ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION Kit
1TJR Body Assembly 5 51-406 AluminumCup
260-TJR-30-XX Needle / Nozzle Set* 6 51-407 Plastic Cup
360-TJR-20 Air Cap 7 91-470 Cup and Collar
460-TJR-10-W Wrench & Brush Kit 8 91-471-50 Lids and Liners (50 Pack)
Repair Kit 60-TJR-10 Soft Seal Repair Kit 9 91-473 TJRPPS Adapter
TJR
TJR PPS
*See Needle & Nozzle Sets Chart
1
2
3
4
7 8 9
TJR
5 6
Available CAT Packs
- TJR
- TJR PPS
Coating Atomization Technologies 337 South Arthur Avenue, Louisville CO 80027 Phone: 888.820.4498, Fax: 303.438.5708
www.spraycat.com
Techline JR
GRAVITY FEED SPRAY GUN
PRODUCT INFORMATION
NEEDLES
PART NO. DESCRIPTION
60-TJR-30-08L 0.8 mmNeedle
60-TJR-30-12L 1.0 mm& 1.2 mmNeedle
60-TJR-30-14L 1.4 mmNeedle
NEEDLE & NOZZLE SETS
PART NO. DESCRIPTION
60-TJR-30-08 0.8 mmNeedle / Nozzle Set
60-TJR-30-10 1.0 mmNeedle / Nozzle Set**
60-TJR-30-12 1.2 mmNeedle / Nozzle Set**
60-TJR-30-14 1.4 mmNeedle / Nozzle Set**
* 1012 needle is used for both the 1.0 and 1.2 nozzle
** Included in standard TJR Kit
ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION Kit
1TJR Body Assembly 7 51-406 AluminumCup
260-TJR-30-12 Needle / Nozzle Set* 8 51-407 Plastic Cup
360-TJR-20 Air Cap 9 91-470 Cup and Collar
4 60-TJR-21 Round Pattern Kit 10 91-471-50 Lids and Liners (50 Pack)
560-TJR-10-W Wrench & Brush Kit 11 91-473 TJRPPS Adapter
660-TJR-30-10-G Glaze Nozzle 1.0 Repair Kit 60-TJR-10
TJR
Glaze
TJR
Glaze PPS
Soft Seal Repair Kit
ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION Kit
1TJR Body Assembly 6 51-406 AluminumCup
260-TJR-30-XX Needle / Nozzle Set* 7 51-407 Plastic Cup
360-TJR-20 Air Cap 8 91-470 Cup and Collar
4 60-TJR-21 Round Pattern Kit 9 91-471-50 Lids and Liners (50 Pack)
560-TJR-10-W Wrench & Brush Kit 10 91-473 TJRPPS Adapter
TJR
Deluxe
TJR
Deluxe
PPS
*See Needle & Nozzle Sets Chart (Soft Seal Repair Kit: 60-TJR-10)
1
23
5
TJR Deluxe
4
*No air needed when using Glaze Nozzle
*Uses1.2needlesuppliedin kit
*Inspired by Wayne Smith
6
89106 7
Available CAT Packs
- TJR Deluxe
- TJR Deluxe PPS
Available CAT Packs
- TJR Glaze
- TJR Glaze PPS
TJR Glaze
23
5 4
9117 8 10
Coating Atomization Technologies 337 South Arthur Avenue, Louisville CO 80027 Phone: 888.820.4498, Fax: 303.438.5708
www.spraycat.com
Techline JR Kits
GRAVITY FEED SPRAY GUN
PRODUCT INFORMATION
NEEDLE & NOZZLE SETS
PART NO. DESCRIPTION
60-TJR-30-10 1.0 mmNeedle / Nozzle Set
60-TJR-30-12 1.2 mmNeedle / Nozzle Set
* 1012 needle is used for both the 1.0 and 1.2 nozzle
NEEDLES
PART NO. DESCRIPTION
60-TJR-30-12L 1.0 mm& 1.2 mmNeedle
60-TJR-40-05 Round Pattern Kit Needle
NEEDLES
PART NO. DESCRIPTION
60-TJR-30-12L 1.2 mm& Glaze Needle
60-TJR-40-05 Round Pattern Kit Needle 1
ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION
1See Page 1 & 2 Air Cap 7 60-TJR-15 Fluid Control Knob / Lock
2See Page 1 & 2 Nozzle 8 60-TJR-14 Air Valve
360-TJR-11 Atomizing Black Spacer 9 60-TJR-12 Fan Control Knob
4See Page 1 & 2 TJR Gravity Cup 10 60-TJR-18 Air Inlet Fitting
560-TJR-16 Fluid Inlet 11 60-TJR-13 Air Control Knob
6See Page 1 & 2 Needle * 60-TJR-10 Repair Kit
*Indicates partincludedinrepairkit 60-TJR-10
Item 3 (Atomizing Spacer)
Front
Facetowards
Air Cap and
Nozzle
Back
Facetowards
the TJR gun
body
Coating Atomization Technologies 337 South Arthur Avenue, Louisville CO 80027 Phone: 888.820.4498, Fax: 303.438.5708
www.spraycat.com
Revised4/28/15
Operating and Maintenance Instructions for the CAT TJR Spray Gun
Setting Up The TJR Spray Gun
The TJR operates best with10PSIat the gun (operating pressure)
The TJRuses 3.5cfm.
The Tjr is supplied with an air inlet fitting which is ¼” NPT male. You will need to hook up a suitable length of 5/16”
air hose fitted with a ¼” NPS(F) connection.
Connect the gravity feed cup to the gun by screwing the cup onto the spray gun fluid inlet.
Adjusting Your Spray Gun
There are twomeans of adjusting airat thegun.The pattern adjusting
valve andthe air adjusting valve.
PatternAdjusting Valve
The pattern-adjustingvalveregulates airtothe“horns” of the gun air cap.
Horn air controls the shape of the spraypattern.
1. When the pattern adjusting valve is closed (turned completely
clockwise) - a round pattern results.
2.Openingthe pattern adjustingvalve(turn counter clockwise)
producesan increasinglywiderand flatterfan pattern.
3. When the maximum spray pattern (widest fan) is achieved,
additional turns will not affect the pattern.
Air Adjusting Valve
The air adjusting valve controls only the flow of air (CFM) to the air cap and has no effect on air pressure (PSI). The
valve is often referred to as the “cheater” valve as it is used to restrict air without adjusting the air regulator.
1. Closing theair-adjusting valve (turncounterclockwise) restricts theair flow.
2. Openingthe valve(clockwise) increases the volume (flow)ofair. This willaffect
the degree of atomization, but will not change the spraypattern.
3.The aircap (CFM) specification willdetermine the(CFM) requirements of thegun.
Using 60-TJR-30-10-G (Glaze Nozzle)
When using the new glaze nozzle the first thing you will notice is that there is no air cap, so you will need no air to
operate this gun with the glaze setup.
1. Once you have placed the glazing needle and nozzle tightly on the gun, choose the
cup you want to use and tighten everything down.
2. Fill the gravity cup with glaze and tighten the lid.
3. Gently press the nozzle tip against the surface you are glazing and pull the trigger.
4. When you come to the point where you no longer want to place the glaze, stop
pulling the trigger and the glaze will stop running from the tip.
5. You can also control the size of your glazing strip by turning the fluid control knob.
6. To clean simply pour out unused glaze and flush with solvent.
To Open
Air Cap Fluid Adjusting Valve
Pattern Adjusting Valve
Air Adjusting Valve Air Inlet
Fluid Inlet
60-TJR-30-10-G wasinspired by
Wayne Smith
Pattern Adjustment Diagram
1 32
Ø Ø
