Car Solutions QROI-XI User manual

Installation Manual
Navigation box on Android 10
for Volvo XC90, S90 2017- OEM Monitors
QROI-XI_VOLVO (HW V3.0)
[email protected]
car-solutions.com
car-solutions.com

CATEGORY SPECIFICATION
OS Version 10.0
CPU ARM Cortex-A72 + [email protected] (HEXA CORE)
ARM Mali-T860 (QUAD CORE) - for GPU
Memory
RAM 4GB LPDDR4
Internal
Storage 32GB eMMC
External
Storage Micro SD slot (MAX 128GB)
Network
WI-FI 802.11 a/b/g/n/ac (2.4 GHz / 5 GHz)
Internally on board with Ant.
Bluetooth 4.0 (Internally on board with Antenna)
MODEM LTE + UMTS + GSM
(CONNECT TYPE : External USB Dongle type): Option
GPS GPS + GLONASS
Video
Out HDMI x 1
In HDMI x 1, FCAM x 1, RCAM x 1
Audio
Out AUX + SPK + BT + FM TX
In MIC
USB Port HOST x 2
(Internal 2.0 Port x 1 + 3.0 Port x 1)
Touch Input UART
Resolution 768 x 1024
Language Multi-Language
Power Input : DC 9V ~ 18V
Consumption : 10 Watt
Operation
Temperature -10
℃ ~ 70 ℃
Storage Temperature -20
℃ ~ 80 ℃
Specification
[email protected]
car-solutions.com
car-solutions.com

Car Compatibility:9inch Vertical
XC40/XC60/XC90/S60/S90
Cap. T/S monitor
Support OEM touch screen function
Support PDC split screen
Specification
[email protected]
car-solutions.com
car-solutions.com

4
Components
MAIN BOARD
QCPASS1726
MULTI1 CABLE
HARETC0360
REMOTE CTRL.
REMOTE0001
BUTTON CABLE
HARETC0001
IR CABLE
HIRCAB0002
POWER CABLE
HPOWER0283
SPK CABLE
SPEAKER007
MIC CABLE
MICPHO0003
LCD CABLE x2
HLCDCA0037
LCD EXTENSION
QCPASS0638
MULTI2 CABLE
HARETC0359
GPS CABLE
GPSANT0013
[email protected]
car-solutions.com
car-solutions.com

5
Components
Wi-Fi/BT Extension
HARETC0406
Wi-Fi/BT Antenna
ETCETC1238
[email protected]
car-solutions.com
car-solutions.com

6
Cable Connection
1. HD OUT: HDMI output
2. USB2.0/3.0: USB host
3. HD IN: HDMI input
4. LED: Red LED on for power input, Blue LED on for android system booting
5. MULTI1: Rear Camera/Front Camera/Remote Control/Toggle Button
6. POWER: connect provided power cable (GND/ACC/B+)
7. MULTI2: SPK OUT/AV OUT/MIC IN/FM-TX ANT/UART [#1 is UART-TX]
8. Wi-Fi/BT: connect provided Wi-Fi/BT extension cable and antenna
9. GPS: connect GPS antenna
10. R TOUCH: Resistive touch panel input
11. C TOUCH: Capacitive touch panel input
12. DIP S/W1: 8POL DIP switch setting
13. OEM IN: Connect one end of the supplied LCD cable and the other end
to the supplied extension board
14. OEM OUT: Connect one end of the supplied LCD cable and the other
end to the OEM monitor
15. TF card: micro SD card input
[email protected]
car-solutions.com
car-solutions.com

* ON: DOWN / OFF: UP
Please make sure to disconnect the power
cable of interface and reconnect to apply dip
switch setting whenever changing DIP switch.
7
PIN FUNCTION Dip S/W SELECT
1
No Use (OFF)
2
3
4 GPS Power OFF : Use QDIS GPS Antenna
ON : Use Original GPS Antenna
5 HDMI Mode OFF : HDMI Mode
ON : HDMI Mode Skip
6 Front Camera OFF : Ext. Front Camera Mode
ON : OEM Front Camera Mode
7 Rear Camera OFF : OEM Rear Camera Mode
ON : Ext. Rear Camera Mode
8 Mode Change
OFF : Always Available
ON : Available after 10 sec after Engine ON
* If Ext. mode goes black after the engine on,
set dip #8 ON (2020/2021 XC60/V60 etc.)
DIP Switch Settings
[email protected]
car-solutions.com
car-solutions.com

8
PARK
PAS TYPE: Select parking line type.
PAS SETUP: Move the position of parking line.
REAR TYPE: Choose rear camera recognition (CAN/LAMP)
AUTO FCAM: Front Camera Display Setting
PARK
FUNC
UTIL
INFO
PAS TYPE : PAS ON
PAS SETUP
REAR TYPE : CAN
AUTO FCAM : OFF
Factory Settings
1. ◀Long Press: Access to the Factory Menu
2. OK Short Press: Selection or Mode Change
3. ▶Long Press: Factory Reset
4. ▲Short Press: Moving Upward
5. ▼Short Press: Moving Downward
6. MENU Short Press: Back
7. PIP Short Press: Split Screen (RCAM/HDMI/AV)
[email protected]
car-solutions.com
car-solutions.com

9
FUNCTION
CAR MODEL: (~2022Y/2023Y~)
-> 2023Y~ has new air conditioner UI at the bottom line and different
OEM camera display size
CAN TYPE: Select Gear CAN type (OBD/Passenger/Steering)
-> OBD : Use CAN data from OBD/Driver’s seat
-> Passenger : Use CAN data from passenger’s door frame [Default]
-> Steering : Use CAN data under the steering wheel
HD1 MODEL: HDMI device settings (SE-TV/I-VIEW)
UTIL
RESET ALL: Factory mode reset (YES/NO)
PARK
FUNC
UTIL
INFO
CAR MODEL : ~2022Y
CAN TYPE : PASSENGER
HD1 MODEL : SE-TV
PARK
FUNC
UTIL
INFO
RESET ALL : NO
Factory Settings
[email protected]
car-solutions.com
car-solutions.com

10
1. Unplug Original LCD cable from the back side of
the monitor and connect it to the extension
board
2. Connect one of the supplied LCD cable from
extension board to the interface “OEM-IN”
3. Connect the other supplied LCD cable to the
back side of monitor and interface “OEM-OUT”
Original
LCD Cable
LCD Cable Connection
Supplied
LCD Cable
Supplied
LCD Cable
Supplied
Extension
Board
[email protected]
car-solutions.com
car-solutions.com

11
* The color of wires may vary
* Find OBD cable under the driver’s seat
CAN Connection_ OBD
POWER CABLE
HPOWER0283
Supplied power cable pin map
CAN-H
CAN-L
Behind the OEM OBD
[email protected]
car-solutions.com
car-solutions.com

12
CAN Connection_ Under Driver’s Seat
In case CAN wires are not located at OBD parts,
Plz find below wire Under the driver’s seat (CAN data is same as OBD)
Supplied power cable pin map
[email protected]
car-solutions.com
car-solutions.com

13
CAN Connection_ Passenger’s Door Frame
In case CAN wires are not located at OBD or Under the Driver’s seat,
Plz find below wire Under the passenger’s door frame.
Violet/White
(CAN-H)
Violet/Green
(CAN-L)
Under the passenger’s
door frame
Supplied power cable pin map
[email protected]
car-solutions.com
car-solutions.com

14
CAN Connection_ Under Steering Wheel
* You could also find CAN wires under the steering wheel.
Please find pin map below.
CAN-L
CAN-H
Supplied power cable pin map
Under the steering wheel
2019Y XC90 and 2022Y XC40
[email protected]
car-solutions.com
car-solutions.com

15
Please connect Original ADC(#11pin)
wire behind the monitor to the supplied
power #10(ADC1) for button use 6
12
11
ADC Connection to Use OEM Button
POWER CABLE
HPOWER0283
1. Press Home button twice ->
mode switch
2. Short press -> Back to OEM
Behind Monitor
Supplied power cable pin map
[email protected]
car-solutions.com
car-solutions.com

16
Please press high lighted button for 3secs long
or short press PIP button on the remote control
to change screen display ratio.
Split Screen on Rear Camera Mode (CVBS / HDMI)
OEM PDC
Ext. Rear + OEM Rear Ext. Rear + OEM PDCExt. Camera Full
2023Y~
2023 S90 * Factory menu ->
Car mode -> 2023Y~
selection for smaller
air conditioner UI at
the bottom and
different Original
camera size
~2022Y
Ext. Rear + OEM Rear
[email protected]
car-solutions.com
car-solutions.com

17
Android10.0 Demo
[email protected]
car-solutions.com
car-solutions.com

18
1. Press recent app button to select
the apps for split screen
2. Drag selected app screen to the
top side
3. And select another app screen
on the bottom side to complete
the split screen mode
Split Screen
①
②
[email protected]
car-solutions.com
car-solutions.com

19
Drag center division bar button
to change the split screen
display ratio
Split Screen
[email protected]
car-solutions.com
car-solutions.com

20
Password : 0603
Device Settings
