Car Solutions LVTX-STD-V1.0 User manual

Your best partner for better driving
PORSCHE CAYENNE 09
(PCM3.0)
Specification & Installation
Last updated : 2014.02.04
Model : LVTX-STD-V1.0, Product Code : LVSTD-0901-000
SUNE TECHNOLOGY
CO.,LTD No.9,Lane 606,Anping Rd,Tainan
City 70849,TAIWAN TEL:[phone] FAX:
[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-Tech

Contents
2
1. Before installation
1.1 Main specification
1.2 Features
1.3 System diagram
1.4 Components
1.5 Exterior
4
3
5
6
7
2. Setup
2.1 DIP switch
2.2 Factory mode
2.3 OSD (on screen display)
2.4 FMTX Setting
2.5 Parking Guide Line
8
9
10
11
12
3. Installation
3.1 Installation diagram
3.2 Cautions on installation
3.3 Installation
13
14
15
4. Troubleshooting 18
CarNavi-Tech

1.1 Main specification
3
1. Input Spec. (MULTI VIDEO INTERFACE)
-. 3 x A/V Input (External video source).
-. 1 x CVBS(REAR CAMERA) Input. (Rear camera source)
-. 1 x Analog RGB Input (Navigation System output)
-. 1 x LCD Input (Car system Input)
-. 1 x Cayenne Input
2. Output Spec.
-. 1 x Cayenne Output
-. 4 x Audio Select (12V power comes out from 4wires of cable by video, Navi mode)
3. Power Spec.
- Input Power : 10VDC ~ 16VDC
- Consumption Power : 12WATT, Max
4. Switch Input mode
- Input Video MUTE Function : Possible to make each input mute by operating Dip S/W.
- Possible to switch Input mode by a Keypad
- Possible to switch Input mode by a toggle button
CarNavi-Tech

1.2 Features
4
-Improved quality
-Auto detection for NTSC, PAL signals
-AV source switching by original button
-FMTX Module Built in.
-Possible to control displayed external NAVI, AV image
CarNavi-Tech

1.3 System diagram
5
DISPLAY
(CAR MAIN BOARD)
A/V 1
NAVIGATION Input
(Analog RGB)
CVBS
(Rear camera)
Car Screen Input
A/V 2
A/V 3
VIDEO
CIRCUIT
VIDEO MUX
MCU
Power Input
(+10VDC ~ +16VDC)
POWER
CIRCUIT
Dip S/W
A/V OUT
HEADREST
MONITOR
Keypad Switch for source toggle
OEM Mavi Button (Can Intrface)
Car Installation
OEM LCD
FMTX
CarNavi-Tech

1.4 Components
AV cable * 1ea
(HAVCAB0002)
POWER cable (10P) * 1ea
(HPOWER0005)
RGB cable * 1ea
(HNAVIC0002)
Mode cable * 1ea
(HARETC0001)
LVDS cable * 1ea
(HLVDSC0006) OR
Keypad * 1ea
(SMTASY0063)
Ground cable * 1ea
(HGROUN0001)
IR cable (8P) * 1ea
(HIRCAB0003)
Remote control * 1ea
(REMOTE0001)
Sub board * 1ea
(QCPASS0041)
Extension cable * 2ea
(HTOUCH0001)
(HTOUCH0003)
TOUCH cable * 1ea
(HTOUCH0002)
Button cable * 1ea
(FPCABL0003)
FFC cable * 2ea
(FFCABL0006)
FPC cable * 1ea
(FPCABL0002)
CarNavi-Tech

1.5 Exterior
7
①POWER
①②③④
⑤⑥⑦
②MODE
③RGB IN
④AV IN/OUT
⑤LED
⑥DIP S/W
⑦KEYPAD/IR
⑧
⑧LCD OUT
Dimension
Horizontal length 155mm
Vertical length 93mm
Height 20mm
CarNavi-Tech

2.1 DIP switch
8
#PIN Function DIP S/W selection
1 RGB INPUT MUTE ON : Skipping RGB Mode
OFF : RGB Display
2 A/V 1 MUTE ON : Skipping A/V 1
OFF : A/V1 Display
3 A/V 2 MUTE ON : Skipping A/V 2
OFF : A/V2 Display
4 A/V 3 MUTE ON : Skipping A/V 3
OFF : A/V3 Display
5 N.C
6 N.C
7 When to choose rear mode (ON : CVBS4, OFF : MAIN)
8 To select original
NAVI
ON : Changing mode ;
Main-Main-NAVI-AV1~3
(This is for original Navi)
OFF : Changing mode ;
Main-NAVI-AV1~3
※DIP S/W Use Example
-. Use Input Mode : A/V2, A/V3
-. Use original Navigation
▷DIP S/W : 1,2 -ON (INPUT MODE SKIP)
▷DIP S/W : 3 -OFF (enable A/V3)
▷DIP S/W : 4 -OFF (enable A/V3)
▷DIP S/W : 5,6,7 -OFF
▷DIP S/W : 8 -ON
※Please make sure to disconnect the power cable of the interface and reconnect
the power cable again to apply the dip switch setting whenever changing DIP switch.
Otherwise, DIP switch setting will not be applied.
CarNavi-Tech

2.2 Factory mode
9
UTIL
- FMTX ENABLE : FMTX setting
- FREQENCY : Adjust frequency
- FACTORY RESET : To reset all the
values
· Factory Mode
① Press ‘UP(▲)’ button of supplied key pad for 2 sec.
②Press ▲→ ▼ → ▲ →MENU buttons in order.
- H_POSITION : Horizontal movement
of the OSD window
-V_POSITION : Vertical movement of
the OSD window
PARK
- PARK ENABLE : Setup of rear view
parking guide line
- H_POSITION : Horizontal movement
of the OSD window
-V_POSITION : Vertical movement of
the OSD window
CarNavi-Tech

2.3 OSD (on screen display)
10
- BRIGHTNESS
- CONTRAST
- SATURATION
- HUE
- SHARPNESS
USER IMAGE : To choose a option among 4 prepared
color shade.
Video ModeAnalog RGB Mode
Video ModeAnalog RGB Mode
Video ModeAnalog RGB Mode
OSD
- LANGUAGE : Choosing OSD language while using
Touch OSD (English, Chinese only)
- TRANS
: Transparency control of the OSD background
- H_POSITION
: Horizontal movement of the OSD window
- V_POSITION
: Vertical movement of the OSD window
UTIL
- FACTORY RESET : To reset all the values
(To reset of Navigation, AV individually)
CarNavi-Tech

2.4 FMTX Setting
11
※ If you do not want this function, kindly set “FM-TX USE” to “OFF”. (Use ▲, ▼buttons on the Remote control)
Factory Default : FMTX USE –ON, FREQENCY –88.2MHz
-Activate the Factory Mode operated with pressing ▲→▼
→▲→MENU buttons on the keypad in sequence.
-Set “FM-TX USE” to “ON” as shown left. (Default -ON)
Control the frequency by “▲”, “▼” buttons on the Remote
control. At the bottom, you can see present frequency and
control it from 87.5MHZ to 108MHZ. (1MHZ per each time
to press)
CarNavi-Tech

2.5 Parking guide line
12
②There are 4 steps of parallel lines distance, the distance is
controlled by ▲, ▼buttons in the Remote control. After
controlling, must press “OK” button to save this status.
(You can see present status at the right in the screen)
① Register the value needed on the “PARK SETUP” with pressing
“OK” button on the Remote control in the PARK section as shown
left. Then, you can control distance between 2 parallel lines.
Factory Default -Types:0, H_Pos:50, V_Pos:120
③After Step. ②, press ▲, ▼buttons on the Remote control to
control left, right position with pressing ‘OK’ button, and then you
can control up, down position. (Able to control 0~255)
※ If you do not this function, kindly set ‘PARK ENABLE” to ‘OFF’.
CarNavi-Tech

Monitor
-13-
LED DIP S/W KEYPAD LCD OUT
POWER MODE RGB(IN) A/V(IN/OUT)
LVDS VIDEO INTERFACE
AV3-SEL
AV2-SEL
AV1-SEL
NAVI SEL
CAN(L)
CAN(H)
SAFE
REAE-C
GND
ACC
Sub
Board
FPC
cable
Head Unit
Button Cable
3.1 Installation diagram
R DATA (red) G DATA (green) B DATA (blue)
N.C
SYNC (white)
GND (black)
N.C
VIDEO
AUDIO R
AUDIO L
REAR C
AV1 AV2 AV3
AV/OUT
YELLOW
YELLOW
RED
WHITE
※Please make sure that the installation
should be carefully conducted to avoid from
the damage of a monitor by ESD(Electrostatic
discharge) and misalignment while
connecting the module of a monitor with
cables.
CarNavi-Tech

3.2 Cautions on Installation
14
Ignition key should be taken off before starting installation, interface power connection must be the last step in
installation.
Power cable should be separated when connecting interface.
Should be no any electronic devices or magnetic pole around installation place.
All steps of installation should be done by well-trained specialist.
Dismantling without manufacturer’s permission can not be guaranteed, (No permission to break attached label on
the board.)
Kindly check all parts are in the box, when receiving the product, if anything missing, inform to the supplier or
manufacturer.
According to our sales policy, any problems caused by user’s mistake, careless can not be guaranteed.
It may not work on a camera with 12V
CarNavi-Tech

3.3 Installation
15
1. Cut the original FFC cable
Trim edges of the original FFC cable
which is connected between head unit
board and monitor as shown left.
(This is to connect the offered Button
cable, be sure not to damage PIN on
the cable. )
Before After
2. Connect the button cable to FFC cable
Connect the cut FFC cable in
previous step to offered Button
cable and connect this button cable
to Head unit as shown left.
Button cable
CarNavi-Tech

3.3 Installation
16
Connect the wire from the Button
cable to the sub-board as shown left.
3. Connect the button cable to Sub-Board & Remove the original FPC cable
Remove the original FPC cable, connect
the offered T-shaped FPC cable to
Head unit and the offered Sub-board
as shown left.
Be sure not to touch the opposite side.
(It is possible to damage on Head unit
when you touch the opposite side!)
CarNavi-Tech

3.3 Installation
17
4. Connect Cayenne Board to Sub-Board
Put LCD cable into Head unit, connect sub-board and interface board.
CarNavi-Tech

4. Troubleshooting
18
Q. I can not switch A/V sources.
A. Check IR or Ground cable connection. Check LED lamps in the interface, if it is not on, check power cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
(Second lamp indicates AV sources connected works well.) Check interface connection has been done well.
Q. Displayed image color is not proper. (too dim or not suitable color)
A. Try to select “INITIAL” in OSD menu, if it does not work, inform the manufacturer.)
Q. Rear camera image does NOT appear.
A. Set DIP switch #7 in “ON”
Q. Unwanted A/V mode is displayed. (A/V source switching order : OEM->RGB->AV1->AV2->AV3)
A. Check DIP Switch Setting.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps on, inform the manufacturer.
Q. Screen only displays white like left picture.
A. Check LCD out cable is connected well, if this status keeps, inform the manufacturer.
CarNavi-Tech
