INSTALLATION INSTRUCTIONS FOR FLUE EXTENSION
EXTENSION Ø 80/125 MM
7 719 003 666
6 720 641 099-00.1O
FOR GAS CONDENSING APPLIANCES:
GREENSTAR HIGHFLOW CDI, GREENSTAR FS CDI REGULAR,
GREENSTAR CDI SYSTEM/COMBI/REGULAR, GREENSTAR I JUNIOR,
GREENSTAR SI, GREENSTAR RI, GREENSTAR SYSTEM
6 720 641 099 (2009/06)

7 719 003 666
6 720 641 099 (2009/06)
2
SAFETY PRECAUTIONS
IF YOU SMELL GAS
BDo not smoke or strike matches.
BDo not turn electrical switches ON or OFF.
BPut out naked flames.
BOpen doors and windows.
BKeep people away from the affected area.
BTurn off the control valve at the meter.
BCall your gas company.
-or-
BCall emergency number 0800 111 999.
IF YOU SMELL FUMES FROM THE APPLIANCE
BSwitch off the appliance.
BOpen windows and doors.
BInform your heating engineer.
INSTALLATION INSTRUCTIONS
Please read these instructions carefully before starting
installation. If you are in any doubt contact Worcester
Technical Support.
These installation instructions must be read in
conjunction with the appliance manual.
Please leave these instructions with the user or at the
gas meter after installation or servicing.
Distance learning and training courses are available from
Worcester, Bosch Group.
BENCHMARK
Please leave these instructions with the completed
Benchmark Checklist (or a certificate confirming
compliance with IS 813, EIRE only) with the owner after
installation or servicing.
The Benchmark Checklist can be found in the back two
pages of the appliance installation manual.
FITTING AND MODIFICATIONS
Fitting the flue system to the appliance must be carried
out by a GAS SAFE registered, competent person in
accordance with these installation instructions and the
current Gas Safety Regulations (Installation and Use).
Flue systems must not be modified in any way other than
as described in the fitting instructions. Any misuse or
unauthorised modifications to the appliance, flue or
associated components and systems will invalidate the
warranty. The manufacturer accepts no liability arising
from any such actions, excluding statutory rights.
BPosition the flue terminal in such a way so that
combustion products do not enter the building or
cause a nuisance.
BPosition the flue in such a way so the flue does not
cause an obstruction.
BEnsure the flue terminal is not obstructed and
combustion products can discharge without
hindrance.
BFit the flue according to the regulations and
standards.
SERVICING
Advise the user to have the system serviced annually by
a GAS SAFE registered, competent person using
approved spares, to help maintain the economy, safety
and reliability of the appliance.
The service engineer must complete the Service Record
on the Benchmark Checklist after each service.

7 719 003 666
6 720 641 099 (2009/06) 3
1Extension Ø80/125 mm
1Extension Ø80/125 mm
1Extension Ø80/125 mm
1Extension Ø80/125 mm
2Screw
1
2
6 720 641 099-01.1O
Ø125
Ø82
990
1000
40
Ø127
1
2
6 720 610 165-02.2O
LV≥160 mm
ø125
LV
1
3
4
5
6 720 610 165-03.2O
1
6 720 641 099-02.1O
40
1
2
6 720 617 795-01.1
O
≤2 m ≤2 m
