BE P1415EN User manual

Operation Manual
ELECTRIC
PRESSURE WASHER
P1415EN
BEPOWEREQUIPMENT
.COM
93497-GN

2 3
Product Specifications............................................................................. 2
Package Contents...................................................................................... 3
Hardware Contents ................................................................................... 3
Safety Information..................................................................................... 4
Assembly Instructions.............................................................................. 7
Operating Instructions ..............................................................................11
Care and Maintenance............................................................................. 12
Pump Saver ................................................................................................ 14
Troubleshooting......................................................................................... 15
Limited Warranty ...................................................................................... 16
Replacement Parts List........................................................................... 17
TABLE OF CONTENTS
SPECIFICATIONS
Model Max PSI (lbs/sq.
in.)
Max GPM
(Gal/per
min)
Cold
Water Volts Amps Weight (lbs.)
P1415EN 1500 1.4 ü120 12 15
PRODUCT SPECIFICATIONS
WARNING: This product can expose you to
chemicals including lead, which is known to the
State of California to cause cancer and birth
defects or other reproductive harm. For more
information, go to www.P65Warnings.ca.gov.
Wash hands after handling.

2 3
PACKAGE CONTENTS
HARDWARE CONTENTS
3
PACKAGE CONTENTS
HARDWARE CONTENTS
PART DESCRIPTION QUANTITY
H Detergent Bottle 1
I Variable Spray Nozzle Lance 1
J Extension Lance 1
K Nozzle Cleaning Wire 1
L O-Ring Kit 1
AA Screws 2
PART DESCRIPTION QUANTITY
A Spray Gun Holster 1
B Handle 1
C Power Washer Unit 1
D Cord Hook 1
E Soft PVC High Pressure Hose 1
F Spray Gun 1
G Spray Gun Lock/Unlock 1
OFF/O
ON/I
E
H
B
C
K
A
DL
AA
PW909112S
J
I
F
G
AA
Screw
Qty. 2
Note: Screws are located in
manual package
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 3 16/12/17 下午12:38
3
PACKAGE CONTENTS
HARDWARE CONTENTS
PART DESCRIPTION QUANTITY
H Detergent Bottle 1
I Variable Spray Nozzle Lance 1
J Extension Lance 1
K Nozzle Cleaning Wire 1
L O-Ring Kit 1
AA Screws 2
PART DESCRIPTION QUANTITY
A Spray Gun Holster 1
B Handle 1
C Power Washer Unit 1
D Cord Hook 1
E Soft PVC High Pressure Hose 1
F Spray Gun 1
G Spray Gun Lock/Unlock 1
OFF/O
ON/I
E
H
B
C
K
A
DL
AA
PW909112S
J
I
F
G
AA
Screw
Qty. 2
Note: Screws are located in
manual package
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 3 16/12/17 下午12:38
Note: Screws are located in manual
package
2
2
7
5
9
3
1
13
15
14
4
8
10
8A
6
11
12
OFF/O
ON/I
Package content:
1. Power washer unit
2. Manual
3. Nozzle cleaning wire
(may be taped
to the manual)
4. Screws (2)
5. Handle
6. Cord hook
7. Spray gun holder
8. Spray gun
(8A shows trigger lock
button)
9. Variable Spray Nozzle
10. Turbo Lance
11. Lance Extension
12. High Pressure Hose
13. Detergent Bottle
14. Power washer quick connect
(QC) lter (clear)
(Connect to
Power Washer Unit)
15. Garden hose adapter (GHA)
(Connect to Garden Hose)
Quick Start Guide
2. Slide Gun holder on
side.
3. Slide cord hook on
side.
6. Release high pressure
hose from gun.
7. Press switch up to unlock and down to lock spray
gun. NOTE: The trigger lock prevents the trigger
from being engaged accidentally.
4. Screw on high pressure
hose to power washer
5. Push to attach high
pressure hose to gun.
OFF/O
ON/I
OFF/O
ON/I
Unlock Lock
1. Screw handle to main
unit.
Screw Driver not incluDeD
PART DESCRIPTION QTY
H Detergent Bottle 1
I Variable Spray
Nozzle Lance
1
J Extension Lance 1
K Turbo Lance 1
AA Screws 2
PART DESCRIPTION QTY
A Spray Gun Holster 1
B Handle 1
C Power Washer Unit 1
D Cord Hook 1
E Soft PVC High
Pressure Hose
1
F Spray Gun 1
G Nozzle Cleaning Wire 1
B
A
C
D
E
F
G
H
I
K
J
AA

4 5
SAFETY INFORMATIONSAFETY INFORMATION
Please read and understand this entire
manual before attempting to assemble,
operate, or install the product.
This manual contains information that
relates to PROTECTING PERSONAL
SAFETY and PREVENTING EQUIPMENT
PROBLEMS. It is very important to read
this manual carefully and understand it
thoroughly before using the product. The
symbols listed below are used to indicate
this information.
DANGER
Potential hazard that will result in
serious injury or loss of life.
WARNING
Hazard that could result in serious
injury or loss of life.
CAUTION
Potential hazard that may result
in moderate injury or damage to
equipment.
Note: The word “Note” is used to inform
the reader of something the operator
needs to know about the tool.
WARNING
To reduce the risk of injury, the user must
read and understand the instructions
before using this product.
1. Warning – When using this product
basic, precautions should always be
followed, including the following
2. Read all the instructions before using
the product
3. Know how to stop the product and
bleed pressures quickly. Be thoroughly
familiar with the controls.
4. Keep operating area clear of persons
5. Do not overreach or stand on unstable
support. Keep good footing and
balance at all times.
6. Follow the maintenance instructions as
specified in the manual
7. To avoid personal injury and/or
damage to property and to maximize
your power washing experience,
carefully follow all of the safety tips,
instructions, warnings and safeguards
and become familiar with all of the
controls.
8. This power washer conforms to
CSA and other safety and consumer
standards. DO NOT modify or rebuild
any part of your power washer.
9. DO NOT use your power washer when
you are under the influence of alcohol
or drugs. Use this power tool carefully
and only when you are alert.
10. Watch your balance and footing while
using your power washer. Surfaces
become slippery when wet and are
extra slippery when using a detergent
or cleaner.
11. NEVER operate the power washer in
bare feet, sandals, or open-toed shoes.
12. When using the power washer near
children, make sure they are closely
supervised by an adult to avoid injury.
NEVER let a child use the power
washer.

4 5
SAFETY INFORMATIONSAFETY INFORMATION
13. Keep fingers, hands, feet and any
part of your body clear of the stream
of high pressure water. The powerful
spray can cause blindness or blast
holes in the skin. It can break a window
if you are too close when you pull the
trigger on the spray gun.
14. ALWAYS wear eye protection to
prevent injury to eyes when operating
the power washer.
15. To avoid mishaps or injury, ALWAYS
use the trigger safety lock when not
using the power washer even if the
spraying stops for a moment.
16. The power washer is equipped with a
Ground Fault Circuit Interrupter (GFCI)
which greatly reduces the chance of
electric shock while the unit is in use.
If replacement of the plug or cord is
needed, use only identical replacement
parts.
17. Point the spray gun in a safe direction
when beginning a power washing
session.
18. NEVER spray directly at a person,
animal, electrical device or the unit
itself.
19. When first using the spray gun, hold
the spray gun and lance with two
hands when pulling the trigger (one
hand to pull the trigger and the other
to stabilize the gun assembly) until you
get used to the “kickback” from the
spray gun.
20. When you press the power switch
to turn o the power washer, water
pressure may remain in the system.
To discharge the pressure, point the
spray gun in a safe direction and pull
the trigger.
21. NEVER spray flammable liquids.
22. NEVER use the power washer in areas
that contain combustible dust, liquids
or vapors.
23. Avoid contact of the pressure hose
with sharp objects and examine the
hose regularly. Replace if damaged.
Due to the high pressure involved, it
cannot be repaired if cut or damaged.
24. Only use detergent specifically
formulated for power washers and
follow instructions on the detergent’s
label.
25. Protect eyes, lungs, and skin from
exposure to detergent. Dish or laundry
soap is too thick and will clog the
nozzle of your detergent bottle.
IMPORTANT: Store the power washer
indoors to prevent the water in the
unit from expanding under freezing
conditions. When the water freezes and
expands, your power washer will be
damaged and become inoperable. Or, if
storing outdoors, it is recommended you
use pump saver (not included) to protect
pumps.
26. NEVER use hot water with your power
washer. It will overheat and damage
the high pressure pump.
27. NEVER leave the power washer
unattended while it is powered “ON”.
28. ALWAYS turn the water supply “ON

6 7
” before turning the power washer
power to “ON”. Running the pump
dry will cause damage to the internal
components.
29. NEVER use a water supply to your
power washer that exceeds 150 PSI
maximum.
30. NEVER disconnect the high pressure
hose from the power washer while the
system is pressurized.
31. NEVER permanently engage the trigger
mechanisms on the spray gun.
32. NEVER operate the power washer
unless all components are properly and
securely connected.
33. NEVER allow the power washer pump
to run for more than one minute after
you have turned o the water supply.
This can cause the motor and pump to
overheat and fail.
34. NEVER use lances or other parts that
are not compatible for this specific AR
Blue Clean unit.
35. NEVER use an extension power cord
since it defeats the eectiveness of
the GFCI and increases the chance of
electrocuting the operator.
36. NEVER spray any electrical outlet with
your power washer.
37. Inspect the power cord before using.
DO NOT use it if it is damaged.
SAFETY INFORMATION
5
Double Insolated Product
SAFETY INFORMATIONSAFETY INFORMATION
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
detergent. Dish or laundry soap is too thick and will clog
the nozzle of your detergent bottle.
IMPORTANT: Store the power washer indoors to prevent
the water in the unit from expanding under freezing
conditions. When the water freezes and expands, your
power washer will be damaged and become inoperable.
Or, if storing outdoors, it is recommended you use pump
saver (not included) to protect pumps.
26. NEVER use hot water with your power washer. It will
overheat and damage the high pressure pump.
27. NEVER leave the power washer unattended while it
is powered “ON”.
28. ALWAYS turn the water supply “ON ” before turning
the power washer power to “ON”. Running the pump
dry will cause damage to the internal components.
29. NEVER use a water supply to your power washer
that exceeds 150 PSI maximum.
30. NEVER disconnect the high pressure hose from the
power washer while the system is pressurized.
31. NEVER permanently engage the trigger mechanisms
on the spray gun.
32. NEVER operate the power washer unless all
components are properly and securely connected.
33. NEVER allow the power washer pump to run for
more than one minute after you have turned off the
water supply. This can cause the motor and pump to
overheat and fail.
34. NEVER use lances or other parts that are not
compatible for this specic AR Blue Clean unit.
35. NEVER use an extension power cord since it defeats
the effectiveness of the GFCI and increases the
chance of electrocuting the operator.
36. NEVER spray any electrical outlet with your power
washer.
37. Inspect the power cord before using. DO NOT use it if
it is damaged.
Servicing of a Double-Insulated Appliance
Ground Fault Circuit Interrupter Protection:
This pressure washer is provided with a ground-fault
circuit-interrupter (GFCI) built into the plugs of the
power-supply cord. This device provides additional
protection from the risk of electric shock. Should
replacement of the plug or cord become necessary,
use only identical replacement parts that include GFCI
protection.
In a double-insulated product, two systems of insulation
are provided instead of grounding. Grounding means
are not provided for a double insulated product, nor
should grounding means be added to the product.
Servicing a double-insulated product requires extreme
care and knowledge of the system, and should only be
done by qualied service personnel.
Replacement parts for a double-insulated product must
be identical to the original parts.
A double-insulated product is marked with the words
“Double Insulation” or “Double Insulated”. Product may
also be marked with symbol shown here.
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 5 16/12/17 下午12:38
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Servicing of a Double-Insulated
Appliance
Ground Fault Circuit Interrupter
Protection:
This pressure washer is provided
with a ground-fault circuit-
interrupter (GFCI) built into the
plugs of the power-supply cord.
This device provides additional
protection from the risk of electric
shock. Should replacement of the
plug or cord become necessary, use
only identical replacement parts
that include GFCI protection.
In a double-insulated product,
two systems of insulation are
provided instead of grounding.
Grounding means are not provided
for a double insulated product, nor
should grounding means be added
to the product.
Servicing a double-insulated
product requires extreme care
and knowledge of the system, and
should only be done by qualified
service personnel.
Replacement parts for a double-
insulated product must be identical
to the original parts.
A double-insulated product is
marked with the words “Double
Insulation” or “Double Insulated”.
Product may also be marked with
symbol shown here.

6 7
1
C
B
AA
ASSEMBLY INSTRUCTIONS
PREPARATION
Power Unit Assembly
Install handle (B) to power
washer unit (C).
Secure with screws (AA).
Note: DO NOT use a power
screwdriver. When the screw is
completely tight, give a small
final clockwise twist of the screw-
driver. DO NOT overtighten.
x 2
Slide spray gun holster (A)
onto left side,when facing
unit, of power washer unit (C)
as shown.
Note: This step does not re-
quire any screws.
Before beginning assembly of
product, make sure all parts
are present. Compare parts
with package contents list and
hardware contents list. If any
part is missing or damaged, DO
NOT attempt to assemble the
product.
Estimated Assembly Time: 5
minutes
Tools Required for Assembly
(not included): Phillips
screwdriver
6
ASSEMBLY INSTRUCTIONS
Power Unit Assembly
Install handle (B) to power washer unit (C).
Secure with screws (AA).
Note: DO NOT use a power screwdriver. When the
screw is completely tight, give a small nal clockwise
twist of the screwdriver. DO NOT overtighten.
1
C
B
AA
Screw x 2
AA
AA
Screw
Qty. 2
OFF/O
ON/I
2
C
A
Slide spray gun holster (A) onto left side,when facing unit,
of power washer unit (C) as shown.
Note: This step does not require any screws.
Hardware Used:
PREPARATION
Before beginning assembly of product, make sure all
parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or
damaged, DO NOT attempt to assemble the product.
Estimated Assembly Time: 5 minutes
Tools Required for Assembly (not included): Phillips
screwdriver
PREPARATION
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 6 16/12/17 下午12:38
HARDWARE USED
3
PACKAGE CONTENTS
HARDWARE CONTENTS
PART DESCRIPTION QUANTITY
H Detergent Bottle 1
I Variable Spray Nozzle Lance 1
J Extension Lance 1
K Nozzle Cleaning Wire 1
L O-Ring Kit 1
AA Screws 2
PART DESCRIPTION QUANTITY
A Spray Gun Holster 1
B Handle 1
C Power Washer Unit 1
D Cord Hook 1
E Soft PVC High Pressure Hose 1
F Spray Gun 1
G Spray Gun Lock/Unlock 1
OFF/O
ON/I
E
H
B
C
K
A
DL
AA
PW909112S
J
I
F
G
AA
Screw
Qty. 2
Note: Screws are located in manual package
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 3 16/12/17 下午12:38
3
PACKAGE CONTENTS
HARDWARE CONTENTS
PART DESCRIPTION QUANTITY
H Detergent Bottle 1
I Variable Spray Nozzle Lance 1
J Extension Lance 1
K Nozzle Cleaning Wire 1
L O-Ring Kit 1
AA Screws 2
PART DESCRIPTION QUANTITY
A Spray Gun Holster 1
B Handle 1
C Power Washer Unit 1
D Cord Hook 1
E Soft PVC High Pressure Hose 1
F Spray Gun 1
G Spray Gun Lock/Unlock 1
OFF/O
ON/I
E
H
B
C
K
A
DL
AA
PW909112S
J
I
F
G
AA
Screw
Qty. 2
Note: Screws are located in
manual package
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 3 16/12/17 下午12:38
Screw
OFF/O
ON/I
2
C
A

8 9
Slide cord hook holster (D) onto
right side, when facing unit, of power
washer unit (C) as shown.
Note: This step does not require any
screws.
4
C
E
Soft PVC High Pressure Hose
Assembly
Screw Soft PVC high pressure
hose (E) clockwise onto bottom
front of power washer unit (C).
Pull back collar and insert o-ring
post into water outlet far enough
so collar can thread onto outlet
threads until hand tight. If it
takes fewer than six turns you
have not properly tightened the
Soft PVC high pressure hose
fitting. It is easier to position
the power washer in front of
you to ensure that the threads
5
E
F
Connect the other end of Soft PVC
high pressure hose (E) to spray gun
(F) by inserting the silver metal tip of
Soft PVC high pressure hose into the
fitting just ahead of trigger guard. It
will lock into spray gun with a “click”.
Confirm hose is locked into spray gun
by slightly pulling on hose. The hose is
now securely attached to spray gun.
Note: DO NOT press button on under-
side of gun when connecting hose to
gun.
are started correctly. Failure to
properly tighten Soft PVC high
pressure hose will result in the
hose slipping or popping o
immediately upon turning unit on.
Do not worry about damage if this
occurs–just reinstall and take extra
care when screwing on the Soft
PVC high pressure hose fitting.
Note: DO NOT use pliers or
locking pliers to tighten.
OFF/O
ON/I
3
C
D

8 9
2
1
6
E
F
To release hose (E) from spray gun (F),
press button on underside of gun to-
ward trigger guard. The hose will slide
out from connection.
Locking Spray Gun (before Lance
installation)
To lock trigger of spray gun (F), point
gun away from you and press bottom
half of lock button to engage lock.
Squeeze or pull trigger to make sure it
is locked.
ALWAYS leave lock button in locked
position when not in use. This ensures
the gun is in “safe” mode until it is
ready for use. To unlock, press top half
Lock
Unlock
7
F
F
1
2
8
J
F
Extension Lance installation
With spray gun (F) in locked
position, attach extension lance
(J) directly to spray gun. Insert
lance extension into gun, pushing
together and turning clockwise
simultaneously. Turn the extension
collar clockwise to lock into place.
To remove extension lance (J), turn
extension collar counterclockwise
to unlock, then push together and
turn counterclockwise to release.
Note: The extension lance must be
inserted in gun before using any of
the other attachments, and in place
for storage. It is recommended that
once extension is connected to
leave it in place.
of lock button to release.
Note: The trigger lock prevents
trigger from being accidentally
engaged.

10 11
Variable Spray Nozzle Lance
installation
Insert variable spray nozzle (I)
or Turbo lance(K) or detergent
bottle (H) into the end of the
extension lance by inserting
and pushing together turning
clockwise simultaneously. To
remove push together and turn
counterclockwise.
Note: Push the safety lock button
to lock the trigger when changing
lances to ensure that they do not
accidentally eject with force during
removal.
Insert detergent bottle (H) into
extension lance (J), push in and
turn clockwise
9
2
1
9
I
J
Variable Spray Nozzle Lance installation
Insert variable spray nozzle lance (I) or detergent bottle
(H) into the end of the extension lance by inserting and
pushing together turning clockwise simultaneously. To
remove push together and turn counterclockwise.
Note: Push the safety lock button to lock the trigger
when changing lances to ensure that they do not
accidentally eject with force during removal.
Insert detergent bottle (H) into extension lance (J),
push in and turn clockwise
10
2
1
H
Detergent Bottle Installation
The detergent bottle comes with a straw which is tted
into screw-on top. If you do not see the straw, look
inside the bottle and attach it to the screw-on top. When
using detergent bottle, ll it with a properly formulated
detergent or cleaner with a water ratio according to
instructions on the container.
• Pressure washer detergents are recommended. See
page 12 for more information.
• DO NOT use thick or gel-like detergents as they will
clog the power washer and can cause damage.
1
J
H
11
2
12
C
Attach a garden hose to built in garden hose
adapter located on the back of the power washer
unit (C). The water is now connected to your power
washer.
Note: Flush out garden hose before connecting
to garden hose adapter.
ASSEMBLY INSTRUCTIONS
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 9 16/12/17 下午12:38
9
2
1
9
I
J
Variable Spray Nozzle Lance installation
Insert variable spray nozzle lance (I) or detergent bottle
(H) into the end of the extension lance by inserting and
pushing together turning clockwise simultaneously. To
remove push together and turn counterclockwise.
Note: Push the safety lock button to lock the trigger
when changing lances to ensure that they do not
accidentally eject with force during removal.
Insert detergent bottle (H) into extension lance (J),
push in and turn clockwise
10
2
1
H
Detergent Bottle Installation
The detergent bottle comes with a straw which is tted
into screw-on top. If you do not see the straw, look
inside the bottle and attach it to the screw-on top. When
using detergent bottle, ll it with a properly formulated
detergent or cleaner with a water ratio according to
instructions on the container.
• Pressure washer detergents are recommended. See
page 12 for more information.
• DO NOT use thick or gel-like detergents as they will
clog the power washer and can cause damage.
1
J
H
11
2
12
C
Attach a garden hose to built in garden hose
adapter located on the back of the power washer
unit (C). The water is now connected to your power
washer.
Note: Flush out garden hose before connecting
to garden hose adapter.
ASSEMBLY INSTRUCTIONS
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 9 16/12/17 下午12:38
Detergent Bottle Installation
The detergent bottle comes with a
straw which is fitted into screw-on
top. If you do not see the straw,
look inside the bottle and attach
it to the screw-on top. When
9
2
1
9
I
J
Variable Spray Nozzle Lance installation
Insert variable spray nozzle lance (I) or detergent bottle
(H) into the end of the extension lance by inserting and
pushing together turning clockwise simultaneously. To
remove push together and turn counterclockwise.
Note: Push the safety lock button to lock the trigger
when changing lances to ensure that they do not
accidentally eject with force during removal.
Insert detergent bottle (H) into extension lance (J),
push in and turn clockwise
10
2
1
H
Detergent Bottle Installation
The detergent bottle comes with a straw which is tted
into screw-on top. If you do not see the straw, look
inside the bottle and attach it to the screw-on top. When
using detergent bottle, ll it with a properly formulated
detergent or cleaner with a water ratio according to
instructions on the container.
• Pressure washer detergents are recommended. See
page 12 for more information.
• DO NOT use thick or gel-like detergents as they will
clog the power washer and can cause damage.
1
J
H
11
2
12
C
Attach a garden hose to built in garden hose
adapter located on the back of the power washer
unit (C). The water is now connected to your power
washer.
Note: Flush out garden hose before connecting
to garden hose adapter.
ASSEMBLY INSTRUCTIONS
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 9 16/12/17 下午12:38
Attach a garden hose to built in
garden hose adapter located on
the back of the power washer unit
(C). The water is now connected
using detergent bottle, fill it with
a properly formulated detergent
or cleaner with a water ratio
according to instructions on the
container.
• Pressure washer detergents are
recommended. See page 12 for
more information.
• DO NOT use thick or gel-like
detergents as they will clog the
power washer and can cause
damage.
2
1
9
I
J
K

10 11
• Turn on water supply at the
faucet to completely open.
• Make sure the “ON/OFF” switch is
in the “OFF” position. The power
switch has international symbols
for ‘on’ and ‘o’: On (|) O (O).
• Unwind the power cord
completely and plug the GFCI
into a grounded 120 volt outlet.
• Release the safety lock button
on the spray gun by pressing the
top half of the safety lock button.
While pointing the spray gun in a
safe direction, squeeze the trigger
on the spray gun until there is a
steady stream of water, letting
the water and air out of the hose.
• Turn the power switch to the
“ON” (|) position. The unit will
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Turn on water supply at the faucet to completely
open.
•Make sure the “ON/OFF” switch is in the “OFF”
position. The power switch has international symbols
for ‘on’ and ‘off’: On (|) Off (O).
• Unwind the power cord completely and plug the GFCI
into a grounded 120 volt outlet.
•Release the safety lock button on the spray gun by
pressing the top half of the safety lock button. While
pointing the spray gun in a safe direction, squeeze
the trigger on the spray gun until there is a steady
stream of water, letting the water and air out of the
hose.
•Turn the power switch to the “ON” (|) position. The
unit will turn on for 1 - 2 seconds and shut off. This is
a normal function of the auto start feature. Squeeze
the spray gun trigger to begin pressure washing.
Unlock
F
OFF/0
ON/I
OFF/0
ON/I
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 10 16/12/17 下午12:38
turn on for 1 - 2 seconds and shut
o. This is a normal function of
the auto start feature. Squeeze
the spray gun trigger to begin
pressure washing.
• Release the safety lock button on
the spray gun by pressing the top
half of the safety lock button. While
pointing the spray gun in a safe
direction, squeeze the trigger on
the spray gun until there is a steady
stream of water, letting the water
and air out of the hose.
• Release the spray gun trigger to
stop the power washer
• Allow the motor to come to a
complete stop before squeezing
the trigger again.
• Squeezing rapidly will cause the
auto start feature to miss an on/
o cycle that may prevent it
from turning on while squeezing
trigger after rapid squeezing. Use
slow deliberate trigger pulls to
avoid such symptoms.
• Always test a small area to avoid
chance of damaging the surface.
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Turn on water supply at the faucet to completely
open.
•Make sure the “ON/OFF” switch is in the “OFF”
position. The power switch has international symbols
for ‘on’ and ‘off’: On (|) Off (O).
• Unwind the power cord completely and plug the GFCI
into a grounded 120 volt outlet.
•Release the safety lock button on the spray gun by
pressing the top half of the safety lock button. While
pointing the spray gun in a safe direction, squeeze
the trigger on the spray gun until there is a steady
stream of water, letting the water and air out of the
hose.
•Turn the power switch to the “ON” (|) position. The
unit will turn on for 1 - 2 seconds and shut off. This is
a normal function of the auto start feature. Squeeze
the spray gun trigger to begin pressure washing.
Unlock
F
OFF/0
ON/I
OFF/0
ON/I
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 10 16/12/17 下午12:38
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Turn on water supply at the faucet to completely
open.
•Make sure the “ON/OFF” switch is in the “OFF”
position. The power switch has international symbols
for ‘on’ and ‘off’: On (|) Off (O).
• Unwind the power cord completely and plug the GFCI
into a grounded 120 volt outlet.
•Release the safety lock button on the spray gun by
pressing the top half of the safety lock button. While
pointing the spray gun in a safe direction, squeeze
the trigger on the spray gun until there is a steady
stream of water, letting the water and air out of the
hose.
•Turn the power switch to the “ON” (|) position. The
unit will turn on for 1 - 2 seconds and shut off. This is
a normal function of the auto start feature. Squeeze
the spray gun trigger to begin pressure washing.
Unlock
F
OFF/0
ON/I
OFF/0
ON/I
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 10 16/12/17 下午12:38
to your power washer.
Note: Flush out garden hose before connecting to garden hose adapter.
OPERATING INSTRUCTIONS

12 13
11
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Begin power washing by squeezing the trigger on the
spray gun all the way into the handle.
• Release the spray gun trigger to stop the power washer
• Allow the motor to come to a complete stop before
squeezing the trigger again.
•Squeezing rapidly will cause the auto start feature to
miss an on/off cycle that may prevent it from turning
on while squeezing trigger after rapid squeezing. Use
slow deliberate trigger pulls to avoid such symptoms.
• Always test a small area to avoid chance of damaging
the surface.
• When using the variable spray nozzle, the spray
pattern and intensity can be adjusted for each task by
twisting the spray nozzle at the far end of the lance.
Operation Tips
• If you hear the motor run intermittently when the
trigger is not being squeezed, that is normal. The
pump is priming itself so it is ready to operate when
the trigger is squeezed. Turn off the power washer if
not being used after ve minutes.
• The o-rings on the bayonet end of the nozzle should
be cleaned regularly and lubricated with non-water
soluble grease such as petroleum jelly.
• Keep the nozzle cleaning wire for use in unclogging
the nozzle. If you lose the cleaning wire, a
straightened paper clip also works.
How to Avoid Damaging Surfaces
• Damage to surfaces being cleaned occurs because
the impact force of the water pressure exceeds
the durability of the surface. Bare wood can be
penetrated; paint can be peeled off, etc. You can vary
the force of your power washer by controlling:
1. The angle of the surface being cleaned
2. The distance of the nozzle from the
surface being cleaned
• NEVER use a narrow high pressure stream of water
on soft surfaces susceptible to damage.
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 11 16/12/17 下午12:38
• When using the variable spray
nozzle, the spray pattern and
intensity can be adjusted for each
task by twisting the spray nozzle at
the far end of the lance.
Operation Tips
• If you hear the motor run
intermittently when the trigger
is not being squeezed, that is
normal. The pump is priming
itself so it is ready to operate
when the trigger is squeezed.
Turn o the power washer if not
being used after five minutes.
• The o-rings on the bayonet end
of the nozzle should be cleaned
regularly and lubricated with
non-water soluble grease such as
petroleum jelly.
• Keep the nozzle cleaning wire
for use in unclogging the nozzle.
If you lose the cleaning wire,
a straightened paper clip also
works.
How to Avoid Damaging Surfaces
• Damage to surfaces being
cleaned occurs because the
impact force of the water
pressure exceeds the durability
of the surface. Bare wood can
be penetrated; paint can be
peeled o, etc. You can vary the
force of your power washer by
controlling:
1. The angle of the surface being
cleaned
2. The distance of the nozzle from
the surface being cleaned
• NEVER use a narrow high
pressure stream of water on
soft surfaces susceptible to
damage.
Detergents
• Use detergents designed for
power washers. You can find
detergents at bepowerequipment.
com. Hardware stores or home
centers also have power washer
detergents for dierent cleaning
projects. The cleaning solution
should be the consistency of
water in order to prevent clogging
your detergent bottle and nozzle.
CARE AND MAINTENANCE

12 13
• This system applies detergent under
low pressure. The cleaning power
of the detergents is enhanced when
applied with low pressure and
enough time is given to break down
dirt and grime. The combination of
low pressure and chemical action
is very eective and can be better
than scrubbing if applied properly.
ALWAYS spray detergent on a dry
surface. DO NOT pre-soak area.
Wetting the surface first dilutes the
detergent and reduces its cleaning
ability. DO NOT allow detergent to
dry on surface. On vertical surfaces
being cleaned, apply detergent to
lower surfaces and work your way up
to prevent detergent from causing
streaks in the dirt and grime. Rinse
detergent by pressure washing from
bottom up for same reason.
• If a stain is particularly tough, it may
be necessary to reapply the detergent
and use a bristled brush to scrub the
stain. Subsequent power washing
after brushing should successfully
complete your cleaning job.
Cleaning Garden Hose Adapter
• The screens inside the adapter should
be cleaned periodically. Rinse it with
clean water, and then place it back in
the adapter.
Cleaning Nozzles
• A clogged or partially clogged nozzle
can cause significant reduction of water
pressure coming out of the nozzle
and/or cause the unit to pulsate while
spraying.
• Turn o the unit.
• Turn o the water supply to the unit.
• Relieve any pressure trapped in the
hose by squeezing the trigger 2-3 times,
and then lock the spray gun by pushing
the lock button from left to right.
• Remove the lance from the extension
lance
• Take o the variable spray nozzle lance.
Rotate the nozzle to narrow the stream
setting which opens up the fan blades
• Using the nozzle tip cleaner provided
(or an unfolded paper clip), insert the
wire into the nozzle hole and move back
and forth until debris is dislodged.
• Tap quick connect end of lance on hard
surface several times
• Back flush water through the nozzles
using garden hose and highest pressure
available (either standard water nozzle
or use your thumb over the nozzle to
create water pressure for back flush).
12
CARE AND MAINTENANCE
Detergents
• Use detergents designed for power washers. These
can be purchased online at our website www.
arblueclean.com. Hardware stores or home centers
also have power washer detergents for different
cleaning projects. The cleaning solution should be
the consistency of water in order to prevent clogging
your detergent bottle and nozzle.
• This system applies detergent under low pressure.
The cleaning power of the detergents is enhanced
when applied with low pressure and enough time is
given to break down dirt and grime. The combination
of low pressure and chemical action is very effective
and can be better than scrubbing if applied properly.
ALWAYS spray detergent on a dry surface. DO NOT
pre-soak area. Wetting the surface rst dilutes
the detergent and reduces its cleaning ability. DO
NOT allow detergent to dry on surface. On vertical
surfaces being cleaned, apply detergent to lower
surfaces and work your way up to prevent detergent
from causing streaks in the dirt and grime. Rinse
detergent by pressure washing from bottom up for
same reason.
• If a stain is particularly tough, it may be necessary
to reapply the detergent and use a bristled brush to
scrub the stain. Subsequent power washing after
brushing should successfully complete your cleaning
job.
Cleaning Garden Hose Adapter
• The screens inside the adapter should be cleaned
periodically. Rinse it with clean water, and then place
it back in the adapter.
Cleaning Nozzles
• A clogged or partially clogged nozzle can cause
signicant reduction of water pressure coming out
of the nozzle and/or cause the unit to pulsate while
spraying.
• Turn off the unit.
• Turn off the water supply to the unit.
• Relieve any pressure trapped in the hose by squeezing
the trigger 2-3 times, and then lock the spray gun by
pushing the lock button from left to right.
• Remove the lance from the extension lance
• Take off the variable spray nozzle lance. Rotate the
nozzle to narrow the stream setting which opens up
the fan blades
• Using the nozzle tip cleaner provided (or an unfolded
paper clip), insert the wire into the nozzle hole and
move back and forth until debris is dislodged.
• Tap quick connect end of lance on hard surface
several times
• Back ush water through the nozzles using garden
hose and highest pressure available (either standard
water nozzle or use your thumb over the nozzle to
create water pressure for back ush).
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 12 16/12/17 下午12:38

14 15
PUMP SAVER
Pump Saver is a product that
protects and prolongs the life of the
pump. This will keep the internal
parts of the pump lubricated and
protected from freezing
while being stored in ALL climates.
It also assists with protection from
internal corrosion. (16 oz. bottle, BE
part number 85.490.046)
Pump Saver Instructions
Follow the previous storage
instructions for your power washer.
To prevent staining, protect the
surface under the power washer from
any excess fluid. Wear eye protection
when using this product.
Turn unit o and disconnect the
gun before adding pump protector.
Unscrew threaded top from bottle to
remove seal and reattach threaded
top to bottle. Remove black cap from
bottle.
1) Place top of pump saver bottle
onto the garden hose adapter
previously installed to pressure
washer inlet.
2) Secure pump saver bottle by
turning in a clockwise direction.
3) Turn power on. Turn the power
washer o as soon as the Pump
Storage
• When your pressure washing session
has been completed, turn o the
power switch located on the front
of the power washer. Unplug the
power cord from the outlet. Turn o
the water supply. Pull the trigger on
the spray gun 2-3 times to drain out
the excess water and to release any
remaining water pressure. Disconnect
the garden hose adapter from the
water inlet. DO NOT allow the power
washer to run with no water flowing
through it.
• Remove detergent bottle and clean
completely. Residual chemical will
stick to the container and can cause
the detergent injector to clog and not
function properly.
• Remove high pressure hose from
spray gun.
• Remove lance from the gun. Place the
gun in the holder on the side. Lances
are placed into any of the slots in the
back of the unit. Make sure to discard
any remaining detergent from the
bottle. Flush the bottle and nozzle
head with fresh water to prevent
clogging.
• Hook the power cord around the cord
hook on the right side of the machine
when facing it.

14 15
TROUBLESHOOTING
13
PUMP SAVER
Pump Saver is a product that protects and prolongs
the life of the pump. This will keep the internal parts
of the pump lubricated and protected from freezing
while being stored in ALL climates. It also assists with
protection from internal corrosion. The Blue Clean part
# is: PW64511 (16oz. bottle). Order online at www.
arblueclean.com
Pump Saver Instructions
Follow the previous storage instructions for your power
washer. To prevent staining, protect the surface under
the power washer from any excess uid. Wear eye
protection when using this product.
Turn unit off and disconnect the gun before adding
pump protector. Unscrew threaded top from bottle to
remove seal and reattach threaded top to bottle.
Remove black cap from bottle.
1) Place top of pump saver bottle onto the garden
hose adapter previously installed to pressure washer
inlet.
2) Secure pump saver bottle by turning in a clockwise
direction.
3) Turn power on. Turn the power washer off as soon
as the Pump Saver begins to exit the HP hose.
Note: Instructions on Pump Saver Bottle are generic and
not model specic.
Storage
• When your pressure washing session has been
completed, turn off the power switch located on the
front of the power washer. Unplug the power cord
from the outlet. Turn off the water supply. Pull the
trigger on the spray gun 2-3 times to drain out the
excess water and to release any remaining water
pressure. Disconnect the garden hose adapter from
the water inlet. DO NOT allow the power washer to
run with no water owing through it.
• Remove detergent bottle and clean completely.
Residual chemical will stick to the container and can
cause the detergent injector to clog and not function
properly.
• Remove high pressure hose from spray gun.
• Remove lance from the gun. Place the gun in the
holder on the side. Lances are placed into any of the
slots in the back of the unit. Make sure to discard
any remaining detergent from the bottle. Flush the
bottle and nozzle head with fresh water to prevent
clogging.
•Hook the power cord around the cord hook on the
right side of the machine when facing it.
CARE AND MAINTENANCE
1
2
15ANR009 AR112S_1500PSI ENG-FR-SP.indd 13 16/12/17 下午12:38
PROBLEM CORRECTIVE ACTION
Unit will not turn on. 1. The GFCI module on the end of the power cord must be plugged directly into an
outlet.
2. Do not use an extension cord.
3. With the GFCI Connected make sure the power switch is turned on.
Note: When power switch is turned on, the power washer will turn on by itself for
1-2 seconds and shut o. This is normal.
The high pressure (HP)
hose will not connect/
stay connected to the
spray gun. Is this a spray
gun problem?
1. In most cases, the spray gun is not the problem. The problem is the rubber sleeve
covering the fitting at the end of the high pressure hose. It has likely slipped up
toward the metal tip. To fix: wiggle, twist and/or pull the rubber sleeve down until
the entire tip is visible plus an 1/8 in. of the metal fitting below the tip. Now try
to insert the hose tip into the spray gun. It should “click” into place and will not
come out until the hose is released by pushing in the lever on the underside of
the gun. You may cut away the end of the sleeve with a sharp knife if unable to
move the sleeve down. Be careful not to cut or puncture the hose.
2. Do not push in the release button when connecting the high pressure hose.
The unit is running but
there is no water flow.
1. Check the water source. Unclog the nozzle on the lance. (See nozzle cleaning
instructions under “Cleaning nozzles”.) Or take o the lance and just spray out of
the spray gun. This will indicate if the problem is with the lance.
Why is water leaking
where the high pressure
hose connects to the
spray gun?
1. Make sure there is an o-ring at the end of the metal tip of the high pressure hose.
If no o-ring is present, the connection between the hose and spray gun will leak.
I can’t remove the lance
from the spray gun.
What should I do?
1. All lances and the detergent bottles are attached and removed from the exten-
sion lance in the same manner. Insert the quick-release end of the lance/deter-
gent bottle into the extension lance. Press the extension lance and lance together
(about a 1/8”) and turn clockwise. The lance will lock in place. Remove the lance
by reversing this procedure. Press the extension lance and lance together and
turn counter clockwise. The lance will slide out.
2. Or, hold the extension lance and lance in an upright position with the nozzle end
on the floor. Push the whole assembly straight down to loosen the connection,
and then follow the removal process again. You may also spray soapy water or a
lubricant in the area where the lance connects to the extension lance.
The power washer turns
on for
2 seconds, shuts o, and
will not turn back on. Do
I have a defective unit?
1. It sounds like your power washer is working just fine. When the water is connect-
ed, the accessories are assembled properly, and the power switch is turned on,
the power washer may turn on for 1 - 2 seconds to prime the pump. It automati-
cally shuts o and waits for the spray gun trigger to be pressed. When the trigger
is pressed, water starts flowing through the pump. The water sensor in the pump
“senses” the moving water and automatically turns the power washer on.
2. Turn the power switch to o, hold in the trigger on the spray gun, so that you
have a steady stream of water. While you are holding the trigger open on the
spray gun, at the same time, turn the power switch on.
Saver begins to exit the HP hose.
Note: Instructions on Pump Saver
Bottle are generic and not model
specific.

16 17
This product is under warranty to the original retail consumer against defects
in material and workmanship for a period of 1 (one) year and is a complete
“bumper to bumper” warranty including the spray gun, the high pressure hose
and all accessories from the date of purchase. The warranty is not transferable
or assignable. This warranty covers replacement parts. This limited one year
warranty applies only to products used in consumer applications and is
void in rental or any commercial application. Reasonable care must be used
in conformity with operation and maintenance instructions in the owner’s
manual and quick start guide. Failure to follow these instructions will void this
warranty. This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
Warranty Process
To place a warranty claim, go to the support section of BE’s website at
bepowerequipment.com and fill out the online form with the following
information:
1. Dealer Information (Contact name and number)
2. Product Model Number and Serial Number
3. Electronic Copy of Customer Invoice
4. Explanation of defect or how it is not performing properly
a) Troubleshooting steps already taken
5. Pictures of product including:
a) Picture of whole unit showing condition
b) Picture of serial number
c) A close up picture of problem area (leaking oil, water, broken part, etc)
You can also contact our technical support at 1-866-850-6662.
TROUBLESHOOTING
LIMITED WARRANTY

16 17
REPLACEMENT PARTS LIST
PART DESCRIPTION PART #
A Gun Holder PW4220580
B Handle PW4220570
C Garden Hose Adapter PW4221570
D GFCI Assembly PW4221160
E Soft PVC Hose PW4221500
F Spray Gun PW4120395
G Cord Hook PW4220590
H Detergent Bottle (14oz.) PW50954
I Varaible Spray Nozzle Lance PW4120410
J Extension Lance PW4120400
K Turbo Nozzle Lance PW4120430
L O-Ring Kit PW909142S
18
rePlacement PartS
Pos. Description Part Number Qty.
1 Detergent Bottle PW50954 1
2 Hose (QC) PW4220600 1
3 Spray Gun 1
4 Vari-Spray Lance/Nozzle 1
5 Turbo Lance/Nozzle 1
6 Extension Lance 1
7 Gun Holder 1
8 Cord Hook 1
9 Handle 1
10 Wheel 2
11 Wheel Cover 2
12 Garden Hose Adapter (clear plastic) 1
13 Garden Hose Adapter (yellow/black) 1
14 GFCI Assembly
PW4120395
PW4120410
PW4120430
PW4120400
PW4220580
PW4220590
PW4220570
PW4220540
PW4220553
PW3082130
PW3082736
PW4221160 1
Pump Spare Part Kits
Water Seals & Valves PW4220620 1
Pre-Assembly TSS PW4220630 1
O-Ring Kit PW909107K 1
Order at: www.bepressure.com / 1-800-663-8331
8
10
9
1
13
12
3
5
4
6
7
2
14
11
10
B
A
D
E
F
G
H
I
K
J
PW909383S
L
C

If you need assistance with the
assembly or operation of this Electric
Pressure Washer please call
1-866-850-6662
POWER EQUIPMENT

Pour de l’assistance, veuillez
communiquer avec le support
technique au numéro de
téléphone suivant:
1-866-850-6662
POWER EQUIPMENT

16 17
LISTE DES PIÈCES DE RECHANGE
PARTIE LA DESCRIPTION PARTIE #
A Porte-pistolet PW4220580
B Manipuler PW4220570
CAdaptateur de tuyau de jardin PW4221570
D Assemblée GFCI PW4221160
E Tuyau en PVC souple PW4221500
F Pistolet à peinture PW4120395
G Crochet de cordon PW4220590
H Bouteille de détergent
(14oz.)
PW50954
I Lance de buse à
pulvérisation variable
PW4120410
J Lance d’extension PW4120400
K Lance de buses rapide PW4120430
L Kit O-Ring PW909142S
18
rePlacement PartS
Pos. Description Part Number Qty.
1 Detergent Bottle PW50954 1
2 Hose (QC) PW4220600 1
3 Spray Gun 1
4 Vari-Spray Lance/Nozzle 1
5 Turbo Lance/Nozzle 1
6 Extension Lance 1
7 Gun Holder 1
8 Cord Hook 1
9 Handle 1
10 Wheel 2
11 Wheel Cover 2
12 Garden Hose Adapter (clear plastic) 1
13 Garden Hose Adapter (yellow/black) 1
14 GFCI Assembly
PW4120395
PW4120410
PW4120430
PW4120400
PW4220580
PW4220590
PW4220570
PW4220540
PW4220553
PW3082130
PW3082736
PW4221160 1
Pump Spare Part Kits
Water Seals & Valves PW4220620 1
Pre-Assembly TSS PW4220630 1
O-Ring Kit PW909107K 1
Order at: www.bepressure.com / 1-800-663-8331
8
10
9
1
13
12
3
5
4
6
7
2
14
11
10
B
A
D
E
F
G
H
I
K
J
PW909383S
L
C
