BROSA Parc Coffee Table User manual

ASSEMBLY GUIDE
Parc Coee Table
v1.0

Components
Upon unpacking your coee table from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new coee table.
Table top x 1 Leg x 2
2
1
Hardware What you need
A x 6
Spec: 5/16 x 30mm
B x 6
Spec: Ø8 x Ø14mm
D x 4
Spec: Ø15 x 15mm
E x 1
Spec: Ø8 x 30mm
F x 1
Spec: 10g
G x 1
Spec: M5
C x 2
Spec: Ø7 x 86

Step 1
D x 4
E x 1
F x 1
C x 2
Place a small amount of glue (F) onto the dowel (E)
on one half and insert it into the middle hole of a leg
(2) as shown in the diagram. Insert a cam screw (C)
into each of the outer holes and apply some more glue
(F) on the other half of the dowel (E). Align the two
legs (2) to each other and rmly press together. Insert
cam locks (D) into each of the four holes as shown.
Step 2 Align the leg structure (2) formed in Step 1 to the
underside of the table (1) so that all of the screw
holes overlap. Fit a washer (B) to a bolt (A) and
screw into each hole and use the allen key (G) to
tighten all in place.
B x 6
G x 1
A x 6
D
CE
F
2
2
1
A
B
G
2

Step 3 Gently lift the table and place upright on a level
surface. e coee table is 100cm long by 60cm wide
and 35cm high and can take up to 60kg maximum
weight on top. Enjoy your new coee table!
35.0cm
60KG
MAX
100.0cm
60.0cm
