BDI SEQUEL 20 User manual

SEQUEL®20 6151/6152
LIFT DESK
DESIGN MATTHEW WEATHERLY
LET’S GET STARTED.
INSTRUCTION MANUAL
6151 SHOWN

BDIUSA.COM | 3NEED ASSISTANCE? customerservic[email protected]
Congratulations on the purchase of your Sequel 20 Lift Desk 6151 / 6152 from BDI. Your
desk has been designed to provide a lifetime of enjoyment. This manual will provide you
with assembly instructions and other helpful information that will ensure that you get
the most out of your desk. Please save it for future reference.
Your Sequel 20 Lift Desk is designed for indoor use on level floors. It has been engineered
for easy assembly. Please follow these directions carefully to prevent any damage.
Should you need further assistance, contact BDI at [e-mail].
ENJOY!

4 | BDIUSA.COM SEQUEL 20 6151 & 6152
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
PART # A1
DESCRIPTION Main Panel
QUANTITY 1
PART # T1
DESCRIPTION 4mm Hex Wrench
QUANTITY 1
PART # H3
DESCRIPTION Cord Wrap
QUANTITY 2
PART # H6
DESCRIPTION M6 x 12mm
Screw
QUANTITY 5
PART # H1
DESCRIPTION Long Wood Screw
QUANTITY 2
PART # H4
DESCRIPTION M6 x 16mm Screw
QUANTITY 8
PART # H7
DESCRIPTION Cord Clip
QUANTITY 6
PART # H8
DESCRIPTION Glass
Bumper
QUANTITY 2
PART # H2
DESCRIPTION Short Wood Screw
QUANTITY 12
PART # H5
DESCRIPTION M6 x 15mm Screw
QUANTITY 10
PART # H9
DESCRIPTION Dual Lock
Dot
QUANTITY 8
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at
customerservic[email protected]om.
Do not use power tools for assembly of this product.
For all other concerns, please contact your BDI retailer.

HARDWARE AND COMPONENTS
BDIUSA.COM | 5NEED ASSISTANCE? customerservic[email protected]
PART # C9
DESCRIPTION Glass Panel
QUANTITY 1
PART # C4
DESCRIPTION Cord Extension
QUANTITY 1
PART # C6
DESCRIPTION Power Cord
QUANTITY 1
PART # C5
DESCRIPTION Foot
QUANTITY 2
PART # C7
DESCRIPTION Wire Tray
QUANTITY 1
PART # C8
DESCRIPTION Cord Conduit
QUANTITY 1
PART # C2
DESCRIPTION Control Module
QUANTITY 1
PART # C1
DESCRIPTION Keypad
QUANTITY 1
PART # C3
DESCRIPTION Leg
QUANTITY 2
PART # C10
DESCRIPTION Grommet Cover
QUANTITY 1
TOOL REQUIRED (NOT INCLUDED)
Phillips Screwdriver

6 | BDIUSA.COM SEQUEL 20 6151 & 6152
Lay (A1) Main Panel upside down on a soft
surface (carpet). Attach (C1) Keypad on the
desired side (choose left or right) with 2 (H2)
Short Wood Screws and a Phillips Screwdriver.
IMPORTANT! Orient the (C2) Control Module
so that the keypad cord socket (labeled HS) is
facing the keypad side and secure between the
2 steel rails with 2 (H1) Long Wood Screws as
shown. Route the keypad cord into the groove
in the panel and through the hole in the metal
frame. Attach 2 (H3) Cord Wraps (Kleet) using
(H2) Short Wood Screws.
STEP 1. INSTALL CONTROL MODULE AND KEYPADASSEMBLY
PART/DESCRIPTION QTY
H1-WOOD SCREW 2
H2-WOOD SCREW 6
H3-CORD WRAP 2
NOT INCLUDED
Phillips Screwdriver 1
Left hand
side Right hand side
Route cord
through hole in
metal frame
Choose
Groove for
keypad cord
C1 C1
H3
H2
C1
H2
A1
C2
H1
H1

BDIUSA.COM | 7NEED ASSISTANCE? customerservic[email protected]
Attach keypad cord into the (C2) Control
Module socket (labeled HS) and bundle the
slack with the hook and loop tie. Secure the
keypad cord into the groove using 6 (H7) Cord
Clips and 6 (H2) Short Wood Screw. Tighten
with a Phillips Screwdriver.
ASSEMBLY
STEP 2. CONNECT & SECURE KEYPAD
PART/DESCRIPTION QTY
H2-WOOD SCREW 6
H7-CORD CLIP 6
NOT INCLUDED
Phillips Screwdriver 1
Hook &
loop tie
Keypad cord
inside groove
H2 H2
H7H7
H7
H7
H7
H7
H7
H2
H2
H2
H2
H2
C2

8 | BDIUSA.COM SEQUEL 20 6151 & 6152
Attach 2 (C3) Legs with 4 (H5) Screws per leg
using (T1) Hex Wrench. Start all 4 screws before
tightening them down. Connect (C4) Cord
Extension into the top of (C2) Control Module.
Connect 1 leg cord to the end of (C4) Cord
Extension, connect the other leg cord to the
other end of the (C2) Control Module and bundle
up any slack using the hook and loop ties.
STEP 3. INSTALL LEGSASSEMBLY
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H5-SCREW 8
C3
C3
C3
C4
C4
C2
C4
C2
C2
H5
H5
H5
H5
H5
H5
H5
H5

BDIUSA.COM | 9NEED ASSISTANCE? customerservic[email protected]
Attach (C5) Feet with (H4) Flathead Screws
and (T1) Hex Wrench. Make sure the longer end
of the feet are facing the front of the desk
(same side as keypad).
ASSEMBLY
STEP 4. INSTALL FEET
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H4-SCREW 8
H4
C5
Long end this side
C5
H4
H4
C5

10 | BDIUSA.COM SEQUEL 20 6151 & 6152
Determine if you prefer the wire tray to be
centered, shifted left or shifted right. If you plan
to use a monitor arm, it might be better to shift
the position of the (C7) Wire Tray to make the
monitor arm attach more centrally. Attach the
metal (C7) Wire Tray to the back edge of the
bottom of the desk with 2 (H5) Screws.
STEP 5. INSTALL WIRE TRAY—OPTIONALASSEMBLY
PART/DESCRIPTION QTY
H5-SCREW 2
Shifted Right Shifted Left
C7
H5
H5
