Bretford CUBE Toploader User manual

031-11197 Rev. 1 10/2021 1 of 10
User Guide

031-11197 Rev. 1 10/2021 2 of 10
About Your Product
Product Overview - Front View
The CUBE ToploaderTM Cart with Caddies provides charging, security,
and distribution for up to 30 devices.
Swivel
Casters
Locking
Casters
Combo Padlock
Push Handles
Lower Access Panel -
Power Adapter
Storage Area

031-11197 Rev. 1 10/2021 3 of 10
About Your Product
Product Overview - Inside View
The CUBE ToploaderTM Cart with Caddies provides charging, security,
and distribution for up to 30 devices.
Cord Cover
Gas Structs
Caddies
CableBossTM
Cord
Management
Cord Winder

031-11197 Rev. 1 10/2021 4 of 10
About Your Product
Technical Specifications
CUBE ToploaderTM Cart 30 with Caddies
Model TVTL30CAD CUBE ToploaderTM Cart 30 with Caddies
TVTL30CADUSB CUBE ToploaderTM Cart 30 with Caddies Pre-Wired
Outer Dimensions
34
ʺ
x 23
ʺ
x 33
ʺ
/ 86.4cm x 58.4cm x 83.8 cm
Caddy Dimensions
External: 8.4
ʺ
x 10.0
ʺ
x 17.0
ʺ
/ 21.3cm x 25.5cm x 43.1 cm
Capacity
30 devices
Weight (empty)
TVTL30CAD 118lb / 53.5kg
TVTL30CADUSB 138lb / 62.6kg
Rating
125Vac, 60Hz, 12A
Charging Supports device power adapters up to 65W each, or 1,440W total
Warranty
For the latest information, please visit bretford.com/warranty.
Certifications
ETL Listed to UL 62368-1

031-11197 Rev. 1 10/2021 5 of 10
Using Your Product
CUBE ToploaderTM Cart
Setting the Combination Lock
Your new CUBE Cart comes equipped with a resettable Combination
Padlock. You can program the lock with your own combination. The lock
starts with 0-0-0-0. Follow the directions with the look for changing the
combination. Remember to depress the shackle before disengaging it
from the lock.
Wiring CUBE ToploaderTM Cart
Before you begin, ensure the unit is off and unplugged from the wall.
1. TVTL30CADUSB comes fully pre-wired with USB-C adapters. SKIP
to Step 10.
2. For TVTL30CAD, use the key from the hardware pack to unlock the
lower access panel.

031-11197 Rev. 1 10/2021 6 of 10
Using Your Product
CUBE Toploader
TM
Cart
3. Remove the lower access panel to expose the power outlet
modules.
4. Open the CUBE ToploaderTM cart lid, remove the three cord covers
by loosening the thumbscrews
5. Drop adapters through the center opening in each row - 10
adapters per opening. After every 5 adapters, access the lower
panel to plug into outlets.
6. Measuring the perfect length: With the device connector end,
measure the length from the divider on the left to reach to the
divider on the right. Then secure the cable into the CableBossTM
cable management feature in the divider on the left
7. Repeat above process for all 30 adapters.

031-11197 Rev. 1 10/2021 7 of 10
Using Your Product
CUBE Toploader
TM
Cart
8. In each row, pull the 10 cords toward the center of the divider and
reinstall the cord cover. Tighten the thumbscrew at the top. Push
extra length behind the cover and toward the bottom of the cart.
9. Replace the lower access panel and lock using the key.
10. Place up to 5 devices into each Bretford Caddy and load into the
CUBE ToploaderTM Cart. Recommended to place all charging ports
on same side and placed into the cart towards the edge.
11. Connect the main CUBE ToploaderTM Cart power cable into the wall.
12. Toggle the power switch on (“RESET").
Power Manager
When the cart is turned on, the timer begins rotating power to half of the
outlets every 10 minutes. This allows efficient charging of the devices in
the cart from one standard wall outlet

031-11197 Rev. 1 10/2021 8 of 10
Important Information
Safety Notice
•
Product for indoor use only
•Ensure the power switch is in the OFF position and CUBE ToploaderTM
Cart is disconnected from the wall outlet before plugging devices into e-
unit.
•Do not plug the unit in if the switch or power cord has been damaged.
•Unplug unit from the wall before moving to a different location.
•The socket-outlet shall be installed near the equipment and shall be easily
accessible.
•For safety purposes, make sure all electrical components do not exceed
the maximum load rating of 12 amps.
•Arranging caddies and devices in the cart should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
•Access panel on rear is for use by Bretford authorized service agent only

031-11197 Rev. 1 10/2021 9 of 10
Important Information
Safety Notice
The CUBE ToploaderTM Cart weight capacity:
175 lbs. in Device
Storage Area
45 lbs. in Lower
Compartment
Cart is not intended to hold items on
top surface. Do not place items on
top surface of cart to avoid damage

031-11197 Rev. 1 10/2021 10 of 10
Additional Resources
Contact Support
Technical support is available by contacting Bretford Customer Care via
phone, email or the web:
Hours of Operation: M-F, 7:30am - 4:30pm CST
Telephone: [phone]
Email: [email protected]om
Website: www.bretford.com/contact
