BEMIS bioBidet SLIM TWO User manual

USER MANUAL SLIM TWO

32
PRODUCT INFORMATION
Important Safeguards
Overview & Parts
Wireless Remote
GETTING STARTED
Functions & Features
INSTALLATION
Installation Guide
MAINTENANCE
Cleaning the Slim Two
Draining the Water Tank
Troubleshooting Guide
Specifications
WARRANTY
Warranty
Customer Support
Notes
04
09
12
16
20
TABLE OF CONTENTS
Questions?
We’re here to help.
847.458.2334
[email protected]
www.biobidet.com
Technical support and alternate
fittings are available.
Registration and
Installation Resources

54
IMPORTANT SAFEGUARDS
PRODUCT INFORMATION
PLEASE OBSERVE THE FOLLOWING PRECAUTIONS
AND INSTRUCTIONS BEFORE INSTALLATION AND USE.
•This product must be connected to a grounded 120V GFCI (ground fault
circuit interrupt) outlet. Do not connect the power cord if it is damaged or
broken. Do not plug the product into a loose electrical outlet.
•It is recommended to operate this product on a separate circuit.
Sharing a circuit could cause the breaker to trip or lights to flicker.
•If it is necessary to use an extension cord, use only a three-pronged
extension cord plugged into a proper GFCI outlet. The marked rating
of the extension cord should be equal to or greater than the electrical
rating of the unit (10 amp). Consult a qualified electrician or service
person if you are not sure whether the unit is properly grounded.
•Do not open this product for repair without authorization from the
manufacturer. Only qualified service personnel should service this
product. Do not use accessories not recommended by the manufacturer.
•Connect this product to a potable cold water supply line.
•Close supervision is necessary when this product is used by children,
eldely, or adults with sensitive skin. A low-temperature burn may occur
when the skin has been in contact with an object at relatively low
temperature for an extended period of time.
•If using any chemical toilet bowl cleaner, be sure to wipe up any spills that
splash onto the bidet. Do not use benzene or any acid chemical detergent,
as they can cause discoloration. Only neutral detergents are permitted.
•Do not plug in the power cord before connecting the water supply hose.
•Install in an area with adequate ventilation to avoid high levels of
humidity, which can damage the electronic components.
•Do not touch the power cord with wet hands or reach for a product
that has fallen into water. Unplug immediately.
•Unplug the bidet seat when cleaning or detaching from the toilet bowl.
Do not plug in until plumbing work has been completed.
•Keep the power cord away from heated surfaces to prevent a fire hazard.
Keep any flammable materials away from this product at all times.

76
OVERVIEW & PARTS
Slim Two Slim Two Parts List
PRODUCT INFORMATION
Wrench Phillips Screwdriver
Recommended Installation Tools
Stainless Steel Nozzle
1. Posterior Wash
2. Feminine Wash
1
2
Lid
Side Control Panel
Power Cord (4ft)
Nozzle
Seat Sensor
Heated Seat
Night Light
T-Valve
*Rubber Washer Inside
Catch Plate
2 AA
Batteries
Wireless
Remote
Remote Mounting
Bracket
Bolt Guides
Mounting Bolts Bidet Hose
Top Mount
Rubber Nuts
Washers

98
WIRELESS REMOTE
The Slim Two is a bidet toilet seat designed for superior
hygiene, comfort, and sustainability. Each use will leave you
feeling clean and confident, while reducing your overall eco footprint.
Sit Down On The Seat
This product includes a built-in seat sensor that must be
activated with skin contact in order to operate bidet functions.
Stop Button
Stops all operations.
Rear Wash
Press to activate the posterior wash cycle, carefully crafted with the
optimum cleansing angle and spray pattern. Press again to oscillate.
Front Wash
Press to activate the feminine wash cycle, which offers an
alternate accommodating spray pattern. Press again to oscillate.
Turbo Wash
Press to activate a focused wash with higher water pressure.
Press again to oscillate.
Massage
Press “Massage” during a wash cycle to activate
a pulsating spray pattern.
Functions & Features
GETTING STARTED
Stop/Reset Button
Rear Wash
Front Wash
Turbo Wash
Adjustable
Nozzle Position
Adjustable
Seat Temperature
Adjustable
Water Pressure
Adjustable
Water Temperature
Massage
Child Wash
Nozzle Cleaning
Energy Saving

10 11
GETTING STARTED
GETTING STARTED
Nozzle Cleaning
While not seated, press “Nozzle Cleaning” to extend the nozzle for
three cycles of automatic cleaning. Afterwards, the nozzle will remain
extended for manual cleaning without spraying. Press the
“Stop” button to rinse and retract the nozzle when finished.
Sitz Bath - While the nozzle cleaning function is in use, press “Wash”
or “Bidet” to switch to a sitz bath. The water pressure changes to
low and operates for 5 minutes. The nozzle cleaning LED will turn
on during this function. Press the “Nozzle Cleaning” button again to
switch to normal wash cycle.
Silent Mode
Press “-” button for 3 seconds to activate slient mode.
Smart Seat Sensor
To deactivate the seat sensor, press the “Massage” button for 3 seconds.
When deactivated, wash functions will work without occupying the seat.
Use of external water filter is only recommended in areas with
known hard water issues.If a filter is used, it must be replaced every
3 months. This product is designed and intended for use exclusively
with Bio Bidet DIB water filters. The purchase or use of any other
water filter is not the responsibility of BBC Innovation LLC. As such,
any use of non DIB water filters is prohibited and will void the
warranty for those Bio Bidet products. Bio Bidet will not be
responsible for any resulting damages or claims related to the
misuse or distribution of non BioBidet DIB filters.
Child Wash
Press to activate a child-friendly wash with low water pressure.
Press again to oscillate.
Adjustable Nozzle Position
Adjust the nozzle position forward or backward to achieve maximum
cleanliness and comfort by pressing the “Front” or “Rear” (^, )buttons.
Adjustable Water Pressure
Press “High” or “Low” (+, -) to adjust the pressure of the
water spray to your desired comfort level.
Adjustable Water Temperature
Adjust the water temperature by pressing the “Water Temp”
button to cycle through preset temperature levels.
Adjustable Seat Temperature
Adjust the seat temperature by pressing the “Seat Temp” button
to cycle through preset temperature levels.
Night Light
Press the “+” button for 3 seconds to turn the night light on/off.
Energy Saving
Switch energy saving features on/off.
•Yellow - The seat and water temperature will
be maintained at 89°F until the seat is occupied.
•Green - The seat and water heater will be turned off until the
seat is occupied.

1312
GETTING STARTED
INSTALLATION GUIDE
BEFORE INSTALLATION
Do not plug the power cord in until installation is complete.
Please contact customer support at 847.458.2334 for
alternate fittings or assistance with this process.
1. Turn Off Water
Turn off the water shut-off
valve. Drain the toilet tank
completely by flushing the
toilet. Unscrew the hose
connected to the toilet tank. Existing
Toilet Hose
2. Remove Toilet Seat
Remove mounting bolts to
release the existing toilet
seat from the toilet.
Bolts
Washers
Top Mount
Rubber Nuts
Bolt Guides
3. Install Catch Plate
Place the catch plate and bolt guides over the mounting holes. Insert the mounting
bolts through the washers, guides, catch plate, and top mount rubber nuts into the
mounting holes. Fasten to secure the catch plate on the toilet.
4. Install Your Slim Two
Slide the bidet seat all the way onto
the catch plate until you hear a click.
Catch Plate

14 15
INSTALLATION
INSTALLATION
Plug the power cord into a 120V power outlet.
1. Install the t-valve onto the toilet tank. Ensure the
rubber washer is properly seated inside the t-valve.
2. Connect your existing toilet hose to the water
shut-off valve and t-valve.
3. Connect the provided bidet hose to the bidet seat and t-valve.
4. Open the water shut-off valve. Check for any leaking or dripping.
Shut-off valves may vary. If supplied parts do not fit, please call
847.458.2334. Alternate fittings may be available upon request.
Toilet Tank
T-Valve
Rubber Washer
*Inside T-valve
Use existing toilet hose
Toilet Hose
Bidet Hose
Shut-Off Valve
5. Connect the Water Hoses
6. Plug It In!
1. Make sure to clean the area thoroughly before attaching. Attach the
remote control bracket to the wall by removing the adhesive protection
to attach the remote control bracket to the wall or other surface.
2. Insert two AA batteries into the battery compartment.
7. Installing the Remote

1716
MAINTENANCE
MAINTENANCE
Cleaning the Slim Two
•Avoid using harsh cleaners to preserve the plastic material of the bidet
seat. Wipe the surface with a damp cloth or neutral cleaning solution.
Do not splash water onto the power plug.
*Close shut-off valve
This product will not operate properly if the strainer is clogged.
Please clean the strainer regularly.
1. Unplug the power cord and close the water shut-off valve.
2. Unscrew the bidet hose from the bidet seat.
3. Clean the strainer with a small brush.
4. Re-connect the bidet hose.
5. Open the water shut-off valve.
6. Plug in the power cord.
Cleaning the Strainer Draining the Water Tank
Before draining, unplug the power cord and wait 30 minutes until the
unit has cooled down. Do not insert your finger into the drain hole.
If you do not intend to use this product for an extended period of time,
drain the water from this product’s water tank.
1. Disconnect the power plug.
2. Close the water shut-off valve.
3. Press the lever button on the right side of the bidet and gently
pull to remove the unit from the catch plate.
4. Use a flathead screwdriver to open the drain plug. It will leak water.
5. Reattach bidet seat back on toilet. The toilet can still be used.
Reverse this to reactivate.
Open the water shut-off valve to refill and resume usage.
*Close shut-off valve

1918
TROUBLESHOOTING GUIDE
SPECIFICATIONS
Problem Solution
Completely out of order
•Check if the power
plug is connected
•Check if the power supply
or outlet has failed
Water does not spray
•Check if water valve is open
•Check if the nozzle is blocked
•Check for any kinked hoses
Water pressure is low
•Check if screen filter is
blocked and clean if needed
•Check if the water pressure
is set to the lowest pressure setting.
Water is not warm enough
•Verify temperature is set correctly
•Verify eco settings
Seat is not warm enough
•Verify temperature is set correctly
•Verify eco settings
Water is leaking
•Check for any loose connections
•Turn off the water supply valve
and contact customer support.
Specifications Slim Two
Rated Voltage 120V, 60Hz
Max. Power Consumption 870W
Reccomended Water Inlet Pressure 9.9~106.6 psi
Power Cord 4 feet
Wash Wash 0.13~0.21gal/min
Bidet Wash 0.13~0.18gal/min
Turbo Wash 0.13~0.18gal/min
Child Wash Wash 0.13~0.16gal/min
Adjustable
Water Pressure
5 Levels
Warm Water Temp Room Temp - Low, Normal, High
Heater 800W
Safety Device Water level sensor, Thermal fuse,
Bi-metal, Temperature sensor
Heated
Seat
Temperature Room Temp - Low, Normal, High
Heater 55 W
Safety Device Thermal fuse
Inlet Water Temperature 37.4°F ~ 95°F ( 3°C~ 35°C )
Ambient Temperature 37.4°F ~ 104°F ( 3°C~ 40°C )
Dimensions Elongated W: 15.43 in / L : 20.9 in / H : 5.98 in
Round W:15.43 in / L: 18.9 in / H: 5.71 in
Weight 10.5 lbs

2120
1 YEAR FULL COVERAGE WARRANTY
Bio Bidet Innovation LLC warrants its product to be free from manufacturing
defects under normal use and service for a period of one (1) year from
original date of purchase.
This warranty is extended only to the ORIGINAL PURCHASER.
•Bio Bidet Innovation LLC’s obligations under this warranty are limited to
repair or replacement, at Bio Bidet Innovation LLC’s option, of products
or parts found to be defective, provided that such products were properly
installed and used in accordance with instructions.
•Bio Bidet Innovation LLC reserves the right to make such inspections as
may be necessary in order to determine the cause of the defect.
•Bio Bidet Innovation LLC will not charge for labor or parts in connection
with authorized warranty repairs.
•Bio Bidet Innovation LLC is not responsible for the cost of removal, return,
initial install, and/or re-installation of products.
•Bio Bidet Innovation LLC shall not be responsible or liable for any failure
of, or damage to, this plumbing product or product component caused by
either chloramines in the treatment of public water supply or in-tank bowl
cleaners containing chlorine (calcium hypochlorite).
This warranty does not apply to the following items:
•Damage or loss sustained in a natural calamity such as fire,
earthquake, flood, thunder, electrical storm, etc.
•Damage or loss resulting from any unreasonable use,
misuse, abuse, negligence, or improper maintenance of the product.
•Damage or loss resulting from removal, improper repair,
or modification of the product.
•Damage or loss resulting from sediments or foreign matter
contained in a water system.
•Damage or loss resulting from improper installation or from
installation of a unit in a harsh and/or hazardous environment.
WARRANTY
This warranty gives you specific legal rights. You may have other rights which vary
from state to state. To obtain warranty repair service under this warranty, you must
contact Bio Bidet Innovation LLC or an authorized distributor.
This written warranty is the only warranty made by Bio Bidet Innovation LLC.
Repair or replacement as provided under this warranty shall be the exclusive
remedy available to the purchaser. Bio Bidet Innovation LLC shall not be
responsible for loss of the product or for other incidental, special or consequential
damages or expenses incurred by the purchaser, or for labor or other costs due to
installation or removal, or costs of repairs by others, or for any other expense not
specifically stated above. Except to the extent prohibited by applicable law, any
implied warranties, including that of merchantability or fitness for use, are
expressly limited to the duration this warranty. Some states do not allow
limitations on how long an implied warranty lasts, or the exclusion or limitation
of incidental or consequential damages, so the above limitation and exclusion
may not apply to you.
WARRANTY
BIO BIDET INNOVATION LLC
7900 S IL Route 31 Crystal Lake IL 60014
T: 847.458.2334
F: 847.854.1296
[email protected]
www.biobidet.com

22 23
Notes
WARRANTY
WARRANTY

Customer Support
T: 847.458.2334
TOLL-FREE: 877.339.5214
7900 S IL Route 31 Crystal Lake, IL 60014
[email protected]
www.biobidet.com
THANK YOU!
10.17.22
