C.A. Technologies Lynx 300C Troubleshooting guide

CONVENTIONAL AIR CAP AND FLUID NOZZLE CHART
MODEL
NO. AIR CAPS
PRESS.
OR
SIPHON
*RECOM. GUN
INLET PRESS.
FAN
CONTROL
SCFM @
MAX GUN
INLET
AI R CAP
RING
STANDARD
IN CAT
PACK
AVAILABLE FLUID
NOZZLES TIPS
NEEDLES /
marking on needle
press/siph Included 33-0608 0.8mm (.022") 40-1308C (308)
press/siph 33-0610 1.0mm (.040") 40-1310C (310)
23-2013* press/siph Included 33-0613 1.3mm (.052") 40-1313C (313)
23-2014* press/siph 33-0614 1.4mm (.055") 40-1314C (314)
23-2016* press/siph Included 33-0616 1.6mm (.063") 40-1315C (315)
Actual fluid nozzle and air cap combinations are determined by application (see application chart page 4)
*Gun inlet pressures may vary as required by application
9-10.7 23-0201
LYNX 300C
(L300C)
23-2010*
45-55 60-1500
PRESSURE/SIPHON FEED SPRAYGUN
PRODUCT INFORMATION
Lynx 300C
DISTRIBUTED BY COATING EQUIPMENT TECHNOLOGY, INC
PHONE: [phone]
WEB: www.cetinc.com

Operation and Maintenance Instructions for L300C Spray Guns
Operation
1. Connect air supply hose at handle of gun.
2. Connect a pressurized fluid supply or paint siphon cup to the gun fluid inlet.
3.Fluidflowcan becontrolledusingthefluid controlknob,thisrestricts flowbylimitingneedle travel.Itisbest tocontrol
fluid flow byproper selection of fluid orifice size and use the fluid control knob to “fine tune flow rate”.
4. Fan width can be adjusted using the fan control knob. Turning the knob clockwise narrows the fan.
Maintenance
IMPORTANT! Routine cleaning and maintenance is essential toinsure propergun operation.
Severalstatesprohibitsprayingsolventinto theatmosphere andrequire theuse ofcovered guncleaner.
1. If a gun cleaner is being used, connect and clean the gun in the gun cleaner according to the manufactures
instructions.
2. If a gun cleaner is not being used:
Removeair cap andclean separatelyusing cleansolvent.
For pressure setups, connect a pressurized solvent supply to the fluid inlet, trigger the gun allowing solvent to flow
thru the gun until clean.
For siphon setups, first clean the siphon cup thoroughly then spray clean solvent thru the gun until clean.
NOTE: Gun head disassembly is not recommended for normal cleaning and maintenance.
Gun head disassembly and reassembly instructions:
Haverepairkit # 10-106availablebeforegundisassembly.
Gun head disassembly
Toremovethe nozzlecarrier (5) andaircap adapter (7):
1. Remove the air cap (2), fluid nozzle tip (3), fluid nozzle body(4), and needle (14).
2.Remove theneedleseal cartridge(24).
3. Loosenthe locknut (10) and remove fluid inlet(11) using a 5/8” open-endwrench.
4. The nozzle carrier (5) and air cap adapter (7) will now slide forward from the gun body (12).
Gun head reassembly
1. Install a new o-ring (8) on the air cap adapter (7).
2. Install the thread locknut (10) onto the fluid inlet (11) as far as possible.
3. Install a new fluid inlet seal (9) into the recess area on the nozzle carrier (5) inlet port.
4. Slide the nozzle carrier (5) into air cap adapter (7) and insert into the gun body (12) as far as possible. Be sure the
nozzle carrier (5) extends into the hole at the back of the gun head. Install the needle seal (24) but do not tighten.
5. Rotate the nozzle carrier (5) until the fluid inlet port in the nozzle carrier (5) is aligned with the threaded hole in the
body. While in this position, insert the fluid inlet (11) and tighten firmly.
6. Tighten the needle seal (24) to approx. 12 ft.-lb. torque.
7. Tighten the fluid inlet (11) to approx. 25 ft.-lb. torque.
8. Tighten the locknut (10) to approx. 33 ft.-lb. torque.

ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION
1See Air Cap Chart Air Cap Retaining Ring** 16 60-205 Spring Seat*
2See Air Cap Chart Air Cap** 17 60-204 Needle Return Spring*
3See Air Cap Chart Fluid Nozzle Tip** 18 60-201 Rear Bushing
4 33-2201 Fluid Nozzle Body 19 60-119 Seal*
560-L31C Nozzle Carrier 20 60-1520 Air Valve Assembly
698-8024 Gasket* 21 60-302 Air Valve Poppet
760-32C Air Cap Adapter 22 60-125 O-Ring*
8 60-131 O-Ring* 23 61-1003 Air Valve Spring*
9 60-124 Fluid Inlet Seal* 24 60-1400 Needle Seal Cartridge*
10 60-128 Locknut 25 60-2101 Trigger
11 60-126 Fluid Inlet Fitting 26 60-1510 Air Control
12 60-1124 Lynx Gun Body Conventional 26A 60-122 Plug (optional)
13 See Air Cap Chart Fan Control Assembly** 27 60-104 Air Inlet Fitting
14 See Air Cap Chart Fluid Needle** 28 60-1033 Trigger Pivot Set
15 60-202 Fluid Control Knob 29 98-0109 Allen Plug
**See air cap selection chart on page 1
*Indicates part included in repair kit # 10-106
*
*
*
*
*
***
*

L300C CONVENTIONAL SPRAY GUN
MATERIAL TYPE FLUID ORIFICE x
AIR CAP MAXIMUM PATTERN WIDTH PRESS. / SIPHON
Very Thin
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
FLUID NOZZLE / AIR CAP SELECTION CHARTS
LYNX Series 300C - Pressure / Siphon Feed Guns
0.8 mm x 2010
1.0 mm x 2010 12 12 P/S P/S
1.4 mm x 2014
1.6 mm x 2016 12 12 P/S P/S
0.8 mm x 2010
1.0 mm x 2010
1.3 mm x 2013
12
12
12
P/S
P/S
P/S
1.3 mm x 2013
1.4 mm x 2014
1.6 mm x 2016
12
12
12
P/S
P/S
P/S
L300C CONVENTIONAL SPRAY GUN
MATERIAL TYPE FLUID ORIFICE x
AIR CAP MAXIMUM PATTERN WIDTH PRESS. / SIPHON
Very Thin
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
FLUID NOZZLE / AIR CAP SELECTION CHARTS
LYNX Series 300C - Pressure / Siphon Feed Guns
0.8 mm x 2010
1.0 mm x 2010 12 12 P/S P/S
1.4 mm x 2014
1.6 mm x 2016 12 12 P/S P/S
0.8 mm x 2010
1.0 mm x 2010
1.3 mm x 2013
12
12
12
P/S
P/S
P/S
1.3 mm x 2013
1.4 mm x 2014
1.6 mm x 2016
12
12
12
P/S
P/S
P/S
Revised12/29/15
CP-L300C-303R2 CP-L300C-PPSR2
CP-L300C
CP-L300C Smart Pack Includes:
98-0104 3/8” Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
CP-L300C-303R2 Includes:
51-303 1 QT Aluminum Pressure Cup
52-5R2 Pressure Cup Regulator
98-0104 3/8” Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
CP-L300C-PPSR2 Includes:
91-460 950 mL 3M™ PPS™ Pressure Cup
91-462 Lids and Liners (Available in 25 Pack)
91-475 #18 PPS Adapter
52-5R2 Pressure Cup Regulator
98-0104 3/8” Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
