Car Solutions MB2019-NTG6.0-TC2 User manual

Instruction Manual
MB2019-NTG6.0-TC2 with PAS for Mercedes Benz
[email protected]
car-solutions.com
car-solutions.com

INDEX
Specifications
1. Main Spec. ----------------------------------
2. Diagram -------------------------------------
3. Components --------------------------------
4. Exterior --------------------------------------
Settings
1. Dip Switch ----------------------------------
2. Touch Control -----------------------------
3. Original button ----------------------------
4. OSD Menu ---------------------------------
Installation
1. Diagram ------------------------------------
2. Classification of LVDS/Power---------------
3. Cautions-------------------------------------
2
3
4
5
6
7
8
9
11
16
17
19
[email protected]
car-solutions.com
car-solutions.com

Specification
1. Main spec.
1. Input Spec. (MULTI VIDEO INTERFACE)
- 1 x Digital RGB Input (Navigation System output)
- 2 x A/V Input (External video source).
- 1 x CVBS(REAR CAMERA) Input. (Rear camera source)
- 1 x CVBS(FRONT CAMERA) Input. (Front camera source)
- 1 x Analog RGB Input (Navigation System output)
- 1 x LVDS Input. (Car Command System)
- 1 x Capacitive Touch Screen
2. Output Spec.
- 1 x LCD Output (LCD Operation)
- 1 x Resistive Touch
3. Power Spec.
- Input Power : 8VDC ~ 24VDC
- Consumption Power : 12Watt, Max
4. Switch Input mode
- By OEM button
1-1. Features
- Easy installation with Plug&Play power/LVDS cable
- Display dynamic PAS(Parking assistance system) with PDC
3
[email protected]
car-solutions.com
car-solutions.com

Specification
2. Diagram
Scaler
(PIP)
MCU EEPROM
CAN
RECEIVER
LVDS
TX RELAY
REAR CAMERA
POWER
LVDS
TX
CAR
COMMAND
SYSTEM
CAN
NAVI System
REAR CAMERA
CAR
TFT-LCD
LVDS
RX
4
FRONT CAMERA
LVDS
[email protected]
car-solutions.com
car-solutions.com

Specification
3. Components
Power Cable 1 EA LVDS Cable 1 EA
RGB Navi Cable 1 EA
5
[SPRINTER 8” / 12.3” / A-class 8”]
OSD Board 1 EA
[email protected]
car-solutions.com
car-solutions.com

Specification
4. Exterior
*NAVI Connect
①R DATA (Red)
②G DATA (Green)
③B DATA (Blue)
④SYNC (White)
⑤GND (Black)
⑥DMB IR (TX)(Green)
⑦DVD IR (RX) (Orange)
① ② ③ ④ ⑤ ⑥ ⑦
138mm
24mm
83mm
6
*POWER Connect
①ACC(Yellow)
②REAR_POWER (Red)
③CAN-HIGH (Orange)
④CAN-LOW (Green)
⑤CAN-HIGH (Purple)
⑥CAN-LOW (White)
⑦REAR_DETECT (Brown)
⑧GND (Black)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧
*Touch Connect
①Y-
②X-
③Y+
④X+
① ② ③ ④
[email protected] car-solutions.com
car-solutions.com

Settings
1. Dip Switch
* ON : DOWN , OFF : UP
NO. Function Selection
1 NAVI ON : Skipping NAVI
OFF : Display
2 DVB-T ON : Skipping Video
OFF : Display
3 DVD ON : Skipping Video
OFF : Display
4,5 N.C
6
Car model
ON : A-Class, Sprinter 8”
OFF : A-Class, Sprinter 12.3”
7 ON : A-Class 12.3”
OFF : A-Class8”, Sprinter8” 12.3”
8 ON : A-Class 8”
OFF : A-Class12.3”
Srpinter8”,12.3”
Aclass 8” Model
A class 12.3” Model
Sprinter 8” Model
Sprinter 12.3” Model
* Example
7
[email protected]
car-solutions.com
car-solutions.com

Settings
2. Touch Control
8
- Touch calibration
Touch OEM screen in any mode more than
7sec. For calibration
(This function can be activated only one time
after switching mode)
Touch the “+” correctly
- DVB-T/DVD Control
Press Touch (Anywhere) Press Icon
DVB-T
DVD
[email protected]
car-solutions.com
car-solutions.com

Settings
3. Original button
9
- Switching mode
/ NAVI : 1. Long Press: Switching mode
2. Short Press: Switching to OEM directly
<Command> <Steering wheel>
<Steering wheel> <Command>
[email protected]
car-solutions.com
car-solutions.com

10
Settings
Config - NAVI-RGB : Setup for the type of NAVI
Config - DVB-T : Setup for the type of TV tuner
Config - DVB-T : Setup for the type of DVD
Reset : Reset all value
5. OSD Menu
※Control the menu below by Original button
4. OSD Key board
①MENU : Activating OSD Menu
②SEL : Selection
③Up : Moving upward / increasing
value
④Down : Moving downward /
decreasing value
MENU SEL UP DOWN
①②③④
CASTIT
Default
NAVI-RGB
DVB-T(DMB)
DVD
RESET
[email protected]
car-solutions.com
car-solutions.com

11
Option
•RearCam- Type : Setup for rear camera
ExtDevice : External rear camera
OEM : Original camera
•RearCam- Power : Setup for Rear VCC wire in power cable
ON : +12V out always (current consumption : 200mA)
AUTO : +12V out in rear mode only (200mA)
OFF : Power OFF
•RearCam- Det : N.C
•FrontCam- Type : Setup for front camera
ExtDevice : External rear camera
OEM : Original camera
•FrontCam- Power : Setup for Front VCC wire in power cable
ON - +12V out always (current consumption : 200mA)
AUTO - +12V out in rear mode only (200mA)
OFF - Power OFF
•FrontCam-Det : Setup for detection of front cam
CAN : by CAN
Wire : by Front-Det wire
Settings
5. OSD Menu
※ Control the menu below by Original button
[email protected]
car-solutions.com
car-solutions.com

12
Option
•RearCam-RcvOpt : Selecting time of displaying Front camera before
switching to RGB, DVD, OEM from Rear
•SteeringwheelBtn : Setup for OEM button on steering wheel
ON : Activated
OFF
•Reset –Excute : Option Menu all Reset
OEM
NAVI
AV1(DVB-T)
AV2(DVD)
REAR FRONT
OEM
NAVI
AV1(DVB-T)
AV2(DVD)
1~30 second
Settings
Select time of display
5. OSD Menu
※ Control the menu below by Original button
SteeringwheelBtn
NAVI COM
Reset
[email protected]
car-solutions.com
car-solutions.com

13
MENU IMAGE NAVI
Config
Option
Screen
Parking
Brightness
Contrast
Color- RED
Color- GREEN
Color- BLUE
50
50
50
50
25
MENU Screen NAVI
Config
Option
Screen
Parking
Horizontal
Vertical
Scale X Up
Scale X Down
Scale X Up
50
50
50
50
50
MENU IMAGE Rear
Config
Option
Screen
Parking
Brightness
Contrast
Saturation
Hue
Sharpness
50
50
50
50
25
- NAVI(RGB) Image / Screen
- DVD, DVBT, NAVI-AV, REAR, FRONT Image
5. OSD Menu
※ Control the menu below by Original button
Settings
[email protected]
car-solutions.com
car-solutions.com

14
- Language
Settings
5. OSD Menu - Parking mode
※ Control the menu below by Original button
Selecting a type of language
(OSD Menu –Parking –Warning lang)
-Parking guide line ON/OFF
Selecting a use of packing guide line
(OSD Menu –Parking –Line display –ON
or OFF)
-PDC display ON/OFF
Selecting a use of OPS(PDC) picture
(OSD Menu –Parking –OSD Display –
ON or OFF)
[email protected]
car-solutions.com
car-solutions.com

15
Settings
-Adjusting the position of guide line
5. OSD Menu - Parking mode
※ Control the menu below by Original button
Left Right
Down
Up
: Original mode
: PAS on/off
: Adjustment of brightness * Can be adjusted by the Jog shuttle
[email protected]
car-solutions.com
car-solutions.com

Installation
1. Installation Diagram
POWER/CAN LCD-OUT
LCD - IN
RGB
+5V NC GND SYNC BLUE GREEN RED
TOUCH
OEM Monitor
GND REAR-DETECT CAN LOW CAN HIGH CAN LOW CAN HIGH REAR POWER ACC
Command
16
[email protected]
car-solutions.com
car-solutions.com

Installation
2. Classification of Power / LVDS cable
17
-Sprinter 12.3”
[Power connector] [LVDS connector]
-Sprinter 8”
[Power connector] [LVDS connector]
[email protected]
car-solutions.com
car-solutions.com

Installation
2. Classification of Power / LVDS cable
18
- A-Clss 12.3”
[Power connector] [LVDS connector]
- A-Class 8”
[Power connector] [LVDS connector]
[email protected]
car-solutions.com
car-solutions.com

19
Cautions
•Not possible to switch mode
- Check connection of OSD Key pad wire
- Check CAN connection
•Display wrong size of picture
- Check Dip s/w setting
•Display black screen in OEM mode
- Check connection of LVDS/LCD cable
•Not possible to switch to rear screen
- Check the packing setting
(OSD Menu –option –RearCam-Det)
1. FQA
•The device must not be installed in where it interferes driving
(close to brake pedal, steering wheel, airbag etc.)
•LVDS cable must be connected correctly according to the manual
•Insulate the end of wire by using electrical tape
•The installation should be done by expert
•GU electronic does not take any responsibility for any problem
caused by wrong installation
2. Caution
