Avaya 4610 User manual

15-601124 Issue 05a - (16 July 2009)
4610/5610 Phone User Guide
IP Office

4610/5610 Phone Page 2
15-601124 Issue 05a (16 July 2009)IP Office
© 2009 AVAYA All Rights Reserved.
Notice
While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of
printing, Avaya Inc. can assume no liability for any errors. Changes and corrections to the information in this document may be
incorporated in future releases.
Documentation Disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to the original published version of this
documentation unless such modifications, additions, or deletions were performed by Avaya.
Link Disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web sites referenced elsewhere within this
Documentation, and Avaya does not necessarily endorse the products, services, or information described or offered within
them. We cannot guarantee that these links will work all of the time and we have no control over the availability of the linked
pages.
License
USE OR INSTALLATION OF THE PRODUCT INDICATES THE END USER’S ACCEPTANCE OF THE TERMS SET FORTH
HEREIN AND THE GENERAL LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE AT
http://support.avaya.com/LicenseInfo/ (“GENERAL LICENSE TERMS”). IF YOU DO NOT WISH TO BE BOUND BY THESE
TERMS, YOU MUST RETURN THE PRODUCT(S) TO THE POINT OF PURCHASE WITHIN TEN (10) DAYS OF DELIVERY
FOR A REFUND OR CREDIT.
Avaya grants End User a license within the scope of the license types described below. The applicable number of licenses and
units of capacity for which the license is granted will be one (1), unless a different number of licenses or units of capacity is
specified in the Documentation or other materials available to End User. “Designated Processor” means a single stand-alone
computing device. “Server” means a Designated Processor that hosts a software application to be accessed by multiple users.
“Software” means the computer programs in object code, originally licensed by Avaya and ultimately utilized by End User,
whether as stand-alone Products or pre-installed on Hardware. “Hardware” means the standard hardware Products, originally
sold by Avaya and ultimately utilized by End User.
License Type(s): Designated System(s) License (DS).
End User may install and use each copy of the Software on only one Designated Processor, unless a different number of
Designated Processors is indicated in the Documentation or other materials available to End User. Avaya may require the
Designated Processor(s) to be identified by type, serial number, feature key, location or other specific designation, or to be
provided by End User to Avaya through electronic means established by Avaya specifically for this purpose.
Copyright
Except where expressly stated otherwise, the Product is protected by copyright and other laws respecting proprietary rights.
Unauthorized reproduction, transfer, and or use can be a criminal, as well as a civil, offense under the applicable law.
Third-Party Components
Certain software programs or portions thereof included in the Product may contain software distributed under third party
agreements (“Third Party Components”), which may contain terms that expand or limit rights to use certain portions of the
Product (“Third Party Terms”). Information identifying Third Party Components and the Third Party Terms that apply to them is
available on Avaya’s web site at: http://support.avaya.com/ThirdPartyLicense/
Avaya Fraud Intervention
If you suspect that you are being victimized by toll fraud and you need technical assistance or support, call Technical Service
Center Toll Fraud Intervention Hotline at [phone] for the United States and Canada. Suspected security
vulnerabilities with Avaya Products should be reported to Avaya by sending mail to: [email protected].
For additional support telephone numbers, see the Avaya Support web site (http://www.avaya.com/support).
Trademarks
Avaya and the Avaya logo are registered trademarks of Avaya Inc. in the United States of America and other jurisdictions.
Unless otherwise provided in this document, marks identified by “®,” “™” and “SM” are registered marks, trademarks and
service marks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners.
Documentation information
For the most current versions of documentation, go to the Avaya Support web site (http://www.avaya.com/support) or the IP
Office Knowledge Base (http://marketingtools.avaya.com/knowledgebase/).
Avaya Support
Avaya provides a telephone number for you to use to report problems or to ask questions about your contact center. The
support telephone number is 1 800 628 2888 in the United States. For additional support telephone numbers, see the Avaya
Web site: http://www.avaya.com/support.

4610/5610 Phone Page 3
15-601124 Issue 05a (16 July 2009)IP Office
Contents
Contents
The Telephone1. ..................................................................... 91.1 Call Appearance Keys
..................................................................... 101.2 Call Appearance Key Icons
..................................................................... 101.3 System Features
..................................................................... 111.4 Logging On
..................................................................... 111.5 Logging Off
..................................................................... 121.6 No User ..................................................................... 121.7 The Display
Basic Call Handling Features2. ..................................................................... 142.1 Answering a Call
..................................................................... 152.2 Making a Call
..................................................................... 152.3 Clearing a Call
..................................................................... 162.4 Headset Working
..................................................................... 172.5 Speakerphone
..................................................................... 182.6 Speed Dial..................................................................... 182.7 Redial ..................................................................... 192.8 Mute ..................................................................... 192.9 Hold ..................................................................... 202.10 Transfer ..................................................................... 212.11 Conference
Using Speed Dials3. ..................................................................... 243.1 Overview of Speed Dials
..................................................................... 253.2 Dialling a Speed Dial Number
..................................................................... 253.3 Adding a Speed Dial from the Call Log
..................................................................... 253.4 Editing a Speed Dial
..................................................................... 253.5 Deleting a Speed Dial
..................................................................... 263.6 Adding a New Speed Dial
Using the Call Log4. ..................................................................... 304.1 Overview of the Call Log
..................................................................... 314.2 Accessing the Call Logs
..................................................................... 314.3 Displaying an Individual Log Entry
..................................................................... 314.4 Making a Call from an Individual Log entry
..................................................................... 324.5 Turning a Log Entry into a Speed Dial
..................................................................... 324.6 Deleting an Individual Log Entry
..................................................................... 324.7 Deleting All Entries from a Log
..................................................................... 324.8 Exiting the Call Logs
Using Visual Voice5. ..................................................................... 345.1 Overview of Visual Voice
..................................................................... 355.2 Listen to Voicemails
..................................................................... 365.3 Send a Voicemail
..................................................................... 365.4 Voicemail Transfer
..................................................................... 375.5 Changing Your Greeting
..................................................................... 375.6 Changing Your Mailbox Password
..................................................................... 385.7 Email Alerts
Changing Options6. ..................................................................... 406.1 Personal Ringing
..................................................................... 406.2 Viewing IP Settings
..................................................................... 416.3 Displaying Contrast
..................................................................... 416.4 Changing Key Labels
..................................................................... 426.5 Displaying Language Selection
..................................................................... 426.6 Phone Screen on Answer
..................................................................... 436.7 Phone Screen on Calling
..................................................................... 436.8 Display Call Timers
..................................................................... 436.9 Message Display Rate
..................................................................... 436.10 Visual Alerting
Function Keys7. ..................................................................... 467.1 Overview of the Function Keys
..................................................................... 477.2 Function Key Programming
..................................................................... 497.3 Shorthand Programming Mode
..................................................................... 507.4 Longhand Programming Mode
System Features8. ..................................................................... 528.1 Introduction
..................................................................... 528.2 Call Waiting
..................................................................... 528.3 Call Forwarding
..................................................................... 538.4 Diverting Calls
..................................................................... 538.5 Do Not Disturb
..................................................................... 548.6 Parking Calls
..................................................................... 548.7 Private Call
..................................................................... 548.8 Ring Back ..................................................................... 558.9 Voicemail ..................................................................... 568.10 Default Feature Codes
Management and Troubleshooting9. ..................................................................... 589.1 Overview ..................................................................... 589.2 Testing Your Phone
..................................................................... 599.3 Troubleshooting Chart
...............................................................................61Index

4610/5610 Phone Page 5
15-601124 Issue 05a (16 July 2009)IP Office
The Telephone
Chapter 1.

4610/5610 Phone Page 7
15-601124 Issue 05a (16 July 2009)IP Office
The Telephone:
1. The Telephone
This guide covers the use of the 4610 and 5610 phones on IP Office. These phones are physically similar, however the
5610 is only supported on the IP Office whereas the 4610 is supported on a range of Avaya phone systems.
The diagram below shows the main phone features:
1. Display, Call Appearance and Feature Buttons:
The Call Appearance keys allow you to handle multiple calls with the display showing call information. There are 4
pages in the display; giving up to 24 system features that can be allocated to the function keys. The information
displayed varies according to the active feature.
2. Message Waiting Lamp: Used as follows:
·On (Continuous): There are new messages in your voicemail mailbox, or in another mailbox for which you
have been configured to receive "Message Waiting Indication".
·Flashing: The lamp can also be set to flash when the phone receives a call. See Visual Alerting .
3. Softkeys:
Used to navigate to or initiate certain features, such as Speed Dial or Call Log, as well as control certain actions
within the features. These keys correspond to the text prompts in the display screen immediately above them.
4. Page Right/Left:
Shifts from one page to another in the same application when the display presents the paging indicator ( ). These
buttons have no effect when the paging indicator is not displayed.
5. Options:
Displays the Options main screen, from which display and application settings can be updated
6. Call Handling Buttons:
·HOLD: Red button used to place a call on hold.
·TRANSFER: Transfers a call to another phone.
· CONFERENCE: Sets up conference calls with more than one other person.
· DROP: Drops the current call or, if on a conference call, drops the last person to join the conference.
·REDIAL: Redials the last number dialed or displays the last 6 numbers dialed from the phone, depending
on configuration via the Options menu.
7. Numeric (dialling) Pad:
Standard 12 button pad for dialling phone numbers.
8. Volume Controls:
Adjusts the handset, speaker, headset, or ringer volume, depending on which item is in use. As you increase or
decrease the volume, the top display area provides either a speaker, headset, handset, or ringer icon to indicate for
which item you are adjusting volume, followed by a visual “volume meter” showing the volume level. These buttons
also control the volume of the key click sounds made when you press fixed buttons on the phone, such as the dial
pad or soft keys.
9. MUTE:
43

4610/5610 Phone Page 8
15-601124 Issue 05a (16 July 2009)IP Office
Turns off the active speaker, handset, or headset microphone to prevent the other person from hearing you. The
associated LED lights steadily when the handset or headset is muted.
10. HEADSET:
With a headset connected, changes audio control from the handset or speaker to the headset. The associated LED
lights steadily when the headset is active.
11. Headset Jack:
Located on the side of the phone and provides a port for connecting a headset.
12. SPEAKER:
Access the speakerphone. The light associated with this button turns on when the speakerphone is active. Note that
while the speakerphone is active the handset is muted.
13. PHONE/EXIT:
Displays the phone application main screen or, if applicable, exits the current IP Office based feature, such as Speed
Dial or Call Log, and normalizes the display.

4610/5610 Phone Page 9
15-601124 Issue 05a (16 July 2009)IP Office
The Telephone:
1.1 Call Appearance Keys
Normally, the first page of the main call handling screen contains three keys set as 'call appearance' keys. These are
allocated to you by your system administrator and are indicated as a=, b= and c=.
Your system administrator can allocate a call appearance key with:
·A Bridged Appearance
A bridged appearance key matches the status and operation of the Call Appearance key on a pre-defined colleague’s
phone. Hence, you can pick-up, make and receive calls on behalf of your colleague.
·A Line Appearance
An IP Office exchange line (but not IP lines) can be allocated to you such that the status of that line is displayed and
you can use the line appearance key to make and receive calls.
·Call Coverage Appearance
A call coverage appearance key alerts you when a pre-defined colleague is receiving a call. The covered user does
not need to be using call appearance keys. Hence, you can pick-up calls on behalf of your colleague.
For details of Bridged, Line and Call Coverage Appearance Keys set-up and their operation, refer the IP Office Key and
Lamp Operation manual.
Having more than two Call Appearance keys is very useful. When holding a call, you can answer or make another call and
then switch between calls, transfer or conference. If you are set to receive call waiting indication, the waiting call is
shown against the next call appearance key.
Note
·If your phone is operating in single line mode, call appearance keys are not available.
Caution
·Although the system administrator can replace the Call Appearance keys with Bridged, Line and Call Coverage
Appearance keys, this would severely restrict the use of features such as conference and transfer.
It is for this reason that it is strongly recommended that all Call Appearance keys remain at their default
settings.

4610/5610 Phone Page 10
15-601124 Issue 05a (16 July 2009)IP Office
1.2 Call Appearance Key Icons
The icons displayed against the Call Appearance/Feature keys allow you to determine the status (for example, on HOLD)
of each call. Icons also indicate whether a feature has been activated for a particular button.
·Incoming Call:
A symbol next to a call appearance key indicates an incoming call. To answer the call and put any other current
call on hold, press the adjacent .
·Connected:
A symbol next to a call appearance key indicates that it is the currently connected call. The caller's phone number
(if available) is also shown. To put the call on hold, press the adjacent . An His displayed.
·On HOLD:
A symbol next to a call appearance key indicates a call on hold. To take the call off hold and put any other
current call on hold, press the adjacent .
·Function Active:
The feature is highlighted on the display.
1.3 System Features
System Features can only be set against soft function keys by your system administrator. However, your system
administrator may allocate you two ‘self administrator’ features that will enable you to add System Features to your soft
function keys. Refer to Overview of the Function Keys for details of the System Feature that can only be allocated
to you by your system administrator.
In addition, there are a number of System Features that you can always access yourself by the use of short codes.
Refer to System Features Introduction for details of System Features that you can always access yourself by
dialling short codes. For example, to listen to your voicemail messages, dial *17.
46
52

4610/5610 Phone Page 11
15-601124 Issue 05a (16 July 2009)IP Office
The Telephone: System Features
1.4 Logging On
Your administrator has created your initial configuration so that you will be automatically logged on to your home
extension. However, you may be required to log in for the following reasons:
·Forced login - if your configuration does not allow automatic login to your home extension.
·To use an extension other than your own (hot desking)
·If you, or somebody else, has logged you out of your extension.
Note
·When hot desking, any short codes you have setup on your home extension will be passed to the extension you have
logged on to.
·Certain information such as speed-dials and call log are telephone model dependent, and will not be passed to the
new extension.
·You will be able to hot desk to extensions on remote sites only if the Small Community Advanced Networking License
is installed on that system.
To login to your home extension (forced login), enter *35*P#, where 'P' is your login code.
To login at another extension (hot desking), enter *35*N*P#, where 'N' is your home extension number and 'P' is your
login code.
Note
·Your login code, if configured, will be supplied by your Administrator.
·You have 4 attempts at logging on. If you fail to logon correctly, the message "Invalid" will be shown on the main
display and you will hear the busy tone. If you fail all 4 attempts to log on, you must wait 90 seconds before any
login will be accepted, whether correct or not.
1.5 Logging Off
If you have been allocated a login code, you can log your phone off to prevent unauthorized use during an absence, or
for privacy purposes.
If you are logging off from another extension, the system will log you back in at your home extension, unless the force-
login option is set.
Caution
·Call Log entries and certain Speed Dial settings will remain on the extension even once you are logged out.
To log your phone off:
1. Press Options.
2. Press and then press Log off.
3. To un-register your phone from the IP Office, delete all Call Log entries and returns any options you may have
configured to their default values, press Yes.
4. To return to the Option menu, press No. Your phone remains logged on to the network and your Call Log and
options values remain unchanged.
To log back on:
·The display will show Ext.=xxx in the top row. Press #and enter your password (consult your system
administrator).

4610/5610 Phone Page 12
15-601124 Issue 05a (16 July 2009)IP Office
1.6 No User
The NoUser configuration will be used for extensions where the home user is not currently logged on, for example:
·The home user is logged on to another extension
·Forced login is enabled
An extension set as NoUser will display the name "NoUser" and the extension number.
If required, and you have been allocated a login code, you can logon using your extension number and login code. (see
Logging On )
Note
·Although internal calls may be made from an extension marked NoUser, normally calls cannot be received on that
extension.
1.7 The Display
B
Phone Locked:
Internal calls only.
D
Call Forwarding On:
See Call Forwarding .
G
In Group:
You can enable/disable group membership.
H
Held Call:
Shows the number of held calls. See HOLD .
N
Do Not Disturb On:
See Do Not Disturb .
NoUser
No User:
The extension is not currently logged on. see No User
O
Out of Hours:
This is displayed if one or more Hunt Groups is in "Out-of-Hours" mode.
P
Parked Calls:
Shows the number of parked calls.
T
Twinned:
The phone is being used as the twin of another phone.
DISC
Disconnected:
To end the call, press SPEAKER or replace the handset.
CONN
Connected:
You are on a call.
CONF
CONFERENCE Call:
You are part of a conference call, displayed on the left hand side of the display. See Conference Calls .
HELD
HELD:
You have been put on hold by the connected party.
ssss
Suppressed Code
When an account code is entered, the number you enter is displayed as "ssss" for security purposes.
11
52
19
53
12
21

4610/5610 Phone Page 13
15-601124 Issue 05a (16 July 2009)IP Office
Basic Call Handling Features
Chapter 2.

4610/5610 Phone Page 14
15-601124 Issue 05a (16 July 2009)IP Office
2. Basic Call Handling Features
2.1 Answering a Call
When a call arrives at your phone, you may hear a ringing tone and a blinking bell icon ( ) icon appears against the
associated call appearance key.
To answer calls at your own extension:
Do one of the following:
·If you are not active on another call, answer the call using your handset, headset, or speakerphone. See
Speakerphone .
·If you are active on a call already, place the active call on hold (see Hold ), and then answer the incoming call by
selecting the associated call appearance key.
·If the call appearance for the ringing call is not displayed on the current screen page, press PHONE/EXIT to
return to the first page of the Home screen. When you locate the call appearance for the ringing call, press the
corresponding call appearance button.
To answer a call at another extension:
You can answer from your own phone by using Call Pick-Up; lift your handset and dial:
·*30 to answer a call ringing anywhere.
·*31 to answer a call within your group.
·*32*201# to answer the call for a particular extension, in this example 201.
The default ring cadences are:
·Internal calls - single ring cadence.
·External calls - double ring cadence.
Notes
·If your phone rings for any longer than a specified period (15 seconds in default), any re-direction feature that you
have activated, such as voicemail or call forwarding, will come into effect.
·To redirect an incoming call, press DROP to redirect the call to Forward On No Answer (if set) or voicemail (if
available).
17
19

4610/5610 Phone Page 15
15-601124 Issue 05a (16 July 2009)IP Office
Basic Call Handling Features: Answering a Call
2.2 Making a Call
You can make calls from the phone using a variety of methods as follows:
To manually make a call:
1. Dial the required number on the key pad. Remember to include the required access code (for example; 9 for an
outside line) and listen to the progress of the call.
2. Adjust the speakerphone volume as necessary. To change the volume, press and . The eight volume levels
are displayed.
3. If the call is not answered, press SPEAKER or press DROP.
When the call is answered, either speak or pick up the handset and speak to the called party.
To automatically make a call:
Do any of the following:
·To have the phone dial the last number that you dialed, press REDIAL and then press .
·Access the Call Log and initiate a call to a specific entry.
·Access the Speed Dial List in your personal directory and initiate a call to a specific entry. See Dialling a Speed Dial
Number .
When the call is answered, either speak or pick up the handset and speak to the called party.
2.3 Clearing a Call
To clear an established call:
Either
·Replace the handset.
or
·Press DROP.
25

4610/5610 Phone Page 16
15-601124 Issue 05a (16 July 2009)IP Office
2.4 Headset Working
When a headset is to be used on your phone, it must be plugged in to the headset socket on the base of the phone. To
activate the headset and switch off the handset, press HEADSET.The lamp beside the button is illuminated when
headset working is activated.
To answer an incoming call:
·Press HEADSET.
If you are already on a call:
1. Place the first call on hold
2. Press next to the flashing bell icon ( ).
To clear a headset call:
·Press DROP.
To manually make a call:
·Press HEADSET.
·Dial the number. Remember to include the required access code (for example; 9 for an outside line) and listen to the
progress of the call.
To automatically make a call:
·Press HEADSET.
Then do any of the following:
·To have the phone dial the last number that you dialed, press REDIAL and then press .
·Access the Call Log and initiate a call to a specific entry.
·Access the Speed Dial List in your personal directory and initiate a call to a specific entry. See Dialling a Speed Dial
Number .
When the call is answered, speak to the called party.
25

4610/5610 Phone Page 17
15-601124 Issue 05a (16 July 2009)IP Office
Basic Call Handling Features: Headset Working
2.5 Speakerphone
The built-in two-way speakerphone allows you to make and answer calls without lifting your handset. Speakerphones
may not operate satisfactorily in every environment; such as in noisy locations. Note that while the speakerphone is in
use the handset is muted.
To make or answer a call without lifting the handset, or to use the speakerphone with any feature:
1. Press SPEAKER. The LED beside the button illuminates.
2. Make or answer the call, or access the selected feature.
3. Adjust the speakerphone volume if necessary. To change the volume, press and . The display shows the eight
volume levels.
To change from the speakerphone to the handset:
·Pick up the handset and talk.
To change from the handset to the speakerphone:
1. Press SPEAKER. The LED beside the button illuminates.
2. Hang up the handset.
To end a speakerphone call:
·Press SPEAKER again. The LED beside the button goes out.

4610/5610 Phone Page 18
15-601124 Issue 05a (16 July 2009)IP Office
2.6 Speed Dial
The Speed Dial feature allows you to have the phone automatically dial calls to phone numbers stored in your personal
directory. See Dialling a Speed Dial Number .
To make a call to a personal directory entry using the Speed Dial feature:
1. From the Home screen, press SpDial. The Speed Dial screen is displayed.
2. Press the button next to the entry you want to call.
3. If the entry you want is not displayed, press and to search through the entries or key the first letter of the
required name to jump to the page with a matching entry.
The phone dials the number for you.
2.7 Redial
The Redial feature automatically redials a previously dialed extension or outside number (up to 24 digits). If you have
dialed the same number twice in succession, it will only have one appearance in the redial list.
To redial a previously dialed number:
·Press REDIAL; up to three numbers are shown. Press the adjacent to the required number.
To redial the last dialed number:
·Press REDIAL twice.
To change REDIAL:
1. Press OPTIONS and then press Application Options.
2. Press REDIAL. It will toggle between Last Number and Last 3 Numbers.
3. Press Save.
25

4610/5610 Phone Page 19
15-601124 Issue 05a (16 July 2009)IP Office
Basic Call Handling Features: Redial
2.8 Mute
During an active call, the Mute feature prevents the party with whom you are speaking from hearing you. This feature is
most commonly used in conjunction with the Speakerphone, but can be used to hold an off-line conversation at any time
during a call.
To prevent the other person on the line from hearing you:
1. Press MUTE. The other party cannot hear you. The indicator next to the MUTE button lights when mute is
active.
2. To reinstate two-way conversation, press MUTE again.
2.9 Hold
If, with a call in progress, a second call arrives and is shown against a Call Appearance key, you can then hold the first
call and answer the second call.
To put an existing call on hold:
1. Press HOLD or press with against it. changes to ; showing that the line is on hold.
2. To answer the second call, press with against it. changes to ; showing that the line is connected.
To return to the held call:
1. If you have a call in progress, then first put that call on hold (as above).
2. To retrieve a held call, press with against it.
Notes
·After a pre-set time (defined by your system administrator), you are reminded that you have a call on hold by
changing for a few moments to and the phone ringing.
·If the system feature AutoHOLD is on (consult your system administrator) then you can hold an active call ( ) by
pressing the second call’s Call Appearance button ( ). If AutoHold is off, then pressing the second call’s Call
Appearance button ( ) will drop the first call.
·To transfer a held call see Transfer .
20

4610/5610 Phone Page 20
15-601124 Issue 05a (16 July 2009)IP Office
2.10 Transfer
This feature allows you to transfer a call from your phone to another extension or outside number.
1.With a call in progress, press TRANSFER.
2.When you hear dial tone, dial the number to which the call is to be transferred. Then do one of the following:
·To transfer the call without announcing it (an unsupervised transfer), press TRANSFER again. The
transfer is complete.
·To announce the call before transferring it (a supervised transfer), wait for the called party to answer:
·If the called party is willing to accept the call, press TRANSFER again to complete the transfer.
·If the called party does not wish to accept the call or there is no answer, press DROP. To return to
the held call, press adjacent to it.
