Belden Lumberg Automation Lumberg Automation 0980 ESL 811-EIP... User manual

Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016
Technical support
[e-mail]
Technical manual
LioN-P EtherNet/IP with QuickConnect
0980 ESL 311-xxx ... 0980 ESL 313-xxx
0980 ESL 391-xxx ... 0980 ESL 393-xxx
LioN-R EtherNet/IP with QuickConnect
0980 ESL 811-EIP 16DI-M12-R
0980 ESL 812-EIP 16DO-M12-R
0980 ESL 813-EIP 8DI/8DO-M12-R

2
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016

Content
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016 3
Content
1 About this manual 7
1.1 General information 7
1.2 Explanation of symbols 8
1.2.1 Use of danger information 8
1.2.2 Use of general information 8
1.3 Version information 9
2 Safety instructions 11
2.1 Intended use 11
2.2 Qualified personnel 12
3 System description 13
3.1 About the LioN-P/-R module series 13
3.2 Special product features 13
3.3 Product overview 14
4 Assembly and wiring 17
4.1 General information 17
4.2 Outer dimensions 19
4.2.1 Module 0980 ESL 813-EIP 8DI/8DO-M12-R 19
4.2.2 Module 0980 ESL 313-111 20
4.2.3 Module 0980 ESL 313-121 21
4.3 Port assignments 22
4.3.1 Ethernet/IP ports 22
4.3.2 Ports for the power supply 22
4.3.3 Connections for power supply, 7/8", 5-pin (only
applies to multiprotocol) 24
4.3.4 Power supply with M12 power L-coded 25
4.3.5 Ports for the sensors/actuators 26
5 Starting operation 27
5.1 Downloading and installing the EDS file 27
5.2 Reading the MAC addresses 28

Content
4Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016
5.3 Setting the network parameters 28
5.4 Configuring the controlling 29
5.4.1 Connections and assembly object 29
5.4.2 Configuration assembly instance 31
5.4.3 Configuration example 33
5.4.4 Initial settings of the connection parameters 37
6 The integrated web server 39
6.1 The Home page 39
6.2 The Configuration page (Config) 39
6.3 The Status page 41
6.4 The Contact page 42
6.5 Reading the process and diagnostic data 43
7 QuickConnect 45
7.1 How it works 45
7.2 Activation 45
7.2.1 Configuration assembly instance 105 46
7.2.2 EtherNet/IP object (TCP/IP object) 46
8 Bit assignment 49
8.1 16DI module 49
8.1.1 Assembly instance ID 101 (input data with diagnosis) 49
8.1.2 Assembly instance ID 102 (input data without
diagnosis) 49
8.1.3 Key: 49
8.2 16DO module 50
8.2.1 Assembly instance ID 101 (input data with diagnosis) 50
8.2.2 Assembly instance ID 102 (input data without
diagnosis) 50
8.2.3 Assembly instance ID 100 (output data) 50
8.2.4 Key 50
8.3 8DI/8DO module 51
8.3.1 Assembly instance ID 101 (input data with diagnosis) 51
8.3.2 Assembly instance ID 102 (input data without
diagnosis) 51
8.3.3 Assembly instance ID 100 (output data) 51
8.3.4 Key 52

Content
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016 5
9 Diagnostics processing 53
9.1 Channel error 53
9.2 Voltage error at the M12 slots (sensor short-circuit) 54
9.3 Overload of output drivers 54
9.4 Error in the actuator power supply 55
9.5 Error in the system/sensor power supply 55
10 Technical data 57
10.1 General 57
10.2 Bus system 57
10.3 Power supply for the module electronics/sensors 58
10.4 Power supply for the actuators 59
10.5 Inputs 59
10.6 Outputs 60
10.7 LEDs 60
11 Declaration of conformity 63
12 Accessories 65

Content
6Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016

About this manual
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016
1.1 General information
7
1 About this manual
1.1 General information
Please read the assembly and operating instructions in this manual carefully
before starting up the LioN-P and LioN-R/ -P modules with EtherNet/IP
interface. Keep the manual where it is accessible to all users.
The texts, figures, diagrams and examples used in this manual are used
exclusively to explain how to operate and apply the LioN-P and LioN-R/ -P
modules with EtherNet/IP interface.
Please contact us if you have any detailed questions on installing and starting
up the devices. We will be happy to help you.
Belden Deutschland GmbH
– Lumberg Automation™ –
Im Gewerbepark 2
58579 Schalksmühle
Germany
Tel. [phone] / 5044-0
Fax [phone]
[e-mail]
www.lumberg-automation.com
Belden Deutschland GmbH – Lumberg Automation™ – reserves the right to
make technical changes or changes to this manual at any time without notice.

About this manual
8
1.2 Explanation of symbols
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016
1.2 Explanation of symbols
1.2.1 Use of danger information
Danger information is denoted as follows:
1.2.2 Use of general information
General information is denoted as follows:
DANGER
Means that death, serious physical injury or substantial damage to property
will occur if the required safety measures are not taken.
WARNING
Means that death, serious physical injury or substantial damage to property
can occur if the required safety measures are not taken.
CAUTION
Means that minor physical injury or damage to property can occur if the
required safety measures are not taken.
NOTE
Contains important information on the product, on how to manage the
product, or on the respective section of the documentation to which your
special attention is being drawn.

About this manual
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016
1.3 Version information
9
1.3 Version information
Index Created Changed Changed
Version number Version 1.0 Version 1.1 Version 1.2
Date March 2013 May 2013 Aug 2014
Name/department Knipp/PM Knipp/PM Knipp/PM
Version number Version 1.3 Version 1.4
Date December 2015 February 2016
Name/department Knipp/PM Lieb/R&D
Table 1: Overview of manual revisions

About this manual
10
1.3 Version information
Technical manual LioN-P/ -R EtherNet/IP
Release 1.4 02/2016
