Bretford TCPUL23 User manual

TCPUL23 TCPUL23FF TCP23 TCP23FF
PAL MULTIMEDIA CART
1 of 3
PARTS LIST
Qty Part# Description
1 022-2882 Cart Handle
1 TCPE10 12 Outlet Power Strip (“FF” Models Only)
1 TCDPT Data Pass Through Plate (Optional Accessory)
HARDWARE LIST
AA BB
STEP 1: Pull out laptop shelf.
STEP 2: Attach handle with screws (AA) and nuts (BB).
Secure nuts
through interior
of cart.
INSTALL TOP SHELF HANDLE
Ref Qty Part# Description
AA 2 030-0307 5/16-18 x 5/8” Hex Hd Screws
BB 2 030-0411 5/16-18 Serrated Nuts
CC 4 030-0915 10-32MT x 3/8” Self Tapping Screws (“FF” Models Only)
DD 2 030-0024 #6-32 Hex Nuts
EE 2 030-0312 #6-32 x 1/4” Phillips Truss Head Screws

STEP 1: Install screws (CC) into bottom shelf.
STEP 3: Using the slot cutout on the back of the power strip, slide and snap power strip
onto installed screws toward the grommet hole on the side wall. NOTE: Your power
cord should be on the same side as the grommet hole as shown above.
INSTALL OPTIONAL TCPE10 12-OUTLET POWER STRIP
Included on “FF” Models
2 of 3
STEP 2: Remove the power strip from the steel plate by moving it sideways until it unsnaps.
INSTALL COVER PLATE OR OPTIONAL TCDPT DATA PASS THROUGH PLATE
STEP 2: Using the hardware provided with the Data Pass Through Plate, install the
TCDPT to the side panel.
STEP 1: Using the hardware provided install the cover plate under the handle.

Part # 031-8158
Rev. 06.10.14 CG 3 of 3
Bretford® Bretford Ltd.
11000 Seymour Avenue 2 Etongate
Franklin Park, IL 60131 110 Windsor Road, Slough
TEL: [phone] Berkshire SL1 2JA England
800.521.9614 TEL: [phone]
FAX: [phone] FAX: [phone]
800.343.1779
www.bretford.com
OPTIONAL LAPTOP TRAY SETTING
The laptop shelf may be inverted for use as a tray, this will provide additional room to store a laptop inside PAL for short
periods of time. Due to heat generated by the computer, it is not recommended that you leave your laptop on or charge
the battery in the tray for more than one hour when it is secured inside the cart.
STEP 1: With the laptop shelf fully extended release the tabs by pressing the left
tab down and the right tab up and ip the shelf over for the traysetting.
STEP 2: Realign the tray with the slides in the fully extended position, making sure that the tray slide ts
inside the extended slide. Slowly push the tray all the way back into the cart to re-lock the tabs.
Carefully extend the shelf once again. Install screw (EE) and nut (DD) into the hole near the front
of the shelf as shown. This will lock the shelf in place from the weight of the laptop.
