Solenoid coil AC19, device with II 2G Ex m approval
english
07 ATEX 2063 X

4
Operating instructions
WARNING!
Warns of a potentially dangerous situation!
• Failure to observe the warning may result in serious injuries or
death.
CAUTION!
Warns of a possible danger!
• Failure to observe the warning may result in moderately serious
or minor injuries.
NOTE!
Warns of damage to property!
designates additional significant information, tips and
recommendations.
refers to information in these operating instructions or in
other documentation.
→designates a procedure which you must carry out.
1. OPERATING INSTRUCTIONS
The operating instructions describe the entire life cycle of the device.
Keep these instructions in a location which is easily accessible to
every user and make these instructions available to every new owner
of the device.
WARNING!
The operating instructions contain important safety
information!
Failure to observe these instructions may result in hazardous
situations. The operating instructions must be read and
understood.
• Carefully read the operating instructions before using the device.
• In particular observe the chapter entitled "Intended use", and
"General safety instructions" as well as the chapter entitled
"Application conditions of the coil AC19".
1.1. Symbols
To identify important information, the following symbols are used in
the operating instructions:
DANGER!
Warns of an immediate danger!
• Failure to observe the warning may result in a fatal or serious
injury.
english
07 ATEX 2063 X

5
Intended Use
2. INTENDED USE
WARNING!
Incorrect use of the coil AC19 can be dangerous to people,
nearby equipment and the environment.
• The solenoid coil AC19 is used to actuate valves which control
gaseous or liquid media. It was designed for use in explosion
group II, category 2D, Ex mbD, IP64, T130°C and in explosion
group II, category 2G and temperature class T4 (see specifica-
tions on the - approval plate).
• The coil AC19 is always attached to the core feed pipe of the
valve fitting and secured with a nut. In this way coil and valve
body are connected in such a way that a closed system is for-
med which may also be used as a category 2 device to control
petrol in petrol pumps. For this application a valve body made of
metal (brass, aluminium or stainless steel) must be used.
When using the device, observe the permitted data, operating
conditions and application conditions which
– are specified in the operating instructions for the solenoid coil
AC19, on the rating plate, in the contract documents
– as well as in the operating instructions for the solenoid valve
actuated with the coil.
The coil may be used only in conjunction with third-party devices
and components recommended and authorised by Bürkert.
Correct transportation, correct storage and installation and careful
use and maintenance are essential for reliable and problem-free
operation.
• Any other use is considered improper use.Bürkert is not liable
for any resulting damage. The user alone bears the risk.
• Use the device only as intended.
2.1. Restrictions
If exporting the system/device, observe any existing restrictions.
2.1.1. Explosion protection approval
The explosion protection approval is only valid if you use the modules
and components authorised by Bürkert, as described in these ope-
rating instructions.
The coil AC19 may be used only in combination with the valve types
released by Bürkert, otherwise the explosion protection approval will
be terminated!
If you make unauthorised changes to the system, the modules or com-
ponents, the explosion protection approval will be terminated.
english
07 ATEX 2063 X

6
General Safety Instructions
3. GENERAL SAFETY INSTRUCTIONS
These safety instructions do not make allowance for any
• contingencies and events which may arise during the installation,
operation and maintenance of the devices.
• local safety regulations, whereby the operator is responsible for their
compliance, by the installation personnel too.
DANGER!
Danger of explosion!
Following installation, solenoid coil and valve body form a closed
system. If used in the EX area, there is a danger of explosion if the
system is opened during operation!
• The system must not be disassembled during operation.
Danger of explosion caused by electrostatic charge!
If there is a sudden discharge from electrostatically charged devices
or persons, there is a danger of explosion in the EX area.
• Take appropriate measures to prevent electrostatic charges in the
EX area.
• Clean the device surface of the solenoid valve by gently wiping
it with a damp cloth
DANGER!
Risk of electric shock!
There is a serious risk of injury when reaching into the equipment.
• Only trained electrical engineers may work on the electrical
system.
• Before starting work, always switch off the power supply and
safeguard to prevent re-activation!
• Observe applicable accident prevention and safety regulations
for electrical equipment!
Danger of burns/danger of fire during long-term operation!
The solenoid coil may become very hot during long-term operation.
• Take hold of a device which has been running for a prolonged
period with protective gloves only.
Danger – high pressure!
There is a serious risk of injury when reaching into the system.
• Only skilled and instructed personnel may work on the system
with suitable tools.
• Before disconnecting lines and valves, switch off the pressure
and bleed the lines.
• During installation note the direction of flow.
• Observe applicable accident prevention and safety regulations
for pressurised devices!
• After an interruption in the power supply or fluid supply, ensure
that the process is restarted in a defined or controlled manner!
english
07 ATEX 2063 X

7
General Information
WARNING!
General hazards!
• Do not use the valve fitting or the complete device as a lever to
screw the valve into the line system.
• Do not put any loads on the housing (e.g. by placing objects on
it or standing on it).
• Do not make any external modifications to the device housings.
Do not paint the housing parts or screws.
Unintentional activation or unauthorised impairment of the system
may cause general hazardous situations through to physical injury.
• Take appropriate measures to prevent the system from being
accidentally actuated!
• Do not make any unauthorised changes to the system.
Non-observance of the generally acknowledged safety rules may
cause general hazardous situations through to physical injury.
• Observe the generally acknowledged safety rules for resource
planning and operation of the coil AC19 and the associated
solenoid valve.
Operate the coil AC19 and the associated solenoid valve in
perfect working order only and in accordance with the operating
instructions.
4. GENERAL INFORMATION
4.1. Contact addresses
Germany
Bürkert Fluid Control Systems
Sales Center
Christian-Bürkert-Str. 13-17
D-74653 Ingelfingen
Tel. + 49 (0) 7940 - 10 91 111
Fax + 49 (0) 7940 - 10 91 448
E-mail: [email protected]
International
Contact addresses can be found on the final pages of the printed
operating instructions.
And also on the Internet at:
www.burkert.com
english
07 ATEX 2063 X

8
Application conditions
4.2. Warranty
The warranty is only valid if the device is used as intended in accordance
with the specified application conditions.
4.3. Approval
The EC Type Examination Certificate PTB 07 ATEX 2063 X was
issued by the
PTB (Physikalisch Technische Bundesanstalt)
Bundesallee 100
38116 Braunschweig (Germany)
which also audits production (CE0102).
4.4. Information on the Internet
The operating instructions and data sheets for Bürkert products can
be found on the Internet at:
www.burkert.com
5. APPLICATION CONDITIONS
5.1. Special conditions
5.1.1. Short-circuit protection
To protect each solenoid against short-circuit, a fuse (max. 3 x Ib in
accordance with IEC 60127-2-1), corresponding to the rated current,
or a motor protection switch with short-circuit and thermal quick release
(set to rated current) must be connected upstream.
• At very low rated currents of the solenoid the fuse with the lowest
current value is adequate according to the stated IEC standard.
This fuse may be housed in the associated supply unit or must be
connected separately upstream.
• The fuse rated voltage must be the same or higher than the indicated
nominal voltage of the solenoid.
• The interruption rating of the fuse link must be the same or higher than
the maximum short-circuit current to be accepted at the installation
site (usually 1500 A).
Example 2/2-way
solenoid valve:
Solenoid coil AC19
Valve body
The nominal value of
the fuse is indicated
on the solenoid
Fuse
F . , . . A
Fig. 1 : Example of coil AC19 as part of a closed system.
english
07 ATEX 2063 X

9
Application conditions
5.2. Operating Conditions
For operation of the solenoid coils Type AC19-..-.-PF09 and Type
AC19-..-.-PF10 observe the following requirements.
5.2.1. Materials
For the selection of materials for the system observe the application-
specific, safety requirements.
Valve body:
DANGER!
Danger of explosion!
If the system is used as a category 2 device, only valve bodies
made of metal can ensure the required safety for the control of
petrol in petrol pumps!
• Use only valve bodies made of metal (brass, aluminium or
stainless steel) for the control of petrol in petrol pumps with
category 2 devices.
• For use in petrol pumps
Metal (brass, aluminium, stainless steel)
• Other applications
Metal (brass, aluminium, stainless steel) or plastic (e.g. polyamide
PA 6 GV ...)
Sheathing of the electrical connection cables:
Type AC19-..-.-PF09 PVC
Type AC19-..-.-PF10 PUR
5.2.2. Minimum dimensions
Valve body:
55 mm x 36 mm x 30 mm (L x W x H)
A larger valve body with improved thermal conductivity may be
used at any time.
5.2.3. Application temperature range:
DANGER!
Danger of explosion!
If the max. permitted temperature values for the coil AC19 are
exceeded, there is a danger of explosion.
• Observe the temperature specifications for the coil
• Observe any restrictions by the max. permitted values for the
solenoid valve combined with the coil.
Temperature values of the solenoid coil AC19
Maximum surface temperatur of the coil at 60 °C ambient tempe-
rature and nominal voltage: 110 °C (for gas)
130 °C (for dust)
Temperature class (for gas) T4
Max. permitted ambient temperatures
Type Material of the electrical
connection cables
Max. permitted
ambient temperature
AC19-..-.-PF09 PVC -40 – +55 °C
AC19-..-.-PF10 PUR -40 – +60 °C
english
07 ATEX 2063 X

10
Application conditions
5.3. Installation conditions
The solenoid coils Type AC19-..-.-PF09 to Type AC19-..-.-PF10 are
suitable for single installation only.
The connection cables must be laid permanently to protect against
damage.
Also observe the specifications in the chapter entitled
"Technical Data".
5.4. Application in petrol pumps
DANGER!
Danger of explosion!
Following installation, solenoid coil and valve body form a closed
system. If used in the EX area, there is a danger of explosion if the
system is opened during operation!
• The system must not be disassembled during operation.
• The valve body may be repaired by the manufacturer only.
Solenoid valves together with the coil AC19 may be used as
category 2 devices only for the control of petrol if there is no air
and no oxygen in the closed system.
• Ensure that the closed system contains no air or oxygen or
cannot be penetrated by air or oxygen.
• When switching off or starting up the system, ensure that nei-
ther air nor oxygen has penetrated the system.
If the system is used as a category 2 device, only valve bodies
made of metal can ensure the required safety for the control of
petrol in petrol pumps!
• Use only valve bodies made of metal (brass, aluminium or
stainless steel) for the control of petrol in petrol pumps with
category 2 devices.
Example: 2/2-way solenoid valve
Solenoid coil AC19
Valve body
Fig. 2 : Example of coil AC19 as part of a closed system.
english
07 ATEX 2063 X

11
Technical Data
6. TECHNICAL DATA
DANGER!
Danger of explosion!
If the safety data and values specified on the rating plate are
not observed or maintained, hazardous situations may be the
consequence!
• Observe the degree of protection and temperature class when
using the device.
It is a safety risk to exceed the voltage indicated on the rating
plate, as this may cause the device to overheat!
• Do not connect the device to a higher voltage than indicated on
the rating plate.
Fuse
F. , . . A
II 2G Exmb II T4
II 2G Ex mbD21 IP64
Tmed130°C 24V AC/DC
12W AC19-U5-K-PF09
PTB 07 ATEX 2063 X
IEC Ex PTB08.0016X
Example
Fig. 3 : Example of rating plate for coil AC19 as part of a closed system.
Wording on the rating plate:
II 2G Exmb II T4
II 2D Ex mbD21 IP64
Tmed130°C 24V AC/DC
12W AC19-U5-K-PF09
PTB 07 ATEX 2063 X
IEC Ex PTB08.0016X
PTB approval no.
IEC explosion protection
approval no.
Device group
Device category
Ignition protection type
Gas group
Temperature class
Protection class:
- Power consumption
- Coil type
- Connection size for-
fluid component
- Coil size
- Code (specific to
company)
- Maximum surface
temperatur of the coil
(for dust)
- Voltage
- Current type
Serial no. of the coil
Ident. no.
Date of manufacture - factory/month/year
Monitoring centre
II 2G Exmb II T4
II 2D Ex mbD21 IP64
english
07 ATEX 2063 X

12
Installation
6.4.1. Electrical Data
Note the electrical data as specified on the rating plate.
7. INSTALLATION
7.1. Safety Instructions
DANGER!
Danger of explosion!
Following installation, solenoid coil and valve body form a closed
system. If used in the EX area, there is a danger of explosion if the
system is opened during operation!
• The system must not be disassembled during operation.
Danger of explosion caused by electrostatic charge!
If there is a sudden discharge from electrostatically charged devices
or persons, there is a danger of explosion in the EX area.
• Take appropriate measures to prevent electrostatic charges in the
EX area.
• Clean the device surface of the solenoid valve by gently wiping
it with a damp cloth
Risk of electric shock!
There is a serious risk of injury when reaching into the equipment.
• Only trained electrical engineers may work on the electrical
system.
• Before starting work, always switch off the power supply and
safeguard to prevent re-activation!
• Observe applicable accident prevention and safety regulations
for electrical equipment!
english
07 ATEX 2063 X

13
Installation
DANGER!
Risk of short-circuit!
Damaged connection cables may cause a short-circuit.
• The connection cables for the coil must be laid permanently and
protected against damage.
Danger of burns/danger of fire during long-term operation!
The solenoid coil may become very hot during long-term operation.
• Take hold of a device which has been running for a prolonged
period with protective gloves only.
WARNING!
Danger – high pressure!
There is a serious risk of injury when reaching into the system.
• Only skilled and instructed personnel may work on the system
with suitable tools.
• Before disconnecting lines and valves, switch off the pressure
and bleed the lines.
• Observe applicable accident prevention and safety regulations
for pressurised devices!
• After an interruption in the power supply or fluid supply, ensure
that the process is restarted in a defined or controlled manner!
7.2. Installation
The solenoid valve with integrated coil AC19 can be ins-
talled in any location. Preferably with top-mounted drive.
Prior to installation:
→Clean any dirt off the pipelines and flange connections.
Installation:
WARNING!
Risk of injury from leaking connections
Danger of explosion!
There is a danger of explosion in fuel pumps if oxygen or air pene-
trates the medium through leaking connections.
Risk of injury from escaping medium!
Medium which escapes through leaking connections may result in
injuries (e.g. burns or chemical burns).
• Carefully seal the connection lines.
→Seal pipeline connections with PTFE tape. The tape must not be
dropped into the pipelines.
→Screw in pipelines.
Important for function of the device!
Note the direction of flow.
→Check valve for leakage.
english
07 ATEX 2063 X

14
Start-Up
7.3. Electrical connection
DANGER!
Risk of electric shock!
There is a serious risk of injury when reaching into the equipment.
• Only trained electrical engineers may work on the electrical
system.
• Before starting work, always switch off the power supply and
safeguard to prevent re-activation!
• Observe applicable accident prevention and safety regulations
for electrical equipment!
→Connect the power
→Always connect protective conductor!
The connection cable is encapsulated with the coil AC19
and cannot be removed.
8. START-UP
8.1. Safety Instructions
WARNING!
Danger due to improper operation!
Improper operation may result in injuries as well as damage to the
device and the area around it.
• Before start-up, ensure that the operating personnel are familiar
with and completely understand the contents of the operating
instructions.
• In particular observe the safety instructions and intended use.
• The device/the equipment may be started by adequately trained
personnel only.
Before start-up, ensure that
→the device has been installed according to the instructions,
→the connection has been made properly,
→the device is not damaged.
english
07 ATEX 2063 X

15
Maintenance and Repairs
9. MAINTENANCE AND REPAIRS
9.1. Maintenance
The coil AC19 is maintenance-free provided the application conditions
described in the instructions are observed
9.2. Repairs
DANGER!
Danger - improper repairs!
Following repairs, the safety and function of the coil AC19 and the
corresponding solenoid valve cannot be guaranteed unless the
repairs were carried out by the manufacturer.
• Have the device repaired by the manufacturer only!
9.3. Troubleshooting
In the event of malfunctions, make sure that
→the device has been installed according to the instructions,
→the connection has been made properly,
→the device is not damaged,
→the voltage and pressure have been switched on,
→the pipelines are free.
10. TRANSPORT, STORAGE, DISPOSAL
NOTE!
Transport damages!
Inadequately protected equipment may be damaged during
transport.
• During transportation protect the device against wet and dirt in
shock-resistant packaging.
• Avoid exceeding or dropping below the allowable storage
temperature.
Incorrect storage may damage the device.
• Store the device in a dry and dust-free location!
• Storage temperature: -40 … +55 °C.
Damage to the environment caused by device components
contaminated with media.
• Ensure the device and packaging are disposed of in an environ-
mentally sound manner.
• Observe applicable regulations relating to refuse disposal and
the environment.
english
07 ATEX 2063 X

16
english
07 ATEX 2063 X

17
PTB 07 ATEX 2063 X
deutsch
Inhalt:
1. BEDIENUNGSANLEITUNG ......................................................................18
1.1. Darstellungsmittel ...........................................................................18
2. BESTIMMUNGSGEMÄSSE VERWENDUNG ...................................19
2.1. Beschränkungen ............................................................................19
3. ALLGEMEINE SICHERHEITSHINWEISE........................................... 20
4. ALLGEMEINE HINWEISE ..........................................................................21
4.1. Kontaktadressen .............................................................................21
4.2. Gewährleistung. ............................................................................22
4.3. Zulassungen ....................................................................................22
4.4. Informationen im Internet ..............................................................22
5. EINSATZBEDINGUNGEN ........................................................................22
5.1. Besondere Bedingungen .............................................................22
5.2. Betriebsbedingungen ....................................................................23
5.3. Montagebedingungen ...................................................................24
5.4. Einsatz in Tanksäulen.....................................................................24
6. TECHNISCHE DATEN ................................................................................ 25
7. MONTAGE .......................................................................................................26
7.1. Sicherheitshinweise .......................................................................26
7.2. Montage ...........................................................................................27
7.3. Elektrischer Anschluss ..................................................................28
8. INBETRIEBNAHME ......................................................................................28
8.1. Sicherheitshinweise .......................................................................28
9. WARTUNG UND REPARATUR................................................................29
9.1. Wartung ............................................................................................29
9.2. Reparatur..........................................................................................29
9.3. Fehlerbehebung ..............................................................................29
10. TRANSPORT, LAGERUNG, ENTSORGUNG .................................29
Magnetspule AC19, Gerät mit II 2G Ex m Zulassung

18
PTB 07 ATEX 2063 X
deutsch
Bedienungsanleitung
WARNUNG!
Warnt vor einer möglicherweise gefährlichen Situation!
• Bei Nichtbeachtung drohen schwere Verletzungen oder Tod.
VORSICHT!
Warnt vor einer möglichen Gefährdung!
• Nichtbeachtung kann mittelschwere oder leichte Verletzungen
zur Folge haben.
HINWEIS!
Warnt vor Sachschäden!
bezeichnet wichtige Zusatzinformationen, Tipps und
Empfehlungen.
verweist auf Informationen in dieser Bedienungsanleitung
oder in anderen Dokumentationen.
→markiert einen Arbeitsschritt, den sie ausführen müssen.
1. BEDIENUNGSANLEITUNG
Die Bedienungsanleitung beschreibt den gesamten Lebenszyklus
des Gerätes. Bewahren Sie diese Anleitung so auf, dass sie für jeden
Benutzer gut zugänglich ist und jedem neuen Eigentümer des Gerätes
wieder zur Verfügung steht.
WARNUNG!
Die Bedienungsanleitung enthält wichtige Informationen zur
Sicherheit!
Das Nichtbeachten dieser Hinweise kann zu gefährlichen Situ-
ationen führen. Die Anleitung muss gelesen und verstanden
werden.
• Lesen Sie die Bedienungsanleitung vor dem Einsatz des Gerätes
sorgfältig durch.
• Beachten Sie vor allem die Kapitel „Bestimmungsgemäße
Verwendung“, und „Allgemeine Sicherheitshinweise“ sowie das
Kapitel „Einsatzbedingungen der Spule AC19“.
1.1. Darstellungsmittel
Für die Kennzeichnung wichtiger Informationen werden in der
Anleitung folgende Darstellungsmittel verwendet:
GEFAHR!
Warnt vor einer unmittelbaren Gefahr!
• Bei Nichtbeachtung sind Tod oder schwere Verletzungen die
Folge.

19
PTB 07 ATEX 2063 X
deutsch
Bestimmungsgemässe Verwendung
2. BESTIMMUNGSGEMÄSSE
VERWENDUNG
WARNUNG!
Bei nicht bestimmungsgemäßem Einsatz der Spule AC19
können Gefahren für Personen, Anlagen in der Umgebung
und die Umwelt entstehen.
• Die Magnetspule AC19 dient zum Betätigen von Ventilen welche
gasförmige oder flüssige Medien steuern.
Sie wurde für den Einsatz in in Explosionsgruppe II, Kategorie D,
EX mbD, IP64, T130° und Explosionsgruppe II, Kategorie 2G
und Temperaturklasse T4 konzipiert (siehe Angaben auf dem
- Zulassungsschild).
• Die Spule AC19 wird immer auf das Kernführungsrohr der Ven-
tilarmatur montiert und mittels einer Mutter befestigt. Auf diese
Weise werden Spule und Ventilkörper so verbunden, dass
ein geschlossenes System entsteht, das auch in Tanksäulen
zur Steuerung von Benzin als Kategorie -2- Gerät eingesetzt
werden darf. Für diesen Einsatzzweck muss ein Ventilkörper aus
Metall (Messing, Aluminium oder Edelstahl) verwendet werden.
Für den Einsatz sind die zulässigen Daten, Betriebs- und Einsatz-
bedingungen zu beachten, die
– in der Bedienungsanleitung für die Magnetspule AC19, auf dem
Typschild, in den Vertragsdokumenten
– sowie in der Bedienungsanleitung für das mit der Spule
betätigte Magnetventil
spezifiziert sind.
Eine andere oder darüber hinausgehende Benutzung gilt als nicht
bestimmungsgemäß.
Für hieraus resultierende Schäden haftet Bürkert nicht.
Das Risiko trägt allein der Anwender.
• Setzen Sie das Gerät nur bestimmungsgemäß ein.
Die Spule darf nur in Verbindung mit von Bürkert empfohlenen
bzw. zugelassenen Fremdgeräten und -komponenten eingesetzt
werden.
Voraussetzungen für den sicheren und einwandfreien Betrieb sind
sachgemäßer Transport, sachgemäße Lagerung und Installation
sowie sorgfältige Bedienung und Instandhaltung.
2.1. Beschränkungen
Beachten Sie bei der Ausfuhr des Systems/Gerätes gegebenenfalls
bestehende Beschränkungen.
2.1.1. Ex-Zulassung
Die EX-Zulassung ist nur gültig, wenn Sie die von Bürkert zugelassenen
Module und Komponenten so verwenden, wie es in dieser Bedienungs-
anleitung beschrieben ist.
Die Spule AC19 dürfen Sie nur in Kombination mit den von Bürkert frei-
gegebenen Ventiltypen einsetzen, andernfalls erlischt die Ex-Zulassung!
Nehmen Sie unzulässige Veränderungen am System, den Modulen
oder Komponenten vor, erlischt die Ex-Zulassung ebenfalls.

20
PTB 07 ATEX 2063 X
deutsch
Allgemeine Sicherheitshinweise
3. ALLGEMEINE
SICHERHEITSHINWEISE
Diese Sicherheitshinweise berücksichtigen keine
• Zufälligkeiten und Ereignisse, die bei Montage, Betrieb und Wartung
der Geräte auftreten können.
• ortsbezogenen Sicherheitsbestimmungen, für deren Einhaltung, auch
in Bezug auf das Montagepersonal, der Betreiber verantwortlich ist.
GEFAHR!
Explosionsgefahr!
Magnetspule und Ventilkörper bilden nach der Montage ein
geschlossenes System. Bei Einsatz im EX-Bereich besteht bei
der Öffnung des Systems im Betriebszustand Explosionsgefahr!
• Das System darf nicht während des Betriebs demontiert werden.
Explosionsgefahr durch elektrostatische Aufladung!
Bei plötzlicher Entladung elektrostatisch aufgeladener Geräte oder
Personen besteht im EX-Bereich Explosionsgefahr.
• Stellen Sie durch geeignete Maßnahmen sicher, dass es im EX-
Bereich zu keinen elektrostatischen Aufladungen kommen kann.
• Reinigen Sie die Geräteoberfläche des Magnetventils nur durch
leichtes Abwischen mit einem feuchten Tuch.
GEFAHR!
Gefahr durch elektrische Spannung!
Bei Eingriffen in die Anlage besteht akute Verletzungsgefahr.
• Arbeiten am elektrischen System dürfen nur von ausgebildenten
Elektrofachkräften durchgeführt werden.
• Schalten Sie vor Beginn der Arbeiten in jedem Fall die Span-
nung ab und sichern Sie diese vor Wiedereinschalten!
• Beachten Sie die geltenden Unfallverhütungs- und Sicherheits-
bestimmungen für elektrische Geräte!
Verbrennungsgefahr/Brandgefahr bei Dauerbetrieb!
Die Magnetspule kann im Dauerbetrieb sehr heiß werden.
• Fassen Sie ein Gerät das bereits länger in Betrieb ist nur mit
Schutzhandschuhen an.
Gefahr durch hohen Druck!
Bei Eingriffen in das System besteht akute Verletzungsgefahr.
• Arbeiten am System dürfen nur durch fachkundiges und unter-
wiesenes Personal mit geeignetem Werkzeug durchgeführt
werden.
• Schalten Sie vor dem Lösen von Leitungen und Ventilen den
Druck ab und entlüften Sie die Leitungen.
• Beachten Sie beim Einbau die Durchflussrichtung.
• Halten Sie die geltenden Unfallverhütungs- und Sicherheitsbe-
stimmungen für druckbeaufschlagte Geräte ein.
• Gewährleisten Sie nach einer Unterbrechung der elektrischen
oder fluidischen Versorgung einen definierten oder kontrollierten
Wiederanlauf des Prozesses!
