Berlin Gardens Bristol BSRDC2036 User manual

Bristol Dining Swivel Rocker
Assembly Guide
Tools Required
Hardware Included
Step 1
Fasten the back to the seat by fitting the
seat supports into the cutouts in the back legs.
Using the #2 square drive bit, drive
4 - 4" buglehead screws into the predrilled
holes in the back legs. You may need to reverse
your drill several times before being able
to pull the pieces tightly together.
Note: Ensure that the outside surfaces of the back leg
and seat support are even and are securily fastened
as noted below!
4 - 4"
Buglehead
Screws
6 - 5/16" X 1 3/4"
Allen Head Bolts
6 - 5/16"
Flange Nuts
4" Buglehead Screws
Ensure that the outside surfaces of both pieces are even and are securely fastened!
Step 2
Using 6 - 5/16"x 1 1/4" Allenhead Bolts and 5/16" Flangenuts,
fasten the 3-Fiberglass Springs and an Aluminum Plate to
the bracket located under the seat. The Springs should point
towards the front of the chair. Only hand tighten the nuts until
all six bolts are installed, then align the springs and fully tighten.
Step 1 Detail
Step 2 Detail
Fiberglass Springs
5/16" Flange Nuts
6 - 5/16"
Lock Washers
6 - 5/16"
Square Nuts
3 - Fiberglass Springs
3 - Aluminum Plates
1 - Swivel Mechanism
Aluminum Plate
Cordless Drill Allen Wrench
(included)
Wrench
#2 Square Drive Bit
5/16" x 1 1/4" Allenhead Bolts
6 - 5/16" X 1 1/4"
Allen Head Bolts

Step 3
Fasten the Swivel Mechanism to the
Figerglass Springs, using 2 - Aluminum
Plates, 6 - 5/16"x 1 3/4" Allenhead Bolts,
Lock Washers and Square Nuts. Only hand tighten
the bolts until all six are installed then fully tighten.
Step 4
Lift the chair and set the swivel stem into the
receiver of the base. Push firmly onto the chair
until it sits securely in the receiver.
Step 5
Install the arms rests on your swivel chair using
the instructions and hardware provided with
the Arm Kit.
DO NOT USE A SWIVEL CHAIR WITHOUT THE ARMS RESTS INSTALLED!
5/16" Square Nuts
5/16" Lock Washer
Swivel Mechanism
Step 3 Detail
Aluminum Plate
Aluminum Plate
Fiberglass Springs
5/16" x 1 3/4" Allenhead Bolts
