Balluff SMARTCAMERA BVS SC 1280Z00-30 Series User manual

BVS SC-_1280Z00-30-0-0
SMARTCAMERA
Fieldbus

3
www.balluff.com
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
1USER INSTRUCTIONS 6
1.1 Introduction........................................................................................................... 6
1.2 Other applicable documents............................................................................... 6
1.3 Symbols and Conventions .................................................................................. 7
1.3.1 Bulleted Lists.................................................................................................... 7
1.3.2 Actions ............................................................................................................. 7
1.3.3 Numbers........................................................................................................... 7
1.3.4 Parameters....................................................................................................... 7
1.3.5 Directory paths................................................................................................. 7
1.3.6 ASCII code....................................................................................................... 7
1.4 Explanation of the warnings................................................................................ 8
1.5 Used Technical Terms and Abbreviations......................................................... 8
1.6 Copyright............................................................................................................... 9
1.7 Legal requirements .............................................................................................. 9
1.8 Updates and upgrades......................................................................................... 9
1.9 Trademarks ........................................................................................................... 9
2SAFETY 10
2.1 Intended use ....................................................................................................... 10
2.2 General safety notes .......................................................................................... 10
2.2.1 Installation and startup................................................................................... 10
2.2.2 Conformity...................................................................................................... 10
2.2.3 Operation ....................................................................................................... 10
2.2.4 Maintenance, inspection, repair..................................................................... 10
2.3 Disposal............................................................................................................... 11
3PRODUCT DESCRIPTION 12
3.1 Product variants ................................................................................................. 13
3.2 Scope of delivery................................................................................................ 13
3.2.1 Assembly........................................................................................................ 15
3.3 Product specification......................................................................................... 16
3.3.1 Image sensor ................................................................................................. 16
3.3.2 Mechanical data............................................................................................. 16
3.3.3 Electrical data................................................................................................. 16
3.3.4 Operating conditions...................................................................................... 17
3.4 Connections and pin assignment..................................................................... 18
3.4.1 Fieldbus versions........................................................................................... 18
3.4.2 Power............................................................................................................. 21
3.4.3 LAN ................................................................................................................ 22
3.4.4 Fieldbus.......................................................................................................... 22
3.4.5 IO-Link............................................................................................................ 23
3.5 Display elements ................................................................................................ 24
3.5.1 Displays on the front / at the plug connectors................................................ 24
3.5.2 Displays on the front ...................................................................................... 24
3.5.3 Displays at the plug connectors..................................................................... 24
3.6 Cleaning............................................................................................................... 25
4FIRST STEPS 26
4.1 Step 1: Establishing a network connection with the SMARTCAMERA ........ 26
4.2 Step 2: Turn on SMARTCAMERA ..................................................................... 27
4.3 Step 3: Opening the BVS Cockpit web interface............................................. 27

4
BVS Cockpit
5STARTUP 28
5.1 Updating software .............................................................................................. 28
5.2 Network topologies ............................................................................................ 29
5.3 System settings.................................................................................................. 30
5.4 Selecting the communication interface for the process data........................ 31
5.5 Network settings / LAN interface ...................................................................... 32
5.5.1 Network configuration via BVS Cockpit ......................................................... 32
5.6 Digital I/O interface............................................................................................. 33
5.7 Fieldbus interfaces............................................................................................. 34
5.7.1 General fieldbus parameters in BVS Cockpit ................................................ 34
5.7.2 Configuration.................................................................................................. 36
5.7.3 Coding IO-Link data modules (slot 2) ............................................................ 37
5.7.4 Data modules for IO-Link inputs .................................................................... 37
5.7.5 Parameter configuration................................................................................. 39
5.7.6 Integration into project planning software...................................................... 42
5.7.7 Process data structure................................................................................... 47
5.7.8 Configuration via explicit messages............................................................... 50
5.7.9 SMARTCAMERA integration in Rockwell Studio 5000.................................. 52
5.8 IO-Link interface ................................................................................................. 54
5.8.1 PLC gateway mode........................................................................................ 54
5.8.2 Camera mode ................................................................................................ 55
5.8.3 IO mode ......................................................................................................... 57
6APPENDIX 58
6.1 Troubleshooting Table....................................................................................... 58
6.2 Type code............................................................................................................ 60
6.3 Accessories ........................................................................................................ 61

www.balluff.com
5
BVS Cockpit
User's manual

6
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
1 User instructions
1.1 Introduction
These operating instructions describe the SMARTCAMERA product from the Balluff Vision Solutions BVS SC product
family as well as the data interfaces and the startup for an immediate operation.
The web-based software interface integrated in the SMARTCAMERA is described in the separate software manual (BVS
Cockpit manual).
Both manuals are available on the Balluff product website via www.balluff.com or via the help system of the BVS Cockpit
interface.
The SMARTCAMERA was developed to identify objects in automated industrial environments via optical codings (bar-
code, 2D codes or plain text) and to recognize and verify characteristics of objects such as presence, contours, dimen-
sions, colors and positions. The test results can be processed in a flexible way and forwarded to the higher-level control-
ler. Some outstanding properties are:
•Complete camera control and evaluation integrated in the device
•Simple camera access from the network
•Simple and user-friendly settings, control of camera without additional software
•Simple, user-supporting operation
•Direct connection to industrial networks (fieldbuses)
•Support of Industry 4.0 through IO-Link
•Separate data channel for larger data volumes
•Integrated, flexible displays of process statistics
These characteristics make it possible to easily create test and identification tasks in automation, to flexibly check the
status of the test process, to monitor long-term processes in a clearly arranged way.
Hence, the SMARTCAMERA perfectly supports logistics processes and quality assurance in different industries.
These operating instructions apply to the following variants of the SMARTCAMERA:
Ordering code
Product name
Description
BVS0029
BVS SC-M1280Z00-30-010
SMARTCAMERA Ident monochrome
PROFINET / EtherNet/IP + IO-Link
BVS002A
BVS SC-M1280Z00-30-000
SMARTCAMERA monochrome
PROFINET / EtherNet/IP + IO-Link
BVS002F
BVS SC-C1280Z00-30-000
SMARTCAMERA color
PROFINET / EtherNet/IP + IO-Link
BVS0033
BVS SC_M1280Z00-30-020
SMARTCAMERA HDevelop monochrom
PROFINET / EtherNet/IP + IO-Link
Balluff GmbH completes the customer offering with a distinct service and accessories palette.
1.2 Other applicable documents
Additional information about this product can be found at www.balluff.com on the product page, e.g. in the
following documents:
•Data sheet
•Declaration of Conformity
•Disposal

www.balluff.com
7
BVS Cockpit
1.3 Symbols and Conventions
The following conventions are used in this manual:
1.3.1 Bulleted Lists
Enumerations are shown as a list with an en-dash.
•Entry1
•Entry 2
1.3.2 Actions
Action instructions are indicated by a preceding triangle. The result of an action is indicated by an arrow.
1. Action instruction 1
a. Action result
2. Action instruction 2
1.3.3 Numbers
•Decimal numbers are shown without additional indicators (e.g. 123).
•Fixed-point numbers are shown with a period (e.g. 0.123).
•Hexadecimal numbers are shown with the additional indicator hex (e.g. 00hex).
1.3.4 Parameters
Parameters are shown in italics (e.g. CRC_16).
1.3.5 Directory paths
Path information for saving data is shown with fixed font width (e.g. Projekt:\Data Types\Benutzerdefin-
iert).
1.3.6 ASCII code
Characters transmitted in ASCII code are set in apostrophes (e.g. 'L').
NOTE
This symbol indicates general notes.

8
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
1.4 Explanation of the warnings
Always observe the warnings in these instructions and the measures described to avoid hazards. The warnings used
here contain various signal words and are structured as follows:
SIGNAL WORD
Type and source of the hazard
Consequences if not complied with
→ Measures to avoid hazards
The individual signal words mean:
ATTENTION
Indicates a danger that can lead to damage or destruction of the product.
1.5 Used Technical Terms and Abbreviations
BVS
Balluff Vision Solutions
CMOS
Complementary metal-oxide-semiconductor
DCP
Discovery and basic Configuration Protocol
DHCP
Dynamic Host Configuration Protocol
DID
Device ID
I/O port
Digital input and output port
EEPROM
Electrical Erasable and Programmable ROM
EMC
Electromagnetic compatibility
EtherNet/IP
Ethernet Industrial Protocol
FCC
Federal Communications Commission
FE
Function ground
GND
Ground
GSD
General Station Description
GSDML
GSD Markup Language
I/O port
Digital input / output port
ID
Identification
IO
Input / Output
IP
Internet Protocol
IRT
Isochronous Real-time
LAN
Local Area Network
LPS
Limited Power Source
MAC
Media Access Control
n.c.
not connected
PC
Personal Computer
PROFINET
Process Field Network
RT
Real-time
RX
Receiver
SC
SMARTCAMERA
SIO
Standard Input/Output
PLC
Programmable Logic Controller
TX
Transmitter
UINT8
unsigned integer, 1 byte long
UINT16
unsigned integer, 2 bytes long
UINT32
unsigned integer, 4 bytes long

www.balluff.com
9
BVS Cockpit
1.6 Copyright
Copyright © Balluff GmbH, Neuhausen a.d.F., Germany, 2021. All rights reserved. In particular: Right to duplication,
modification, dissemination and translation into other languages. Please note that all texts, graphics and images con-
tained in these operating instructions are protected by copyright and other protection laws. Commercial duplications, re-
productions, modifications and disseminations of any type require the prior written approval of Balluff GmbH. All infor-
mation and notes in these operating instructions, particularly the chapter Safety Instructions, must be observed.
1.7 Legal requirements
The General Terms and Conditions of Balluff GmbH in their respective current version and the conditions in these oper-
ating instructions exclusively apply to all deliveries of products and to all other services of Balluff GmbH (henceforth re-
ferred to as “GTC”). The provisioning of the software is exclusively subject to the respective current GTC, the conditions
in these operating instructions as well as the regulations of the “Balluff Enduser Licensing Agreement”. You may use the
software only in compliance with these provisions. If they should not yet be available, Balluff GmbH will gladly provide the
current GTC upon request.
The SMARTCAMERA uses an embedded Linux/GNU as the operating system. Also used are a variety of freely available
tools which were published under various open source licenses. Some licenses require that the source code and modifi-
cations be published. These sources are published on the Product homepage.
The license texts for all software products used can be downloaded from the web interface along with the manuals. They
are available as ZIP files.
1.8 Updates and upgrades
Balluff GmbH is authorized –but not obligated –to make updates or upgrades of the firmware available via the website
of Balluff GmbH or in any other form. In such a case, Balluff GmbH is authorized –but not obligated –to inform you
about the updates or upgrades. The use of such upgrades or updates assumes that you accepted the validity of the cur-
rent GTC as well as the additional conditions in the operating instructions.
1.9 Trademarks
The product, trade, company and technology designations used (e.g. Microsoft®, Windows 7®, Internet Explorer®,
Google Chrome®, Mozilla Firefox® and HALCON®) are trademarks of the respective owners.

10
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
2 Safety
2.1 Intended use
The SMARTCAMERA BVS SC is a camera with integrated image analysis for contactless acquisition and examination of
objects in industrial environments.
The intended use also includes that you have read these operating instructions in their entirety and follow all the infor-
mation –particularly the section “Safety”.
2.2 General safety notes
2.2.1 Installation and startup
Installation and startup may only be performed by trained technical personnel. Qualified personnel are people who are
familiar with installation and operation of the product and have the necessary qualifications for these tasks. Manufactur-
er's guarantee, warranty and liability are void for damage caused by unauthorized tampering or unapproved use, installa-
tion or handling in violation of the specifications of this user's guide. The operator must ensure that appropriate safety
and accident prevention regulations are observed
ATTENTION
Short circuit
A faulty polarity can damage the camera.
•When connecting the SMARTCAMERA to an external controller, observe proper selec-
tion and polarity of the connection as well as the power supply (see “Connections and
pin assignment”).
The SMARTCAMERA may only be used with an approved power supply (see “Product specification”).
2.2.2 Conformity
This product was developed and manufactured in accordance with all applicable European
Directives. CE conformity has been verified.
This product is approved by UL
PROCESS CONTROL EQUIPMENT File No. E227256.
All approvals and certifications are no longer valid in the following cases:
•Components are used that are not part of the SMARTCAMERA BVS SC.
•Components are used that have not been explicitly approved by Balluff. For a list of the approved components,
see chapter “Accessories”.
2.2.3 Operation
Before commissioning, carefully read the user's guide.
The system must not be used in applications in which the safety of persons is dependent upon proper functioning of the
device.
The operator is responsible for ensuring that local safety regulations are observed.
2.2.4 Maintenance, inspection, repair
The working principle used in this SMARTCAMERA is maintenance- and wear-free. The operator must regularly inspect
the SMARTCAMERA for signs of damage or malfunctions in line with the operating conditions and environmental

www.balluff.com
11
BVS Cockpit
influences. If any damage or wear is found, the SMARTCAMERA must be immediately taken out of operation and se-
cured against unauthorized use.
Only service technicians from Balluff GmbH may repair defective devices. Intervention in the product by the operator is
not permitted due to safety reasons. The SMARTCAMERA's housing may not be opened or loosened!
NOTE
In the interests of product improvement, Balluff GmbH reserves the right to change the tech-
nical data of the product and the content of this manual at any time without notice.
2.3 Disposal
Observe the national regulations for disposal.
NOTE
Additional information can be found at www.balluff.com on the product page.

12
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
3 Product description
The Balluff SMARTCAMERA BVS SC is a camera for the acquisition and analysis of black- and white and color images.
Application areas are optical identifications of codes and plain text, inspections for quality assurance and the measure-
ment of objects. The camera can also be used in robot environments.
With the fieldbus system interface or via the Gigabit LAN interface, the host system can affect the camera and read out
customer-specific result data.
An IO-Link master interface is available as additional interface which enables a direct integration of IO-Link components.
This allows the SMARTCAMERA to make a valuable contribution for implementing requirements in the environment of
Industry 4.0.
Since the complete software is located on the SMARTCAMERA itself, no external software is required for the configura-
tion and monitor display. Using standardized web browsers such as Google Chrome, Mozilla Firefox or Internet Explorer,
the user can easily connect with the SMARTCAMERA and work in the Balluff BVS Cockpit interface developed specifi-
cally for camera systems.

www.balluff.com
13
BVS Cockpit
3.1 Product variants
The SMARTCAMERA has been designed in accordance with current, industrial standards:
•Image acquisition: C-mount lenses with corresponding matching filters; 1280 x 1024 pixel monochrome or color
sensor
•LAN connection via Gigabit Ethernet M12
•Configuration/monitoring via Google Chrome, Mozilla Firefox or Microsoft Internet Explorer
•Digital input/output channels for NPN and PNP connections
•Fieldbus interface PROFINET IO or EtherNet/IP via M12 plug connectors
•4 GB NAND Flash, 1 GB SDRAM
The SMARTCAMERA product family is available in different designs.
Designation
Sensor
Image processing
LAN
Fieldbus
IO-
Link
Digital
I/Os
BVS0029
BVS SC-M1280Z00-
30-010
Mono-
chrome
Identification tools
yes
PROFINET /
EtherNet/IP
(configura-
ble)
yes
2/81)
BVS002A
BVS SC-M1280Z00-
30-000
Mono-
chrome
All tools
yes
PROFINET /
EtherNet/IP
(configura-
ble)
yes
2/81)
BVS002F
BVS SC-C1280Z00-
30-000
Color
All tool
yes
PROFINET /
EtherNet/IP
(configura-
ble)
yes
2/81)
BVS0033
BVS SC-M1280Z00-
30-020
Mono-
chrome
All tools plus HDevelop
interface
yes
PROFINET /
EtherNet/IP
(configura-
ble)
yes
2/81)
1) depending on the configuration of the IO-Link port
3.2 Scope of delivery
Included in the scope of delivery
•SMARTCAMERA BVS SC
•Filter (mounted):
owith monochrome sensor: protection glass
owith color sensor: IR-Cut
•2 × cap M12
•Safety Precautions
•Condensed Guide
A lens protection is available for specific environmental conditions which is screwed directly onto the camera housing,

14
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
thereby meeting the requirements in accordance with IP67.
NOTE
Only C-mount lenses with a maximum diameter of 42 mm and a length of 40 mm can be
used here. For lenses up to 69 mm the long tube BAM PC-VS-023-1-01 (BAM02W0) may
be used. For lenses up to 86 mm the long tube BAM PC-VS-023-1-02 (BAM039R) may be
used.
The following accessory groups complete the Balluff product range:
•C-mount lenses (BAM LS-VS)
•Screw-on filter (BAM OF-VS-002-xx-yy)
•Lights (BAE LX)
•Touchpanel PC (BAE-PD-VS-011-01)
•Mounting accessories
•Connection cables (BCC)
•Power supply units
NOTE
Visit www.balluff.com for more information on available software and accessories.

www.balluff.com
15
BVS Cockpit
3.2.1 Assembly
The camera features 12 internal threads for installation at the location of use. Four threads each at the rear, the left and
the right. This ensures secure and reliable mounting. The following drawings describe the exact position of all mounting
holes.
Individual threads are also used for fastening optional accessories (see chapter “Accessories”).
The screw connections at the rear plate have M4 threads. The maximum engagement length is 5 mm. The maximum
tightening torque is 2 Nm.
The lateral screw connections have an M5 thread. The maximum engagement length is 5 mm. The maximum tightening
torque is 2.6 Nm.

16
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
3.3 Product specification
3.3.1 Image sensor
Model variant
Monochrome (CMOS)
Color (CMOS)
Resolution
1280 × 1024
Max. frame rate [Hz]
60
Shutter type
Global Shutter 1)
Sensor size
1/1.8"
Pixel size [µm]
5,3 x 5,3
Spectral sensivity
1) A global shutter sensor is not read line by line or column by column, but in one access. This rules out distortions with
moving motifs (rolling shutter effect).
3.3.2 Mechanical data
Housing material
Painted aluminum die-cast box
Degree of protection
IP67 (with connectors and protection tube) 2)
Weight
approx. 360 g
Dimensions (L × W × H, without
connector, without lens)
110 × 62 × 55 mm
2) The enclosure rating has not been UL certified.
3.3.3 Electrical data
Supply voltage
24 V ±20 %
Residual ripple
≤ 5 %
Rated current consumption without external load
300 mA
Max. current consumption
4 A
Protective circuit
Reverse polarity protection
WARNING
The SMARTCAMERA and accessories shall be supplied by limited energy in accordance to
UL 61010-1 Third Edition, Sub. Clauses 9.4 or LPS in accordance to UL 60950-1 or Class 2
in accordance to UL 1310 or UL 1585.

www.balluff.com
17
BVS Cockpit
3.3.4 Operating conditions
Ambient temperature
0 °C to +55 °C
Storage temperature
–25 °C to +70 °C
EMC
EMV EN 61000-4-2/3/4/5/6
EN 61000-6-2
EN 61000-6-3
EN 55011
Vibration/shock for operation in-
side
EN 60068 Part 2-6/27
Operation
Internally
Height
up to 2000 m
Relative humidity
maximum 80 % for temperatures up to 31 °C, decreasing linearly to 50 % at
40 °C
Pollution degree
Pollution degree 2
Vibration/shock was verified for the SMARTCAMERA –the C-mount lens used and its adjustment rings must be secured
accordingly for operation.

18
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
3.4 Connections and pin assignment
The product variants differ by the existing interfaces.
3.4.1 Fieldbus versions
Connection
Function
Power
Voltage supply of SMARTCAMERA, wo freely configurable I/O signals are also availa-
ble.
IO-Link
Connects the SMARTCAMERA with an IO-Link device or, e.g. an external lighting.
LAN
Integrates the SMARTCAMERA in a local network.
PROFINET / Ether-
Net/IP
Connects the SMARTCAMERA with the fieldbus network (PROFINET / EtherNet/IP)
ATTENTION
Risk of equipment damage
The SMARTCAMERA and accessories shall be supplied by limited energy in accordance to
UL 61010-1 Third Edition, Sub. Clauses 9.4 or LPS in accordance to UL 60950-1 or Class 2
in accordance to UL 1310 or UL 1585.
NOTE
In order to ensure enclosure rating IP67, unused I/O ports must be closed with cover caps.

www.balluff.com
19
BVS Cockpit
Power
5-pin M12 plug, A-coded
Pin
Description
Function
1
+24 VDC
Supply voltage
2
I/O 0
Input/output
3
GND
Ground
4
I/O 1
Input/output
5
Not used
None. Pin may not be used.
NOTE
The digital sensor inputs correspond to the guideline concerning inputs, EN 61131‑2,Type
3.
The maximum load on any output is 100 mA. The total current of the module must not ex-
ceed 4 A per pin. The load or supply must be limited accordingly.
IO-Link
5-pin M12 female, A-coded
Pin
Description
Function
1
L+
Supply voltage
2
I/Q, IO 6
Input/output
3
L-
Ground
4
C/Q, IO 7
IO-Link/Input/output
5
Not used
None. Pin may not be used.
NOTE
The maximum load on the supply voltage output is 1.2 A.
Every output may be loaded with a maximum current of 2 A.
Unused ports must be provided with cover caps in order to ensure enclosure rating IP67.

20
BVS SC-_1280Z00-30-0-0
SMARTCAMERA Fieldbus
LAN
8-pin M12 socket, X-coded
Pin
Description
Function
1
BI_DA +
Bidirectional data, Pair A +
2
BI_DA –
Bidirectional data, Pair A –
3
BI_DB +
Bidirectional data, Pair B +
4
BI_DB –
Bidirectional data, Pair B +
5
BI_DD +
Bidirectional data, Pair D +
6
BI_DD –
Bidirectional data, Pair D –
7
BI_DC –
Bidirectional data, Pair C –
8
BI_DC +
Bidirectional data, Pair C +
Fieldbus
Female M12, 4-pin, D-coded
Pin
Description
Function
1
+ Tx
Transmit data +
2
+ Rx
Receive data +
3
- Tx
Transmit data -
4
- Rx
Receive data -
NOTE
The cable must correspond at least to category 5e in accordance with EIA/TIA-568.
Transfer in accordance with 1000BASE-T/100BASE-TX/10BASE-T is being supported.
NOTE
The cable must correspond at least to category 5 in accordance with EIA/TIA-568.
