Technical Manual
0940 ESL 601

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 2 of 30
Table of contents
1. About this manual................................................................................................................. 4
1.1. Explanation of the symbolism ....................................................................................... 4
1.1.1. Use of notes ........................................................................................................... 4
1.1.2. Use of hazard warnings.......................................................................................... 4
1.2. Safety guidelines ........................................................................................................... 5
1.2.1. Normal conditions of use ....................................................................................... 5
1.3. Qualified personnel........................................................................................................ 6
1.4. Version information of the manual................................................................................. 6
2. System description............................................................................................................... 7
3. Product overview.................................................................................................................. 8
3.1. Module variants............................................................................................................. 8
3.2. Accessories ................................................................................................................... 8
4. Mounting ............................................................................................................................ 10
4.1. Outer dimensions ........................................................................................................ 10
4.2. Notes for the field installation...................................................................................... 11
5. Wiring ................................................................................................................................. 12
5.1. Pin assignments .......................................................................................................... 12
5.1.1. PROFINET ports, M12-socket, 4-pole, D-coded ................................................. 12
5.1.2. Power supply connector for the BusHead, M12-plug, 5-pole.............................. 12
5.1.3. Link system connector, M12-socket, 5-pole........................................................ 13
5.2. Intermediate power supply feed on LioN-Link I/O-modules........................................ 14
5.2.1. T-connector for intermediate power supply ......................................................... 14
5.2.2. Auxiliary tool for the determination of the voltage drop and the place of the
intermediate power supply feed. ........................................................................................ 15
6. Configuring and commissioning ......................................................................................... 16
6.1. GSDML-file.................................................................................................................. 16
6.2. MAC addresses........................................................................................................... 16
6.3. SNMP .......................................................................................................................... 16
6.4. Configuration of the LioN-Link PROFINET system in STEP7 ...................................... 17
6.4.1. Assignment of a unique device name .................................................................. 18
6.4.2. Assignment of the device name to the BusHead ................................................. 18
6.4.3. Device exchange without removeable media/PG ................................................ 19
6.4.4. The parameter Interchanged Modules ................................................................. 21
6.4.5. Prioritized startup ................................................................................................. 22
6.4.6. Resetting the BusHead to factory settings........................................................... 22

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 3 of 30
7. The integrated web server.................................................................................................. 23
7.1. The homepage (Overview)........................................................................................... 23
7.2. The configuration page (Configuration) ....................................................................... 24
7.3. The monitoring page (Monitoring) ............................................................................... 25
8. Firmware update................................................................................................................. 26
9. Alarm and error messages of the BusHead........................................................................ 27
9.1. Evaluation of alarms in STEP7 .................................................................................... 27
9.1. Reaction of the BusHead to a module breakdown („pull “ alarm) ............................... 27
9.2. Channel diagnostics.................................................................................................... 28
10. Technical data .................................................................................................................... 29
10.1. General data................................................................................................................ 29
10.2. Technical data of the bus system................................................................................ 29
10.3. Technical data of the power supply for the BusHead electronics............................... 29
10.4. LED indicators ............................................................................................................. 30

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 4 of 30
1. About this manual
Please read the assembly and operating instructions of this manual carefully, before you put the LioN-Link system into
operation. The manual should be kept at a place that is accessible for all users.
The texts, illustrations, diagrams and examples being used in this manual are solely intended to explain the operation and
handling of the PRO INET BusHead of the LioN-Link system.
To obtain further information on the installation and putting into operation of the devices, please do not hesitate to contact
us. We will be glad to be at your disposal at any time.
Belden Deutschland GmbH
– Lumberg Automation –
Im Gewerbepark 2
58579 Schalksmuehle
Germany
Tel. [phone]
ax +49 (0) 23 55 / 5044-333
support-automa[email protected]
www.lumberg-automation.com
Belden Deutschland GmbH -Lumberg Automation- reserves any technical changes or changes to this manual without prior
notice.
1.1. Explanation of the symbolism
1.1.1. Use of notes
The following sign is used to mark important information.
1.1.2. Use of hazard warnings
Hazard warnings are marked as follows:
DANGER:
Violation of appropriate protection measures may cause danger to the life and health of the user.
ATTENTION:
Violation of appropriate protection measures may cause damage to other devices or material assets.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 5 of 30
1.2. Safety guidelines
1.2.1. Normal conditions of use
The devices that are explained in this manual are intended to be used as decentralized Input / Output assemblies in a PRO INET
network.
Our products are designed, manufactured, tested and documented with respect to common safety standards. With attention to
the handling specifications for planning, development and mounting and the safety instructions our products do not cause any
danger to persons and property under normal conditions.
The modules comply to the rules of the
EMC-directive (89/336/EWG, 93/68/EWG und 93/44/EWG)
Low voltage directive (73/23/EWG)
They are designed to be used in the industrial area. The industrial environment is characterized by the fact that electrical
consumers are not connected directly to the public low voltage network. or the application in residential areas, business areas
and commercial areas additional measures are to be taken.
Caution!
This equipment can cause interferences in the residential area. In this case the operator can be required to
accomplish appropriate measures.
The proper and safe function of the product requires an appropriate transport, storage, installation and mounting as well as a
careful operation.
The intended operation of the device is only guaranteed with a completely installed housing. All devices connected to this
equipment must fulfil the requirements of the EN 61558-2-4 and EN 61558-2-6.
Projecting, installation, commissioning, maintenance and test of the devices may be carried out only by an approved qualified
electrical specialist who is familiar with the security standards of the automation technology.
During projecting, installation, commissioning, maintenance and test of the devices the regulations for safety and prevention
of accidents in the specific application case have to be considered.
Only cables and accessories shall be installed that correspond to the requirements and regulations for safety, electromagnetic
compatibility and if necessary telecommunication terminals as well as the specification data.
More information about the admitted cables and accessories for installation may be obtained from Belden Deutschland –
Lumberg Automation- or are described in this technical manual.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 6 of 30
1.3. Qualified personnel
The requirements for the personnel depend on the requirement profile described by the ZVEI and VDMA or comparable
organizations.
Only electrical specialists, who know the content of this manual, may install and maintain the described products.
These are persons who
can assess the works to be performed and recognize possible dangers based on their technical education, knowledge
and experience as well as their knowledge of the relevant standards.
have the same level of knowledge as after a technical education due to an activity in a comparable area for several
years.
Modifications to the hard- and software of our products, as far as they are not described in this technical manual, may be
carried out only by Belden Deutschland GmbH -Lumberg Automation.
ATTENTION!
Unqualified modifications to the hardware or software or the non-observance of the warning instructions given in
this technical manual can entail heavy personal damages or damages to property.
1.4. Version information of the manual
Index Created Changed Changed Changed Changed Changed
Version number V1.0 V1.1 V1.2
Date 01.06.2010 09.07.2014 29.08.2014
Name / department Knipp/PM Knipp/PM Knipp/PM

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 7 of 30
2. System description
LioN (Lumberg i/o network)-Link is a modular system for the decentralized operation in rough industrial environment for the
simple handling of the I/O data in a superordinate bus system. It is particularly suitable for application places with high I/O
concentration on distributed assemblies.
By the very compact dimensions and the low weight the system can be used under limited space conditions and on handling
devices. As a protection class LioN-Link offers IP 67.
The LioN-Link system consists of the BusHead - the connection to the superordinate field bus - and the different field-bus-
independent I/O modules. The maximum expansion of the link system amounts to 100 m for each link connection (two
connections for each BusHead => total extension 200 m).
Each line can be extended with up to 15 I/O modules. The distance between two link participants is arbitrary. The permissible
overall length for each line may not be exceeded however. Using the maximum expansion of the system an additional feed of
the power supply for the system and sensors is possible through T-connectors and/or at the last link participant.
In order to keep the permissible values for a safe power supply of the modules it is necessary to calculate each system under
the actual conditions (number of the modules and sensors as well as the cable length between the modules). or this a
calculation table is available at the link
http://www.beldensolutions.com/en/Service/Downloadcenter/Software_Lumberg/index.phtml
An example can be found in this manual in chapter 5.2.2.
As a link cable we recommend a standard CAN/DeviceNet cable. Also unshielded 5-pole cables with standard M12 plugs and
jacks are suitable. As an alternative also ixcon plugs and jacks can be used.
With the use of an unshielded cable an extension of 25 m for each line connection should not be exceeded. In plants with EMC
load (in the near of controlled motors, frequency converter drives or in welding applications) the use of shielded cables
(standard CAN/DeviceNet) is necessary.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 8 of 30
3. Product overview
3.1.
3.2. Module variants
Part number
Descr
iption
I/O
-
connection
Design
LioN
-
Link
BusHead
0940 ESL 601
BusHead
PRO INET IO
M
LioN
-
Link
m
odule
s u
niversal I/O digital
0942 UEM 600
8 In/Out universal
4xM12
S
0942 UEM 650
8 In/Out universal
8xM8
S
0942 UEM 700
16 In/Out universal
8xM
12
M
0942 UEM 780
16 In/Out universal
Multipol
e
interface
M
LioN
-
Link
m
odule
s
input
I digital
0942 UEM 601
8 In
4xM12
S
0942 UEM 651
8 In
8xM8
S
0942 UEM 701
16 In
8xM12
M
LioN
-
Link
m
odule
s
input
I
analogue
0942 UEM 630
I/O
-
m
odul
e
4A I
(0)4
–
20mA
4xM12
S
0942 UEM 631
I/O
-
m
odul
e
4A I 0
–
10V
4xM12
S
LioN
-
Link modules output
O digital
0942 UEM 602
4 Out
4xM12
S
0942 UEM 612
4 Out
(for safety related
applications)
4xM12
S
0942 UEM 782
16 Out
Multipol
e
interface
M
LioN
-
Link
speci
al modules
0942 UEM 620
IO
-
Link
m
aster
4xM12
S
0942 UEM 783
Motion
drive c
ontrol
8xM12
M
3.3. Accessories
Part number
Description
PRO INET
0985 342 100/… M
Connecting cable
fo
r PRO INET,
double ended
with M12
-
plug
,
straight, 4-pole, D-coded
0985 342 10
2/… M
Connecting cable for PRO INET, single ended with M12
-
plug,
straight, 4-pole, D-coded
0985 342 104/… M
Connecting cable for PRO INET, double ended with M12
-
plug
,
straight, 4-pole, D-coded and RJ45-plug, straight
LioN
-
Link lines
0935 253 103/… M
Con
necting cable for
LioN
-
Link
line, double ended,
with M12
-
plug,
straight, 5-pole, A-coded and M12-socket, straight, 5-pole, A-coded
0935 253 104/… M
Connecting cable for LioN
-
Link line, single ended, with M12
-
plug,
straight, 5-pole, A-coded
0935 253 105/…
M
Connecting cable for LioN
-
Link line, single ended, with M12
-
socket
,
straight, 5-pole, A-coded
0935 253 106/… M
Connecting cable for LioN
-
Link line, single ended, with M12
-
socket,
angled, 5-pole, A-coded
0935 253 107/… M
Connecting cable for LioN
-
Link
line, single ended, with M12
-
plug,
angled, 5-pole, A-coded

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 9 of 30
Part number
Description
0935 253 108/… M
Connecting cable for LioN
-
Link line, double ended, with M12
-
plug,
angled, 5-pole, A-coded and M12-socket, angled, 5-pole, A-coded
Power supply
RKT 5
-
2
28/… M
Connecting cable for power supply
,
single ended, with M12
-
socket,
straight, 5-pole, A-coded
RKWT 5
-
228/… M
Connecting cable for power supply, single ended, with M12
-
socket,
angled, 5-pole, A-coded
RKT 5
-
226/… P89
Connecting cable for additional
po
wer feed, single ended,
with
M12
-
socket, straight, 5-pole, contacts 1&3 connected, A-coded
ield attachables
0986 EMC 102
ield attachable
M12
-
plug
for PRO INET cable
,
straight, 4
-
pole
,
D
-
coded, with spring-type terminals
RSC 5/9
ield attachable M12
-
pl
ug for
LioN
-
Link
line
a
nd
power supply
,
straight, 5-pole, A-coded
RSCW 5/9
ield attachable M12
-
plug for LioN
-
Link line and power supply,
angled, 5-pole, A-coded
RKC 5/9
ield attachable M12
-
socket for LioN
-
Link line and power supply,
straight, 5-pole, A-coded
RKCW 5/9
ield attachable M12
-
socket for LioN
-
Link line and power supply,
angled, 5-pole, A-coded
T
-
connectors
0906 UTP 101
T
-
connector for
daisy
-
chaining the power supply
.
Pay attention to the current load!
0906 UTP 104
T
-
connector
for addition
al power feed
in the LioN
-
Link line.
Other accessories

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 10 of 30
4. Mounting
4.1. Outer dimensions

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 11 of 30
4.2. Notes for the field installation
The modules are to be mounted on a flat surface, each with or at least with two screws.
Type of mounting
Screws
Torque
flat
M
4x30/35
1,0
Nm
laterally
M4x40/70
1,0
Nm
With all types of mounting
a flat washer
according to DIN 125 has to be
used.
Important note:
For the derivation of interference currents and/or for the EMC stability the module provides a metal
grounding sheet.
It is necessary to connect this metal grounding sheet by a low impedance connection to the
reference earth. In case of a grounded mounting surface the connection can be set up directly
through the mounting screws (not with laterally mounting).
With a not grounded mounting surface or lateral mounting a ground strap or a suitable PE-cable has
to be used.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 12 of 30
5. Wiring
5.1. Pin assignments
5.1.1. PROFINET ports, M12-socket, 4-pole, D-coded
Colour code of the connectors: green
ATTENTION, risk of destruction!
Do not connect power supply lines (24 V DC) to the data lines.
5.1.2. Power supply connector for the BusHead, M12-plug, 5-pole
Colour code of the connector: grey
Connector
Pin
Signal
un
c
tion
PRO INET
ports P1, P2
1
TD+
Transmit Data +
2
RD+
Receive Data
-
3
TD
-
Transmit Data +
4
RD
-
Receive Data
-
Connector
Pin
Signal
un
c
tion
Power supply
BusHead/
System
1
+24VDC
system/sensors
line 1/2 +
BusHead
2
+24VDC
system/sensors
line 1/2 +
BusHead
3
0V
system/sensors line 1/2 +
BusHead
4
0V
syste
m/sensors line 1/2 +
BusHead
5
Earth
E
arth

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 13 of 30
5.1.3. Link system connector, M12-socket, 5-pole
Colour code of the connector: orange
ATTENTION! Risk of destruction!
Do not connect the power supply lines (+24 V DC) to the data lines (Data + -> Pin 4, Data - -> Pin 5).
Also the reverse connection of the power supply lines can lead to the destruction of the module.
Important note!
With long cable lengths an additional power supply feed is recommended, see following chapter.
Connector
Pin
Signal
un
c
tion
System bus
out
1
Drain
S
hield
2
+24
V
24 V
sy
stem
/
s
ensor
s
3
0
V
0 V
syst
em / sensors
4
Data +
Data
+
5
Data
-
Data
-
The 24 V power supply in the bus connectors is used to energize the module
electronics and the sensors of the system bus participants.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 14 of 30
5.2. Intermediate power supply feed on LioN-Link I/O-modules
During the planning of a machine or a plant it has to be considered that starting from certain cable lengths an intermediate
power supply feed for the electronics and sensors of the I/O-modules can be necessary.
If the power supply for the I/O-modules is not sufficient they deliver a diagnostics message.
The warning threshold for the diagnostics is approximately 19 V.
5.2.1. T-connector for intermediate power supply
An easy possibility of realizing the intermediate power supply on an I/O-module is the use of the T-connector 0906 UTP 104. Its
internal wiring is shown in the following drawing. The T-connector is screwed onto the link input (M12-plug) of a LioN-Link
I/O-module.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 15 of 30
5.2.2. Auxiliary tool for the determination of the voltage drop and the place of the intermediate
power supply feed.
or the calculation of the voltage drop on the LioN-Link line a calculation table as a Microsoft Excel sheet is available under
http://www.beldensolutions.com/en/Service/Downloadcenter/Software_Lumberg/index.phtml.
The table determines the voltage drop on the LioN-Link lines based on the current consumption of the I/O-modules and the
sensors as well as the cable lengths and conductor cross sections of the LioN-Link lines. urthermore the I/O-module is
indicated at which the intermediate power supply feed seems to be reasonable.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 16 of 30
6. Configuring and commissioning
The configuration and commissioning of the LioN-Link BusHead described on the following pages was accomplished with the
help of the STEP7 -software of the Siemens AG . In case of using a control system from another controller supplier please attend
to the associated documentation.
6.1. GSDML-file
or the configuration of the BusHead in the control system a GSD-file in XML-format is required. This GSDML-file can be
downloaded from our homepage under
http://www.beldensolutions.com/en/Service/Downloadcenter/Software_Lumberg/index.phtml.
On request the GSDML-file is also mailed by the support team.
The name of the file is as follows:
GSDML-v2.2-Lumberg Automation-LioN Link-yyyymmdd.xml,
in which „yyyymmdd“ expresses the release date of the file.
In STEP7 you create a new project and open the hardware manager HW-Config . By the menu item Options – Install GSD ile…
and the subsequent dialogue the GSDML file is installed. The LioN-Link system with the PRO INET BusHead is displayed
afterwards in the hardware catalogue.
6.2. MAC addresses
The BusHead gets three MAC addresses assigned on delivery. These are unique and cannot be changed by the user.
6.3. SNMP
The BusHead supports the Ethernet network protocol SNMP (Simple Network Management Protocol). The information of the
network management is presented according to the MIB-II (Management Information Base) which is defined in the R C 1213.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 17 of 30
6.4. Configuration of the LioN-Link PROFINET system in STEP7
After the installation of the GSDML file for the BusHead the LioN-Link system is available in the hardware catalogue under
PRO INET IO – Additional ield Devices - I/O - Lumberg LioN-Link .
irst configure the control system in the usual way. Assign an IP-address and a subnet mask for the PRO INET port of the
control unit.
Afterwards click on the part description of the BusHead 0940ESL601 in the hardware catalogue . Move the system to the
PRO INET line of the control unit.
Insert now the I/O modules of the LioN link system connected to the BusHead into the configuration.
Locate the I/O-modules connected to line 1 to the slots 1 to 15. The slots 16 to 30 are to be filled with the I/O-modules of the
second line. It is allowed to leave slots free, placeholder modules are not necessary. However, the correct order of the I/O-
modules has to be observed.
Both lines of the BusHead can be filled with a maximum of 15 I/O-modules each.
I/O
-
modules at the line 1 are
inserted into the slots 1-15.
I/O
-
modules at the
line 2
are
inserted into the slots 16-30.
Virtual module necessary for
the operation of LioN-Link
motion module
0942 UEM 783.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 18 of 30
6.4.1. Assignment of a unique device name
PRO INET IO devices are addressed in PRO INET by a unique device name. The name can be assigned freely by the user but may
only occur once in the network.
Select the LioN-Link System in HW-Config and choose the menu item Edit – Object Properties . In the opening dialogue window
you can change the device name.
Check whether the displayed IP-address is correct and control unit and BusHead are located in the same Ethernet subsystem.
Confirm the settings with OK .
6.4.2. Assignment of the device name to the BusHead
An online PRO INET connection between the programming device and the BusHead is required for the assignment of the device
name to the BusHead.
Select the LioN-Link system and choose the dialogue PLC – Ethernet –Assign Device Name .

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 19 of 30
6.4.3. Device exchange without removable media/PG
PRO INET IO devices that support the function device exchange without removable media or PG can be exchanged in an
existing PRO INET network without the need to use a removable media or programming device. In this case the IO-Controller
takes over the task to assign the device name. or the assignment of the device name the IO-controller uses the configured
topology and the adjacent relationships determined by the IO-Devices.
The LioN-Link PRO INET BusHead supports the function of device exchange without removable media/PG.
The topology of the network has to be configured for the use of the function.
During the configuration of the IO-Controller in HW-Config the function has to be selected. A double click on the PRO INET IO
port of the controller opens the properties dialogue. Activate the function “ Support device replacement without exchangeable
medium”
.
The interconnections of the PRO INET ports of the individual devices have to be configured also. A double click on a port of a
device in HW-Config opens its properties dialogue. In the register Topology the interconnections with the partner ports of
other devices in the network are defined.

Technical Manual
LioN-Link PROFINET
Subject to change without notice! Version 1.2 / August 2014
Page 20 of 30
