BDI OCTAVE 8377 User manual

1
Product Registration
Registering your new BDI product allows us to send you important
product updates, service information and helpful hints related to your
BDI products. Register today, and you will be entered to win free a BINK
table from BDI: www.bdiusa.com/register
Placement and Maintenance
Your Octave Console is designed for indoor use on level floors.
Clean wood veneer and steel parts with a moist cloth.
Octave is engineered for easy assembly. Carefully follow this procedure
to prevent any damage. Do not use power tools for assembly of this
product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, contact BDI Customer Service at: [email protected].
For all other concerns, please contact your BDI retailer.
bdiusa.com
customerservic[email protected]om
Designed by BDI Studio.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Octave & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2016, BDI
Made in China. 09.08.2017 V3
OCTAVE™8377/8379
3 DOOR & 4 DOOR CONSOLE
A1 Cabinet x 1
[quad (shown)
or triple wide]
C5 Back Panels x 2
H3 KLEET™ Cord Wrap x 2
C4 Side Shelf x 2
(Quad only)
C3 Middle Shelf x 1
(Quad only)
C1 Sub-frame C2 Leg Frame x 2
T2 Hex Wrench x 1
H1 1/4-20 x 40 mm
Machine Screw x 14
H2 12mm wood
Screw x 4
T1 Phillips Screwdriver x 1

bdiusa.com
customerservic[email protected]om
OCTAVE 8377/8379
3 & 4 DOOR CONSOLE
2
Step 2 - Attach the 2Leg frames C2 to Sub-frame C1 with 8Screws H1 using Hex wrench T2.
Make sure the red arrow on the sub-frame faces as shown.
Step 3 Quad - With help from another person, carefully position the cabinet A1 on its back (as shown) or
upside down. Caution-do not remove blocking above the shelves. Attach the base to the cabinet with 6
Screws H1 using Hex Wrench T2. Do NOT fully tighten until all 6 screws are started.
H1 Screw x 8
C1
C2
2 Person Ta sk
T2
H1
T2
H1 Screw x 6
Red arrow
H1
A1
C2

bdiusa.com
customerservic[email protected]om
OCTAVE 8377/8379
3 & 4 DOOR CONSOLE
3
Step 4 Rotate onto Base
1) Place packing material under the rear legs (to protect your floor), 2) With help from another person, rotate the
console to the upright position.
2 Person Ta sk
Step 3 Triple - With help from another person, carefully position the cabinet A1 on its back (as shown) or up
side down. Attach the base to the cabinet with 6 Screws H1 using Hex Wrench T2. Do NOT fully tighten until
all 6 screws are started.
2 Person Ta sk
2
Place cardboard angles
under the back legs to
protect the floor during
rotation, then remove.
T2
H1 Screw x 6
1
Front
Front
H1
A1

bdiusa.com
customerservic[email protected]om
OCTAVE 8377/8379
3 & 4 DOOR CONSOLE
4
Step 6 - The 2 Back Panels C5 are removable and can slide towards the middle. To remove lift up and pull the
bottom edge out of its groove. To re-install, put the top edge of the back panel into the top groove, then drop
the bottom edge into the bottom groove.
Your Octave Console comes with 2KLEET Cord Wraps H4. Install into the pre-drilled holes as shown using 4
wood screws H2 and Phillips screwdriver T1.
2
C5
C5
H4 Cord Wrap
H4 H4
Step 5 Quad Only - Adjustable Shelves
The shelf pins located inside all three cabinet spaces may be repositioned using Screwdriver T1, allowing you
to raise or lower Middle and Side Shelves C3 and C4 to the desired level.
C3
C4
C4
T1
1
H2 Wood screw
x 4
T1 Phillips
Screwdriver x 1

bdiusa.com
customerservic[email protected]om
OCTAVE 8377/8379
3 & 4 DOOR CONSOLE
5
Fine tuning your new BDI Media Furniture
These steps are to be followed after you have unpacked and completed the simple assembly instructions for
your console. Due to jostling in freight or perhaps an uneven floor, the doors on your cabinet may not appear
to be in perfect alignment. Making a few minor adjustments can rectify this situation. The high-quality European
hinge hardware is adjustable. Through a little adjustment, you can modify the orientation of the cabinet doors to
make sure that they are sitting perfectly on your unit.
STEP 1 - Level your unit
Levelers are integrated into each leg assembly and are accessed at the bottom of each cabinet leg. If your floor
is uneven, you may extend one or more levelers to attain a level, stable cabinet placement. Turning the leveler
clockwise will extend the leveler; turning it counter-clockwise will retract it.
STEP 2 - Adjust Door Hinges (if needed)
The doors on your console should be evenly spaced and the doors should open and close freely without rubbing
against the door frame. If the cabinet’s doors appear out of alignment, this condition can be corrected with minor
adjustment to the European hinges on each door. Because these hinges are adjustable, adjusting one hinge
element can sometimes cause the need for adjustments to other elements. But with a few adjustments, you
can modify the orientation of the cabinet doors to make sure that they hang
perfectly within your cabinet.
Use the Phillips Screwdriver T1 supplied to adjust the door hinges:
• By adjusting Screw 1, the door will move LEFT or RIGHT within the frame.
Make minor adjustments at both top and bottom hinges for best results.
• By adjusting Screw 2, the door will move UP or DOWN.
• By adjusting Screw 3 the entire door will move IN or OUT, opening or
closing the gap between the door frame and cabinet. (This screw rarely
needs adjustment.)
Loosening screw 1
on top hinge will close the
seam between Door C
& Door D here.
Tightening screw 1
on this hinge will open
the seam between Door C
& Door D here.
1 2 3
Door A Door B Door C Door D
Door C
