CP-SP-1217E
Quick Reference Guide for Model C25/26
This guide offers a summary of key operations, parameter flowcharts, and settings, for convenient reference
at the operation site. This guide is made for repeated use. Dirt wipes off easily and even notes written with an
oil-based felt-tip pen can be removed with an eraser. If more detailed information on model C25/26 is needed,
refer to the user's manuals: CP-SP-1149E for installation and configuration.
The most convenient way to configure the C25/26 is with the Smart Loader Package (model No. SLP-C35J50).
Please contact the azbil Group or a distributor for more information.
Upper display
Lower display
Indicator during AT
Loader connector
Mode indicator
Mode
indicator
[mode] key
[para] key
Various indicators
[para] key
[display] key
[enter] key
[display] key
[enter] key
Loader connector
[mode] key
[<], [ ], and [ ] keys
Upper display
Lower display
Multi-Status (MS) display
[<], [ ], and [ ] keys
Upper display This display shows either the PV value or the display value and set value for each displayed item. If an alarm is triggered, the
normal display and alarm code are displayed alternately. During auto tuning (AT), the rightmost decimal point flashes twice
repeatedly.
Lower display This display shows either the SP/MV/CT or the display value and set value for each displayed item. The rightmost decimal
point lights up or flashes to show RUN/READY mode or communications status, depending on the setting.
Multi-Status (MS) display Turns ON in READY mode or when an alarm occurs, depending on the ON conditions and the current status. When lit, in ad-
dition to flashing and reciprocating between left and right, it performs MV graph, DI monitor, internal event monitor, and
other display functions.
Mode indicators man: Lights when MANUAL (AUTO mode if not lit)
ev1, ev2, ev3: Lights when event relays are ON
ot1, ot2: Lights when the control output is ON (always lit when the current output is used)
[mode] key • When this key is pressed and held for more than 1 second in the operation display mode, any of the following operations
from 0 to 7 which have been set previously can be executed:
0 : Mode key does not operate
1 : AUTO/MANUAL mode selection (Initial value)
2 : RUN/READY mode selection
3 : AT (Auto Tuning) start/stop selection
4 : LSP (Local SP) group selection
5 : Release all DO (Digital Output) latches
6 : Mode key does not operate
7 : ON/OFF selection of communication DI1
[display] key This key is used to change the display item in the operation display mode.
When pressing this key in the bank selection, bank setup, or user function setup display mode, the display is changed ot the
operation display.
[para] key When this key is kept pressed for 2 s. or longer in the operation display mode, the display is then changed to the setup
display.
[<], [ ] , [ ] keys Theses keys are used to increase or decrease the numeric value, or to shift the digit.
The [ ] and [ ] keys are used to change the bank or display item.
[enter] key This key is used to begin changing settings (display goes from lit to flashing) and to finalize new settings (display goes from
flashing to steadily lit).
Loader connector This connector is used for connecting to a PC using the dedicated cable supplied with the Smart Loader Package.
: Initial value
(Not for use in Japan)

2
Flowchart of key operations and displays
[display] key
[para] key
[display] key
2-second press + hold
of [para] key
[display] key *2
PV value
SP value
(2) (1)
LSP group
number
SP value
PV value
MV value
Timer remaining
time 3
Internal event 3
delay time
[display] key *3
Heat manipulated
variable
MV value
Internal event 3
sub setting
Setting value
Internal event 3
main setting
Setting value
[para] key
*1
[para] key
or
[] key
[enter] key 2-second
press + hold
of [para] key
[] key
[enter] key
(AUTO)
For change
from MANUAL
to AUTO
to (2)
(MANUAL)
For change
from AUTO to
MANUAL
to (1)
User
function
[Mode] [SP] [Event] [PID] [Parameter] [ Extended tuning ]
2-second press +
hold of [para] key
Upper and lower
displays remain off for
5s after power ON. Each
mode indicator lights
sequentially, and then the
operation display appears.
When the power
is turned ON

3
Analog inputControl actions
SPContinuous outputs
CommunicationsKey operations and displays
Some items are not displayed depending on the availability of optional functions, model number,
display setup (C73 to C78) and User level (C79).
Pressing [display] key while bank item or user function item is displayed has the effect of canceling
and returning to the operation display item.
*1 The parameters and numerical values registered as user functions UF are displayed.
*2 If no key is pressed for 3 minutes, the display automatically returns to 2, the basic display.
*3 If the [<] key is pressed while holding down the [para] key, various displys/settings can be
navigated in reverse order.
*4 Cannot be selected if ROM version 1 (id02) of the instrument information bank is 2.26 or earlier.
Explanation of arrows
[display] key :
[para] key, [ ] key, [para] key or [ ] key :
[enter] key :
Movement through each setup menu
• [ ] key
• [para] key or [ ] key
Bank selection
Operation displays
Timer remaining
time 2
Internal event 2
delay time
Cool manipulated
variable
MV value
Internal event 2
sub setting
Setting value
PV value
AT progress
value
Internal event 2
main setting
Setting value
CT1
Current value
Timer remaining
time 1
Internal event 1
delay time
CT2
Current value
Internal event 1
sub setting
Setting value
Internal event 1
main setting
Setting value
[display] key
[enter] key 2-second
press +
hold of
[para] key
[para] key
or
[] key
[] key
[Setup] [ Event configuration ] [ DI assignment ] [DO assignment] [User function] [Lock] [ Instrument information ]
*4
*4

4
Setup of PV input range type
1Press [display] once
to get the operation
display.
If the sensor has not been
wired or is disconnected,
an alarm for abnormal PV
input (any one from AL0 1
to AL 11) may appear on
the upper display.
2Press and hold [para]
for more than 2s to get
the parameter setup
display.
MOde flashes on the
upper display.
3Press [ ] or [ ] repeat-
edly, and Stup flashes
on the upper display.
4Press [enter].
The current set value
for C0 1(PV input
range type) is
displayed.
5Press [enter].
The rightmost digit on the lower display flashes and its value
can be changed.
Press [<], [ ] or [ ] to change to the desired sensor type in the
PV input range list.
Then press [enter] to finalize your selection.
If the number is flashing, the [enter] key has not yet been
pressed, and the setting has not yet been saved.
Setup of event operation type
In this example, the event 1 operation type is set to deviation high
limit.
1Press [display] once
to get the operation
display.
2Press and hold [para]
for more than 2s to get
the parameter setup
display.
MOde flashes on the
upper display.
3Press [ ] or [ ] repeat-
edly to get evCf
flashing on the upper
display.
4Press [enter] to get
e1.c 1on the upper
display and 0is dis-
played on the lower
display.
0on the lower display indi-
cates that the event opera-
tion type is set to "none."
5When [enter] is
pressed, the rightmost
digit on the lower dis-
play flashes.
Press [ ] or [ ] to get 4
flashing on the display.
4on the lower display
indicates that the event
operation type is set for
deviation high limit.
6Press [enter], and the
displayed value 4
on the lower display
changes from flashing
to continuously lit and
the displayed value
is set.
Similarly, use e2.C 1to set the event 2 operation type, and use
e3.C1for event 3.
Red letters : Items before operation
Blue letters : Items during operation
Execution of auto tuning (AT)
AT forces ON/OFF of the MV a number of times (a limit cycle) to cal-
culate PID values.
Check that this operation does not create any problems for the as-
sociated equipment before executing AT.
1Press [display] once
to get the operation
display.
2
Press and hold [para]
for more than 2s to get
the parameter setup
display.
MOde
flashes on the
upper display.
3Press [enter] or [<]
to get A--M on the
upper display and
autO on the lower
display.
If the control method is
ON/OFF control and if Bit
3 (AT stop/start display) of
the mode display setting
(C73) is set to "disabled: 0,"
nothing is displayed.
4Press [ ] as needed
until At and at.Of
appear on the upper
and lower displays
respectively.
5When [enter] is
pressed, at.Of flashes
on the lower display.
The display flashes only
in RUN and AUTO modes,
and only if there is no PV
problem.
Also, if DI is set to "AT stop/
start", the display does not
flash and the setting can-
not be changed.
6Press [ ] or [ ] once,
and at.Of flashes on
the lower display.
7If [enter] is pressed, at.ON remains steadily lit and AT begins.
During AT, the rightmost decimal point flashes twice repeat-
edly.
When AT is done, the light goes off and the new PID values
go into effect.
During the AT process, if the mode is changed to READY or MANUAL, if PV
input is faulty, or if a power failure occurs, AT stops automatically without
changing the PID values.
AT can also be stopped by changing the setting from At.ON to At.OF (return
to step 4 above).
Setup of SP value
1Press [display] re-
peatedly so that the
orange SP indicator
lights up on the lower
display.
The operation display
now shows the SP.
2If [enter] is pressed,
the rightmost digit
on the lower display
flashes and numerical
value can be changed.
3Press [<], [ ] or [ ] to
change to the desired
SP value.
The flashing of the
number indicates that
the setting has not yet
been finalized.
If an SP limit is in effect, the
numerical value cannot be
changed to a value above
the limit. The SP limit must
be changed first.
4If [enter] is pressed,
the displayed value
is set and the display
changes from flashing
to continuously lit.
If the [display] key is
pressed without pressing
[enter] key, the status re-
turns to that of step 1.
Operation examples

5
For step numbers indicated in red like 5, the following precaution applies:
• If the key lock is set, the numerical value does not flash, and the value cannot be changed.
To change a numerical value, cancel the key lock first.
AUTO/MANUAL mode selection
1Press [display] once
to get the operation
display.
The [mode] key can be
used for 1 of 7 different
operations.
The initial (factory) set-
ting is "AUTO/MANUAL
selection".
2Press and hold [mode]
for more than 2s, Man
flashes on the lower
display.
If the control method is
set to "ON/OFF control"
and if the DI assignment
is "AUTO/MANUAL," the
display does not blink
and the setting cannot be
changed.
3When Man appears,
stop pressing [mode].
The MV is shown on
the lower display.
The rightmost digit of
the MV on the lower
display flashes and its
value can be changed.
4Press [<], [ ] or [ ] to
change to the desired
MV value.
Even while the num-
ber is flashing, the MV
is changed at the same
time that the number
is changed.
For the flashing MV in step 3, either bumpless transition (the same
value as before the change) or preset MANUAL value (the value set
in setup C20) can be selected (in setup C19, Output operation at
changing Auto/Manual).
Setup of PID value
1Press [display] once
to get the operation
display.
2Press and hold [para]
for more than 2s to get
the parameter setup
display. MOde flashes
on the upper display.
3
Press [ ] or [ ] re-
peatedly until
PID
is
flashing on the upper
display.
4When [enter] is
pressed, p-1 (for pro-
portional band of PID
group No. 1) is shown
on the upper display,
and the preset value
is shown on the lower
display.
If the control method is
"ON/OFF control," nothing
is displayed.
5
Press [enter].
The rightmost digit
on the lower display
flashes and its nu-
merical value can be
changed.
Press [<], [ ] or [ ] to
change to the desired
proportional band
setting.
The flashing of the
number indicates that
the setting change has
not yet been finalized.
6If [enter] is pressed,
the changed numeri-
cal value is set and
changes from flashing
to continuously lit.
The proportional band can
be set in a range from 0.1
to 999.9%.
Similarly, use i-1 to set the integral time (0 to 9999s), and d-1 to set
the derivative time (0 to 9999s).
Setup of event value
In this example, the event set value and hysteresis for the event 1
operation type is set to deviation high limit.
1Press [display] once
to get the operation
display.
2
Press and hold [para]
for more than 2s to get
the parameter setup
display.
MOde
flashes
on the upper display.
3Press [ ] twice or [ ]
repeatedly, and EV
flashes on the upper
display.
4Press [enter] to get e1
on the upper display
and 0is displayed on
the lower display.
0on the lower display indi-
cates that the event main
setting is "0".
5If [enter] is pressed,
the rightmost digit
on the lower display
flashes, and can be
changed.
Press [<], [ ] or [ ], and
change to the desired
value for event set
value. In this case, the
flashing of the numeri-
cal value implies that it
is not yet set.
6If [enter] is pressed,
the changed numeri-
cal value is set and
changes from flashing
to continuously lit.
Similarly, use e2 to set a value for event 2, and e3 to set a value
for event 3.
7To continue from this
point and set hyster-
esis as well, press [ ]
twice or [ ] repeatedly
to get E1.HY on the
upper display. The
lower display says 5.
5on the lower display
indicates that the event
hysteresis is "5".
8In the same way that
event settings were
changed, press [enter]
to make the number
flash, and then press
[<], [ ] or [ ] to change
to the desired setting
for hysteresis. After
that, press [enter] to
finalize the setting.
Similarly, use E2.HY to set a value for event 2, and E3.HY to set a
value for event 3.
Memo

6
List of operation displays
Display
Upper display: PV
Lower display: SP
Item Contents Initial
value
Setting
value
PV
SP
SP (Target value) SP low limit to SP high limit 0
LSP 1(
Display example )
LSP
LSP No.
(
1st digit: Value at the right end digit )
1 to LSP system group (Max. 8) 1
PV
MV
MV (Manipulated Variable) -10.0 to +110.0% Setting is enabled in MANUAL
mode (Numeric value flashed)

HEAt
Numeric value
Heat MV (Manipulated Variable) Setting is disabled.
-10.0 to +110.0%

COOL
Numeric value
Cool MV (Manipulated Variable) 
PV
At 1(
Display example )
AT progress display (1st digit=
Numeric value at right end digit)
Setting is disabled. 
Ct 1
Numeric value
CT current value 1 Setting is disabled. 
Ct2
Numeric value
CT current value 2 Setting is disabled. 
E1
Numeric value
Internal Event 1 main setting -1999 to +9999U or 0 to 9999U 0
E1.Sb
Numeric value
Internal Event 1 sub setting 0
t1.--(
Display example )
Numeric value
Timer remaining time 1 Setting is disabled.
Upper display: The distinction by ON delay or
OFF delay is displayed at the side location of“t1.”.

E2
Numeric value
Internal Event 2 main setting Same as Internal Event 1 main setting 0
E2.Sb
Numeric value
Internal Event 2 sub setting Same as Internal Event 1 sub setting 0
t2.--(
Display example )
Numeric value
Timer remaining time 2 Same as Timer remaining time 1 
E3
Numeric value
Internal Event 3 main setting Same as Internal Event 1 main setting 0
E3.Sb
Numeric value
Internal Event 3 sub setting Same as Internal Event 1 sub setting 0
t3.--(
Display example )
Numeric value
Timer remaining time 3 Same as Timer remaining time 1 
List of parameter setting displays
MOdE [Mode bank]
Display Item Contents Initial value Setting value
A--M AUTO/MANUAL AUTO: AUTO mode MAN: MANUAL mode AUTO
r--r RUN/READY RUN: RUN mode RDY: READY mode RUN
At AT stop/start At.OF: AT stop At.ON: AT start AT stop
dO.Lt Release all DO latches Lt.ON: Latch continue Lt.OF: Latch release
Latch continue
C.dI 1Communication DI1 dI .OF: OFF dI .On: ON OFF
SP [SP bank]
Display Item Contents Initial value Setting value
SP- 1to SP-4 SP (for LSP 1 to 4 ) SP low limit to SP high limit 0
Pid. 1to Pid.4 PID group No. (LSP 1 to 4) 1 to 4 1
Ev [Event bank]
Display Item Contents Initial value Setting value
E1to E5
Internal Event 1 to 5 main setting -1999 to +9999 or 0 to 9999 * 0
E1.Sb to E5.Sb
Internal Event 1 to 5 sub setting 0
E1.Hy to E5.Hy
Internal Event 1 to 5 hysteresis 0 to 9999 * 5
E1.On to E5.On 
Internal Event 1 to 5 ON delay time 0.0 to 999.9 or 0 to 9999 0
E1.OF to E5.OF 
Internal Event 1 to 5 OFF delay time 0
* The decimal point position varies by meeting the internal event operation type.
PI D[PID bank]
Display Item Contents Initial value Setting value
P- 1to P-4
Proportional band (PID1 to 4 group) 0.1 to 999.9% 5.0
I-1to I-4
Integration time (PID1 to 4 group) 0 to 9999s or 0.0 to 999.9s
(No integration control action when set at "0")
120
d- 1to d-4 Derivative time (PID1 to 4 group) 0 to 9999s or 0.0 to 999.9s
(No derivative control action when set at "0")
30
rE- 1to rE-4 Manual reset (PID1 to 4 group) -10.0 to +110.0% 50.0
OL- 1to OL-4 MV low limit (PID1 to 4 group) -10.0 to +110.0% 0.0
OH- 1to OH-4 MV high limit (PID1 to 4 group) -10.0 to +110.0% 100.0
P- 1C to P-4C
Cool-side proportional band (PID1
to 4 group)
0.1 to 999.9% 5.0
I-1C to I-4C Cool-side Integration time (PID1
to 4 group)
0 to 9999s or 0.0 to 999.9s
(No integration control action when set at "0")
120
d- 1C to d-4C Cool-side derivative time (PID1
to 4 group)
0 to 9999s or 0.0 to 999.9s
(No derivative control action when set at "0")
30
OL. 1C to OL.4C Cool-side MV low limit (PID1 to
4 group)
-10.0 to +110.0% 0.0
OH. 1C to OH.4C Cool-side MV high limit (PID1 to
4 group)
-10.0 to +110.0% 100.0
PARA [Parameter bank]
Display Item Contents Initial value Setting value
Control
CtrL Control method 0: ON/OFF control 1: Fixed PID 0 or 1
At. OL MV low limit at AT -10.0 to +110.0% 0.0
At. OH MV high limit at AT -10.0 to +110.0% 100.0
dI FF ON/OFF control differential 0 to 9999U 5
OFFS 
ON/OFF control operating point offset -1999 to +9999U 0
PV
FL PV filter 0.0 to 120.0s 0.0
rA PV ratio 0.001 to 9.999 1.000
bI PV bias -1999 to +9999U 0
Time proportional output
CyU Time proportional cycle unit 1 0 to 3 *10
Cy Time proportional cycle 1 5 to 120s or 1 to 120s *210 or 2
CyU2 Time proportional cycle unit 2 0 to 3 *10
Cy2 Time proportional cycle 2 5 to 120s or 1 to 120s *210 or 2
tP. ty 
Time proportional cycle mode 0: Controllability aiming type
1: Operation end service life aiming type (Only ON/
OFF operation within Time proportional cycle)
0 or 1
SP
SPU SP up ramp (U/min) 0.0 to 999.9U(No ramp when set at "0.0U") 0.0
SPd SP down ramp (U/min) 0.0
*1 0: Unit of "1s" 1: Fixed at 0.5s 2: Fixed at 0.2s 3: Fixed at 0.1s
*2 5 to 120s when output includes the relay output
U: Unit Maximum unit of Industrial volume in
PV range (°C, Pa,L/min, etc.)
: Essential parameters for PV measurement and control
: Basic parameters
: Required parameters when using optional functions
Et [Extended tuning bank]
Display Item Contents Initial value Setting value
At.ty AT type 0: Normal 1: Immediate response 2: Stable *10
JF.bd Just-FiTTER setting band 0.00 to 10.00 0.30
SP.LG SP lag constant 0.0 to 999.9 0.0
At-P AT Proportional Band adjust 0.00 to 99.99 1.00
At-I AT Integral time adjust 0.00 to 99.99 1.00
At-d AT Derivative time adjust 0.00 to 99.99 1.00
Ctr.A Control algorithm
0: PID(Conventional PID) 1: Ra-PID(High-performance PID) 0
JF.Ov 
Just-FiTTER assistance coefficient 0 to 100 0
*1 Normal = Standard control characteristics, Immediate response = Control characteristics that respond immediately to
external disturbance, Stable = Control characteristics having less up/down fluctuation of PV
List of setup setting displays
StUP [Setup bank]
Display Item Contents Initial value Setting value
Analog input
C0 1PV input range type For details, refer to the PV Input Range Table 88
C02 Temperature unit 0: Celsius (°C) 1: Fahrenheit (°F) 0
C03 Cold junction compensation
0: Performed (internal) 1: Not performed (external) 0
C04 Decimal point position 0: No decimal point
1 to 3: 1 to 3 digits below decimal point
0
C05 PV range low limit
When the PV input type is DC voltage/DC current,
-1999 to +9999U
0
C06 PV range high limit 1000
C07 SP low limit PV input range low limit to PV input range high
limit
0
C08 SP high limit 1000
C09 
PV square root extraction dropout 0.0 to 100.0% (PV square root extraction is not
performed when set at "0.0".)
0.0
Control action
C13 PID calculation adjustment
function *1
0: Enabled 1: Disabled 0
C14
Control action (Direct/Reverse) 0: Heat control (Reverse action)
1: Cool control (Direct action)
0
C15 Output operation at PV alarm 0: Control calculation is continued.
1: Output at PV alarm is output.
0
C16 Output at PV alarm -10.0 to +110.0% 0.0
C17 Output at READY (Heat) -10.0 to +110.0% 0.0
C18 Output at READY (Cool) -10.0 to +110.0% 0.0
C19 
Output operation at changing
AUTO/MANUAL
0: Bumpless transfer 1: Preset 0
C20 Preset MANUAL value -10.0 to +110.0%
0.0 or 50.0
C2 1Initial output type (mode) of
PID control
0: Auto 1: Not initialized 2: Initialized 0
C22 Initial output of PID control -10.0 to +110.0%
0.0 or 50.0
C26 Heat/Cool control 0: Not used 1: Used 0
C27 Heat/Cool 0: Normal 1: Energy saving 0
C28 Heat/Cool control dead zone -100.0 to +100.0% 0.0
C29 Heat/Cool change point -10.0 to +110.0% 50.0
SP
C30 LSP system group 1 to 4 1
C3 1SP ramp type 0: Standard 1: Multi-ram
2: Step operation When the power is turned ON
again, the step operation is stopped (READY)
3: Step operation When the power is turned ON
again, the step operation is reset
0
C32 SP ramp unit 0: 0.1U/s 1: 0.1U/min 2: 0.1U/h 1
C36 CT1 operation type 0: Heater burnout detection
1: Current value measurement
0
C37 CT1 output
0 to 1: Control output 1 to 2, 2 to 4: Event output 1 to 3 0
C38 CT1 measurement wait time 30 to 300ms 30
C39 CT2 operation type Same as CT1 0
C40 CT2 output Same as CT1 0
C4 1CT2 measurement wait time Same as CT1 30
Continuous output
C42 Control output 1 range 1: 4 to 20mA 2: 0 to 20mA 1
C43 Control output 1 type
0: MV 1: Heat MV 2: Cool MV 3: PV
4: PV before ratio, bias, and filter 5: SP 6: Deviation
7: CT1 current value 8: CT2 current value 9: Invalid
10: SP+MV 11: PV+MV
0
C44
Control output 1 scaling low limit -1999 to +9999U 0.0
C45
Control output 1 scaling high limit 100.0
C46 Control output 1 MV scalable
bandwidth
0 to 9999 (Valid when control output 1 type is 10 or 11) 200
C47 Control output 2 range Same as control output 1 1
C48 Control output 2 type Same as control output 1 3
C49
Control output 2 scaling low limit Same as control output 1 0
C50
Control output 2 scaling high limit Same as control output 1 1000
C5 1
Control output 2 MV scalable bandwidth Same as control output 1 200
C52 Auxiliary output range Same as control output 1 1
C53 Auxiliary output type Same as control output 1 3
C54
Auxiliary output scaling low limit Same as control output 1 0
C55
Auxiliary output scaling high limit Same as control output 1 1000
C56
Auxiliary output MV scalable bandwidth Same as control output 1 200
Communication
C64 Communication type
0: CPL 1: Modbus (ASCII format) 2: Modbus (RTU format) 0
C65 Station address
0 to 127 (Communication is disabled when set at "0".) 0
C66 Transmission speed (bps) 0: 4800 1: 9600 2: 19200 3: 38400 2
C67 Data format (Data length) 0: 7 bits 1: 8 bits 1
C68 Data format (Parity) 0: Even parity 1: Odd parity 2: No parity 0
C69 Data format (Stop bit) 0: 1 bit 1: 2 bits 0
C70 Communication minimum
response time
1 to 250ms 3
C7 1Key operation type 0: Standard type 1: Special type 0
C72 [mode] key function 0: Invalid 1: AUTO/MANUAL selection
2: RUN/READY selection 3: AT Stop/Start
4: LSP group selection 5: Release all DO latches
6: Invalid 7: Communication DI1 selection 8: Invalid
1
C73 MODE display setup
(Sum of the weighting)
Bit 0: AUTO/MANUAL display (Enabled: +1)
Bit 1: RUN/READY display (Enabled: +2)
Bit 2: Invalid
Bit 3: AT Stop/Start display (Enabled: +8)
Bit 4: Release all DO latches display (Enabled: +16)
Bit 5: Communication DI1 ON/OFF display (Enabled: +32)
Other invalid setting, 0, +4, +64, +128
255
C74 PV/SP display setup
(Sum of the weighting)
Bit 0: PV display (Enabled: +1)
Bit 1: SP display (Enabled: +2)
Bit 2: LSP group number display (Enabled: +4)
Other invalid setting, 0, +8
15
C75 MV display setup
(Sum of the weighting)
Bit 0: MV display (Enabled: +1)
Bit 1: Heat MV/cool MV display (Enabled: +2)
Bit 2: Invalid
Bit 3: AT progress display (Enabled: +8)
Other invalid setting, 0, +4
15
C76 
Event setting value display setup
(Operation display)
0: Not displayed
1: Set value of Internal event 1 is displayed
2: Set values of Internal event 1 to 2 are displayed
3: Set values of Internal event 1 to 3 are displayed
0
C77 
Event remaining time display setup
(Operation display)
0: Not displayed 1: Internal event 1 is displayed
2: Internal event 1 to 2 is displayed
3: Internal event 1 to 3 is displayed
0
C78 
CT input current value display setup
(Operation display)
0: Not displayed 1: CT1 current value is displayed
2: CT1 to 2 current values are displayed
0
C79 User level 0: Simple configuration 1: Standard configuration
2: High function configuration
1
List of parameters

7
Display Item Contents Initial value Setting value
Key operation • display
C80 LED monitor 0: Not used
1:
Flashing while data is sending through RS-485 communication.
2: Flashing while data is receiving through RS-485 communication.
3: Logical OR of all DI statuses 4: Flashing in READY mode
0
C8 1MS indicating lamp ON condi-
tion (1st priority)
0: Normally OFF 1: Normally ON 2 to 6: Internal event 1 to 5
7 to 9: Invalid 10 to 13: Undefined 14: MV1 15: MV2
16 to 17: Undefined 18 to 21: DI1 to 4 22 to 25: Undefined
26 to 30: Internal contact 1 to 5 31 to 33: Undefined
34 to 37: Communication DI 1 to 4 38: MANUAL 39: READY
40: Invalid 41: AT 42: During ramp 43: Undefined 44: Alarm
45: PV alarm 46: Undefined 47: [mode] key pressing status
48: Event output 1 terminal status
49: Control output 1 terminal status
39
C82 MS indicating lamp ON status
(1st priority)
0: lit 1: Slow flashing 2: Flashing twice
3: Fast flashing 4: Left to right 5: Right to left
6: Reciprocating between left and right 7: Deviation OK
8: Deviation graph 9: MV graph 10: Heat-side MV graph
11: Cool-side MV graph 12: Invalid 13: DI monitor
14:
Internal contact monitor 15: Internal event monitor
1
C83 MS indicating lamp ON condi-
tion (2nd priority)
Same as MS display, Condition (1st priority) 44
C84 MS indicating lamp ON status
(2nd priority)
Same as MS display, Status (1st priority) 6
C85 MS indicating lamp ON condi-
tion (3rd priority)
Same as MS display, Condition (1st priority) 1
C86 MS indicating lamp ON status
(3rd priority)
Same as MS display, Status (1st priority) 9
C87 
MS indicating lamp deviation range 0 to 9999U 5
C88 Special function
0 to 15 (This value becomes "0" when the power is turned ON.) 0
C89 Zener barrier adjustment The value can be changed with the adjustment.
The numeric value cannot be directly input with
the manual operation.
0.00
C90 Number of CT1 turns 0: 800 turns 1 to 40: CT turns divided by 100 8
C9 1
Number of CT1 power wire loops 0: 1 time 1 to 6: Number of times 1
C92 Number of CT2 turns 0: 800 turns 1 to 40: CT turns divided by 100 8
C93 
Number of CT2 power wire loops 0: 1 time 1 to 6: Number of times 1
C97 PV input failure (under range)
type *1
0: 10 %FS
1: 5 mV (This setting is applicable if C01 (PV input range
type) is set for sensor type B (No.17) or PR40-20 (No. 23))
0
*1 Cannot be selected if ROM version 1 (
i d02) of the instrument information bank is 2.26 or earlier.
EvCF [Event configuration bank]
Display Item Contents Initial value Setting value
E1.C 1to E5.C 1
Internal event 1 to 5
Configuration 1 Operation type
Refer to event type (see page 8) 0
E1.C2 to E5.C2
Internal event 1 to 5
Configuration 2
The digits are determined to 1st, 2nd, 3rd, and
4th digit from the right end.
1st digit: Direct/Reverse 0: Direct 1: Reverse 0
2nd digit: Standby 0: None 1: Standby 2:
Standby + Standby at SP change 0
3rd digit:
EVENT state at READY 0: Continue 1: Forced OFF 0
4th digit: Undefined 0 0
E1.C3 to E5.C3 
Internal event 1 to 5
Configuration 3
The digits are determined to 1st, 2nd, 3rd, and
4th digit from the right end.
1st digit: Alarm OR 0: None 1: Alarm direct + OR operation
2: Alarm direct + AND operation
3: Alarm reverse + OR operation
4: Alarm reverse + AND operation
0
2nd digit: Special OFF 0: As usual
1: When the event set value (main setting) is 0,
the event is "OFF".
0
3rd digit: Delay time unit 0: 0.1s 1: 1s 2: 1min 0
4th digit: Undefined 0 0
di [DI assignment bank]
Display Item Contents Initial value Setting value
dI 1. 1to dI 5. 1Internal contact 1 to 5
Operation type
0: No function 1: LSP group selection (0/+1)
2: LSP group selection (0/+2) 3: LSP group selection (0/+4)
4: PID group selection (0/+1) 5: PID group selection (0/+2)
6: PID group selection (0/+4) 7: RUN/READY selection
8: AUTO/MANUAL selection 9: Invalid 10: AT Stop/Start
11: Invalid 12: Control action direct/reverse
13: SP Ramp enabled/disabled 14: PV Hold
15: PV Maximum value hold
16: PV Minimum value hold 17: Timer Stop/Start
18: Release all DO latches (Continue/Release)
19: Invalid 20: Invalid
0
dI 1.2 to dI 5.2 Internal contact 1 to 5
Input bit operation
0: Not used (Default input) 1: Function 1 ((A and B) or (C and D))
2: Function 2 ((A or B) and (C or D)) 3: Function 3 (A or B or C or D)
4: Function 4 (A and B and C and D)
0
dI 1.3 to dI 5.3 Internal contact 1 to 5
Input assignment A
0: Normally opened 1: Normally closed
2: DI1 3: DI2 4: DI3 5: DI4 6 to 9: Undefined
10 to 14: Internal event 1to 5 15 to 17: Undefined
18 to 21: Communication DI1 to 4 22: MANUAL
23: READY 24: Undefined 25: AT running
26: During SP ramp 27: Undefined
28: Alarm occurs 29: PV alarm occurs
30: Undefined 31: mode key pressing status
32: Event output 1 status 33: Control output 1 status
2 to 5
or 0
dI 1.4 to dI 5.4 Internal contact 1 to 5
Input assignment B
0
dI 1.5 to dI 5.5 Internal contact 1 to 5
Input assignment C
0
dI 1.6 to dI 5.6 Internal contact 1 to 5
Input assignment D
0
dI 1.7 to dI 5.7 Internal contact 1 to 5
Polarity A to D
The digits are determined to 1st, 2nd, 3rd and
4th digit from the right end.
1st digit: Polarity A 0: Direct 1: Reverse 0
2nd digit: Polarity B 0
3rd digit: Polarity C 0
4th digit: Polarity D 0
dI 1.8 to dI 5.8 Internal contact 1 to 5 Polarity 0: Direct 1: Reverse 0
dI 1.9 to dI 5.9 Internal contact 1 to 5
Internal event No. assignment
0: Every Internal Event
1 to 8: Internal Event No.
0
dO [DO assignment bank]
Display Item Contents Initial value Setting value
Ot 1. 1to Ot2. 1�
Ev 1. 1to Ev3. 1
Control output 1 to 2, event
output 1 to 3 Operation type
0: Default output 1 to 2: MV1 to 2
3 to 6: Function 1 to 4
0
Ot 1.2 to Ot2.2�
Ev 1.2 to Ev3.2
Control output 1 to 2, event
output 1 to 3 Output assign-
ment A
0: Normally opened 1: Normally closed
2 to 6: Internal Event 1 to 5 7 to 9: Invalid
10 to 13: Undefined 14 to 15: MV1 to 2
16 to 17: Undefined 18 to 21: DI1 to 4
22 to 25: Undefined
26 to 30: Internal Contact 1 to 5
31 to 33: Undefined 34 to 37: DI1 to 4 38: MANUAL
39: READY 40: Undefined 41: AT running
42: During SP ramp 43: Undefined
44: Alarm occurs 45: PV alarm occurs
46: Undefined 47: Mode key pressing status
48: Event output 1 status 49: Control output 1 status
14: Output 1
15: Output 2
2: Event 1
3: Event 2
4: Event 3
Ot 1.3 to Ot2.3�
Ev 1.3 to Ev3.3

Control output 1 to 2, event output
1 to 3 Output assignment B
0
Ot 1.4 to Ot2.4�
Ev 1.4 to Ev3.4

Control output 1 to 2, event output
1 to 3 Output assignment C
0
Ot 1.5 to Ot2.5�
Ev 1.5 to Ev3.5

Control output 1 to 2, event output
1 to 3 Output assignment D
0
Ot 1.6 to Ot2.6�
Ev 1.6 to Ev3.6
Control output 1 to 2, event
output 1 to 3 Polarity A to D
The digits are determined to 1st, 2nd, 3rd, and
4 th digit from the right end.
1st digit: Polarity A 0: Direct
1: Reverse
0
2nd digit: Polarity B 0
3rd digit: Polarity C 0
4the digit: Polarity D 0
Ot 1.7 to Ot2.7�
Ev 1.7 to Ev3.7
Control output 1 to 2, event
output 1 to 3 Polarity
0: Direct
1: Reverse
0
Ot 1.8 to Ot2.8�
Ev 1.8 to Ev3.8
Control output 1 to 2, event
output 1 to 3 Latch
0: None 1: Latch (Latch at ON)
2: Latch (Latch at OFF except for initialization at power ON)
0
UF [User function bank]
Display Item Contents Initial value Setting value
UF- 1to UF-8 User function 1 to 8  
LOC [Lock bank]
Display Item Contents Initial value Setting value
LOC Key lock 0: All settings are possible
1: Mode, event, operation display, SP, UF, lock,
manual MV can be set
2: Operation display, SP, UF, lock, manual MV can be set
3: UF, lock, manual MV can be set
0
C.LOC Communication lock 0: read/write enabled 1: read/write disabled 0
L.LOC Loader lock 0: read/write enabled 1: read/write disabled 0
PASS Password display 0 to 15 (5: Password 1A to 2B display) 0
PS 1A Password 1A 0000 to FFFF (Hexadecimal value) 0000
PS2A Password 2A 0000 to FFFF (Hexadecimal value) 0000
PS 1b Password 1B 0000 to FFFF (Hexadecimal value) 0000
PS2b Password 2B 0000 to FFFF (Hexadecimal value) 0000
Id[Instrument information bank]
Display Item Contents Initial value Setting value
Id0 1ROM ID 1: Fixed 0
Id02 ROM Version 1 XX. XX (2 digits after decimal point) 
Id03 ROM Version 2 XX. XX (2 digits after decimal point) 
Id04 Loader information 
Id05 EST information 
Id06 Manufacturing date code
(year)
Subtract 2000 from the year.
Example: "3" means the year 2003.

Id07 Manufacturing date code
(month, day)
Month + day divided by 100.
Example: "12.01" means the 1st day of December.

Id08 Serial No. 
Precaution for setup
• The type of auto tuning can be changed by changing the value of
At.ty (AT type) in the extended tuning bank. Set it to match the
control characteristics.
Memo
Changing the user level
This controller's user level can be set to 1 of 3 types in setup C79.
The number of possible displays and settings decreases according
to the user level: high function > standard > simple. All items are
displayed when high function is selected.
1Press [display] once
to get the operation
display.
Next, press and hold
[para] for more than 2s
to get the parameter
setup display. MOde
flashes on the upper
display.
2Press [ ] or [ ] repeat-
edly as needed to get
STUP flashing on the
upper display.
3Press [enter].
C0 1is shown on the
upper display.
Press [<], [ ] or [ ] to
change to c79 (user
level).
4When [enter] is
pressed, the lower
display flashes.
Press [ ] or [ ] to
change to the desired
setting, and press
[enter] to finalize your
selection.
0: Simple configuration
1: Standard configuration
(initial value)
2: High function configuration
• Items marked in the tables are displayed in standard and/or high function configuration.
• To change a user level, refer to Changing the user level in the lower right part of this page.

8
1-12-2 Kawana, Fujisawa
Kanagawa 251-8522 Japan
URL
: https://www.azbil.com
(11)
Specifications are subject to change without notice.
PV input range table
[Thermocouple] [RTD]
C0 1
set value
Sensor
type
Range
(°C)
Range
(°F)
C0 1
set value
Sensor
type
Range
(°C)
Range
(°F)
1 K -200 to +1200 -300 to +2200 41 Pt100 -200 to +500 -300 to +900
2 K 0 to 1200 0 to 2200 42 JPt100 -200 to +500 -300 to +900
3 K 0.0 to 800.0 0 to 1500 43 Pt100 -200 to +200 -300 to +400
4 K 0.0 to 600.0 0 to 1100 44 JPt100 -200 to +200 -300 to +400
5 K 0.0 to 400.0 0 to 700 45 Pt100 -100 to +300 -150 to +500
6 K-200.0 to +400.0 -300 to +700 46 JPt100 -100 to +300 -150 to +500
7 K-200.0 to +200.0 -300 to +400 47 Pt100 -100 to +200 -150 to +400
8 J0 to 1200 0 to 2200 48 JPt100 -100 to +200 -150 to +400
9 J 0.0 to 800.0 0 to 1500 49 Pt100 -100 to +150 -150 to +300
10 J 0.0 to 600.0 0 to 1100 50 JPt100 -100 to +150 -150 to +300
11 J -200.0 to +400.0 -300 to +700 51 Pt100 -50.0 to +200.0 -50 to +400
12 E 0.0 to 800.0 0 to 1500 52 JPt100 -50.0 to +200.0 -50 to +400
13 E 0.0 to 600.0 0 to 1100 53 Pt100 -50.0 to +100.0 -50 to +200
14 T -200.0 to +400.0 -300 to +700 54 JPt100 -50.0 to +100.0 -50 to +200
15 R 0 to 1600 0 to 3000 55 Pt100 -50.0 to +100.0 -50 to +200
16 S 0 to 1600 0 to 3000 56 JPt100 -60.0 to +40.0 -60 to +100
17 B 0 to 1800 0 to 3300 57 Pt100 -60.0 to +40.0 -60 to +100
18 N 0 to 1300 0 to 2300 58 JPt100 -40.0 to +60.0 -40 to +140
19 PL II 0 to 1300 0 to 2300 59 Pt100 -40.0 to +60.0 -40 to +140
20
WRe5-26 0 to 1400 0 to 2400 60 JPt100 -10.00 to +60.00 -10 to +140
21
WRe5-26 0 to 2300 0 to 4200 61 Pt100 -10.00 to +60.00 -10 to +140
22
Ni-Ni·Mo 0 to 1300 0 to 2300 62 JPt100 0.0 to 100.0 0 to 200
23
PR40-20 0 to 1900 0 to 3400 63 Pt100 0.0 to 100.0 0 to 200
24 DIN U -200.0 to +400.0 -300 to +700 64 JPt100 0.0 to 200.0 0 to 400
25 DIN L -100.0 to +800.0 -150 to +1500 65 Pt100 0.0 to 300.0 0 to 500
26
Gold iron
chromel
0.0K to 360.0 K 0 to 360 K 66 JPt100 0.0 to 300.0 0 to 500
67 Pt100 0 to 500 0 to 900
68 JPt100 0 to 500 0 to 900
[DC voltage/DC current]
C0 1
set value
Input type Range
81 0 to 10 mV The scaling and deci-
mal point position can
be changed variably
in a range of –1999 to
+9999
82 -10 to +10 mV
83 0 to 100 mV
84 0 to 1 V
86 1 to 5 V
87 0 to 5 V
88 0 to 10 V
89 0 to 20 mA Initial value
90 4 to 20 mA
*1 • The accuracy of the B thermocouple is ±4.0 %FS for a range of 260 °C or less, ±0.4 %FS for 260
to 800 °C. The PV values under 20 °C are not shown.
• The accuracy of the No.23 (sensor type PR40-20) is ±2.5 %FS for 0 to 300 °C, and ±1.5 %FS for
300 to 800 °C, ±0.5 %FS for 800 to 1900 °C.
• The accuracy of the No.26 (sensor type gold iron chromel) is ±2.0 K.
*2 The indicated low limit for a B thermocouple is 20°C. However, if ROM version 1 of the instrument
information bank (Id02) is prior to 2.04, the value is -180°C.
List of alarm codes
Alarm
code
Failure name Cause Corrective action
Input failure
AL0 1PV input failure
(Over-range)
Sensor burnout, incorrect wiring,
incorrect PV input type setting
Check the wiring.
Set the PV input type
again.
AL02 PV input failure
(Under-range)
Sensor burnout, incorrect wiring,
incorrect PV input type setting
AL03 CJ failure Terminal temperature is
faulty (thermocouple).
Check the ambient
temperature.
PV input failure
(RTD)
Sensor burnout, incorrect
wiring
Check the wiring.
AL 11CT input failure
(Over-range)
(CT input 1 or 2,
or both)
A current exceeding the
upper limit of the display
range was measured. The
number of CT turns or the
number of CT power wire
loops is incorrectly set, or
wiring is incorrect.
• Use a CT with the cor-
rect number of turns for
the display range.
• Reset the number of CT
turns.
• Reset the number of CT
power wire loops.
• Check the wiring.
Unit failure
AL70 A/D conversion
failure
A/D converter is faulty. Replace the unit.
AL95 Parameter failure Power is shut-down while
the data is being set, or
data is corrupted by noise.
• Restart the unit.
• Set the data again (set
data for AL95/97 and
adjustment data for
AL96/98.
• Replace the unit.
AL96 Adjustment data
failure
Power is shut-down while
the data is being set, or
data is corrupted by noise.
AL97 Parameter failure
(RAM area)
Data is corrupted by noise.
AL98 Adjustment data
failure (RAM area)
Data is corrupted by noise.
AL99 ROM failure ROM (memory) is faulty. • Reset the unit.
• Replace the unit.
Handling Precautions
• If ROM version 1 (id02) of the instrument information bank
is 2.04 or earlier, CT input failure (AL 11) is not displayed.
Event type
Operation
type
Set
value
Direct action
:
shows that the ON/OFF is changed at this value.
: shows that the ON/OFF is changed at a point
that "1U" is added to this value.
Reverse action
:
shows that the ON/OFF is changed at this value.
: shows that the ON/OFF is changed at a point
that "1U" is added to this value.
No event 0 Always OFF Always OFF
PV high
limit
1ONHYS
Main setting
PV
ON HYS
Main setting
PV
PV low limit 2
Main setting
PV
ON HYS
Main setting PV
ON
HYS
PV high/low
limit
3
Main setting
*1 Sub-setting *1
PV
ON HYS ONHYS
Main setting *1 Sub-setting *1
PV
ONHYS HYS
Deviation
high limit
4ONHYS
SP + Main setting
PV
ON HYS
SP + Main setting
PV
Deviation
low limit
5
SP + Main setting PV
ON HYS
SP + Main setting
PV
ONHYS
Deviation
high/low
limit
6
Main setting Sub-setting
SP
PV
ON HYS ONHYS ONHYS HYS
Main setting Sub-setting
SP
PV
Deviation
high limit
(Final SP
reference)
7ONHYS
SP + Main setting
PV
ON HYS
SP + Main setting
PV
Deviation
low limit
(Final SP
reference)
8
SP + Main setting PV
ON HYS
SP + Main setting
PV
ONHYS
Deviation
high/
low limit
(Final SP
reference)
9
Main setting Sub-setting
SP
PV
ON HYS ONHYS ONHYS HYS
Main setting Sub-setting
SP
PV
Heater 1
burnout/
Over-current
16
CT1 at output ON
Main setting
*
Sub-setting *
ON HYS ONHYS ONHYS HYS
Main setting *
Sub-setting *
CT1 at output ON
OFF before measuring the CT1 current value OFF before measuring CT1 current value
Heater 1
short-circuit
17 ON
HYS
Main setting
CT1 at output OFF
ON HYS
Main setting
CT1 at output OFF
OFF before measuring CT1 current value OFF before measuring CT1 current value
Heater 2
burnout/
Over-current
18
CT2 at output ON
Main setitng *1
Sub-setting *1
ON HYS ONHYS ONHYS HYS
Main setting *1
Sub-setting *1
CT2 at output ON
OFF before measuring CT2 current value OFF before measuirng CT2 current value
Heater 2
short-circuit
19 ON
HYS
Main setting
CT2 at output OFF
ON HYS
Main setting
CT2 at output OFF
OFF before measuring CT2 current value OFF before measuring CT2 current value
Alarm
(status)
23 ON if alarm occurs (alarm code AL01 to 99).
OFF in other cases.
OFF if alarm occurs (alarm code AL01 to 99).
ON in other cases.
: initial value
*1 If the main setting is greater than the sub-setting, operations are performed with the
main setting and sub-setting automatically swapped.
Event types other than the above:
Operation type Set
value
Operation type Set
value
Operation type Set
value
SP high limit 10 Loop diagnosis 1 20 During AT (status) 27
SP low limit 11 Loop diagnosis 2 21 During SP ramp 28
SP high/low limit 12 Loop diagnosis 3 22 Control action (status) 29
MV high limit 13 READY (status) 24 ST settling standby (status) *130
MV low limit 14 MANUAL (status) 25
Estimated position contorol (status) *131
MV high/low limit 15 RSP (status) *126 Timer (status) 32
*1 Invalid in this unit
1st edition: Nov. 2007 (W)
3rd edition: May 2019 (B)© 2007–2019 Azbil Corporation. All Rights Reserved.
