BDI ALIGN 7477 User manual

ALIGN™7477
3 BAY MEDIA CABINET WITH CONSOLE / MEDIA LEG
DESIGN MATTHEW WEATHERLY
LET’S GET STARTED.
INSTRUCTION MANUAL

BDIUSA.COM | 3NEED ASSISTANCE? [e-mail]
Congratulations on the purchase of your Align Media Cabinet 7477 from BDI. Your
cabinet has been designed to provide a lifetime of enjoyment. This manual will provide
you with assembly instructions and other helpful information that will ensure that you
get the most out of your cabinet. Please save it for future reference.
Your Align cabinet has been engineered for simple assembly. Please follow these
directions carefully to prevent any damage.
Should you need further assistance, contact BDI at [e-mail].
ENJOY!

4 | BDIUSA.COM ALIGN 7477
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
PART # H3
DESCRIPTION M6 x 83mm Flathead Screw
QUANTITY 6
PART # H5
DESCRIPTION TV Safety Strap
QUANTITY 1
PART # H2
DESCRIPTION M6 x 12mm Screw
QUANTITY 8
PART # H4
DESCRIPTION KLEET™ Cord Wrap
QUANTITY 2
PART # T1
DESCRIPTION Hex Wrench
QUANTITY 1
PART # T2
DESCRIPTION Hex Leveler
QUANTITY 1
PART # H1
DESCRIPTION M6 x 18mm
Flathead Screw
QUANTITY 8
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at
[e-mail].
Do not use power tools for assembly of this product.
For all other concerns, please contact your BDI retailer.

HARDWARE AND COMPONENTS
BDIUSA.COM | 5NEED ASSISTANCE? [e-mail]
PART # A1
DESCRIPTION Cabinet
QUANTITY 1
PART # A3
DESCRIPTION End Plate
QUANTITY 2
PART # A2
DESCRIPTION Base Rail
QUANTITY 2
PART # A4
DESCRIPTION Media Leg
QUANTITY 2
PART # A5
DESCRIPTION Console Leg
QUANTITY 2
PART # A6
DESCRIPTION Back Panel
QUANTITY 2
OR

6 | BDIUSA.COM ALIGN 7477
Connect (A3) End Plates to (A2) Base Rails using
8 (H1) Flathead Machine Screws. Tighten with
(T1) Hex Wrench.
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H1-FLATHEAD MACHINE
SCREW 8
STEP 1. BUILD THE BASEASSEMBLY
A3
A3
A2
A2
H1
H1
H1
H1
H1
A3
A2
T1

BDIUSA.COM | 7NEED ASSISTANCE? [e-mail]
Connect either (A4) Media or (A5) Console
Legs to the ends of the base assembly using
8 (H2) Machine Screws as shown. Start all
screws before fully tightening the screws with
(T1) Hex Wrench.
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H2-MACHINE SCREW 8
ASSEMBLY
STEP 2. ATTACH THE LEGS
MEDIA LEGS CONSOLE LEGS
A4
A4
A5
A5
H2
H2
H2
H2

8 | BDIUSA.COM ALIGN 7477
Make sure cartons are still inside the (A1) Cabinet
to keep the shelves in place. With help from
another person, carefully position the (A1) Cabinet
on its back as shown. Attach the base to the
(A1) Cabinet with 6 (H3) Flathead Screws using
(T1) Hex Wrench. Do NOT fully tighten until all
screws are started.
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H3-FLATHEAD SCREW 6
STEP 3. ATTACH THE BASEASSEMBLY
2 PERSON TASK
MEDIA BASE
CONSOLE BASE
A1
A1
H3
H3
H3
H3
H3
H3
H3
H3
H3
H3
H3
H3

BDIUSA.COM | 9NEED ASSISTANCE? [e-mail]
The 2 (A6) Back Panels are removable and can slide towards the middle. To install, put the top edge
of the back panel into the top groove, then drop the bottom edge into the bottom groove.
Your Align Media Cabinet comes with 2 (H4) KLEET Cord Wraps which can be used for cord
management.
A (H5) TV Safety Strap is included. To secure your TV to the cabinet, unravel the bundle and follow
the instructions on the hang tag.
ASSEMBLY
STEP 4. INSTALL BACK PANELS
A6
A6
2
1
TV Safety
Strap
Cord Management

10 | BDIUSA.COM ALIGN 7477
Levelers are accessed at the bottom of each leg.
If your floor is uneven, extend one or more levelers
using (T2) Hex Leveler Wrench to attain a level,
stable cabinet placement. Turning the leveler
clockwise will extend the leveler; turning it counter-
clockwise will retract it. Leveling the cabinet will
improve door alignment.
LEVEL CABINET
FINE TUNING
down
PART/DESCRIPTION QTY
T2-HEX WRENCH 1
T2
