Bretford CoreX Series User manual

WARNINGS
WARNING: Relocating audio and/or video devices to a cart
not specifically designed to support audio and/or video
devices may result in death or serious injury due to the cart
collapsing or over turning onto a child. !
WARNING: Death or serious injury may occur when children
climb on a cart. A remote control or toys placed on the cart
may encourage a child to climb on the cart and as a result,
the cart may tip over on to the child.
SAFE USE INSTRUCTIONS
•The socket outlet shall be installed near the cart and
shall be easily accessible.!
•Make sure all devices do not exceed the maximum
load rating of 12 amps.!
•Power strips inside cart are intended only for charging
compatible devices. Any other use may cause
overload.!
•Do not move cart by pulling the power cord. Before
moving cart from one room to the next, wrap power
cord around the cord winder located on the side of
the cart.!
•Do not plug the cart in if the switch, receptacle(s), or
power cord has been damaged. Contact Bretford or a
qualified electrician before attempting to make any
type of electrical repair or parts replacement.!
•Engage locking casters when cart is not in transit.!
•Do not block ventilation holes on cart. Proper air flow
is required for safe operation.!
•Cart is not designed to be operated by a child or
student. Adult operation and supervision is
recommended at all times.!
•Liquids should not be stored in, set on or placed
inside the cart.!
•Only clean the surfaces of cart with soft dry cloth.
Do not use liquid or spray or abrasive cleansers.
Use only disinfecting wipes containing no bleach.!
•Product is for indoor use only.!
•User can plug in up to 36 devices at one time.!
•Turn power switch offbefore plugging in devices!
•Turn power switch offbefore unplugging the cart.!
•Do not pull the cart. Always push cart using the
handles. Use extra caution on ramps and thresholds.!
•Do not plug the power cord into another extension
cord or re-locatable power tap.!
•Be sure to turn power switch offand unplug cart
before moving to a different location.!
•Ensure casters are locked before opening the cart
doors.!
•Be sure to lock up cart in a secure environment after
every use.!
•do not share the lock combination code with any
unauthorized persons.
USER GUIDE
CoreX Carts
TCOREX24
TCOREX36
TECHNICAL SPECIFICATIONS
CAPACITY per slot width! ! 1.25”!1.50”
TCOREX24 2 shelves! ! 24!20!devices
TCOREX36 3 shelves! ! 36!30!devices
COMPATIBILITY Designed for various sized laptops &
chromebooks, yet versatile enough to support most tablets.
Uses the device manufacturer supplied AC power cord and
adapter.
$OUTSIDE DIMENSIONS 29.50”W x 26.00”D x 44.75”H!
$SLOT DIMENSIONS$1.25” or 1.50” W x 17”D x!
$ $ 12.00”H for TCOREX24!
$ $ 10.00”H for TCOREX36!
$WEIGHT WITHOUT DEVICES!163 pounds for TCOREX24!
$ $ 175 pounds for TCOREX36!
$POWER MANAGER!Digital!
POWER REQUIREMENTS 100 -125V ac, 12A, 50/60Hz;
SHIPPING Ships fully assembled, ready to load devices
WARRANTY For product specific warranty information, please
visit: bretford.com/warranty
Part # 031-10608 rev March 2016
MADE IN USA
www.bretford.com

"WARNING": This Safe User Label is attached to the side of the cart, warning that
the cart may tip over if transported incorrectly, which could cause injury.
•Do not allow children under 16 to move cart. Only adults should move this cart.
•Move the cart slowly
•Apply moving force on the narrow dimension.
•Always push using the handles. Push the cart, do not pull it.
•Engage the directional lock casters when moving the cart for added stability & safety.
POWER SWITCH
Located on the left
side of the cabinet,
in the Power Cord
Shroud
GENERAL USE
POWER CORD SHROUD
Located on the left side
of the cabinet, provides
a cord winder for the
power cord, and an IEC
outlet for plugging in the
12-foot power cord
DIRECTIONAL LOCK CASTERS
When engaged, keep the
cart rolling in the right
direction. When
unengaged, allow the cart
to be easily maneuvered
into small spaces. Marked
with a Green Locking Tab
CORD PASS-THRU ON TOP
Allows devices to be
powered outside of the
cart, while their power
cords are plugged inside
the cart.
Front View
Rear View
REAR SECURITY PANEL
Securely held in place
with Security Bolts.
Panel easily lifts off to
expose the back of the
cart, where the
adapters and cord
sets are kept in cable
bins.
DOOR LOCK SHROUD
Protects the padlock
and the locking
handle during
transport
WARNING:
This cart is not intended
to hold items on the top
surface. Do not place
any item weighing more
than 1 pound on the top
surface of the cart to
avoid damage.
INTEGRATED HANDLE
Handle integrated into the
top of the cart for pushing
and moving the cart.
USER GUIDE | CoreX CARTS
SETTING THE COMBINATION LOCK
Your new EVER Cart comes equipped with a resettable Combination Padlock. You can program the
lock with your own combination. The lock starts with 0-0-0-0. Follow the directions with the look for
changing the combination. Remember to depress the shackle before un-engaging it from the lock.

Changing the Slot Width from 1.25” to 1.5”
USER GUIDE | CoreX CARTS
Device Storage & Cable Management
1. At the back of the cart, unscrew the two security screws using the Security Bit provided.
Lift the back panel off of the chassis. This exposes the power outlet modules for each
of the three shelves.
2. Starting in the rear of the cart with the back panel removed, insert a power adapter in
the storage bin for the associated device storage shelf (top, middle or bottom).
3. Measure the amount of cable necessary to reach from the power adapter located in the
bin to the front of the cart (over the AC outlet box, from the back to the front of the cart,
through the cable management hooks). Leave sufficient slack for the power connector
to plug into the device.
4. Plug the AC cord into one of the outlets nearest to where the power adapter is located
in the bin.
5. Repeat the above process for the total number of devices’ power adapters & cable sets.
6. In the front of the cart, insert a device into each of the slots, and plug in the power
connector to each device.
7. Place the cart near a wall outlet and plug the cart in.
8. Turn on the power switch - located in the front of the cord winder shroud
9. Once the cart is turned on, the power manager begins rotating power to the 3 power
strips very 5 minutes. This allows efficient charing of the devices in the cart from one
single 15 amp circuit.
1. Unscrew the Security Screws - one on
each side of the cart at the back. Lift off
the Back Panel.
1
TCOREX36
TCOREX24
Security Screws & Security Bit
1
rear view of the power outlet modules!
2-5. Plug adapters in & thread power
connectors to the front of the cart
front view of the dividers & slot ID numbers!
6. Hang the power connectors above the
slots using the slots hooks provided
1. Slot widths ship automatically at the 1.25” width. If your devices need
the larger 1.5” width, follow these simple directions.
2. Tabs located at the front of the plastic device platforms on each of the
shelves can be depressed, and the platform lifts out of the cart.
3. Flip the device platform over, and remove each of the plastic dividers by
“pinching” the divider tabs that stick thru the platform.
4. Reinsert the dividers into the square slots which create the 1.5” slot width.
(see the closeup at the left of the underside of the platform.)
5. Flip the device platform upright and reinsert into the shelf.
6. The slot number indicator can now be repositioned at “10”, replacing “12”
….. “20” replacing #24” and “30” replacing “36”
1.25”
1.50”
closeup underside of device platform
