BullFrog OD1720 MIU User guide

ASSEMBLY AND INSTRUCTION MANUAL
www.bullfrog-design.com
08.11.2021
MODEL OD1720 MIU
© 2016 K URT BEI E R &KATI QU I N G E R
Braided back Practical throw cushion for
individual comfort
Filigree feet
For general informations please refer to the information about outdoor furniture!
Bullfrog recommends the suitable waterproofed protective covers for outdoor furnitures.

OD1720 MIU
© 2020 K URT BEI E R &KATI QU I N G E R
FUNKI - How ist works !!!
1. Take the cushion at its upper side and
put the cushion on your knees with the
zipper on the bottom. The seamless side
faces you.
2. Move the upper part of the cushion
towards yourself until the final position is
reached.
4. Now put the cushion in the preferred
position (e.g. in the back, seamless side
in front and zipper at the bottom). By pulling
the upper part of the chushion towards
yourself, you are now able to choose
among 16 raster positions, however you
like it.
3. Now you are able to move the upper
part backwards until the upper part of the
cushion will click into place in the zero
position.
seam
zipper

OD1720 MIU
© 2016 K URT BEI E R &KATI QU I N G E R
ATTENTION! To ensure secure assembly, please observe the individual steps of instruction!
The furniture should always be mounted in pairs (2 persons)!
Assembly:
Info:
1. Position the elements at the place supposed to stay.
2. To remove the transport lock (a) tilt the element backwards! If necessary, use a suitable underlay to
prevent damage to the cover.
a
c
c

OD1720 MIU
© 2016 K URT BEI E R &KATI QU I N G E R
3. Unscrew the 2 screws (c) from the transport lock (a). Remove the transport lock (a) from the element. The
screws (c) of the transport lock are not used for assembling the element.
5. Lift the fully assembled element onto its feet.
2 x
Screw
(b)
c
c
4. Then screw the 2 supplied screws (b) into the holes (d).
b
b
d
d
a

OD1720 MIU
© 2016 K URT BEI E R &KATI QU I N G E R
Mounting of connectors
1
2
1. Turn connector ratchet 1 of element A to the outside.
2. Firmly push together part A and B, until metal guides 2 catch into guides 1.
3. In case of dismounting lift part B with the metal guides 2 and pull away.
AB
