AZZA P4X2 Series User manual

The AZZA P4X2 Mainboard Series
Cover Click Here
Table Of Contents Click Here
Introduction Click Here
Hardware Installation Click Here
BIOS Management Click Here
R

The AZZA P4X2-A MAINBOARD SERIES Page 1
P4X2
P4X2P4X2
P4X2-
--
-A Mainboard Series
A Mainboard SeriesA Mainboard Series
A Mainboard Series
SOCKET 478 DDR ATX Mainboard
P4X2
P4X2P4X2
P4X2-
--
-AD
ADAD
AD
P4X2
P4X2P4X2
P4X2-
--
-AS
ASAS
AS
P4X2
P4X2P4X2
P4X2-
--
-AV
AVAV
AV
P4X2
P4X2P4X2
P4X2-
--
-AC
ACAC
AC
Version 1.x
UM-P4X2-ACVSD-E1
Rev 1.0V
Creation Date: 22 August 2001

The AZZA P4X2-A MAINBOARD SERIES
Page 2
Copyright
This publication contains information that is protected by copyright. No part of it
may be reproduced in any form or by any means or used to make any transforma-
tion adaptation without prior written permission from the copyright holders. This
publication is provided for informational purposes only. The manufacturer makes
no representations or warranties with respect to the contents or use of this man-
ual and specifically disclaims any express or implied warranties of merchantability
or fitness for any particular purpose. The user will assume the entire risk of the
use or the results of the use of this document. The manufacturer reserves the
right to revise this publication and make changes to its contents at any time, with-
out prior notice.
2001. All Rights Reserved.
Trademarks
Trademarks
Trademarks
Microsoft®, MS-DOS®, WindowsTM, Windows® 95 and Windows® 98 are regis-
tered trademarks of Microsoft Corporation. AMD DuronTM and AMD AthlonTM are
registered trademarks of AMD corporation. Award is the registered trademark of
Award Software, Inc. Other trademarks and registered trademarks of products
appearing in this publication are the properties of their respective holders.
Package Checklist
Package Checklist
Package Checklist
This package contains the following items:
•Mainboard
•Users manual
•One IDE cable
•One 34-pin floppy disk drive cable
•One Driver Utility CD
If any of these items are damaged or missing, please contact your dealer or sales
representative for assistance.
Technical Support
Technical Support
Technical Support
If you require additional information or assistance during installation please con-
tact your dealer. Your dealer will be able to provide the latest information.
Copyright Notice

The AZZA P4X2-A MAINBOARD SERIES Page 3
Table of Contents
Table of Contents
Table of Contents
Contents
ContentsContents Contents
Chapter 1:- Introduction Page 5
1.1. Mainboard Layout ..................................................................................... 5
1.1.1. Mainboard Series ...................................................................................6
1.1.2. Mainboard Dimensions ...........................................................................6
1.1.3. Environmental Limitations.......................................................................6
1.2. Features and Specifications ...................................................................... 6
1.3. System Health Monitor Functions ............................................................. 9
1.3.1. Hardware Monitoring System Utility.........................................................9
1.3.2. Installation ............................................................................................10
1.4. System Intelligence .................................................................................. 10
Chapter 2:- Hardware Installation Page 11
2.1. Installation Checklist ................................................................................ 11
2.2. Installation Steps...................................................................................... 12
2.3. CPU, Memory and Expansion Slots............................................................ 14
2.3.1. Installation of the CPU............................................................................14
2.3.2. Memory Modules....................................................................................14
2.3.3. PCI Slots ...............................................................................................15
2.3.4. AGP (Accelerated Graphics Port) Slot.......................................................15
2.3.5. CNR (Communications Network Riser) Slot ..............................................16
2.4. Internal Connectors .................................................................................. 16
2.4.1. Floppy Disk Drive (FDD) .........................................................................16
2.4.2. Primary and Secondary IDE Connectors...................................................16
2.4.3. Standard Infrared Connector ..................................................................17
2.4.4. CPU and Chassis Fan Connectors ............................................................17
2.4.5. ATX Power Supply Connectors ................................................................18
2.4.6. WOL (Wake-On-LAN) and WOM (Wake-On-Modem) Connectors...............19
2.4.7. CD Audio In Connector...........................................................................19
2.4.8. USB 3, USB 4, USB 5 and USB 6 Connectors............................................19
2.4.9. S/PDIF Connector ..................................................................................19
2.4.10. Front Audio Connector............................................................................20
2.4.11. Smart Card Reader (SCR) Connector .......................................................20
2.4.12. SMB Connector ......................................................................................21
2.5. System Panel Buttons and LED Connectors .............................................. 20
2.5.1. PW: Power On/Off and External Suspend Switch Connector.......................21
2.5.2 Standby LED Connector...........................................................................22
2.5.3. IDE HDD LED Connector ........................................................................22
2.5.4. Reset Button Connector...........................................................................22

The AZZA P4X2-A MAINBOARD SERIES
Page 4
Contents
ContentsContents Contents
Table of Contents
Table of Contents
Table of Contents
2.6. Speaker and Power LED Connector........................................................... 22
2.6.1. Speaker Connector..................................................................................22
2.6.2. Front Panel Power LED Connector............................................................22
2.7. External Connectors.................................................................................. 23
2.7.1. PS/2 Keyboard Connector.......................................................................23
2.7.2. PS/2 Mouse Connector ...........................................................................23
2.7.3. COM 1 and COM 2 Connectors................................................................23
2.7.4. Parallel Port Connector...........................................................................23
2.7.5. USB 1 and USB 2 Connectors....................................................................23
2.7.6. Audio Game Port Connector......................................................................24
2.8. Jumper Settings ........................................................................................ 24
2.8.1. JP 1: Keyboard Power ..............................................................................24
2.8.2. JP 2: USB1 and USB2 Power.....................................................................24
2.8.3. JP 4: CPU Clock........................................................................................25
2.8.4. JP12: STR Mode.......................................................................................25
2.8.5. JP13: Clear CMOS Memory ......................................................................25
2.8.4. JP 14: Select English or Chinese for Voice Warning Message.......................25
Chapter 3:- Managing The PC BIOS
Page 26
3.1. AWARD BIOS CMOS Setup Utility........................................................... 26
3.2. Main Menu.............................................................................................. 26
3.3. Standard CMOS Setup ............................................................................ 27
3.4. ADVANCED BIOS FEATURES................................................................... 29
3.5. ADVANCED CHIPSET FEATURES ............................................................. 32
3.6. INTEGRATED PERIPHERALS................................................................... 35
3.7. Power Management Setup ..................................................................... 39
3.8. PNP/PCI Configuration .......................................................................... 42
3.9. PC Health Status .................................................................................... 43
3.10. Frequency/Voltage Control .................................................................... 44
3.11. Load Optimized Defaults ........................................................................ 45
3.12. Set Supervisor Password........................................................................ 46
3.13. Set User Password.................................................................................. 47
3.14. SAVE & EXIT SETUP/EXIT WITHOUT SAVING........................................ 48

The AZZA P4X2-A MAINBOARD SERIES Page 5
Chapter 1
Chapter 1
Chapter 1 -
-
-Introduction
Introduction
Introduction
Introduction
1.1. MAINBOARD LAYOUT
Speaker Power LED System Panel and LED Connectors
CN 17: Chassis Fan
CN 30: USB 3 CN 31: USB 4 JP13: Clear CMOS CN 32: USB5 CN 38: USB6 JP14: Voice Warning
CN 10: IDE 2 CN 9: IDE 1 CN 8: FDD
PCI 3 PCI 2 PCI 1
PCI 4 PCI 5 PCI 6 CNR Slot
CN 15-C:ATX Power Supply
JP12: STR Function
CN 42: SMB
DIMM1 DIMM2 DIMM3 CN 13: CPU Fan
JP1: K/BPower
JP2: USB 1, 2 Power
PC 99 ATX Connector CN 39: Front
AudioConnector
CN15-B: ATX Power Supply CN 15-A: ATX Power Supply
CPU 478 Socket Heat Sink Bracket
CN 21: CD-IN
AGP Slot
CN 41: SCR
CN 16: WOL CN 24: WOM
CN 12: IR
Introduction

The AZZA P4X2-A MAINBOARD SERIES
Page 6
1.1.1. Mainboard Series
The P4X2-A mainboard series use a Pentium 4 CPU with a VIA chipset. There are four
models to choose from. They are:
i) P4X2-AD iii) P4X2-AV
ii) P4X2-AS iv) P4X2-AC
1.1.2. Mainboard Dimensions
Width & Length: 305 mm x 230 mm
1.1.3. Environmental Limitations
Operating Temperature: 10°C to 40°C . (50°Fto 104°F)
Required Airflow: 50 linear feet per minute across CPU.
Storage Temperature: - 40°C to 70°C. (- 40°F to 158°F)
Humidity: 0 to 90% non-condensing.
Altitude: 0 to 10,000 feet
Processor
Supports Intel® Socket 478 Pentium 4.
Chipset
VIA P4X266 + VT8233
I/O Chipset
For hardware monitoring: Winbond W83697HF P4X2-AD, P4X2-AS, P4X2-AV
For Smart Card Reader : Winbond W83697SF P4X2-AC
CPU Vcore Select (optional for P4X2-AC and P4X2-AV)
You can use the system BIOS to select the CPU Vcore Voltage.
CPU Switching Voltage Regulator
Equipped with a switching voltage regulator that automatically detects +1.10V to +1.85V DC
power supply.
System Memory
•3.0GB DRAMs for registered DDR SDRAM modules.
•1.5GB DRAMs for unbuffered DDR SDRAM modules.
•Three 184-pin DIMM sockets.
•Supports PC1600 and PC2100 DDR SDRAM.
Introduction
1.2. Features and Specifications
Introduction

The AZZA P4X2-A MAINBOARD SERIES Page 7
Expansion Slots
These mainboards are equipped with six dedicated PCI slots, one CNR slot and one 4x AGP
slot.
Onboard Audio Features
Supports Microsoft DirectSound/ DirectSound 3D and AC97 Full Duplex.
Word Size
• Data Path: 8-bit, 16-bit, 32-bit, 64-bit
• Address Path: 32-bit
Front Side Bus Frequency (FSB)
For a P4 Socket 478 CPU a 400 MHz FSB (100 MHz QDR) is supported.
BIOS
•2Mb Flash ROM
• Award BIOS, Windows 95/98 Plug and Play (PnP) compatible.
• Supports SCSI sequential boot-up.
• Flash EPROM for easy BIOS upgrades.
• Supports DMI 2.0 function
Desktop Management Interface (DMI)
The mainboard comes with DMI 2.0 built into the BIOS. The DMI utility in the BIOS will
automatically record different information about your system configuration and store this
information in the DMI pool, which is a part of the system board's Plug and Play BIOS. DMI,
along with the appropriately networked software, is designed for easy inventory, mainte-
nance and the simplified troubleshooting of computer systems.
WOL (Wake-On-LAN) Port
One WOL connector supports Wake-On-LAN functionality.
WOM (Wake-On-Modem) Port
One WOM connector supports Wake-On-Modem functionality.
USB Ports
The mainboard is equipped with Six Version 1.1 USB ports. USB allows data exchange
between your computer and a wide range of simultaneously accessible external Plug and
Play peripherals. USB 1 and USB 2 are external ports. They can be found on the PC 99 ATX
connector. USB 3, USB 4, USB 5 and USB 6 are internal connectors that can be used to
connect other USB devices. (Optional cable for four connectors is sold separately).
Connectors
•One connector for IrDA interface (Optional for P4X2-AS, P4X2-AV and P4X2-
AC)
Introduction
Introduction

The AZZA P4X2-A MAINBOARD SERIES
Page 8
•Two IDE connectors.
•One floppy drive interface supports up to two 2.88MB floppy drives.
•One 20-pin ATX 12V power supply connector.
•One 2x2 ATX 12V power supply connector.
•One 1x6 ATX 12V power supply connector.
• CPU and chassis fan connectors.
• One CD audio-in connector.
• One system management bus (SMB) connector.
• Front Audio connector for use with a Front Utility Panel. (Optional for P4X2-AS,
P4X2-AV and P4X2-AC)
• Οne Smart Card Reader (SCR) for use with a Smart Card Reader Kit. (Only for
P4X2-AC)
• One S/PDIF connector. (Optional for P4X2-AS, P4X2-AV and P4X2-
AC)
ATX Double Deck Ports (PC 99 color-coded connectors) )
•Two USB ports.
•Two external DB-9 serial port connectors: COM 1 and COM 2 (UART).
•One SPP/ECP/EPP DB-25 parallel port.
•One mini-DIN-6 PS/2 mouse port.
•One mini-DIN-6 PS/2 keyboard port.
•One game/MIDI port.
•Three audio jacks: speak-out, line-in and mic-in.
PCI Bus Master IDE Controller
•Two PCI IDE interfaces support up to four IDE devices.
•Both models support ATA/33, ATA/66 and ATA100 hard drives.
•PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up to 16.6MB/sec.).
•Bus mastering reduces CPU utilization during disk transfer.
•Supports ATAPI CD-ROM, LS-120 and ZIP.
IrDA Interface (Optional for P4X2-AS, P4X2-AV and P4X2-AC)
The mainboard is equipped with an IrDA connector for wireless connectivity between your
computer and peripheral devices. It supports peripheral devices that meet the HPSIR or
ASKIR standard.
Special Features for the P4X2-AD Model
ALARM
The ALARM is an intelligent voice debugging device. When you boot your system it exam-
ines the status of your system to determine if the system is operating correctly. If a device is
incorrectly installed, not installed or damaged a voice announcement will be made. Devices
which are supported by this alarm are: CPU, Memory, Video Card, FDD, HDD, Keyboard and
Battery.
Introduction
Introduction

The AZZA P4X2-A MAINBOARD SERIES Page 9
Introduction
The mainboard is capable of monitoring the following health conditions of your system:
1. Processor temperature. It has an overheat alarm.
2. VCORE/3.3V/5V/12V/-12V voltages and failure alarm.
3. Processor and chassis fan speeds. It has a failure alarm for these fans.
4. Read back capability that displays temperature, voltage and fan speed.
1.3.1. Hardware Monitoring System Utility
The mainboard comes with the Hardware Monitoring System utility contained on the CD. It
is capable of monitoring the system’s hardware conditions such as the temperature of the
processor, voltage, and the speed of both the CPU and chassis fans. You are allowed to
manually set a range to the items being monitored. If the values are over or under the set
Only use this utility in Windows ® 95 or Windows ® 98 operating systems.
The surround sound feature should be used together with a Front Utility Panel. This panel
brings the MIC-IN, LINE-IN and Earphones lines, together with some USB ports, to the front
of the system. The Front Utility Panel can be connected to the internal Front Audio Connec-
tor. The Front Utility Panel is shown below.
SPK–OUT
LINE-IN
MIC-IN
Front Utility Port
Center
LFE Woofer
Ground
Center
Left
Right
Ground
Front
Front Speaker
Woofer and Center Speaker
Rear Speaker
ATX Audio Port 3.5 mm Audio Signal Plugs
Left
Right
Ground
Rear
1.3. System Health Monitor Functions (Only for P4X2-AD, P4X2-
AS and P4X2-AV)
Surround Sound (AC-3 5.1 Channel)
This model supports surround sound. Speakers can be connected to MIC-IN, LINE-IN and
SPK-OUT ports on the ATX audio port at the back of your computer. The speaker plugs must
be 3.5 mm and have the same pin assignment as shown in the diagram.
Introduction

The AZZA P4X2-A MAINBOARD SERIES
Page 10
Dual Function Power Button
Depending on the setting in the Soft-Off By Power-Button field of the Power Management
Setup, this switch allows the system to enter the Soft-Off or Suspend mode.
External Modem Ring-on (only for P4X2-AD)
The Modem Ring-on feature allows the system that is in the Suspend mode or Soft Power
Off mode to wake-up/power-on to respond to incoming calls. This feature supports the ex-
ternal modem only.
RTC Timer to Power-on the System
The RTC installed on the system board allows your system to automatically power-on at a
set date and time.
Wake-On-LAN Ready
The Wake-On-LAN function allows the network to remotely wake up a Soft Power Down
(Soft-Off) PC. Your LAN card must support the remote wakeup function. The 5V SB power
source of your power supply must be at least 720mA.
ACPI Ready
The mainboard is designed to meet the ACPI (Advanced Configuration and Power Interface)
specification. ACPI has energy saving features that support OS Direct Power Management
(OSPM) for round the clock PC operation.
Introduction
1.4. System Intelligence
range a warning message will automatically pop up. We recommend that you use the
Default Settings, which are the ideal settings that will maintain the system in a good working
condition.
Introduction

The AZZA P4X2-A MAINBOARD SERIES Page 11
Hardware Installation
Chapter 2
Chapter 2
Chapter 2 -
-
-Hardware Installation
Hardware Installation
Hardware Installation
The following is a checklist of all the expansion slots, jumpers and connectors that should be
configured on your mainboard before you can run your pc.
Installation Checklist
CPU Slot
DIMM Slots
PCI Slots
CNR Slot
AGP Slot
Socket 478 CPU Slot which supports Pentium 4
Three 184 pin slots that supports 3 GB DDR SDRAM.
Six 32 bit PCI Slots.
One Communications Network Riser Slot
One Accelerated Graphics Port Slot
CN8
CN9
CN10
CN12
CN13
CN15-A
CN15-B
CN15-C
CN16
CN17
CN21
CN24
CN30
CN31
CN32
CN36
CN38
CN39
CN41
CN42
Floppy Disk Drive FDC
Primary IDE IDE1
Secondary IDE IDE2
Infrared IR
CPU Fan CPU Fan
ATX 12VPower Supply ATX
ATX 12V Power Supply ATX
ATX 12V Power Supply ATX
Wake On Lan WOL
Chassis Fan Chassis Fan
CD-In without housing CD-In
Wake On Modem WOM
Universal Serial Bus 3 USB3
Universal Serial Bus 4 USB4
Universal Serial Bus 5 USB5
Sony Phillips Digital Interface S/PDIF
Universal Serial Bus 6 USB6
Front Audio Connector Front Audio
Smart Card Reader SCR
System Management Bus SMB
CN1
CN2
CN3
CN4
CN5
PS/2 Keyboard Connector PS/2 KB
PS/2 Mouse Connector PS/2 MS
Serial Port 1 COM1
Serial Port 2 COM2
Parallel Port LPT
Expansion Slots and Sockets
Internal Connectors
External Connectors
Hardware Installation
2.1. Installation Checklist

The AZZA P4X2-A MAINBOARD SERIES
Page 12
Installation Checklist (Continued)
PW
S5L
HL
RS
Power On/Off and Suspend Switch Connector.
Standby LED Connector
HDD LED Connector
Reset Button LED Connector
PWR-LED
SPK
Power LED
Speaker Connector
JP1
JP2
JP4
JP12
JP13
JP14
Keyboard Power
USB 1 and 2 Power
CPU Clock
STR Mode Function
Clear CMOS
English/Chinese Selection for Voice Alarm
CN6
CN7
CN18
Universal Serial Port 1 USB1
Universal Serial Port 2 USB2
Game/Audio Port Audio/Game
Speaker and Power LED Connector
Jumpers
System Panel Buttons and LED Connectors
You need to complete the following installation steps before you can use your PC.
•Check and Set the Mainboard Settings.
•Install the Central Processing Unit (CPU).
•Install the Memory Modules.
•Install the Expansion Cards.
•Connect the Ribbon Cables, Panel Wires and the Power Supply.
•Setup the system BIOS
Before you start installing your mainboard we strongly recommend that you use a
grounded anti-static mat. We further recommend that you attach an anti-static wrist-
band, which is grounded at the same location as the mat, to your wrist.
A Diagram of the Expansion Slots, Jumpers and Connectors can be seen
on the following page
Hardware Installation
2.2. Installation Steps
Only use an ATX 12V Power Supply.
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES Page 13
Expansion Cards, Connectors and Jumpers For The P4X2 Series
Power LED Speaker
1
System Panel Buttons and LED Connectors
PCI 1PCI 2PCI 3PCI 4
PCI 5
PCI 6
JP13: ClearCMOS 1
CNR
CN17: Chassis
Fan
JP14: Voice Warning CN31: USB 4
CN38: USB 6
CN32: USB 5
CN30: USB 3
1 1
1
1
1
1
AGP Slot
CN16: WOL
CN24: WOM
1 1 CN12:
IR CN41: SCR
CN21: CD IN
1
1
CN39: FrontAudio
1
CN15-B: ATX 12VPower Supply
CN15-A: ATX 12VPower Supply
1
JP 2: K/B PWR
CN13: CPU Fan
DIMM 3 DIMM 2 DIMM 1
1
JP 1: USB PWR
1
1
JP4: CPU Clock
CN42: SMB
JP12: STR Mode
1
CN15-C: 1x6 ATX 12VPower Supply
CN10: IDE2 CN9: IDE1 CN8: FDD
1
Hardware Installation
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES
Page 14
2.3.1. Installation of the CPU
To install your processor, please complete the following set of instructions
1. Locate a small dot marked on the top of the CPU. This mark indicates Pin 1 of the
CPU.
2. Locate Pin 1 for the Socket on the mainboard.
3. There is a lever on the side of the socket. First push this lever sideways and then
lift it to a 90-degree angle.
4. Insert the CPU into the Socket. Please make sure that Pin 1 for the CPU is inserted
into Pin 1 of the Socket.
4. When the CPU is installed correctly push the lever back into place.
5. Install a proper heat sink with cooling fan for proper heat dissipation. Failing
to install a heat sink with cooling fan may cause overheating which will burnout
your CPU and damage your mainboard. The heat sink with cooling fan should be
installed on the retention mechanism that is provided. This retention mechanism is
designed to hold the bigger Heat Sink that is required for the Pentium 4 CPU.
2.3.2. Memory Modules
These mainboards all have three 184-pin DDR SDRAM slots. If registered DDR SDRAM mod-
ules are used then they can support a maximum of 3 GB DRAM. If unbuffered DDR SDRAM
modules are used they can support a maximum of 1.5 GB DRAM
The DDR SDRAM slots are located on the right hand side of the board. To install the DIMM’s
into these slots, make sure the white lever at each side of the slot has been pulled down to
an angle of approximately 45°. Make sure that the DIMM is in the correct orientation. Place
the DIMM on the slot and push down firmly.The white levers will come back up and lock the
module in place.
Heat Sink and Retention Mechanism
You must use an Intel approved Heat Sink. This CPU operates at a very high fre-
quency and therefore heats up very quickly. (A normal heat sink will not be ade-
quate to cool the CPU and the CPU will burn-out.) These heat sinks are very
heavy. A retention mechanism for the Heat Sink has been provided with the main-
board.
52 pins40 pins
Top View of a 184-pin DIMM Slot
Hardware Installation
2.3. CPU, Memory and Expansion Slots
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES Page 15
Important: The DIMM’s can only be fitted into the slots in one orientation. Make
sure that the DIMM’s are in the correct orientation and the pins are correctly
aligned before you insert them.
2.3.3. PCI Slots
These boards come with six PCI slots. They are located on the left hand side of the board.
Both PCI and PCI expansion cards may require IRQ’s. This mainboard complies with Plug
and Play (PnP) specifications. Whenever a PnP compliant card is added the system will auto-
matically be configured and the IRQ’s will be assigned automatically.
When you are inserting your PCI card make sure that the pins are correctly aligned. When
the pins are properly aligned with the hole’s in the slot, push down gently.
2.3.4. AGP (Accelerated Graphics Port) Slot
AGP is a dedicated bus slot. It operates at 66 MHz and transfers data at a rate up to 1066
MB/s. This allows 3D applications to run more smoothly. The P4X2-A mainboards each come
with one AGP slot. This slot is able to support 1x, 2x and 4x AGP cards.
11 pins 49 pins
Top View of a PCI Slot
66 pins
Top View of an AGP Slot
Hardware Installation
NOTE: “Out Of Memory” Error Message
If you have installed more than 512 MB of RAM and are running Microsoft Windows Millennium Edition, Win-
dows 98 Second Edition, Windows 98 or Windows 95 you may experience memory problems. Two symptoms
of these problemsare beingunable to run anMS-DOS sessionwhile you are running Windows orthe computer
may stop responding while Windows isstarting.
Thereare three possible solutionsto thisproblem:
1) Reduce the amount of memory Vcache uses to 512 MB or less by altering the MaxFileCache setting in
the System.ini file.
2) Use the System Configuration Utility to reduce the amount of memoryWindows uses to 512MB or less.
3) Reduce the memory installed on your computer to 512 MB or less.
This problem can also occurif you are using an Advanced GraphicPort (AGP)video adapter.
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES
Page 16
2.3.5. CNR (Communications Network Riser) Slot (optional for P4X2-AC)
These slots integrate audio, modem and networking on the same card. CNR specifications
support the Audio Codec 97 (AC 97) interface, LAN interfaces, USB interfaces and System
Management Bus (SMBus) interfaces (used specifically to provide Plug and Play functionality).
11 pins 19 pins
Top View of an CNR Slot
2.4.1. Floppy Disk Drive (FDC)
Connector: CN 8
Type: 34 pin block
The FDD connector can support two Floppy drives. It is located at the front of the main-
board. To connect, use the ribbon-cable that has been provided. Make sure that the red
strip is connected to PIN 1 of the connector.
Top View of a Floppy Disk Drive
Connector PIN 1
17 Pins
2.4. Internal Connectors
2.4.2. Primary and Secondary IDE connectors
Connector: CN 9 (primary)/ CN 10 (secondary)
Type: 40 pin blocks
The P4X2-A mainboards all have two IDE connectors: a primary and secondary. Each IDE
connector can support two IDE drives. These mainboards can therefore support up to four
IDE devices each. If you install two hard drives, you need to configure the second drive to
slave mode in the BIOS setup
. Please refer to your hard drive manual for the appropriate
jumper settings.
Hardware Installation
Top View of an IDE
Connector
20 PINS
PIN 1
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES Page 17
2.4.5. ATX Power Supply Connectors
Connector: CN 15-A/ CN15-B/ CN15-C
Type: 20 pin block/2x2 12V/1x6
The mainboards in this series all come with three onboard power supply connectors labled
from CN15-A to CN15-C. CN15-A and the CN15-B are regular ATX power supply connectors
that have been used on all recent motherboards. The CN15-C power connector is for a
+3.3V and +5V power supply. These increased power supplies are necessary to provide ex-
tra power for the slot. The ATX 12V power supplies are all downward compatible with stan-
dard ATX power supplies.
2.4.3. Standard Infrared Connector (Optional for P4X2-AS, P4X2-AV and
P4X2-AC)
Connector: CN 12
Type: 5 pin
The SIR connector supports an optional wireless transmitting and receiving module. You
must configure UART 2 to select whether UART 2 is directed for use with COM 2 or IrDA.
2.4.4. CPU Fan and Chassis Fan Connector
Connector: CN 13 (CPU Fan 1)/CN 17 (Chassis Fan)
Type: 3 pin
The cooling fans must be connected to their respective power connectors.
Fan Signal +12V DC
Ground
1 Ground
2 +12V DC
3 Fan Signal
Top View of a Fan Connector Front View of a Fan Connector
1 5V DC
2 No Connection
3 IR Reciever
4 Ground
5 IR Transmitter
Top View of an IR Connector
5V DC
IR Receiver Ground IR Transmitter
Front View of an IR Connector
Hardware Installation
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES
Page 18
10 pins
PIN 1
Normal ATX Power Supply
2x2 12V ATX Power Supply. 1x6 12V ATX Power Supply
2.4.6. WOL (Wake On LAN) Connector and WOM (Wake On Modem) Con-
nector
Connector: CN 16 (WOL)/CN 24(WOM)
Type: 3 pin
The WOL connector must be connected to a LAN card that has Wake-On-LAN (WOL) output.
This connector powers up the system when a wakeup packet or signal is received through
the LAN card.
The WOM connector must be connected to a Modem that has Wake-On-Modem (WOM) out-
put. This connector powers up the system when a wakeup packet or signal is received from
the Modem.
In order to use the WOL LAN card or the modem to trigger the power on the PC system,
the switching power supply must have the ability to provide a driving current of at least 720
mA and be connected to a “5V standby” voltage.
WOL/WOM
5V_SB
Ground
1 5V_SB
2 Ground
3 WOL/WOM
Top View of a WOL/WOM Connec-
tor Front View of a WOL/WOM Con- nector
Hardware Installation
Hardware Installation

The AZZA P4X2-A MAINBOARD SERIES Page 19
2.4.7. CD Audio-in Connector
Connector: CN 21
Type: 4 pin un-housed
This mainboard has one CD Audio-in connectors. This connector is used to connect the CD
ROM audio out.
2.4.8. USB Connectors: USB3, USB4, USB5 and USB6
Connector: CN 30 (USB1)/ CN 31 (USB2)/ CN 32 (USB 3)/CN 38 (USB 4)
Type: 5 pin
This mainboard comes with 4 extra onboard USB ports. Ribbon cable for these four connec-
tors are optional. These connectors allow you to connect 4 USB devices to the mainboard.
5V DC
Ground
Ground Data -
Data +
1 5V DC
2 Data-
3 Data+
4 Ground
5 Ground
Top View of a USB Port Front View of a USB Port
Hardware Installation
Right Channel
Audio In
Left Channel
Audio In Ground
1 Left Channel Audio In
2 Ground
3 Ground
4 Right Channel Audio In
Top View of a CD Audio In
Connector Front View of a CD Audio In Connector
2.4.9. S/PDIF Connector (Only for P4X2-AD)
Connector: CN 36
Type: 2 pin
The mainboard comes with an internal S/PDIF connector. S/PDIF is a digital interface that
can be used to improve the quality of the sound output from your system. The diagram is on
the following page.
Hardware Installation
