HARDWARE PACKAGE
16 ¼" x 2" Allen Head Bolts
16 ¼" Flange Nuts
40 3" Screws
24 1½" Screws
2 Umbrella Knobs
1Allen Wrench
PACKAGE CONTENTS
1Top
4 Bases
8 Braces
4 Footrests (Bar and Counter Height)
2 Long Cross Supports
1 Short Cross Support
1 Hardware Package
1 Umbrella Plug
TOOLS NEEDED:
Hammer
7/" Wrench
Cordless Drill/Screwdriver
Allen Wrench (Included)
Firmly tap bolts into pre-drilled
holes before tightening.
CORRECT INCORRECT
1 2 34 5
Use to measure bolts
Garden Classic Table
NOTE: Bar
and Counter
Height Only
Assembly Directions for
44"x96" Rectangular Table
Be sure to
use 1½"
screws when
fastening
braces.
!
Base
Upright
Top Boards
Apron
Brace
Umbrella
Holder
Curved End Board
Footrest
Garden Classic
Table
Long Cross Support
Short Cross
Support

STEP #1 - First assemble both Bases and Long Cross
Supports using 3" Screws.
Please note: ere are two outside Bases and
two center Bases. e two center Bases have
extra mortises for the Umbrella Holder and
Short Cross Supports (see Step #3).
STEP #2 - Attach the rst Base Assembly to the
aluminum frame of the Top using
8- ¼" x 2" Allen Head Bolts.
STEP #3 - Attach the two Short Cross Supports and the
Umbrella Holder to the Base using 3" Screws.
STEP #4 - First attach the second Base Assembly to the
aluminum Frame of the Top using 8- ¼" x 2"
Allen Head Bolts. Second fasten the Base
Assembly to the Short Cross Pieces and
Umbrella Holder using 3" Screws.
STEP #5 - Last, attach the Braces to the Top and the Base
using 1½" Screws.
Caution: Do not overtighten the Screws into
the Top!
Umbrella
Knobs
¼" x 2" Allen Head Bolts
¼" x 2" Allen Head Bolts
Cross Support
Footrest
1½" Screws (circled)
3" Screws
3" Screws
3" Screws
