Bircher Reglomat ProxySwitch User manual

1 Cover frame
2 Front lens cap
2a 2b 2c
1
234
5
67
89
ProxySwitch
presence
Touchless Push Plate Questions? Call us at 800 - 252-1272, 8am - 5pm central standard time.
1Safety Instructions
*The device must only be operated at a protective low voltage with safe electrical insulation.
*Product repairs must be performed solely by the manufacturer.
*Shut off all power going to the sensor before attempting any wiring procedures.
*Maintain a clean & safe environment when working in public areas.
*Constantly be aware of pedestrian traffic around the door area.
*Always stop pedestrian traffic through the doorway when performing tests that may result in unexpected reactions by the door.
*Always check placement of all wiring and components before powering up to ensure that moving door parts will not catch any
wires and cause damage to equipment.
*Ensure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation.
DO NOT LEAVE ANY PROBLEMS UNRESOLVED - NEVER SACRIFICE SAFETY FOR ANY REASON
3 Jumper scanning ranges
4 Connection terminal
5 Jumper scanner/switch ON/OFF
6 Pot. scanning range setting
7 Transmitter
8 Receiver
9 Function indication red LED
2Design / Overview
Surface mounting use accessory PRSW-SMB
3Mounting / Installation
User s guide
,
IMPORTANT: WHEN CONNECTING THE DEVICE TO THE OPERATING VOLTAGE, NO OBJECT MAY BE IN THE DETECTION AREA.

1-12 - 24 V AC - 0%/+15%
+ 12 - 30 V DC - 0%/+15%
common
NO
NC
K6202.029 04/07
Potentiometer for
scanning range setting
4b 4c
4a
EN EN
TS TS
4Adjustments
Jumper EN
Pos. N= 1.97"–7.87" (50-200 mm)*
Jumper TS
Pos. T=scanner
Jumper EN
Pos. E= 1.97"–23.62" (50-600 mm)*
Jumper TS
Pos. S=switch ON/OFF
Attention: After adjustment of the scanning range/mounting of the cover, turn off power for approx. 5 seconds, and then turn it on again.
*standard settings
5Wiring diagrams
6Technical Data
If after troubleshooting a problem, a
satisfactory solution cannot be achieved,
please call:
Bircher Reglomat at 800- 252-1272
from 8am - 5pm central standard time.
You may also visit our website at:
www.bircherreglomat.com
DO NOT LEAVE ANY PROBLEMS UNRESOLVED
NEVER SACRIFICE SAFETY FOR ANY REASON
Bircher Reglomat reserves the right to change
any information on this document without
notice.
For the latest version, please log on to
www.bircherreglomat.com
or call us at 847-952-3730 to request a copy of
the current version.
7Contact 8Disclaimer 9FCC Approval
-This Class B digital apparatus complies with
Canadian ICES-003. Cet appareil numérique de la
classe B est conforme à la norme NMB-003 du
Canada.
-This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any interference
received, including interference that may
cause an unwanted operation.
Adjustable Short Range (enhanced sensitivity)
Adjustable Long Range (standard sensitivity)
B/W Difference
Power supply
Current consumption
Temperature range
Atmospheric Humidity
Relay Output
Switching voltage
Switching current
Switching capacity
Function indication
Protection class
Protection class with sealing
Electromagnetic compatibility
1.97” - 7.87” (50 - 200 mm)*
1.97” - 23.62” (50 - 600 mm)
approximately 10%
12 - 24 V AC - 0%/+15%
12 - 30 V DC - 0%/+15%
approximately 50 mA
-4° to 140°F (-20° to 60°C)
0to 90% rel.
48 V AC/DC
1 A
30 W/60 VA
LED (red “on” when active)
IP 52
IP 65
EMC dir. 89/336/EEC
*standard settings
