BROSA Kaneko Lamp Table with Drawer User manual

ASSEMBLY GUIDE
Kaneko Lamp Table with Drawer
v1.0

Components
Upon unpacking your table from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new table.
A x 4
(Cross Dowel)
B x 4
(Threaded Rod)
C x 4
(Flat Washer)
D x 4
(Lock Washer)
E x 4
(Hex Nut)
F x 1
(Spanner)
Hardware
What you need
Leg x 4Table top x 1

Step 1 Insert the cross dowel (A) into the top hole of the leg
so that the mark faces the bolt hole. Repeat for all
four legs.
Step 2 Screw the threaded rod (B) into the corner hole.
Repeat for all four legs.
A x 4
B x 4
A
B

Step 3 Place the table top on a at surface with underside
facing up. Fit a leg into a corner with the rod pro-
truding from the metal connector. Fit a at washer
(C), a lock washer (D) then a hex nut (E) to the
threaded rod and tighten with the spanner (F).
Repeat for the remaining legs.
Step 4 Gently ip the table and place on a level surface.
C x 4
D x 4
E x 4
F x 1
CD
EF

Step 5 Turn the knob inside the drawer to adjust it’s posi-
tion vertically so that there are equal gaps above and
below the front wall.
+2.5
-2.5

UNLOCK
Step 6 To take the drawer out, open it, pull the lock inside
the drawer. Gently lift the front part of of the drawer.

Step 7 To put the drawer back in, align the drawer with the
drawer runner rails. Fit the raised plates at the back
of the runners into the holes at the back of the
drawer. Place the drawer on the runners completely
and t the plates at the side of the runners to the
holes at the side of the drawer. Push the lock to
secure the drawer in place.
LOCK

Step 8 Enjoy your new table!
