BEA LZR-WIDESCAN User manual

75.5917.02 LZR-WIDESCAN QSG 20171220 Page 1 of 475.5917.02 LZR-WIDESCAN QSG 20171220 Page 1 of 4
Make sure the cover is not locked (red cover lock).
Pull the two legs on top in order to open the cover.
Completely remove the cover
before installing the sensor.
a. Adjust the sensor before mounting for easier access to the LCD screen.
b. Adjust the function and logic of the outputs only if required by your application.
c. Open the USB cap and power the sensor using a mini USB charger or battery.
Adjustments may also be made after Teach-In, if not using the USB.
QUICK START GUIDE
Quick Start
In-Out
Motion
Out1Function
Motion or PC
Out1Logic
I/O Out2Logic
Out 2 Function
Pres or Sfty
Out 2 Logic
Out1Logic
NO
Out2Function
I/O Out2Logic
NC
RelFunction
RelayLogic
De-energized
>More
Out 2 Logic
RelayFunction
HeightTrigger
RelayLogic
OPENING THE SENSOR
ADJUST SETTINGS (IF NEEDED)
OUT 1
Ex: OUT 2 REL AY
Motion detection or
presence detection
in pull cord zone
Normally open
Presence detection
of object in presence
or safety field
Normally closed
Detection of object
if height > 7 ft 4 in
De-energized
in no detection
READ BEFORE BEGINNING INSTALLATION & SET-UP
Refer to the user’s guide
for safety instructions and
supplemental information.
Do not remove the protection
film during the mechanical
adjustments. Remove it
before launching a teach-in.
75.5916.01 LZR-WIDESCAN 20170918 Page 1 of 1575.5916.01 LZR-WIDESCAN 20170918 Page 1 of 15
LZR®-WIDESCAN
TechSupport: 1-800-407-4545 | Customer Service: 1-800-523-2462 | General Tech Questions: T[email protected]| Tech Docs: www.BEAinc.com
6
1
2
3
4
5
7
8
9
10
11
12
13
14
75.5916.01 LZR-WIDESCAN 20170918 Page 1 of 1575.5916.01 LZR-WIDESCAN 20170918 Page 1 of 15
1. main connector
2. protection film
3. laser window
4. USB cap
5. LED display
6. cover
7. cover lock
8. cable passage
9. LCD screen
10. keypad
11. tilt angle adjustment screw (1)
12. parallel angle adjustment screw (2)
13. lateral angle lock screw (1)
14. mounting bracket
ENGLISH
Motion, Presence, and Safety Sensor
for Industrial Doors
(USversion)
DESCRIPTION
LZR-WIDESCAN
ENGLISH
!
1
2
!
Following installation, always
test for proper operation
before leaving the premises.
Motion, Presence, and Safety Sensor
for Industrial Doors
(US version)

Page 2 of 4 75.5917.02 LZR-WIDESCAN QSG 20171220Page 2 of 4 75.5917.02 LZR-WIDESCAN QSG 20171220
Remove the rotation plate from the sensor and secure
it to the wall. You can also install the sensor directly
without using the rotation plate.
Verify if the angle lock screw is positioned as indicated.
Unscrew if necessary.
Orient the sensor horizontally to the left and secure
the sensor to the rotation plate.
Plug the connector and pass the cable through the
cable passage without making a loop.
Connect the wires accordingly.
Install the sensor in the left corner (recommended) or the center of
the door as high as possible (max. 19’6").
The size of the detection field depends on the mounting height.
INSTALL
Launch teach-in after
angle adjustment.
All presence/safety
outputs are activated.
* output status during non-detection
** default value (see IN/OUT)
5
MOUNTING & WIRING
3
a
c
b
d
COM
NO
NC
*
*
*
TEST
POWER
OUTPUT 2
OUTPUT 1
RELAY
H
W
D

75.5917.02 LZR-WIDESCAN QSG 20171220 Page 3 of 475.5917.02 LZR-WIDESCAN QSG 20171220 Page 3 of 4
Power the sensor. The LCD screen shows the detection display.
Activate the 2 visible laser spots by double-clicking OK or using the remote
control sequence shown to teh right.
The visible laser beams stay activated for 15 minutes or can be turned off by
double-clicking OK.
Do not look directly into the laser emitter or the visible red laser beams.
ANGLE ADJUSTMENT
4
1 2 3 A
4 5 6 B
7 8 9 C
F1 0 F2 D
PRESS
2X
1. Push and hold OK to launch the POSITION WIZARD.
2. Rotate the sensor in order to align the center of the red spots with the center
of the door. Push OK.
3. Rotate the sensor until the LCD screen validates the position. Push OK to exit.
OK
LONG
Position the curtain closer to or farther away from the door by turning the screw at the top.
When the safety
function is required,
the red spots should be
as close to the door as
possible.
Negative angles reduce
the depth of the
detection fields.
Lock the sensor position by tightening the angle lock screw (see step 6A).
Make sure the curtain is parallel to the door by adjusting one or both screws on the side.
PARALLEL ANGLETILT ANGLELATERAL ANGLE
Launch the POSITION WIZARD to position the detection field correctly in front of the door.
CLOSER
AWAY
Remove the blue protection film from the laser window.
7.2 × 7.2 ft
10.8 × 10.8 ft
14.4 × 14.4 ft
18 × 18 ft
6 ft
9 ft
12 ft
15 ft
The size of the detection
field depends on the
mounting height:
DETECTION FIELD

Page 4 of 4 75.5917.02 LZR-WIDESCAN QSG 20171220Page 4 of 4 75.5917.02 LZR-WIDESCAN QSG 20171220
Reclip the sensor cover horizontally
and close it as indicated.
Lock the lateral angle by firmly
fastening the angle lock screw.
Lock the cover by turning the
lock screw clockwise.
CLOSING THE SENSOR
6
a c
b
©BEA | 75.5917.02 LZR-WIDESCAN QSG 20171220 PLEASE KEEP FOR FURTHER USE – DESIGNED FOR COLOR PRINTING
Tech Support: 1-800-407-4545 | Customer Service: 1-800-523-2462
General Tech Questions: T[email protected] | Tech Docs: www.BEAinc.com
| Original Instructions
BEA, the sensor manufacturer, cannot be held responsible for incorrect installations or inappropriate adjustments of the sensor/device; therefore, BEA
does not guarantee any use of the sensor outside of its intended purpose.
BEA strongly recommends that installation and service technicians be AAADM-certified for pedestrian doors, IDA-certified for doors/gates, and factory-
trained for the type of door/gate system.
Installers and service personnel are responsible for executing a risk assessment following each installation/service performed, ensuring that the sensor
system installation is compliant with local, national, and international regulations, codes, and standards.
Once installation or service work is complete, a safety inspection of the door/gate shall be performed per the door/gate manufacturer recommendations
and/or per AAADM/ANSI/DASMA guidelines (where applicable) for best industry practices. Safety inspections must be performed during each service
call – examples of these safety inspections can be found on an AAADM safety information label (e.g. ANSI/DASMA 102, ANSI/DASMA 107, UL 325).
Verify that all appropriate industry signage and warning labels are in place.
BEA INSTALLATION/SERVICE COMPLIANCE EXPECTATIONS
The teach-in zone (square in front of the 2 visible spots) should be completely free and flat.
This teach-in must be launched each time one of the sensor angles has been changed.
Make sure the protection film is removed.
2. Clear the teach-in zone in front of the sensor.
The learning process starts. Position, angle, and height are learned; the background
is analyzed and the teach-in ends successfully. If this is not accomplished, refer to the
TROUBLESHOOTING section in the user’s guide (75.5916). 5
1 2 3 A
4 5 6 B
7 8 9 C
F1 0 F2 D
Quick Start
In-Out
TeachIn
Presettings
QS
Install
TeachIn
1. Launch a teach-in by LCD or remote control (Quick Start > Teach-in > Install).
LCD REMOTE
CONTROL
TEACH-IN: INSTALL
5
SETTINGS FOR 3 MAIN FUNCTIONS
MOTION
WIDTH 000 – 999 Factory value: 240 in
DEPTH 000 – 999 Factory value: 287 in
PRESENCE
WIDTH 000 – 999 Factory value: 240 in
DEPTH 000 – 999 Factory value: 80 in
SAFETY
WIDTH 000 – 999 Factory value: 240 in
DEPTH 000 – 999 Factory value: 16 in
...
....
..
