications that are currently
working. To open an app, touch it. To remove
an app, swipe it to the right.
Chrome Launches the Chrome browser.
Camera
Opens the camera with short press; takes and
saves screenshot image with long press. The
saved files are auto-
stored in the Data
Manager application for later reviews. See
Data Manager Operations on page 50.

Getting Started Powering Up
12
Name Button Description
Display & Sound Allows you to adjust the brightness of the
screen and the volume of the audio output.
MaxiSys
Shortcut
Returns to the MaxiSys operation interface
from other Android applications.
Multi Task
Tapping this button will open up a Multi Task
menu, on which displays the bookmarks of the
active application
s. Tapping a specific
bookmark enables you to switch directly to the
selected application screen.
 To use the camera:
1. Tap the Camera button. The camera screen opens.
2. Focus the image to be captured in the view finder.
3. Tap the inner blue circle. The view finder now shows the captured
picture and auto-saves the taken photo.
4. Tap the thumbnail image on the top right corner of the screen to
view the stored image.
5. Tap the Back or Home button to exit the camera application.
Refer to Android documentation for additional information.
3.1.3 System Status Icons
These are the standard status icons of the Android operating system. Your
display tablet is a fully functional Android Pad. Refer to Android
documentation for additional information.
By tapping on this area (bottom right corner), a S hortcuts Panel will be
displayed, on which you are allowed to set various system settings of the
tablet. Operations of each button on the panel are described in the table
below:
Table 3-3 Shortcuts Panel Buttons
NOTE: The shortcuts buttons will be highlighted when enabled, and dimmed
when disabled.

Getting Started Powering Down
13
Name Button Description
Calculator Launches calculator when pressed.
Clock Launches clock when pressed.
Wi-Fi Enables/disables Wi-Fi when pressed.
Torch Turns on/off the torch when pressed.
Auto Rotate Enables/disables auto-rotate screen when
pressed.
Airplane Mode
Enables/disables Airplane Mode when
pressed.
System Settings
Launches the Android System Settings
interface when pressed.
3.2 Powering Down
All vehicle communications must be terminated before shutting down the
display tablet. A warning message displays if you attempt to shut down while
the display tablet is communicating with the vehicle. Forcing a shut down while
communicating may lead to ECM problems on some vehicles. Exit the
Diagnostics application before powering down.
 To power down the display tablet:
1. Press and hold the Lock/Power Button.
2. Tap Power off option.
3. Tap OK; the tablet will turn off in a few seconds.
3.2.1 Reboot System
In case of system crash, press and hold the Lock/Power button for 8 seconds
to reboot the system.
